Electrolux EHG6415 Manuel utilisateur
Gas Hob
Варочные панели
Kuhala
EHG 6415
EHG 6835
EHG 6833
LT
LV UAKZ
RU EE
operating instructions
Pуководство по эксплуатации
Upute za uporabu
EN HR
2electrolux
electrolux 3
Welcome to the world of Electrolux
Thank you for choosing a first class product from Electrolux, which hopefully
will provide you with lots of pleasure in the future.
The Electrolux ambition is to offer a wide variety of quality products that make
your life more comfortable.
You find some examples on the cover in this manual. Please take a few minutes
to study this manual so that you can take advantage of the benefits of your new
machine.
We promise that it will provide a superior User Experience delivering Ease-of-
Mind.
Good luck!
4electrolux
Important Safety Information ............................................................................. 5
Operation .......................................................................................................... 7
Using the hob correctly ..................................................................................... 8
Cleaning and Maintenance ................................................................................ 9
Guarantee ....................................................................................................... 20
For the User
For the Installer
Technical data ................................................................................................. 11
Installation ....................................................................................................... 13
Adaptation to different types of gas ................................................................. 15
Electrical Connection ....................................................................................... 16
Building In ....................................................................................................... 17
Possibilities for insertion .................................................................................. 19
Contents
The following symbols will be found in the text to guide you throughout the
Instructions:
Safety Instructions
Step by step instructions for an operation
Hints and Tips
Environmental information
!
Guide to Use the instructions
This appliance complies with the following E.E.C. Directives:
•2006/95 (Low Voltage Directive);
•89/336 (Electromagnetical Compatibility Directive);
•93/68 (General Directives) and subsequent modifications.
It is very important that this instruction book should be kept safely for future
consultation. If the appliance should be sold or given to another person,
please ensure that the booklet goes together with it, so that the new owner
can know of the functions of the machine and also be aware of the warnings.
These instructions are only for the countries stated by the symbol printed on
the front cover of this instruction book.
electrolux 5
Installation
"The work of installation must be
carried out by competent and qualified
installers according to the regulations
in force.
• Any modifications to the domestic
electrical mains which may be
necessary for the installation of the
appliance should be carried out only
by competent personnel.
During Operation
• This appliance has been designed for
non professional purpose in private
houses only. It is meant to cook edible
foodstuff only and must not be used
for any other purposes.
• It is dangerous to alter the specification
in any way.
• For hygiene and safety reasons, this
appliance should be kept clean at all
times. A build-up of fats or other
foodstuff could result in a fire.
• Under no circumstances should you
attempt to repair the appliance
yourself. Repairs carried out by
unexperienced persons may cause
injury or serious malfunctioning. Refer
to your local Service Centre. Always
insist on genuine spare parts.
• Ensure that all control knobs are in the
OFF position when not in use.
• Should you connect any electrical tool
to a plug near this cooking appliance,
ensure that electric cables are not in
English
This warnings has been given for the safety of you and others. We therefore
ask you to carefully read the procedures of installing and using this cooker.
Important safety information
contact with it and keep them far
enough from the heated parts of this
appliance.
• If the appliance is out of order,
disconnect it from the electric supply.
Child Safety
• This appliance has been designed to
be operated by adults and children
under supervision. Young children
must not be allowed to tamper with the
controls or play near or with the oven.
• This appliance is not intended for use
by children or other persons whose
physical, sensory or mental capabilities
or lack of experience and knowledge
prevents them from using the
appliance safely without supervision or
instruction by a responsible person to
ensure that they can use the appliance
safely.
• Accessible parts of this appliance may
become hot when it is in use. Children
should be kept away until it has
cooled.
About Installation, Cleaning and
Manteinance
"It is mandatory that all operations
required for the installation are carried
out by a qualified or competent
person, in accordance with existing
rules and regulations.
• Disconnect the appliance from the
electrical supply, before carrying out
any cleaning or manteinance work.
