Elettrotest TPS/T 10kVA Manuel utilisateur

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 1

TPS/T 10-90kVA

USER MANUAL

Clicca qui per vedere la versione in Italiano.

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 2

TPS/T Models covered in this manual:

Model

Code

TPS/T 10kVA

99110547

TPS/T 20kVA

99110557

TPS/T 40kVA

99110585

TPS/T 60kVA

99110540

TPS/T 60kVA 50k120S

99116523

TPS/T 90kVA

99110600

This manual is written from TPS/T firmware version TPSX 09_.

Please check the latest manual version at www.elettrotestspa.it

To consult older manual versions, please contact our support at

[email protected]

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 3

Document list:

This manual is completed by a list of documents, useful to understand all the features of your

TPS/T.

Scan the QR-code or click on the link to directly download the documents.

Documents

Description

Link

QR-code

User Manual

Latest manual version

Manual

Brochure

Brochure for all the TPS-HPS-CPS models

Brochure

TPS Parameters

Describes all the machine modifiable

parameters and the start-up sequence.

TPS

Parameters

TPS protocol

Elettrotest

Describes how the Elettrotest remote

communication protocol works.

Elettrotest

Protocol

TPS protocol

SCPI

Describes how the SCPI remote

communication protocol works with your

TPS/T.

SCPI

Protocol

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 4

Documents

Description

Link

QR-code

PS Interface

Software for remote use.

PS_interface

Driver LabView

Manual and LabView Drivers for PS-

interface

Driver

LabView

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 5

Elettrotest Spa

P,zza R.Riello 20/B

45021 Badia Polesine (RO)

Italy

+39 042553567

www.elettrotestspa.it

After sale support

[email protected]

Thank you for purchasing the TPS/T generator.

TPS/T is a three-phase generator that provides a perfectly sinusoidal and stable voltage. The

voltage value can be adjustable either in frequency and amplitude.

TPS/T combines the advantage of the power line, the variac and the rotary converter, without

having their shortcomings.

Responsability:

Elettrotest disclaims any responsibility for damage to people or things

caused by an improper use of its products.

Mandatory

-Verify voltage, power and frequency compatibility between TPS/T range and electrical

specification of equipment under test (EUT).

-Electrical components of the system must be suitable for the rated voltage and current of TPS/T

model

-The electrical components, which by construction cannot support external influences (of the

generator in all its range), can only be used on condition that adequate additional protection has

been provided with automatic disconnection protection.

Notes:

This manual lists precautions and information about operating procedure of device.

The content of this manual is subject to change without prior notice because of continuing

improvements on the instrument’s

Should you have any questions or find any error please contact us by email.

Copying or reproducing all or any part of the contents of this document is strictly

prohibited, without Elettrotest permission

Version:

This manual is written for TPS/T firmware version TPSX 09_ and higher

To consult older manual versions, please contact our support at [email protected]

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 6

SAFETY WARNINGS

The manufacturer urges users to read the user manual for our products before installation.

The installation must be carried out by qualified technical staff. The non-observance of the

warnings in this manual can cause electric shocks, even fatal ones.

Please find some general safety warnings below.

•This equipment must be connected to the mains supply using the appropriate safety

devices.

•TPS/T must be connected to safety ground through the correct connections. The non-

observance or the degradation of this earth connection can lead to electric shocks, even fatal

ones. As regards the correct connection modes, please refer to the information contained in

paragraph 4.

•Disconnect TPS/T from the mains before any work on the equipment and on the connected

power loads.

•Before touching the load or the output connector make sure that the power supply on the

device has been disconnected for at least 5 minutes. This is the time necessary in order for the

capacitors inside the device to discharge. The non-observance of this discharge time can lead to

electric shocks, even fatal ones.

•Avoid heavy shocks to the equipment (especially during transport) or exposure to extreme

weather conditions.

•Any damage to the product due to transportation, incorrect installation or improper use is

not covered by the guarantee supplied by the manufacturer.

•Do not use the equipment in explosive environments or in the presence of dust, acids or

corrosive and/or inflammable gases.

•Tampering with or dismantling any component in the equipment will void the warranty

automatically.

•Do not operate or store under conditions where condensing may occur or where

conductive debris may enter in the case.

•Keep the ventilation holes on the front and rear free from obstruction.

•Do not make dielectric strengths test on the input or output of the equipment. Contact

Elettrotest if you need to do specific test

ELECTRIC RISK

There are dangerous voltages inside TPS/T and over the output connector.

