Electrolux EQAXF01BXWP Manuel utilisateur

EQAXF01BXWP

USER MANUAL 1EN

Thank you for choosing ELECTROLUX. This manual contains

Welcome

Environmental Notice

all the information you need to safely and correctly use your water

dispenser. Please read all the instructions prior to using the appliance,

and keep this manual in a secure place for future reference. Do not

remove the rating plate label which attached adhesive identiﬁcation label

containing the code, model number, manufacturer and other information.

This label will be used by an ELECTROLUX authorized service

representative in the event that your water dispenser needs service.

The packaging material used is recyclable. We

recommend that you separate plastic, paper and

cardboard and give them to recycling agents.

To help preserve the environment, the refrigerant

used in this product is R134a (Hydrofluorocarbon -

HFC), which does not affect the ozone layer and

has little impact on the greenhouse effect.

According to WEEE (Waste of Electrical and

Electronic Equipment) guidelines, waste from

electrical and electronic devices should be

collected separately. If you need to remove of this

appliance in the future, do not throw it away with

the rest of your domestic garbage. Instead, please

take the appliance to the nearest WEEE collecting

agents, where available.

Do not use mechanical devices or other means to accelerate the

defrosting process, other than those recommended by the manufacturer.

Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

Customer Care

12Troubleshooting

properties incident.

To avoid danger of suffocation, keep plastic bag away from babies and children.

power

5. Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

1. This unit is designed for drinkable water only. Put bottles as speciﬁed inside

the cabinet before using.

3. This dispenser can provide hot, cold and room temperature water.

4. With the adoption of distinctive thermal isolation technology, this unit can

minimize thermal exchange between hot, room temperature and cold water.

The heating method of machine can only be used within 1500m elevation.

6. Regional restrictions

Do not use an extension cord or

plug adaptor.(Fig.2)

Fig. 1

Fig. 2

1. Plug the water dispenser directly into the

socket. The unit requires proper

grounding and the correct voltage (as

technical information speciﬁed on page 13

of this manual).(Fig. 1)

2. An appropriate length of power-supply cord

is provided to reduce the risks of becoming

entangled in, or tripping over a longer cord.

5. Choose a place that is near a grounded

electrical socket. Keep the dispenser at least

20cm away from walls and other appliances

and furnitures on all 4 sides.

6. Do not place the water dispenser sitting over the

power cord.

3. Recommend to install the anti-tilt bracket at the

back side of this water dispenser to prevent

the dispenser from falling down which could

cause injury.(Fig. )6

8. Use the switch when turning the heating/

cooling On/Off. Located at the at the left

side back of water dispenser.(page 6)

10. Keep the unit in a dry place and away from

direct sunlight. Do not place the machine on

paper or foam. Do not place anything

ﬂammable beside this machine.(Fig. 4)

12. Unplug the unit when the unit will not be

used for a long period to save electricity.

14. Never use organic liquids polishing chemical

to clean the machine.

15. The thermostat to control temperature has

been set up by There is nomanufacturer.

need to adjust it yourself.

Fig. 3

(Fig. 3)

Fig. 4

Fig. 5

(Fig. 5)

until the water can flow out from the hot water

spout when the hot water button be activated.

button of cold water

button of hot w

(FRONT)

ater

button of normal water

panel

spout

front carapace

condenser

power cord

drain hole

cooling switch

drip tray

heating switch

Fig. 7

Fig. 6

Installing the ﬂoor Bracket kit(Fig.6)

1. Open cabinet door.

2. Place fresh bottle outside of cabinet.

3. Remove the entire plastic cap from top

of bottle.

4. Clean outside of new bottle with a cloth.

5. Place probe assembly into bottle.

6. Slide collar with head down until it clicks

in place.

7. Slide bottle into cabinet and close door.

front carapace.

near a grounded socket. Do not plug in power cord yet.

1. Use 13 mm screw to fix the fixing bracket on the

side of base pan.

2. Drill out a screw hole(6 mm) on the floor.

3. Insert a screw anchor (wall plug) into the drilled hole.

4. Move water dispenser, Align fixing bracket hole

with screw hole of the floor.

5. Put the 25mm screw into the screw hole of fixing

bracket.

6. Tighten the screw.

1 1 1 2-3

4-5 6

Fig. 8

Fig. 9

switches

one liter

socket.

The pump will begin to move water

from the bottle to the hot and cold

tanks. It will take up to approximate

12 minutes to fill the tanks for the

first time. During this period the

pump will run continuously. This is

normal.

Push the red child lock button from

right to left and press hot water button

downward to start hot water ﬂow.

After setup, it will take up to approximate

1 hour get water to maximum cold

button

Fig

button