• Ensure a good ventilation around the
6electrolux
appliance. A poor air supply could
cause lack of oxygen.
• Ensure that the gas supply complies
with the gas type stated on the
identification label, placed near the gas
supply pipe.
• This appliance is not connected to a
combustion products evacuation
device. It must be installed and
connected in accordance with current
installation regulations. Particular
attention shall be given to the relevant
requirements regarding ventilation.
•The use of a gas cooking
appliance results in the production
of heat and moisture in the room in
which it is installed. Ensure that
the kitchen is well ventilated: keep
natural ventilation holes open or
install a mechanical ventilation
device (mechanical extractor
hood).
•Prolonged intensive use of the
appliance may call for additional
ventilation, for example opening of
a window, or more effective
ventilation, for example increasing
the level of mechanical ventilation
where present.
• Once you removed all packaging from
the appliance, ensure that it is not
damaged and the electric cable is in
perfect conditions. Otherwise, contact
your dealer before proceeding with the
installation.
•The manufacturer disclaims any
responsability should all the safety
measures not be carried out.
Service
• Under no circumstances should you
attempt to repair the appliance
yourself. Repairs carried out by
unexperienced persons may cause
injury or serious malfunctioning. Refer
to your local Service Centre. Always
insist on genuine spare parts.
Environmental Information
"After installation, please dispose of
the packaging with due regard to
safety and the environment.
• When disposing of an old appliance,
make it unusable, by cutting off the
cable.
The symbol on the product or
on its packaging indicates that this
product may not be treated as household
waste. Instead it shall be handed over to
the applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. For more detailed information
about recycling of this product, please
contact your local city office, your
household waste disposal service or the
shop where you purchased the product.
electrolux 7
Operation
Hob burner control knobs
The symbols on the knobs mean:
= no gas supply
= maximum gas supply
= minimum gas supply
For easier lighting, proceed before
putting a pan on the pan support.
Lighting the burners
To light a burner, turn the relevant
knob anticlockwise to maximum
position ( ) and push down the knob
to ignite.
After lighting the flame, keep the
knob pushed down for about 5
seconds. This will allow the
"thermocouple" to be heated and the
safety device to be switched off,
otherwise the gas supply would be
interrupted. Then, check the flame is
regular and adjust it as required.
If you cannot light the flame even
after several attempts, check the "cap"
and “crown” are in the correct position.
In the absence of electricity, ignition
can occur without the electrical device;
in this case approach the burner with a
flame, push the relevant knob down and
turn it anti-clockwise until it reaches the
"maximum" position.
To switch off burners
To put the flame out, turn the knob to
the symbol ( ).
!
Take care when frying food in
hot oil or fat, as the overheated
splashes could easily ignite.
When switching on the mains, after
installation or a power cut, it is quite
normal for the spark generator to be
activated automatically.
!
8electrolux
Using the hob correctly
Practical hints
The burners
To ensure maximum burner
efficiency, you should only use pots and
pans with a flat bottom fitting the size of
the burner used.
Triple Crown Burner
diameter 18-26 cm
Rapid Burner
diameter 18-26 cm
Front Semi-rapid Burner
diameter 12-18 cm
Rear Semi-rapid Burner
diameter 12-22 cm
Auxiliary Burner
diameter 8-18 cm
• For easier lighting, proceed before
putting a pan on the pan support.
• Use only pans or pots with flat bottom.
•Take care when frying food in hot
oil or fat, as the overheated
splashes could easily ignite.
• If you use a saucepan which is smaller
than the recommended size, the flame
will spread beyond the bottom of the
vessel, causing the handle to overheat.
• Prolonged cooking with
potstones, earthenware pans or
cast-iron plates is inadvisable.
Also, do not use aluminium foil to
protect the top during use.
•Make sure pots do not protrude over
the edges of the cooktop and that they
are centrally positioned on the rings in
order to obtain lower gas
consumption.
• Do not place unstable or deformed
pots on the rings: they could tip over or
spill their contents, causing accidents.
