EN Chest Freezer User Manual 2

LV Horizontālā saldētava Lietošanas instrukcija 15

LT Šaldymo dėžė Naudojimo instrukcija 28

PL Zamrażarka skrzyniowa Instrukcja obsługi 41

CONTENTS

1. SAFETY INFORMATION....................................................................................3

2. SAFETY INSTRUCTIONS..................................................................................4

3. OPERATION.......................................................................................................6

4. BEFORE FIRST USE......................................................................................... 7

5. DAILY USE.........................................................................................................7

6. HINTS AND TIPS............................................................................................... 8

7. CARE AND CLEANING......................................................................................8

8. TROUBLESHOOTING........................................................................................9

9. INSTALLATION................................................................................................ 12

10. NOISES.......................................................................................................... 13

11. TECHNICAL INFORMATION......................................................................... 14

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible if an incorrect installation and use causes

injuries and damages. Always keep the instructions with

the appliance for future reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

•Do not let children play with the appliance.

•Cleaning and user maintenance shall not be made by

children without supervision.

•Keep all packaging away from children.

1.2 General Safety

•This appliance is intended to be used in household

and similar applications such as:

–Farm houses; staff kitchen areas in shops, offices

and other working environments

–By clients in hotels, motels, bed and breakfast and

other residential type environments

•Keep ventilation openings, in the appliance enclosure

or in the built-in structure, clear of obstruction.

•Do not use mechanical devices or other means to

accelerate the defrosting process, other than those

recommended by the manufacturer.

•Do not damage the refrigerant circuit.

•Do not use electrical appliances inside the food

storage compartments of the appliance, unless they

are of the type recommended by the manufacturer.

ENGLISH 3

•Do not use water spray and steam to clean the

appliance.

•Clean the appliance with a moist soft cloth. Only use

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

•Do not store explosive substances such as aerosol

cans with a flammable propellant in this appliance.

•If the supply cord is damaged, it must be replaced by

the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must

install this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Obey the installation instruction

supplied with the appliance.

• Always be careful when you move the

appliance because it is heavy. Always

wear safety gloves.

• Make sure the air can circulate

around the appliance.

• Wait at least 4 hours before

connecting the appliance to the power

supply. This is to allow the oil to flow

back in the compressor.

• Do not install the appliance close to

radiators or cookers, oven or hobs.

• The rear of the appliance must stand

against the wall.

• Do not install the appliance where

there is direct sunlight.

• Do not install this appliance in areas

that are too humid or too colds, such

as the construction appendices,

garages or wine cellars.

• When you move the appliance, lift it

by the front edge to avoid scratching

the floor.

2.2 Electrical connection

WARNING!

Risk of fire and electrical

shock.

• The appliance must be earthed.

• All electrical connections should be

made by a qualified electrician.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the electrical components (e.g. mains

plug, mains cable, compressor).

Contact the Service or an electrician

to change the electrical components.

• The mains cable must stay below the

level of the mains plug.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

www.electrolux.com4

2.3 Use

WARNING!

Risk of injury, burns,

electrical shock or fire.

• Do not change the specification of this

appliance.

• Do not put electrical appliances (e.g.

ice cream makers) in the appliance

unless they are stated applicable by

the manufacturer.

• Be careful not to cause damage to the

refrigerant circuit. It contains

isobutane (R600a), a natural gas with

a high level of environmental

compatibility. This gas is flammable.

• If damage occurs to the refrigerant

circuit, make sure that there are no

flames and sources of ignition in the

room. Ventilate the room.

• Do not let hot items to touch the

plastic parts of the appliance.

• Do not put soft drinks in the freezer

compartment. This will create

pressure on the drink container.

• Do not store flammable gas and liquid

in the appliance.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Do not touch the compressor or the

condenser. They are hot.

• Do not remove or touch items from

the freezer compartment if your hands

are wet or damp.

• Do not freeze again food that has

been thawed.

• Obey the storage instructions on the

packaging of frozen food.

2.4 Internal light

• The type of lamp used for this

appliance is not suitable for

household room illumination

2.5 Care and cleaning

WARNING!

Risk of injury or damage to

the appliance.

• Before maintenance, deactivate the

appliance and disconnect the mains

plug from the mains socket.

