Electrolux IK3035SZR Manuel utilisateur
CONTENTS
1. SAFETY INFORMATION...................................................................................... 3
2. SAFETY INSTRUCTIONS.....................................................................................4
3. OPERATION........................................................................................................ 5
4. FIRST USE...........................................................................................................7
5. DAILY USE.......................................................................................................... 7
6. HINTS AND TIPS............................................................................................... 11
7. CARE AND CLEANING......................................................................................11
8. TROUBLESHOOTING........................................................................................13
9. INSTALLATION..................................................................................................16
10. NOISES........................................................................................................... 16
11. TECHNICAL INFORMATION............................................................................18
12. GUARANTEE ..................................................................................................18
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that
brings with it decades of professional experience and innovation. Ingenious and
stylish, it has been designed with you in mind. So whenever you use it, you can be
safe in the knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com/webselfservice
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.electrolux.com2
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible for any injuries or damages that are the result
of incorrect installation or usage. Always keep the
instructions in a safe and accessible location for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged 8 years
and above and by persons with reduced capabilities
provided that they have been given instruction and/or
supervision regarding the safe use of the appliance and
understand the potential hazards involved.
•Do not let children play with the appliance.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
•Keep all packaging away from children and dispose of it
appropriately.
1.2 General Safety
•This appliance is intended to be used in household and
similar applications such as:
–Farm houses; staff kitchen areas in shops, offices
and other working environments
–By clients in hotels, motels, bed and breakfast and
other residential type environments
•Keep ventilation openings, in the appliance enclosure or
in the built-in structure, clear of obstruction.
•Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the
type recommended by the manufacturer.
ENGLISH 3
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging and the
transit bolts.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before connecting
the appliance to the power supply. This
is to allow the oil to flow back in the
compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too colds, such
as the construction appendices,
garages or wine cellars.
• When you move the appliance, lift it by
the front edge to avoid scratching the
floor.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
electrical components (e.g. mains plug,
mains cable, compressor). Contact the
Authorised Service Centre or an
electrician to change the electrical
components.
• The mains cable must stay below the
level of the mains plug.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns, electrical
shock or fire.
www.electrolux.com4
• Do not change the specification of this
appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• Be careful not to cause damage to the
refrigerant circuit. It contains isobutane
(R600a), a natural gas with a high level
of environmental compatibility. This gas
is flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not store flammable gas and liquid
in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
2.4 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the appliance.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• The insulation foam contains flammable
gas. Contact your municipal authority
for information on how to discard the
appliance correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
3. OPERATION
3.1 Control Panel
1
23456
1Display
2Temperature warmer button
3Temperature colder button
4OK
5Mode
6ON/OFF
ENGLISH 5
It is possible to change predefined sound
of buttons by pressing together Mode and
temperature colder button for a few
seconds. Change is reversible.
3.2 Display
Off
min
A B C D E
FGH
A. Timer indicator
B. ON/OFF indicator
C. Shopping function
D. NaturaFresh function
E. Temperature indicator
F. Alarm indicator
G. ChildLock function
H. DrinksChill function
3.3 Switching on
1. Connect the mains plug to the power
socket.
2. Press the appliance ON/OFF if the
display is off. The temperature
indicators show the set default
temperature.
To select a different set temperature refer
to "Temperature regulation".
If "dEMo" appears on the display, refer to
"Troubleshooting" .
3.4 Switching off
1. Press the appliance ON/OFF for 5
seconds.
The display switches off.
2. Disconnect the mains plug from the
power socket.
3.5 Temperature regulation
Set the temperature of the appliance by
pressing the temperature regulators.
Default set temperature:
• +5°C for the fridge
The temperature indicators show the set
temperature.
The set temperature will be
reached within 24 hours.
After a power failure the set
temperature remains stored.
3.6 Shopping function
If you need to insert a large amount of
warm food, for example after doing the
grocery shopping, we suggest activating
the Shopping function to chill the products
more rapidly and to avoid warming the
other food which is already in the
refrigerator.
1. Press the Mode until the
corresponding icon appears.
The Shopping indicator flashes.
2. Press the OK to confirm.
The Shopping indicator is shown.
The Shopping function shuts off
automatically after approximately 6 hours.
To switch off the function before its
automatic end, repeat the procedure.
The function switches off by
selecting a different fridge set
temperature.
3.7 NaturaFresh compartment
setting
1. Press Mode until the corresponding
icon appears.
