Electrolux ECN 1050 Manuel utilisateur

ECN 1050

Chest freezer

User manual EN

We were thinking of you

when we made this product

electrolux 3

Contents

Safety Information . . . . . . . . . . . . . . .4

Product Description . . . . . . . . . . . . .4

Installation . . . . . . . . . . . . . . . . . . . .5

Electrical connection . . . . . . . . . . . . .5

First use . . . . . . . . . . . . . . . . . . . . . .5

Switch on-off . . . . . . . . . . . . . . . . . .6

Daily use . . . . . . . . . . . . . . . . . . . . .6

Care and Cleaning . . . . . . . . . . . . . .6

Helpful hints and tips . . . . . . . . . . . . .7

What to do if... . . . . . . . . . . . . . . . . .7

Service or repair . . . . . . . . . . . . . . . .8

Technical Data . . . . . . . . . . . . . . . . .9

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

Disposal

By ensuring this product is disposed of correctly, you will help

prevent potential damaging consequences for the environment

and human health.

The symbol on the product indicates that this product may not be

treated as household waste, instead it should be taken to the

appropriate collection point for the recycling of electrical and

electronic equipment. For more detailed information about

recycling of this product, please contact your local council, your

household waste disposal service or the shop where you

purchased the appliance.

4electrolux EN

Safety Information

Before installing and using the appliance

read this user's instruction book carefully.

It contains safety precautions, hints,

information and ideas. If the freezer is

used in compliance with the instructions

written, it will operate properly and

provide you with the greatest satisfaction.

These warnings are provided in the

interest of safety. You must read them

carefully before installing or using the

appliance.

Use the freezer only for storing frozen

food, freezing fresh food and making

ice cubes.

Do not eat ice cubes or ice lollies

immediately after taking them out of

the freezer, as they may cause frost

burns.

Do not allow children to play or hide

inside the freezer, as they may

become trapped inside and suffocate.

Do not store glass containers with

liquids in the freezer, as they may

burst.

Ensure that the freezer is not resting

on the power supply cable.

Before servicing or cleaning, always

unplug the appliance or disconnect

the power supply.

Do not use other electrical appliances

(such as ice cream makers) inside the

appliance.

Your appliance contains an

environmentally friendly natural gas,

isobuthane (R600a). Caution is

required however, since isobuthane is

flammable. Therefore it is essential to

ensure that the refrigerant pipelines

are not damaged.

It is most important that this instruction

book should be retained with the

appliance for future reference.

Product Description

1. Lid handle

2. Seal

3. Thermostat knob: temperature

adjustment

4. Upper edge

electrolux 5

Installation

Wait at least 2 hours before

connecting the freezer to the power

supply to ensure the refrigerant circuit

is fully efficient.

Install the freezer in a dry, well

ventilated room. Avoid locations near a

source of heat or in direct sunlight.

The room temperature should

correspond to the climatic

classification for which the freezer was

designed, see chapter "Technical

data".

Place the freezer horizontally on a firm

surface, resting on all four feet.

For optimum operation and in order to

avoid damage when the lid is opened,

leave a space of at least 5 cm from the

rear wall and 5 cm at the sides.

Before connecting the freezer to the

power supply, ensure that the voltage

corresponds to that indicated in

chapter "Technical data" under

"Voltage".

Danger!

Ensure that the freezer is not resting

on the power supply cable.

Do not remove the power supply cable

by pulling on its lead, particularly when

the freezer is being pulled out of its

niche.

The power supply cable may only be

replaced by a competent service

personnel.

Ensure that the power plug is not

squashed or damaged by the back of

the freezer.

There must be adequate ventilation

around the appliance.

Any electrical work required to install

this appliance should be carried out

by a competent electrician.

Electrical connection

The appliance is supplied with a 13amp

plug fitted. In the event of having to

change the fuse in the plug supplied, a

13amp ASTA approved (BS1362) fuse

must be used. Should the plug need to

be replaced for any reason. The wires in

the power supply cable are coloured in

accordance with the following code:

Green and Yellow - Earth: must be

connected to the terminal marked with

the letter "E" or by the earth symbol or

coloured green and yellow.

Blue - Neutral: must be connected to

the terminal "N" or coloured black.

Brown - Live: must be connected to

the terminal marked "L" or coloured

red.