• This appliance contains hydrocarbons

in the cooling unit. Only a qualified

person must do the maintenance and

the recharging of the unit.

• Regularly examine the drain of the

appliance and if necessary, clean it. If

the drain is blocked, defrosted water

collects in the bottom of the

appliance.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door to prevent children

and pets to be closed inside of the

appliance.

• The refrigerant circuit and the

insulation materials of this appliance

are ozone-friendly.

• The insulation foam contains

flammable gas. Contact your

municipal authority for information on

how to discard the appliance

correctly.

• Do not cause damage to the part of

the cooling unit that is near the heat

exchanger.

ENGLISH 5

3. OPERATION

3.1 Control panel

21 3

1Temperature regulator

2Power indicator light

3High temperature alarm light

3.2 Switching on

A. Temperature Regulator

B. Half Loaded position

C. Full Loaded position

1. Insert the plug into the wall socket.

2. Turn the Temperature Regulator to

the Full Loaded position and let the

appliance run for 24 hours to allow

the correct temperature to be

reached before placing food inside.

The power indicator light will light up.

3. Adjust the Temperature Regulator

according to the quantity of the

stored foods.

3.3 Switching off

Turn the Temperature regulator to the

OFF position.

3.4 Temperature regulation

The temperature within the appliance is

controlled by the Temperature Regulator

situated on the control panel.

To operate the appliance, proceed as

follows:

• to obtain the minimum coldness, turn

the Temperature Regulator toward

lower settings.

• to obtain the maximum coldness. turn

the Temperature Regulator toward

higher settings.

In case of freezing less food

volumes, the Half Loaded

setting is the most suitable.

In case of freezing much

food volumes, the Full

Loaded setting is the most

suitable.

3.5 High temperature alarm

An increase in the temperature in the

freezer (for example due to an power

failure) is indicated by switching on of the

Alarm light

During the alarm phase, don't place food

inside the freezer.

When normal conditions are restored the

Alarm light will switch off automatically.

www.electrolux.com6

4. BEFORE FIRST USE

WARNING!

Refer to Safety chapters.

4.1 Cleaning the interior

Before using the appliance for the first

time, the interior and all internal

accessories should be washed with

lukewarm water and some neutral soap

to remove the typical smell of a brand-

new product, then dried thoroughly.

CAUTION!

Do not use detergents or

abrasive powders, as these

will damage the finish.

5. DAILY USE

WARNING!

Refer to Safety chapters.

5.1 Freezing fresh food

The freezer compartment is suitable for

freezing fresh food and storing frozen

and deep-frozen food for a long time.

The maximum amount of food that can

be frozen in 24 hours is specified on the

rating plate. 1)

The freezing process lasts 24 hours:

during this period do not add other food

to be frozen.

5.2 Storage of frozen food

When first starting-up or after a period

out of use, before putting the products in

the compartment let the appliance run at

least 24 hours Temperature Regulator to

the Full Loaded position.

CAUTION!

In the event of accidental

defrosting, for example due

to a power failure, if the

power has been off for

longer than the value shown

in the technical

characteristics chart under

"rising time", the defrosted

food must be consumed

quickly or cooked

immediately and then re-

frozen (after cooling).

5.3 Opening and closing the lid

CAUTION!

Never pull the handle with

immense force.

As the lid is equipped with a tightly

closing seal, it is not easy to reopen it

shortly after closing (due to the vacuum

formed inside). Wait for few minutes

before reopening the appliance.

The vacuum valve will help you to open

the lid.

5.4 Storage baskets

Hang the baskets on the upper edge of

the freezer (A) or place them inside the

freezer (B). Turn and fix the handles for

these two positions as shown in the

picture.

A B

The following pictures show how many

baskets can be placed inside the various

freezer models.

The baskets will slide into each other.

1) Refer to "Technical data"

ENGLISH 7

230

806606 946 1061

1201 1336 1611

You can purchase additional baskets

from your local Service Centre.

6. HINTS AND TIPS

WARNING!

Refer to Safety chapters.

6.1 Hints for freezing

To help you make the most of the

freezing process, here are some hints:

• The maximum quantity of food which

can be frozen in 24 hours is shown on

the rating plate.

• The freezing process takes 24 hours.