• Pots must not enter the control zone.
• If the control knobs become difficult to
turn, please contact your local Service
Force Centre.
• As soon as a liquid starts boiling, turn
down the flame so that it will barely
keep the liquid simmering.
electrolux 9
Cleaning and Mainteinance
Disconnect the appliance from
the electrical supply, before
carrying out any cleaning or
manteinance work.
The hob is best cleaned whilst
it is still warm, as spillage can
be removed more easily than if
it is left to cool.
This appliance cannot be
cleaned with steam or with a
steam cleaning machine.
The burners
"The burner caps and crowns can be
removed for cleaning.
"Wash the burners taps and crowns
using hot soapy water, and remove
marks with a mild paste cleaner. A
well moistened soap impregnated
steel wool pad can be used with
caution, if the marks are particularly
difficult to remove.
"After cleaning, be sure to wipe dry
with a soft cloth.
"Frequently wash the "caps" and the
"crowns" with hot soapy water,
carefully taking away any built-up of
food.
The pan supports
"After cleaning, make sure that the
pan supports are correctly
positioned.
"To make burners work properly,
ensure that pan supports are placed
in a way that the arms are centred
upon the burner as shown in the
picture.
"Pay attention when replacing the
pan supports in order to avoid
damaging the hob top.
NO
YES
10 electrolux
Hobs with cast iron pan sup-
ports: after cleaning, place
the pan supports back on
their position.
The Hob Top
"Regularly wipe over the hob top
using a soft cloth well wrung out in
warm water to which a little wasing
up liquid has been added. Avoid the
use of the following:
- household detergent and bleaches;
- impregnated pads unsuitable for
non-stick saucepans;
- steel wool pads;
- bath/sink stain removers.
"Should the hob top become heavily
soiled, the following products are
recommended:
- For stainless steel hobs use a
proprietary stainless steel cleaner.
- For other hobs use Hob Brite or Bar
Keepers Friend.
"Do not leave acid or alkaline
substances (e.g. vinegar, salt,
lemon juice, etc.) on the cooktop.
The Ignition electrode
The electric ignition is obtained
through a ceramic electrode with a
metal electrode (Fig - C). Keep these
components very clean, to avoid difficult
lighting, and check that the burner
crown holes (Fig - B) are not obstructed.
A- Burner cap
B- Burner crown
C- Ignition candle
D- Thermocouple
A
B
D
C
Triple Crown Burner
(EHG 6833 -EHG 6835)
Ce manuel convient aux modèles suivants
2
Table des matières
Autres manuels Electrolux Plaque
Electrolux
Electrolux EHH 600 Guide produit
Electrolux
Electrolux EHG 30215 Manuel utilisateur
Electrolux
Electrolux KGM64310X Manuel utilisateur
Electrolux
Electrolux EHD68200P Manuel utilisateur
Electrolux
Electrolux EHD60150P Manuel utilisateur
Electrolux
Electrolux EGL6382 Manuel utilisateur
Electrolux
Electrolux HOI630PF Manuel utilisateur
Electrolux
Electrolux LIT30230C Manuel utilisateur
Electrolux
Electrolux GK29TCO Manuel utilisateur
Electrolux
Electrolux GK58TSPLCN Manuel utilisateur
Electrolux
Electrolux HKK670MF Manuel utilisateur
Electrolux
Electrolux EHL9530FOK Manuel utilisateur
Electrolux
Electrolux RGG6242OOX Manuel utilisateur
Electrolux
Electrolux EGG3213N Manuel utilisateur
Electrolux
Electrolux KGG75362W Manuel utilisateur
Electrolux
Electrolux EFC90460OX Manuel utilisateur
Electrolux
Electrolux ECCG3672AS Manuel utilisateur
Electrolux
Electrolux EHL6540FOK Manuel utilisateur
Electrolux
Electrolux EGG 689 Manuel utilisateur
Electrolux
Electrolux EGT6242NOK Manuel utilisateur