Upon completion there must be no cut,

or stray strands of wire present and the

cord clamp must be secure over the

outer sheath.

Warning! This appliance must be

earthed.

First use

Before first use, the freezer should be

cleaned inside, see chapter "Care and

cleaning".

Plug in the appliance and allow the

freezer to run for several hours before

placing food inside.

6electrolux EN

Switch on-off

Switch on the freezer

Turn the thermostat knob to a postion

between “”and “”.

Switch off the freezer

Turn the thermostat knob to the

position “OFF”.

Daily use

Temperature adjustment

To adjust the temperature of the freezer,

proceed as follows:

Turn the thermostat knob clockwise

towards “”for a colder storage

temperature.

Turn the thermostat knob counter-

clockwise towards “”for a less cold

storage temperature.

Storage baskets

Hang the baskets on the upper edge

(X) or place the stackable baskets

inside the freezer (Y).

Turn and fix the handles for these two

positions, as shown in the drawings.

Spare baskets can be obtained from your

local Service Force Centre or from the

Electrolux website (depending on

country). The illustrations on this page

show how many baskets can be placed in

the various freezer models.

Care and Cleaning

Defrosting the freezer

When the ice layer is 10-15 mm thick, the

freezer should be defrosted. We suggest

that you defrost your freezer when there

is little or no food inside.

Disconnect the appliance from the

power supply.

Remove the contents of the freezer,

wrap them in newspapers, and keep

them in a cold place.

Leave the appliance lid open.

Speed up defrosting by using the

enclosed scraper to detach the ice

from the appliance walls.

Dry the interior of the appliance

thoroughly.

Important! Never use a knife or any

other sharp implement to remove frost or

ice.

Cleaning

The best time to clean your freezer is

after defrosting.

Disconnect the appliance from the

power supply and remove all loose

accessories.

Use a damp cloth to clean your

freezer. Use hot water and a mild, non-

aromatic detergent.

Clean the loose accessories, before

replacing them again.

electrolux 7

Important! Never use strong detergents,

scouring powder or aromatic detergents

to clean your freezer.

When not in use

Disconnect the appliance from the power

supply.

Remove all food from the freezer.

Clean the freezer as described above.

Leave the lid slightly open.

Helpful hints and tips

Freezing food

Before freezing, fresh food must be

packed in airtight and moisture-proof

packaging to prevent it from drying

out.

Only use fresh food of the best quality.

Always leave hot food to cool to room

termperature before placing in the

freezer.

Divide food into small portions before

freezing; this ensures that freezing is

more rapid, and that you only need to

defrost the amount needed for

immediate consumption.

Mark the freezer packaging with the

date of freezing.

Place fresh food for freezing close to

the cold sides of the freezer, making

sure that it is not in contact with the

frozen food already in the freezer.

Frozen food can be stored anywhere

inside the freezer, but should be kept

at least 5 mm below the upper edge.

If freezing is too slow, the quality of the

food being frozen deteriorates. The

amount of fresh food (expressed in kg)

that can be frozen in 24 hours is

indicated in the chapter "Technical

data" under "Freezing capacity".

Food storage

For fresh frozen food, please refer to

the storage period table underneath.

For purchased frozen food, never

exceed the expiry date.

When you buy frozen food, make sure

that it has been stored at the correct

temperature. Do not buy products

which have wet or damaged

packaging. Place purchased products

in your freezer as quickly as possible.

We recommend using an insulated

bag to bring such products home with

you.

Important! Remember that fully or

partially defrosted food must not be re-

frozen. However, dishes which have

been cooked using defrosted food may

be frozen.

In the case of a power failure or

breakdown

Do not open the lid.

Important! If the power has been off for

longer that the value shown in the

chapter "Technical data" under "Hold-

over time", the defrosted food must be

consumed quickly or cooked

immediately and then refrozen (after

cooling).

What to do if...

Try the solutions suggested here first to

avoid the cost of an unnecessary service

call.

Your freezer will not operate

Is the power supply cord unplugged?

8electrolux EN

Has a household fuse blown?

Is there a power failure?

Is the temperature control set to the

Off position?

The alarm remains audible and/or the

red light/symbol ( ) is on

Is the lid not closed completely? See

underneath for any obstructions.

Is the temperature control set

correctly for the surrounding

conditions?

