Bedienungs-undEinbauanleitungfürGlaskeramikkochfelder

OperaingandAssemblyInstructionsforCeramicBuilt-In

Hobs

Noticed’utilisationetdemontagedesplansdecuissonen

vitrocéramique

Gebruiksaanwijzingeninbouwinstruktiesvoorglaskeramiek-

EHO800/EHO800K/EHO801/EHO801K

We thank you for choosing a ceramic hob of

ELECTROLUX. Thus you chose quality, innovation

and durability. These operating and assembly

instructions will allow you to become acquainted

with the appliance and to do everything withhin its

possibilities.

Dear Customer GB

Unpackingandcontrol .............14

Descriptionsofappliances ...........14

Hotplates.....................15

Heat control knobs . . . . . . . . . . . . . . . . 15

Touch control knob for the double-circuit

heatingelement..................15

Residualheatindicator..............15

Practical information for the houswife . . . . 16

Careancleaning.................18

Whattodoincaseoffault?...........18

Content GB

Please examine the appliance for any damage sus-

tained during transportation!

EHO800/EHO800K

1) Hotplate section, 18 cm Ø, 1800 W (Halogen)

2) Hotplate section, 14,5 cm Ø, 1200 W

(single circuit)

3) Hotplate section, Ø 14 cm x 24 cm, 1800 W

(double circuit)

4) Hotplate section, 14,5 cm Ø , 1200 W

(single circuit)

5) Residual heat iridicator (four lights pilot lamp)

6) Main signal lamp

7) Touch control knob for the double circuit

element

EHO 801 / EHO 801 K

1) Hotplate section, 18 cm Ø, 1800 W (Halogen)

2) Hotplate section, 14,5 cm Ø, 1200 W

(single circuit)

3) Hotplate section, Ø 14 cm x 24 cm, 1800 W

(double circuit)

4) Hotplate section, 14,5 cm Ø , 1200 W (Halogen)

5) Residual heat iridicator (four lights pilot lamp)

6) Main signal lamp

7) Touch control knob for the double circuit

element

Unpacking and control

Description of appliances

156

The hot plate sections are indicated by markings on

the ceramic top.

The dimensions of the heated surfaces are such that

they can accommodate commercially available pans.

Heat control knobs

The heat control knobs allow stepless regulation of

the heat output from 1 to 12.

Theycanbeturnedbothtotherightandtotheleft.

Touch control knob for the double-

circuit heating element

The second heating circuit is activated when the

corresponding heat control knob is turned on and the

touch control pressed.

The heating circuit is switched off when the control

knob is turned back to the zero-position.

Residual heat indicator

This warning lamp will light up when the surface of

the hot plate section reaches a temperature which

could cause burning.

This lamp will also remain lit after heated area has

been switched off as long as the residual heat at the

surface of the ceramic plate is enough to cause burns.

Thelamp will onlygoout when thereceases to beany

danger (temperature under 60° C).

The residual heat should be used to completing the

cooking process or to keeping warm food.

Hot plates

The correct pans - See figure 4

Panswithaflat,solidbasemustbeusedontheheating

sections of the ceramic hotplate.

Uneven pans or pan bases will lead to unnecessarily

long cooking times, and thus higher energy con

sumption.

For cooking which requires a particularly high tem

perature pans with thick flat bases are most suitable.

Using pans without lids wastes energy. So always use

pans with lids.

The pans should not be smaller than the heating

sections.

Very important!

When in use the surface of the appliance willbecome

hot, hence particular care should be exercised.

Small children should be kept away.

Do not place any wet pans or steamy pan lids on

unused hot plate sections.

Wetness and steamwill in time lead to lime depo sits!

Do not place any plastic containers on the hot surfa

ces.

Do not prepare any food, whether wrapped in alumi

nium foil or not, on the surface.

Do not use the ceramic hot plate surface as a chop

ping board.

Keep sugar or juices containing sugar away from the

hot plates.

Please read the following notes on care and clean ing.

As overheated fat and oil are liable to ignite, dishes

involving the use of fat and oil (e.g. French fries)

should always be prepared under supervision.

The ceramic hot plate surface should not be used as a

work top or for putting things down on.

Take care when using other electrical appliances,

whose connection leads are plugged in near to the

hob. These leads must not come into contact with the

hot surface of the hob.

Practical Information for the housewife

Abb. 4

lf, due to careless use, ruptures, cracks of fissures

should occur then the appliance should no longer

be used, that is to say that it should be

disconnected from the mains, for example by

disconnection of the safety devices.

In this case immediately call in the customer service

engineer.

Practical Information for the housewife

Your ceramic hob surface is resistant to extremes of

temperature. Neither the cold nor the heat can harm

it.

However, it can be damaged by the impact of any

thing which is punctiform such as a springkling of

salt, a spice bottle or any other small object.

Clean your ceramic hot plates surface thouroughly

before its first use and then clean it regularly, when it

is just warm or cold, and avoid continual burning of

dirt until it is solidified.

For cleaning use:

kitchen roll or clean cloth

razor blade scraper

Sidol stainless steel cleaner with alcohol or a steel

fixer or Cera-Fix or Collo Profi

The choiceof cleaning material isdetermined by how

dirty the surface is:

Light dirt which has not been burnet solid can be

wiped off with a soft cloth.

All larger amounts of dirt which have become

encrusted upon the surface can be simply and easily

removed with a razor blade scraper. Lime and water

deposits, fat splashes and discolourations which

shimmer in a metallic way are to be cleaned with

Sidol steel cleaner and steel fixer or Cera-Fix and

Collo Profi.

Do not use scourers containing powder and sponges

with abrasive sides.

Pay special attention to making sure that residual

quantities of sugar, jam and juices containing sugar,

and of plastic objects or aluminium foil are immedi-

atelywhilethey are still hotwithaglasscraper.lfthey

are not removed quickly the ceramic surface may be

damaged.

Care and cleaning

Note:

Changes in colour ofthe hotplate sectionsare not due

to a change in the material, but they are food residues

which have become burnt on as they have not been

regularly removed by cleaning. They have no effect

on the functioning and durability of the ceramic.

The cleaning agents which have been recommended:

Steel Fixer, Sidol Special, Cera-Fix and Collo Profi

can be obtained in department stores, specialist

electrical shops, chemist’s shops, grocery stores and

specialist kitchen shops.

Razor blade scrapers may be obtained from craft

shops, builder’s, merchants as well as from shops

selling artists’ materials.

lf your hob is in need of servicing then please give

your branch of the customer services the following

details:

You will find this information on the service plaque

we are providing on the separate sheet, since the

original plate on your applicance is no longer

accessible after installation.

This information will enable customer services to

prepare the replacement parts for your model so that

yourappliancecanbefullyrepairedonourengineer’s

first visit.

The right to make technical changes is reserved.

Care and cleaning

What to do in case of a fault?

Model

Type

Fabr.-Nr

374 2088-00 / 09.95
