Electrolux Ergospace Manuel utilisateur

Dust Magnet

+ Hepa H12 filtration

2193584-02Outline.indd 1 10/17/08 1:58:18 PM

2193584-02Outline.indd 2 10/17/08 1:58:18 PM

Electrolux Ergospace 진공 청소기를 구입해 주셔서 감사합니

다. 본 사용 설명서는 Ergospace 전 모델에 적용될 수 있습니

다. 따라서, 구입하신 모델에는 일부 부속품 또는 기능이 빠져

있을 수 있습니다. 세부 모델명 및 부속품명은 박스 겉면 라벨

에 표시되어 있습니다. 제품을 최상의 상태로 사용하려면 항상

Electrolux의 정품 부속품을 사용하십시오. 해당 정품 부속품은

사용하시는 진공 청소기에 가장 잘 맞게 특별 제작된 것입니다.

한국 4–14

感謝您選用 Electrolux Ergospace 吸塵機。這些「操作說明」

覆蓋所有 Ergospace 型號。這表示您所選用的特定型號的某些

配件可能不包含在內。請參閱您的外箱標籤所示的特定型號與配

件。為了確保最佳的使用效果，請一律使用原廠的 Electrolux

配件。這些配件是專門針對您的吸塵機而設的。

繁體中文 4–14

Thank you for having chosen an Electrolux Ergospace vacuum

cleaner. These operating instructions cover all Ergospace mod-

els. This means that with your specic model, some accesso-

ries/features may not be included. Please refer to your specic

model and its accessories, which are shown on the outer box

label. In order to ensure the best result, always use original

Electrolux accessories. They have been designed especially for

your vacuum cleaner.

English 4–14

2193584-02Outline.indd 3 10/17/08 1:58:18 PM

1* 2

3 4

7 8

1a*

2193584-02Outline.indd 4 10/17/08 1:58:19 PM

Safety precautions

If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualied person

in order to avoid a hazard. Never use the vacuum cleaner if

the cable is damaged. Damage to the machine’s cable is not

covered by the warranty.

This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have been

given supervision or instruction concerning use of the appliance

by a person responsible for their safety.

Children should be supervised to ensure that they do not play

with the appliance.

Please remove the plug from the socket outlet before cleaning

or maintaining the appliance.

Never use the vacuum cleaner:

•In wet areas.

•Close to ammable gases etc.

•When housing shows visible signs of damage.

•On sharp objects.

•On hot or cold cinders, lighted cigarette butts, etc.

•On ne dust, for instance from plaster, concrete, our, hot or

cold ashes.

Using the vacuum cleaner in the above circumstances may

cause serious damage to its motor. Such damage is not covered

by the warranty. Never use the vacuum cleaner without its lters.

Electrical cable precautions

•A damaged cable should only be replaced by an authorised

Electrolux service centre.

•Damage to the machine’s cable is not covered by the

warranty.

•Never pull or lift the vacuum cleaner by the cable.

•Disconnect the plug from the mains before cleaning or

maintenance of the vacuum cleaner.

•Regularly check that the cable is not damaged. Never use

the vacuum cleaner if the cable is damaged. All servicing

and repairs must be carried out by an authorised Electrolux

service centre. Be sure to keep the vacuum cleaner in a dry

place.If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similary qualied person

in order to avoid a hazard.

Accessories

English

1* Telescopic tube

1a* Extension tube.

2. Hose handle + hose

3* Carpet / hard oor nozzle

4* Dust magnet,

combination carpet / hard

oor nozzle

5. 3 in 1 Multi tool nozzle.

6. Dust bag, s-bag®, dust

bag holder.

7* Turbo nozzle

8* Parquet nozzle

9* Easy Clean kit

* Certain models only.

2193584-02Outline.indd 5 10/17/08 1:58:20 PM

10 11

15 16

2193584-02Outline.indd 6 10/17/08 1:58:21 PM

Before starting

Open the front cover on the machine and check that the

dust bag, s-bag®and the motorlter are in place. (See also

Replacement of lter(s))

10 Open the back lid on the machine and check that the

exhaust lter is in place.

11 Insert the hose until the catches click to engage (press the

catches to release the hose). (2). Insert the hose into the

hose handle until the catches click to engage (press the

catches to release the hose).

12 Attach the extension tube* or telescopic tube* to the hose

handle and nozzle by pushing and twisting together. (Twist

and pull apart to dismantle.)

13 Extend the electric cable and connect it to the mains. The

vacuum cleaner is tted with a cable winder. Once the

electric cable has been extended, it stays in that position.

14 To rewind the cable, press the cord rewinder button. The

cable will then rewind.

15 ON/OFF control: Push the ON-OFF button once to start the

vacuum cleaner. Push same button once more to turn it off.

16 Power Regulation: Twist the power control towards „max”

to increase the suction power. Twist the power control

towards „min” to decrease suction power. Additional suction

power control: Use the suction control on the hose handle.

17 Practical parking positions (and at the same time a

backsaving feature) when you pause during cleaning or

when you carry and store the vacuum cleaner.

18 You can also carry the vacuum cleaner using the handle

on top or on the lower front edge of the machine.

19 Keep the hose in place while storing the vacuum cleaner

by extending the elastic bumper cord and placing it across

the hose.

English

* Certain models only.

2193584-02Outline.indd 7 10/17/08 1:58:21 PM

23 24

8 7

21 22

5b 5c

2193584-02Outline.indd 8 10/17/08 1:58:22 PM

Getting the best results.

20 Accessories on board 3 in 1 multi tool nozzle to be found

in the back of the cleaner.

Use the nozzles as follows:

Carpets: * Use the carpet/hard oor nozzle with lever in position

(21). Reduce suction power for small carpets.

* On the Dust Magnet nozzle (23 and 24) there is normally

no need to switch mode. It can be used with brush up on all

surfaces for maximal convenience with maintained excellent

dust removal result. The brush setting should be used to reach

optimal dust removal even on difficult hard oors or to get a

combing effect on carpets.

Hard ﬂoors: * Use the carpet/hard oor nozzle with lever in

position (22).

Wooden ﬂoors: * Use the parquet nozzle (8).

Upholstery: Curtains, lightweight fabrics etc.: Use the upholstery

function of the 3 in 1 multi tool nozzle (5a). Reduce suction

power if necessary.

Frames, bookshelves, etc.: Use the dusting brush function of the 3

in 1 multi tool nozzle (5b).

* Use the easy clean kit (9).

Crevices, corners, etc.: Use the crevice function of 3 in 1 multi

tool nozzle (5c).

* Using the turbo nozzle (7)

Note: Do not use the turbo nozzle on skin rugs, rugs with long

fringes or a pile depth exceeding 15 mm.To avoid damaging

the carpet, do not keep the nozzle stationary whilst the brush is

rotating. Do not pass the nozzle across electric cables, and be

sure to switch off the vacuum cleaner immediately after use.

25 The dust bag must be replaced latest when the indicator

window is completely red. Read with the nozzle lifted up.

English

* Certain models only.

2193584-02Outline.indd 9 10/17/08 1:58:23 PM
