Electrolux Dito TRK70VV Manuel utilisateur
Item
Model
ProjectName
Vegetable slicers
603324
TRK70
The TRK70 is a versitile machine capable
of changing from vegetable slicer to food
processor in a matter of seconds. With
the fast and easy to change attachments,
you can be ready to prepare a menu
ranging in anything from hors d'oeuvres to
dessert. When using the vegetable slicer
attachment, it is possible to quickly and
easily make over 70 different types of cuts
for stylish and imaginative presentations
of salads, garnishings, macedonies, chips
and many other combinations. When
using the food processing attachment, it
is possible to mince meat, create
elaborate: mousses, stuffings, creams,
pastries, etc. The capacities of the TRK70
make it a perfect complement for kitchens
of any size.
FEATURES
V Vegetable slicer attachment for shredding,
grating, dicing and mincing your favorite recipes.
V Cutter-mixer attachment to mix, blend, chop
and puree meats, vegetables and even
desserts.Designed for easy cleaning thanks to
the rounded shapes and stainless steel top.
V User friendly touch button control panel to
select required speed and pulse funcion.
V Efficient scraper eliminates the need to
manually remove food from the sides of the bowl
in addition to keeping the lid clean for optimal
visibility.
V The extensive range of slicing discs and
cutting blades makes even difficult preparations
possible.
V Specially designed smooth or microtoothed
blades in 420 AISI stainless steel guarantee food
will not separate.
V Base adjustable from flat to inclined with the
simple movement of a lever, making vegetable
preparations even easier.
Specifications
MODEL
TRK70VV
603324
External dimensions - mm
width 252
depth 485
height 530
Cutting capacity - kg/h
carrots 250
chips 500
dicing 450
Chopping capacity - kg/cycle
condiments 2
Mincing capacity - kg/cycle
meats 2.5
Preparation mayonnaise/sauces - kg/cycle
mayonnaise 3.5
Pastry preparation - kg/cycle 2.5
Power - kW
installed-electric 1.5
Net weight - kg. 27.9
Supply voltage 200...240 V, 1N, 50/60
V Designed for easy cleaning thanks to the rounded
shapes and stainless steel top.
V User friendly touch button control panel to select
required speed and pulse funcion.
V Efficient scraper eliminates the need to manually
remove food from the sides of the bowl in addition to
keeping the lid clean for optimal visibility.
V Specially designed smooth or microtoothed
blades in 420 AISI stainless steel guarantee food will
not separate.
V Thanks to its wide versatility, the machine always
allows to select the correct slicing/processing speed,
according to the accessory being used.
Included accessories
CODE DESCRIPTION
653593 7 LITRE S/S BOWL FOR CUTTER-MIXER 1
653592 LID+BOWL SCRAPER FOR 7 LT CUTTER-MIXER 1
653584 MICROTOOTHED BLADE ROTOR-7L CUTTER-MIXER 1
Optional accessories
CODE DESCRIPTION
653593 7 LITRE S/S BOWL FOR CUTTER-MIXER ✓
653568 DICING GRID 10 MM FOR VEGETABLE SLICER ✓
653569 DICING GRID 12 MM FOR VEGETABLE SLICER ✓
653570 DICING GRID 20 MM FOR VEGETABLE SLICER ✓
653566 DICING GRID 5 MM FOR VEGETABLE SLICER ✓
653567 DICING GRID 8 MM FOR VEGETABLE SLICER ✓
653122 DISC WITH CORRUGATED BLADES 2 MM ✓
653123 DISC WITH CORRUGATED BLADES 3 MM ✓
653126 DISC WITH CORRUGATED BLADES 6 MM ✓
653111 DISC WITH CURVED BLADES 1 MM ✓
653511 DISC WITH CURVED BLADES 10 MM ✓
653112 DISC WITH CURVED BLADES 2 MM ✓
653113 DISC WITH CURVED BLADES 3 MM ✓
653115 DISC WITH CURVED BLADES 5 MM ✓
653162 GRATING DISC 2 MM ✓
653163 GRATING DISC 3 MM ✓
653164 GRATING DISC 4 MM ✓
653167 GRATING DISC 7 MM ✓
653498 GRATING DISC 9 MM ✓
653008 GRATING DISC FOR KNODELN AND BREAD ✓
653170 GRATING DISC FOR PARMESAN AND BREAD ✓
653573 GRID FOR CHIPS 10MM FOR VEGETABLE SLICER ✓
653571 GRID FOR CHIPS 6MM FOR VEGETABLE SLICER ✓
653572 GRID FOR CHIPS 8MM FOR VEGETABLE SLICER ✓
653594 KIT VEG .SLICER FOR VAR.SP.CUTTER-MIXERS ✓
653592 LID+BOWL SCRAPER FOR 7 LT CUTTER-MIXER ✓
653584 MICROTOOTHED BLADE ROTOR-7L CUTTER-MIXER ✓
653283 S/S WORK TABLE+FOLDING SHELVES+DISK RACK ✓
653214 SHREDDING DISC 2X2 MM ✓
653153 SHREDDING DISC 3X3 MM ✓
653154 SHREDDING DISC 4X4 MM ✓
653289 SLICING BLADES VARIABLE DEPTH 1MM-7MM ✓
653565 SLICING DISC FOR MOZZARELLA 10 MM ✓
653101 SLICING DISC WITH STRAIGHT BLADES 1 MM ✓
653110 SLICING DISC WITH STRAIGHT BLADES 10 MM ✓
653185 SLICING DISC WITH STRAIGHT BLADES 14 MM ✓
653102 SLICING DISC WITH STRAIGHT BLADES 2 MM ✓
653103 SLICING DISC WITH STRAIGHT BLADES 3 MM ✓
653106 SLICING DISC WITH STRAIGHT BLADES 6 MM ✓
653108 SLICING DISC WITH STRAIGHT BLADES 8 MM ✓
653583 SMOOTH BLADE ROTOR FOR 7LT CUTTER-MIXER ✓
653180 TABLE+SHELF+GN 1/1 POLYCARBONATE TRAY ✓
AABD010
www.dito-electrolux.com
Vegetable slicers
The manufacturer reserves the right to modify and make improvements to the products without
giving prior warning. Dimensions, illustrations, technical data, weights, etc. are given as an
indication only.
Installation drawings
XXX
I - Electrical connection 200...240 V, 1N, 50/60
MODEL
TRK70VV
603324
603324
I
I
745
220
410
530
252
725
224
485
320
252
505