The display shows 3. This is the default
setting that ensures the most effective
performance.
2. Press the temperature buttons on the
control panel to select necessary
setting.
3. Press OK to confirm the setting.
The indicator returns to the fridge
temperature setting in a few seconds.
Setting Application
1-3 Meat and fish
www.electrolux.com6
Setting Application
4-5 Meat, fish, vegetables and fruit
stored together
3.8 Door open alarm
An acoustic alarm will sound if the door is
left open for a few minutes. The door open
alarm conditions are indicated by:
• a flashing Alarm indicator;
• an acoustic buzzer.
When normal conditions are restored
(door closed), the alarm will stop. The
buzzer can also be switched off by
pressing any button.
3.9 ChildLock function
Activate the ChildLock function to lock the
buttons from unintentional operation.
1. Press Mode until the corresponding
icon appears.
The ChildLock indicator flashes.
2. Press OK to confirm.
The ChildLock indicator is shown.
To deactivate the ChildLock function,
repeat the procedure until the ChildLock
indicator goes off.
3.10 DrinksChill function
The DrinksChill function is to be used to
set an acoustic alarm at the preferred
time, useful for example when a recipe
requires to cool down food products for a
certain period of time.
1. Press Mode until the corresponding
icon appears.
The DrinksChill indicator flashes.
The Timer shows the set value (30
minutes) for a few seconds.
2. Press the Timer regulator to change
the Timer set value from 1 to 90
minutes.
3. Press OK to confirm.
TheDrinksChill indicator is shown.
The Timer start to flash (min).
At the end of the countdown the
DrinksChill indicator flashes and an audible
alarm sounds. Press OK to switch off the
sound and terminate the function.
To switch off the function repeat the
procedure until the DrinksChill goes off.
It is possible to change the
time at any time during the
countdown and at the end by
pressing the Temperature
colder button and the
Temperature warmer button.
4. FIRST USE
4.1 Cleaning the interior
Before using the appliance for the first
time, the interior and all internal
accessories should be washed with
lukewarm water and some neutral soap to
remove the typical smell of a brand-new
product, then dried thoroughly.
CAUTION!
Do not use detergents or
abrasive powders, as these
will damage the finish.
5. DAILY USE
WARNING!
Refer to Safety chapters.
5.1 Positioning the door shelves
To permit storage of food packages of
various sizes, the door shelves can be
placed at different heights.
ENGLISH 7
1. Gradually pull the shelf in the direction
of the arrows until it comes free.
2. Reposition as required.
This model is equipped with a variable
storage box which can be moved
sideways.
5.2 Movable shelves
The walls of the refrigerator are equipped
with a series of runners so that the shelves
can be positioned as desired.
For better use of space, the front half-
shelves (A) can be placed under the rear
ones. (B)
A
B
Do not move the glass shelf
above the vegetable drawer
to ensure correct air
circulation.
5.3 NaturaFresh Compartment
The storage temperature and the relative
humidity (between 45 and 90 %) provide
optimal conditions for the storage of
various kinds of food.
To learn about the temperature settings in
the NaturaFresh compartment please refer
to the “NaturaFresh compartment setting”
section
NaturaFresh compartment is suitable for
the storage of a variety of fresh food as it
preserves its high nutritional values as well
as high humidity level much longer in
comparison to the regular refrigerator.
The NaturaFresh compartment is also
suitable for defrosting food.
The thawed food can be stored up to two
days.
5.4 Humidity control
Both drawers can be used according to
the desired storage conditions
independently of each other with lower or
higher humidity.
Regulation for each drawer is separate
and is controlled using the slide valve at
the front of the drawer.
• “Dry“: low air humidity - up to 50 %
relative humidity
This humidity level is reached when
both sliders are set into this position
and the ventilation openings are wide
open.
• Humid“: high relative humidity - up to
90%
This humidity level is reached when
both sliders are set in this position
www.electrolux.com8
and the ventilation openings are
closed. Humidity is kept and can not
escape.