The non-observance of the warnings suggest in this manual can lead to electric

shocks, even fatal ones.

OVERHEATING RISK

In the case of a ventilation system failure, the metal parts of the inverter may reach

high temperatures (in some cases higher than 70°C).

27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 7

DISPOSAL

INFORMATION FOR USERS ON THE CORRECT HANDLING OF WASTE

ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE)

In reference to European Union directive 2012/19/EU issued on 24 July 2012 and the related

national legislation, please note that:

•WEEE cannot be disposed of as municipal waste and such waste must be collected and

disposed of separately;

•the public or private waste collection systems defined by local legislation must be used. In

addition, the equipment can be returned to the manufacturer at the end of its working life when

buying new equipment;

•the equipment may contain hazardous substances: the improper use or incorrect disposal

of such may have negative effects on human health and on the environment;

•the symbol (crossed-out wheeled bin) shown on the product or on the packaging and on

the instruction sheet indicates that the equipment must be disposed of separately;

•in the event of illegal disposal of electrical and electronic waste, the penalties are specified

by local waste disposal legislation.


27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 8

INDEX

INTRODUCTION..........................................................................................................................10
1. MAIN FEATURES ..................................................................................................................10
1.1. Output voltage .............................................................................................................10
1.2. Output frequency.........................................................................................................10
1.3. User interface...............................................................................................................11
MODELS......................................................................................................................................12
1. MECHANICAL DRAWINGS....................................................................................................13
1.1. TPS/T 10K 7.5K22.5S ....................................................................................................13
1.2. TPS/T 20K 15K45S | TPS/T 40K 30K60S......................................................................14
1.3. TPS/T 60K | TPS/T 60K 50K120S ................................................................................15
1.4. TPS/T 90K EVOLUTION.................................................................................................16
NOTES FOR USERS......................................................................................................................17
1. SWITCHING ON....................................................................................................................17
2. PARAMETERS PROGRAMMING MODE................................................................................17
3. VOLTAGE MENU ..................................................................................................................17
3.1. Setting Voltage.............................................................................................................18
4. RANGE SETTING...................................................................................................................18
5. VOLTAGE VISUALIZATION....................................................................................................19
6. FREQUENCY MENU..............................................................................................................20
6.1. Frequency setting.........................................................................................................20
6.2. Frequency reference setting........................................................................................20
7. MODE MENU.......................................................................................................................21
7.1. Voltage reaction...........................................................................................................21
7.2. Output type..................................................................................................................22
7.3. Continuous or INRUSH mode.......................................................................................22
8. ALARMS ...............................................................................................................................22
8.1. Supply alarms...............................................................................................................24
8.2. System alarms..............................................................................................................24
8.3. Current alarm...............................................................................................................24
8.4. Voltage alarm...............................................................................................................24
INSTALLATION............................................................................................................................25
1. GENERAL NOTES..................................................................................................................25
1.1. INSPECTION..................................................................................................................25
1.2. Line Connection ...........................................................................................................25
2. PROTECTIONS......................................................................................................................26
2.1. RCD Protection.............................................................................................................26
2.2. Magneto-Thermic protections.....................................................................................26
2.3. Protections Wiring Diagram.........................................................................................27
3. WIRING DIAGRAM...............................................................................................................28
3.1. 2-WIRES configuration .................................................................................................28
3.2. 4-WIRES configuration .................................................................................................29
4. INSTALLATION NOTE ...........................................................................................................30
4.1. TPS/T 10K 7.5K22.5S ....................................................................................................30
4.2. TPS/T 20K 15K45S | TPS/T 40K 30K60S......................................................................31
4.3. TPS/T 60K | TPS/T 60K 50K120S ................................................................................32
4.4. TPS/T 90K EVOLUTION.................................................................................................32
REMOTE CONTROl......................................................................................................................33