No further food to be frozen should be

added during this period.

• Freeze only top quality, fresh and

thoroughly cleaned foodstuffs.

• Prepare food in small portions to

enable it to be rapidly and completely

frozen and to make it possible

subsequently to thaw only the quantity

required.

• Wrap up the food in aluminium foil or

polythene and make sure that the

packages are airtight.

• Do not allow fresh, unfrozen food to

touch food which is already frozen,

thus avoiding a rise in temperature of

the latter.

• Lean foods store better and longer

than fatty ones; salt reduces the

storage life of food.

• Water ices, if consumed immediately

after removal from the freezer

compartment, can possibly cause the

skin to be freeze burnt.

• It is advisable to show the freezing in

date on each individual pack to

enable you to keep tab of the storage

time.

6.2 Hints for storage of frozen

food

To obtain the best performance from this

appliance, you should:

• make sure that the commercially

frozen foodstuffs were adequately

stored by the retailer;

• be sure that frozen foodstuffs are

transferred from the store to the

freezer in the shortest possible time;

• not open the lid frequently or leave it

open longer than absolutely

necessary.

• Once defrosted, food deteriorates

rapidly and cannot be refrozen.

• Do not exceed the storage period

indicated by the food manufacturer.

7. CARE AND CLEANING

WARNING!

Refer to Safety chapters.

7.1 Periodic cleaning

CAUTION!

Unplug the appliance before

carrying out any

maintenance operation.

www.electrolux.com8

Do not use detergents,

abrasive products, highly

perfumed cleaning products

or wax polishes to clean the

inner side of the appliance.

Prevent damage to the

cooling system.

There is no need to clean

the compressor area.

1. Switch off the appliance.

2. Regularly clean the appliance and

the accessories with warm water and

neutral soap.

Clean the lid seal carefully.

3. Fully dry the appliance.

4. Connect the mains plug to the mains

socket.

5. Switch on the appliance.

7.2 Defrosting the freezer

CAUTION!

Never use sharp metal tools

to scrape off frost as you

could damage the appliance.

Do not use a mechanical

device or any artificial

means to speed up the

thawing process other than

those recommended by the

manufacturer. A temperature

rise of the frozen food packs,

during defrosting, may

shorten their safe storage

life.

Defrost the freezer when the frost layer

reaches a thickness of about 10-15 mm.

The amount of frost on the walls of the

appliance will be increased by the high

level of the outer environment humidity

and if the frozen food is not wrapped

properly.

The best time to defrost the freezer when

it contains no or only a little food.

1. Switch off the appliance.

2. Remove any stored food, wrap it in

several layers of newspaper and put

it in a cool place.

3. Leave the lid open , remove the plug

from the defrost water drain and

collect all defrost water on a tray.

Use a scraper to remove ice quickly.

4. When defrosting is completed, dry

the interior thoroughly and refit the

plug.

5. Switch on the appliance.

6. Set the temperature regulator to

obtain the maximum coldness and

run the appliance for two or three

hours using this setting.

7. Reload the previously removed food

into the compartment.

7.3 Periods of non-operation

When the appliance is not in use for long

periods, take the following precautions:

1. Switch off the appliance and

disconnect the appliance from

electricity supply.

2. Remove all food

3. Defrost and clean the appliance and

all accessories.

4. Leave the lid open to prevent

unpleasant smells.

If the cabinet will be kept on,

ask somebody to check it

once in a while to prevent

the food inside from spoiling

in case of a power failure.

8. TROUBLESHOOTING

WARNING!

Refer to Safety chapters.

ENGLISH 9

8.1 What to do if...

Problem Possible cause Solution

The appliance does not

operate. The appliance is switched

off. Switch on the appliance.

The mains plug is not con‐

nected to the mains socket

correctly.

Connect the mains plug to

the mains socket correctly.

There is no voltage in the

mains socket. Connect to a different elec‐

trical mains socket. Con‐

tact a qualified electrician.

The appliance is noisy. The appliance is not sup‐

ported properly. Check if the appliance

stands stable.

Audible or visual alarm is

on. The cabinet has been re‐

cently switched on or the

temperature in the appli‐

ance is too high.

Refer to "High Tempera‐

ture Alarm" and if the prob‐

lem still occurs contact the

nearest Authorized Service

Centre.