5.5 Fresh food storage time in the NaturaFresh compartment
Type of food Air humidity adjustment Storage time
Onion "dry” up to 5 months
Butter “dry” up to 1 month
Large pork cuts “dry” up to 10 days
Beef, venison, small pork
cuts, poultry “dry” up to 7 days
Tomato sauce “dry” up to 4 days
Fish, shellfish, cooked
meat products “dry” up to 3 days
Cooked seafood “dry” up to 2 days
Salad, vegetables Car-
rots, herbs, Brussels
sprouts, celery
“humid” up to 1 month
Artichokes, cauliflower,
chicory, iceberg lettuce,
endive, lamb’s lettuce, let-
tuce, leeks, radicchio
“humid” up to 21 days
Broccoli, Chinese leaves,
kale, cabbage, radishes,
Savoy cabbage
“humid” up to 14 days
Peas, kohlrabi “humid” up to 10 days
Spring onions, radishes,
asparagus, spinach “humid” up to 7 days
Fruit
Pears, dates (fresh), straw-
berries, peaches
“humid” up to 1 month
Plums
rhubarb, gooseberries “humid” up to 21 days
Apples (not sensitive to
cold), quinces “humid” up to 20 days
Apricots, cherries “humid” up to 14 days
Damsons, grapes “humid” up to 10 days
ENGLISH 9
Type of food Air humidity adjustment Storage time
Blackberries, currants “humid” up to 8 days
Figs (fresh) “humid” up to 7 days
Blueberries, raspberries “humid” up to 5 days
Cakes containing cream and
other kinds of pastry
products can be stored in the
NaturaFresh compartment for
2 or 3 days.
Not to be placed in the
NaturaFresh compartment:
• cold sensitive fruit which have to be
stored at cellar or room temperature
like pineapple, bananas, grapefruit,
melons, mango, papaya, oranges,
lemons, kiwi fruit.
• The types of food not mentioned above
should be stored in the refrigerator
compartment (e.g. all sorts of cheese,
cold cuts, etc.)
The level of air humidity in the
drawers depends on the
content of humidity in the
stored food, vegetable and
fruit and on the frequency of
door opening
The NaturaFresh compartment is also
suitable for slow thawing of food. In this
case the thawed food can be stored in the
NaturaFresh compartment for up to two
days.
• Pay attention to the freshness of the
food, especially on the expiry date.
Quality and freshness influence the
storage time.
• The whole storage cycle time will
depend on the preservation conditions
made prior to the final storage in the
fridge.
• Food, fruit or vegetables should always
be packed or wrapped up before
storage.
• Animal food always store packed and
dry.
• Food rich in proteins will go bad
quicker. This means seafood will spoil
before fish which in turn will spoil
before meat. While storing food in a
NaturaFresh compartment storage
time for that kind of food can be
increased by up to three times as well
without loss on quality.
• All food stored in a NaturaFresh
compartment should be taken out of
the drawers roughly 15-30 min before
consumption, particularly fruit and
vegetables to be consumed without
any additional cooking process.
Allowing fruit and vegetables to return
to room temperature will improve the
texture and flavour.
5.6 FreeStore
The refrigerator compartment is equipped
with a device that allows for rapid cooling
of foods and more uniform temperature in
the compartment.
This device activates by itself when
needed, for example for a quick
temperature recovering after door opening
or when the ambient temperature is high.
The FreeStore device stops
when the door is open and
restarts immediately after the
door closing.
www.electrolux.com10
Autres manuels pour IK3035SZR
2
Table des matières
Langues :
Autres manuels Electrolux Réfrigérateur
Electrolux
Electrolux EQE5660A-B Manuel utilisateur
Electrolux
Electrolux A Guide de démarrage rapide
Electrolux
Electrolux TC 15012 Manuel utilisateur
Electrolux
Electrolux ER 1148T Guide rapide
Electrolux
Electrolux RM 4180 Manuel utilisateur
Electrolux
Electrolux EI23BC32SS1 Manuel utilisateur
Electrolux
Electrolux ERN 2820 Manuel utilisateur
Electrolux
Electrolux ERN23800 Manuel utilisateur
Electrolux
Electrolux ERH 3620 X Manuel utilisateur
Electrolux
Electrolux EK 158 Manuel utilisateur
Electrolux
Electrolux ER8761B Manuel utilisateur
Electrolux
Electrolux SANTO Z 9 12 40-6i Manuel utilisateur
Electrolux
Electrolux 728510 Manuel utilisateur
Electrolux
Electrolux ER 7428 C Guide rapide
Electrolux
Electrolux ER 2522 B Guide rapide
Electrolux
Electrolux FI23/11ND Manuel utilisateur
Electrolux
Electrolux ER 1625 T Manuel utilisateur
Electrolux
Electrolux E23BC68JPS6 Manuel utilisateur
Electrolux
Electrolux IK305BNL Manuel utilisateur
Electrolux
Electrolux ERA 39395 X8 Manuel utilisateur
