Electrolux FC48 Manuel utilisateur

05306004/GB

26.2019

Installation manual

Finishing cabinet

FC48

Translated from french

05306004

Page

Notice Date

INSTALLATION

MANUAL

01004 0

General instructions

Environmental information .................................................................................... 1/1

Preliminary instructions ......................................................................................... 1/2

Note about the A.C. power ................................................................................... 3/2

Handling/Weight

Handling ................................................................................................................ 1/3

Packing - Weight................................................................................................... 1/4

Technical characteristics

Setting up dimensions........................................................................................... 1/5

Technical characteristics ...................................................................................... 2/5

Sound level ........................................................................................................... 3/5

Installation/Putting into service

Unpacking ............................................................................................................. 1/6

Installation ............................................................................................................. 2/6

Mechanical installation .......................................................................................... 2/6

Working place lighting .......................................................................................... 2/6

Gas connection ..................................................................................................... 3/6

Connection of the ironer evacuation system ........................................................ 9/6

Steam connection ................................................................................................ 13/6

Electricity power supply ....................................................................................... 15/6

Operating inspection............................................................................................... 1/7

Appendices

Conversion of measurement units ........................................................................ 1/9

Table of contents

The manufacturer reserves the right to modify construction and equipment characteristics.

Pages/Chapters

05306004

PageNotice Date INSTALLATION

MANUAL

1004 1 11. General

instruction

Environmental information

Concerned by providing the end user with useful and necessary environmental information,

we wish to precise :

•Data about energetic consumptions, wastes (atmospheric and liquid) and sound level are

indicated in the paragraph "Technical characteristics".

•Forseeing its recycling, this machine is fully dismantable.

•This machine is free from any asbestos.

•In conformity with French regulations:

- Law No. 76-663 of July 19th 1976

- Decree No. 77-1133 of September 21st 1977

- The decree of 7th July 1992

- The decree of 29th December 1993

- The decree of 28th December 1999

- No. 2311 of the nomenclature for classified installations

Commercial linen cleaning laundries and launderettes are subject to:

- prefectural authorisation if the washing capacity exceeds five tonnes per day.

- a declaration to the prefecture if the washing capacity exceeds 500 kilos per day but is

below or equal to five tonnes per day.

•In application of the Law of 15 July 1975 and the decrees of 01 April and 13 July 1994 on

the disposal of industrial and commercial packing waste «All owners of packing waste

producing a weekly volume below 1100 litres can forward these to the local collection and

treatment department. If exceeding this volume, the owners of packing waste will ensure

their valuation by reuse, recycling or, any other action aiming at producing reusable

materials or energy... or provide them contractually to a certified intermediate authorised

to transport, trade or broke waste».

Therefore, these texts forbid:

- land filling raw waste

- open air burning or incineration without energy collection.

•Packaging of our machines are according with the provisions of decree 98-638 from July

20 1998 related to environment requirements.

For additional information, do not hesitate to consult with our environmental department.

05306004

Page

Notice Date

INSTALLATION

MANUAL

1004

2. Preliminary instructions

SAFETY

The mechanical and electrical

installation of the machine should

only be done by qualified

personnel.

CAUTION

Do not use the machine unless it is

plugged into a correctly earthed

power socket complying with

standards in force.

This machine should be installed in conformance to the health and safety

regulations, and only used in a sufficiently aerated area.

Check the instructions before installing or using the machine.

CAUTION

Under no circumstances should a

gas-heating machine be installed in

a building which includes a dry-

cleaning machine.

CAUTION

Evacuation duct must never be

connected to the evacuation used

for a dry cleaning machine or other

machine of the same type.

CAUTION

When embedding the finishing cabinet in a

technical area, it is recommended to use

temperature and fire resistant materials.

05306004

PageNotice Date INSTALLATION

MANUAL

0305

CAUTION

In order to avoid any bending of

casings, you should never climb

and stand on top of the machine.

2. Preliminary instructions

05306004

Page

Notice Date

INSTALLATION

MANUAL

0305 3 2

2. Preliminary instructions

Note about the A.C. power

•According to the EN 60204-1:1997 standard, the machine is provided for AC supplies

corresponding to the extracted caracteristics below :

4.3.2 AC supplies

Voltage :

Steady state voltage : from 0.9 to 1,1 of nominal voltage.

Frequency :

from 0.99 to 1.01 of nominal frequency continuously.

from 0.98 to 1.02 short time.

Harmonics :

Harmonic distorsion not to exceed 10% of the total r.m.s. voltage between live

conductors for the sum of the second through to the fifth harmonic. An additional 2%

of the total r.m.s. voltage between live conductors for the sum of the sixth through to

the 30th harmonic is permissible.

Voltage unbalance :

Neither the voltage of the negative sequence component nor the voltage of the zero

sequence component in three-phase supplies shall exceed 2% of the positive

sequence component.

Voltage interruption :

Supply interrupted or at zero voltage for not more than 3ms at any random time in the

supply cycle. There shall be more than 1s between successive interruptions.

Voltage dips :

Voltage dips shall not exceed 20% of the peak voltage of the supply for more than one

cycle. There shall be more than 1s between successive dips.

05306004

PageNotice Date INSTALLATION

MANUAL

D1188

1004 1 3

D1189

500 daN

3. Handling

WARNING

It is obligatory that all these

operations are undertaken by

handling specialists.

Lifting with a fork-lift truck

The machine is delivered secured on a

transport pallet.

Lifting with handling straps

Lifting in that case can only be done with

handling straps (minimum capacity 500

daN) which bear weight of the machine

(350 daN).

Use the two rings on top of the machine

to attach the handling straps and to lift

the machine.

05306004

Page

Notice Date

INSTALLATION

MANUAL

D0787

10905

1060 1500 2200

345 340 350

415 410 420

---

- 480 -

4. Packing - Weight

Identification plate

Adjustment label

(for gas machine only)

Packing

Packing dimensions Size A Size B Size C

Weight in daN

Gas Electric Steam

(machine + pallet) (without boiler)

(machine + pallet) (with boiler)

(machine + box) (without boiler)

(machine + box) (with boiler)

07100130

1612

1920

1390

1000

335

2050

1975

1420

1860

210

1475

10 220

100

105 110

130

870

1325

1220

1270

820

435

1350

05306004

PageNotice Date INSTALLATION

MANUAL

5. Technical

characteristics

Setting up dimensions