Power indicator light is

flashing. An error has occurred in

measuring the temperature

or the appliance is not

working properly.

Contact the nearest Au‐

thorized Service Centre.

The lid doesn't close com‐

pletely. Food packages are block‐

ing the lid. Arrange the packages in

the right way, see the stick‐

er in the appliance.

There is excessive frost. Eliminate excess frost.

The lid is difficult to open. The lid gaskets are dirty or

sticky. Clean the lid gaskets.

The valve is blocked. Check the valve.

The lamp does not work. The lamp is defective. Refer to "Replacing the

lamp".

The compressor operates

continually. Temperature is set incor‐

rectly. Refer to "Operation" chap‐

ter.

Large quantities of food to

be frozen were put in at

the same time.

Wait some hours and then

check the temperature

again.

The room temperature is

too high. Refer to climate class chart

on the rating plate.

Food placed in the appli‐

ance was too warm. Allow food to cool to room

temperature before storing.

The lid is not closed prop‐

erly. Check if the lid closes well

and the gaskets are un‐

damaged and clean.

www.electrolux.com10

Autres manuels pour EC4200AOW1

Table des matières

Autres manuels Electrolux Congélateur

Electrolux

Electrolux ECM 1957 Manuel utilisateur

Electrolux

Electrolux EUC14291W Manuel utilisateur

Electrolux

Electrolux EU 2117C Manuel utilisateur

Electrolux

Electrolux EC5231AOW Manuel utilisateur

Electrolux

Electrolux EUC19001W Manuel utilisateur

Electrolux

Electrolux Air-O-Chill 726964 (AOFP202RCU) Manuel utilisateur

Electrolux

Electrolux FCW 200 Manuel utilisateur

Electrolux

Electrolux 253.60722012 Manuel

Electrolux

Electrolux A Mode d’emploi

Electrolux

Electrolux EUC25300W Manuel utilisateur

Electrolux

Electrolux Air-O-Chill 726998 (AOFP202RCU4) Manuel utilisateur

Electrolux

Electrolux A63230GT Manuel utilisateur

Electrolux

Electrolux U30394 EUC 25291 S Manuel utilisateur

Electrolux

Electrolux ENG2793AOW Manuel utilisateur

Electrolux

Electrolux LRC5ME38W3 Manuel utilisateur

Electrolux

Electrolux EUC 05002 W Manuel utilisateur

Electrolux

Electrolux EU 3216C Manuel utilisateur

Electrolux

Electrolux EUF20230W Manuel utilisateur

Electrolux

Electrolux KUT5NF25W Manuel utilisateur

Electrolux

Electrolux LUC4NE23W Manuel utilisateur

Electrolux

Electrolux Freezer Manuel utilisateur

Electrolux

Electrolux EU7119C Manuel utilisateur

Electrolux

Electrolux IK2755BL Manuel utilisateur

Electrolux

Electrolux EUN12510 Manuel utilisateur

Manuels Congélateur populaires d'autres marques

Siemens

Siemens GU..D SERIES Manuel utilisateur

Omcan

Omcan FR-CN-0155 Manuel utilisateur

Beko

Beko FNE290E24W Manuel utilisateur

Dometic

Dometic CoolFreeze CFX95DZ Manuel utilisateur

Polar Electro

Polar Electro CT330 Manuel utilisateur

MPM

MPM MPM-145-SK Series Manuel utilisateur

SAF

SAF PRESTOTIG 200AC/DC Guide rapide

Zanussi

Zanussi ZFT11407WA Manuel utilisateur

AEG

AEG A63190GT Manuel utilisateur

AEG

AEG A81000TNW0 Manuel utilisateur

Matsui

Matsui MUC50S15E Manuel utilisateur

NEFF

NEFF G4344X8 Manuel utilisateur

Frigidaire

Frigidaire FV 1246 H Manuel utilisateur

Frigidaire

Frigidaire FFC13K1AW Manuel utilisateur

Beko

Beko RFNE350L24W Manuel utilisateur

IKEA

IKEA TYNNERAS Manuel utilisateur

Zanussi

Zanussi ZYAE82FR Manuel utilisateur

Beko

Beko RFSA300S Mode d’emploi