27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 9
1. SERIAL REMOTE CONTROL ..................................................................................................34
1.1. RS232 Serial cable ........................................................................................................34
2. EXISTENCE TABLE.................................................................................................................34
ACCESSORies ..............................................................................................................................35
1.1. TPS/T 10K 7.5K22.5S ....................................................................................................35
1.2. TPS/T 20K 15K45S | TPS/T 40K 30K60S......................................................................35
1.3. TPS/T 60K | TPS/T 60K 50K120S ................................................................................35
1.4. TPS/T 90K EVOLUTION.................................................................................................36
inrush limit current ....................................................................................................................37
Service and maintenance...........................................................................................................38
1. MAINTENANCE / CLEANING................................................................................................38
1.1. Scheduled maintenance...............................................................................................38
2. ALARMS DIAGNOSIS AND REPAIRS .....................................................................................38
3. BASIC TROUBLESHOOTING..................................................................................................39
3.1. Overvoltage/Undervoltage alarms ..............................................................................39
3.2. Overtemperature alarm...............................................................................................39
3.3. Inverter alarm ..............................................................................................................40
3.4. Max DV OUT alarm.......................................................................................................40
3.5. Limit IOUT alarm ..........................................................................................................40
GUARANTEE ...............................................................................................................................41
REVISION INDEX ......................................................................................................................41



27/01/22 User Manual TPS/T 10-90kVA 62000560_09_ 10

1. INTRODUCTION

TPS/T is a power source that supplies sinusoidal stable voltage. Its output voltage is adjustable in

frequency and amplitude.

TPS/T has an isolated output thanks to a special isolating transformer at constant power. This

transformer allows to have always the maximum power in any application, keeping the complete

insulation from the electrical line.

TPS/T can also be controlled remotely.

1.1. MAIN FEATURES

1.1.1. Output voltage

The output voltage is guaranteed perfectly sinusoidal, with a distortion of less than 0.3 %

regardless of the load.

The value of output voltage is kept perfectly stable within 0.3 % regardless of the load.

It’s designed for harmonics and flicker test. It meets the corresponding specifications as per EN

61000-3-2 and EN 61000-3-3.

TPS/T is also able to compensate for possible voltage drops on the output wires, ensuring the

exact amount of voltage you want on the load.

The load that TPS/T is able to drive can vary from the pure capacity to the pure inductance; not

only, but also up to non-symmetrical current loads, as for instance a single halfwave rectifier.

The output voltage is adjustable with continuity from zero to full scale of each range.

TPS/T can in fact provide the nominal power at various full scales and this allows the TPS/T to

adapt himself to the disparate needs of the user, without having heavy limitations on the output

current.

Furthermore TPS/T is capable to keep the voltage stable also with time variable loads, as for

example the pulsating loads.

In fact TPS/T recovers the distortion of the waveform within 0.3 % and the amplitude of the

voltage within 0.3% in less than half period.

TPS/T can bear a shortcircuit for an indefinite time without suffering any consequence.

1.1.2. Output frequency

TPS/T allows the regulation of the output frequency from 40Hz to 80Hz.

This output frequency can be regulated with continuity within the above-mentioned range of

frequencies and it has a stability of 0.01% with regards to the set frequency.

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Elettrotest Alimentation

Elettrotest

Elettrotest CPS/T Series Manuel utilisateur

Elettrotest

Elettrotest TPS/M/D Manuel utilisateur

Elettrotest

Elettrotest CPS/M 1000VA Manuel utilisateur

Elettrotest

Elettrotest TPS/M 1500 Manuel utilisateur

Elettrotest

Elettrotest HPS/T Manuel utilisateur

Elettrotest

Elettrotest RPS/T 20kVA Manuel utilisateur

Manuels Alimentation populaires d'autres marques

Monacor

Monacor PS-12CCD Manuel utilisateur

VOLTIMA

VOLTIMA MagicBox 15 Manuel utilisateur

Agilent Technologies

Agilent Technologies 6032A Manuel utilisateur

Miller

Miller Auto Deltaweld 452 Manuel utilisateur

BCP

BCP PUOUBK Feuille d'instructions

HC 2210 Manuel utilisateur

Puls

Puls CT5.241 Manuel utilisateur

OCZ

OCZ ZX1250W Manuel utilisateur

iseg

iseg ECH 238 Manuel utilisateur

Power

Power XXL A Series Manuel utilisateur

Agilent Technologies

Agilent Technologies 6631B Manuel utilisateur

Renogy

Renogy PHOENIX 300 Manuel utilisateur

HP 6200B Manuel de service

Epson

Epson Stylus Scan 2500 Manuel d'utilisation

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Manuel utilisateur

Puls

Puls MiniLine ML50.100 Manuel utilisateur

Puls

Puls AS-Interface SLA4.100 Manuel utilisateur

Kenwood

Kenwood PS-60 Manuel utilisateur
