Electronics Line SecuPlace Manuel d'instructions
1
Quick User Guide
SecuPlace
2
Connecting to MyELAS
To get started connect to MyELAS via the Web or Smartphone apps.
Registering & Logging into MyELAS – Web App
To register to MyELAS:
1. Go to: www.MyELAS.com register. On the registration
screen fill in all required fields:
2. Press REGISTER.
3. Open the e-mail (sent to the e-mail address defined as the
Login name), and then click the link.
To log in to MyELAS:
1. Go to: www.MyELAS.com. On the login screen enter the
user name and password used when registering:
2. Enter your PIN code (same as your user code – the default
master code is 1234), and then press ENTER.
3
Registering & Logging into MyELAS – Smartphone App
To register to MyELAS:
1. Download the Smartphone app:
iOS app Android app
2. On the registration screen fill in all required fields:
Android registration screen iOS registration screen
3. Press Register.
4. Open the e-mail (sent to the e-mail address defined as the
Login name), and then click the link.
4
To login to MyELAS:
1. Go to the Login screen.
Android login screen iOS login screen
2. Enter the user name and password used when registering.
3. Enter your PIN code (same as your user code – the default
master code is 1234).
4. Press ENTER.
5
Describing Control Panel Keypad & System LEDs
Control Panel Keypad
Keypad buttons Description
Arming – from left to right: full
arm, partial arm, perimeter arm
Alphanumeric
buttons for user code
Disarming – for disarming the
system. Also silences the sounder.
Accept / OK –for confirming
selection and for saving.
Reject / cancel – for cancelling, or
returning to prior menu item.
Menu navigation – for scrolling
up / down through menu options.
Panic alarm – sends notification
(control panel is silent).
6
Control Panel LEDs
L D Color State Status
OK L D
/A Off Both AC electrical power and
battery power are disconnected
Green On System power status is ok (no
system trouble)
Green Flashing
Open (activated) zone. Check that
the windows and doors are closed
and no movement is detected by
the detectors within the protected
area.
Yellow On System trouble
Yellow Slow flashing Low battery (in control panel or
transmitters)
Yellow Quick
flashing AC power loss
Yellow Slow and
quick flashing
System trouble in addition to AC
power loss / low battery
(System
Status
L D)
/A Off System is disarmed
Green On System is armed
Red Flashing
Alarm activation (flashes until
system is disarmed).
NOT : Scroll on keypad to view
trouble message(s).
Keyfob LED
The keyfob LED flashes once when transmitting a command, and
flashes repeatedly to indicate a low battery condition.
PIR-Pet Detector LED
The PIR-Pet detector LED flashes upon detection.
7
Defining Users & Follow-Me Contact
SecuPlace supports up to 32 users, each requiring a unique 4-digit
user code to operate the system.
NOTE: ontrolled codes communicate your system commands to
the alarm receiving centre, whereas non-controlled codes do not.
Slot(s) Code type Description
1 Master code
[Controlled] For master user. Default is 1234.
NOT : For security, it is best to change the code
immediately after system setup.
2-19 User codes [Controlled] For system users.
20-25 User codes [Non-controlled] For system users.
26-27 Limited
user codes [Controlled] For temporary users, valid 24 hours.
28 Duress
code
For all system users, for situations when one is
forced to disarm the system. It sends a “silent”
duress event message to the alarm receiving
centre or to a pre-defined user.
29 Telecontrol
code
For remote system operations and two-way
audio (TWA) communication to the control
panel via telephone.
30
Alarm
Receiving
Centre /
TWA code
For alarm receiving centre operator. For two-way
audio (TWA) communication with control panel
for up to 10 minutes after an alarm activation.
32 Engineer
code
For the engineer only. Default code is 1111.
NOT : For security, it is recommended to change
the code immediately after system installation.
8
Defining User Codes
System user codes are typically designated from MyELAS. They can
also be assigned from the control panel by the Master user.
To define user codes at the control panel:
1. Press , and then enter the master code (default is
1234) or the engineer code (default is 1111).
2. Use to scroll to 4. USER ODES, then press .
3. Use to scroll to the specific code slot that you
would like to assign, edit or delete (see chart above for the
available slots and their descriptions), and then press .
4. Scroll and select either: 1. EDIT ODE (to change or delete
a code) or 2.DES RIPTOR (to change the code description
name), and then press .
5. Enter either the changed code or the changed code
description as follows:
•Use to move from character to character on
the display (or wait a second after entering a character to
automatically move to the next space).
•Press any button repeatedly to toggle between the letters
and number printed on it.
•Press to delete a character.
NOTE: If you want to delete a code, change it to 0000.
6. Press to confirm.
9
Designating a Follow Me Contact Number
Designate the cell phone number of a system user to receive SMS
Follow Me notifications of system events.
To designate a Follow Me number:
1. At the control panel press , then enter the master code
(default is 1234) or the engineer code (default is 1111).
2. Use to scroll to 5. FOLLOW ME #, then press .
3. Enter the area code and number, and then press .
NOTE: To edit the number, scroll to 5. FOLLOW ME #, then
press . Use to move between digits, and
press to delete a digit.
10
Performing Commands
User-performed commands can be performed at the control panel,
keyfob, and via the Smartphone and Web apps.
Control Panel and Keyfob Commands
Command Control Panel Procedure Keyfob
Procedure
Full arm Press . Then if prompted enter code. Press .
Partial
arm Press . Then if prompted enter code Press .
Perimeter
arm Press . Then if prompted enter code. Press .
Disarm
(& silence
alarms)
Enter code Press .
Panic
alarm Press and simultaneously.
Press
&
simultaneously
Fire alarm Press and simultaneously. /A
Medical
alarm
Press and simultaneously;
control panel beeps to indicate alarm
activation.
/A
View
troubles
If a trouble message displays, press
to scroll and view system troubles.
/A