Is the freezer too close to a source of

heat?

The inside light does not work

Is the power supply cord unplugged?

Is the light bulb loose in the socket or

burned out?

The motor seems to run too much

Is the lid not closed completely? See

underneath for any obstructions.

Is the room temperature hotter than

normal?

Has a large amount of fresh food just

been added to the freezer?

Is the lid opened often?

Is the temperature control set

correctly for the surrounding

conditions?

Is the lid seal damaged or deformed?

Is there enough air circulation space

around the freezer?

Is the Super Freeze function activated

accidentally?

Temperature is too warm

Has a large amount of food just been

added to the freezer?

Is the lid opened often?

Is the temperature control set

correctly for the surrounding

conditions?

Too much ice has formed

Is the lid not closed completely? See

underneath for any obstructions.

Is the water drainage plug correctly

positioned?

The lid will not close completely

Is there excessive frost or a package

preventing the lid from closing?

Are food packages blocking the lid?

Is the lid seal dirty or sticky?

Does the freezer wobble or seem

unstable?

The lid is difficult to open

Is the lid seal dirty or sticky?

If you still need help, please contact your

local Sercive Force Centre.

Service or repair

In cases of breakdown or faults, your

freezer must be serviced by an

authorized Electrolux Service Centre.

Important! Under no circumstances

should you attempt to repair the

appliance yourself.

electrolux 9

Technical Data

Model CFI 105

ECN 1050

Volume (gross) Liter 105

Volume (net) Liter 102

Height Cm 85

Width Cm 55

Depth Cm 59,3

Weight Kg 27

Energy consumption/24h kWh/24h 0,684

Freezing capacity kg/24h 12

Hold-over time Hours 26

Rated power Watt 60

Voltage Volts 230

Climatic class SN

Climatic classification Ambient temperature limits

SN from +10°C to +32°C

N from +16°C to +32°C

ST from +18°C to +38°C

T from +18°C to +43°C

This appliance complies with the following EC Directives:

73/23/EEC of 19. 02. 1973 Low-Voltage Directive

89/336/EEC of 03. 05. 1989 (including Amendment Directive 92/31/EEC - EMC Directive)

10 electrolux

820 418 639 - 03072007

Autres manuels pour ECN 1050

Table des matières

Autres manuels Electrolux Congélateur

Electrolux

Electrolux EC2800AOW Manuel utilisateur

Electrolux

Electrolux EUF 23292 W Manuel utilisateur

Electrolux

Electrolux E32AF75FPS - Icon - Refrigerator Guide de l'utilisateur

Electrolux

Electrolux TF110 Manuel utilisateur

Electrolux

Electrolux SG235NFCN Manuel utilisateur

Electrolux

Electrolux U04454 Guide de démarrage rapide

Electrolux

Electrolux EUF2900 Manuel utilisateur

Electrolux

Electrolux S85528KG1 Manuel utilisateur

Electrolux

Electrolux ecostore Premium ESP142FFCG Manuel utilisateur

Electrolux

Electrolux EC4231AOW Manuel utilisateur

Electrolux

Electrolux ENT6TE18SX Manuel utilisateur

Electrolux

Electrolux EUN12510 Manuel utilisateur

Electrolux

Electrolux TR1177 Mode d’emploi

Electrolux

Electrolux D) Guide de démarrage rapide

Electrolux

Electrolux EUC 2325 X Manuel utilisateur

Electrolux

Electrolux TR906 Mode d’emploi

Electrolux

Electrolux EU 1045T Guide rapide

Electrolux

Electrolux LYB2AF82S Manuel utilisateur

Electrolux

Electrolux ARCTIS 2686-4GT Manuel utilisateur

Electrolux

Electrolux U29251 EUFG2900 Manuel utilisateur

Electrolux

Electrolux EU 1323T Manuel utilisateur

Electrolux

Electrolux ECM2471/BMI 265 F Manuel utilisateur

Electrolux

Electrolux CI 800 FA Manuel utilisateur

Electrolux

Electrolux TF770 Mode d’emploi

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Beko

Beko RFNE350L24W Manuel utilisateur

IKEA

IKEA TYNNERAS Manuel utilisateur

Zanussi

Zanussi ZYAE82FR Manuel utilisateur

Beko

Beko RFSA300S Mode d’emploi
