Dear Electrolux customer!

Welcome to the family of Electrolux customers.

We hope that you will have many years of use from your new

machine.

The machine has many features. To make the most of its

functions, we recommend that you read the operating

instructions before using the machine. The operating

instructions include information on how you can help protect

the environment.

Operating Instructions

Tumble dryer

Electrolux TW SL3 M100

Before using your machine for

the first time

Language selection

4Safety instructions

Safety

Transport/Winter storage

Packing material

Recycling

6Child safety

General

Child safety catch

Activating/deactivating Child-safe

start

7Description of the tumble dryer

Advice and tips before you

tumble-dry

Materials that can be tumble-dried

Materials that must not be

tumble-dried

Static electricity

9Tumble drying

Sort your fabrics

Select the programme

Press the Start button

Drying programme finished

14Settings

You can carry out the following

settings

How to choose the settings:

Audible Volume

Language

Child-safe

15Care and cleaning

Cleaning the lint filter

Emptying the condensed water

container

Cleaning the steamer filter

Cleaning the outside of the

machine

18Troubleshooting

The machine will not start

Overheating cut-out

Drying takes too long

Error messages

19Technical information

Technical data

Standard tests

20Service

Before contacting the service

division

21Installation

Positioning the tumble dryer

Adjusting the feet

Condensed water

Electrical installation

24Door hanging

Follow these instructions:

28Quick guide

Contents

Language selection

You will be prompted to select the display

language when you have connected your machine

and start it for the first time. Do as follows:

Turn the programme selector to choose from: US

English, English, Svenska, Dansk, Norsk, Suomi,

Français, Deutsch, Italiano, Espanol, Русский,

Nederlands.

Press Stop to save the setting.

Laundry labels

Certain materials are not suitable for

tumble-drying. Always check and follow the

instructions on each item’s laundry label. You can

find more information in the "Advice and tips

before you tumble-dry" chapter.

NOTE!

When starting the tumble dryer for the first time

or after a long period without use, you may notice

a slight thumping noise. This noise is completely

normal and will disappear after a few loads.

Before using your machine for the first time

Read the operating instructions and

keep them in a safe place!

• Electrical installation, if required, should be

carried out by a qualified electrician.

• The machine should only be used for

tumble-drying as described in these

instructions.

• Repairs and maintenance relating to safety or

performance must be carried out by a qualified

professional.

•Damaged mains cables must only be replaced

by a qualified electrician.

• Sufficient ventilation is required to prevent

smoke from open fires or fumes from

equipment burning other fuels being sucked

into the room when the tumble dryer is running.

• Do not dry dirty laundry in the tumble dryer.

• Items that are stained with e.g. cooking oil,

acetone, alcohol, petrol, kerosene, stain

remover, turpentine, wax and wax remover

should be washed in hot water with extra

detergent before they go in the tumbler dryer.

• Items such as foam rubber, latex, plastic,

waterproof textiles, rubber-coated items and

clothes and foam-rubber filled cushions must

not be dried in the tumbler dryer.

• Fabric softener or similar products should be

used as per the recommendations of the

detergent manufacturer.

• The machine is not designed to be used by

persons (even children) that are physically or

mentally handicapped or lack experience and

knowledge. Such persons must receive

instruction in how to use the machine from the

person responsible for their safety.

• Children must be watched to ensure they do

not play with the machine.

• Do not let lint accumulate near the dryer

• Do not install the dryer behind doors with lock,

sliding doors or next to the doors with hinges

so that opening of the dryer door will never be

hindered.

Safety

•The machine must not be used for drying items

that have been dry-cleaned at home or fabrics

that may contain residues of flammable liquids.

• The tumble dryer is protected by an

overheating cut-out. This shuts off the machine

if the temperature gets too high.

• A float shuts off the machine in the event of a

blockage in the condensed water hose or if

there is a risk of the condensed water container

overflowing.

WARNING!

When the tumble dryer is operating, the back of

the tumble dryer will get very hot. Leave the

machine to cool completely before touching the

back.

Installation

See the "Installation" chapter.

WARNING!

Do not start the machine until it has been in

position for 24 hours. If for some reason the

tumble dryer needs to be laid down for transport

or service, it must be laid on its left side viewed

from the front.

Transport/Winter storage

If you need to move your machine or store it over

the winter in unheated premises, make sure that

you drain the condensed water container

beforehand.

Packing material

Please sort waste materials in accordance with

local guidelines.

Safety instructions

Recycling

This machine is manufactured and labelled for

recycling. In order to prevent personal injury, the

machine must be made inoperable after deciding

to take it out of service. Contact your local

authority for information about where and how

your machine should be correctly recycled.

Safety instructions

General

WARNING!

Do not allow children to play with the

tumble dryer.

• If the door is opened when a programme is

running the garments may be very hot, with a

risk of burn injuries.

• The tumble dryer does not start automatically

when the door is closed (if a child pulls the

door shut from the inside, for example).

Child safety catch

By activating the child-safe start function you can

prevent children from starting the tumble dryer or

changing the current programme.

Activating/deactivating Child-safe

start

Do as follows to open the settings menu:

1. Turn off the machine using the main power

switch.

2. Press the Stop button and switch on the

machine with the main power switch. Then

press the Stop button 5 times within 10

seconds.

3. Select the setting you want to change by

turning the programme selector.

4. Press the Stop button once.

5. Change and save the setting as described

below.

6. Press the Start button to return to the

programme menu.

You can activate the Child-safe start option to

prevent children from starting the machine.

1. Turn the programme selector and choose

"Child-safe On" or "Child-safe Off".

2. Press the Stop button once to save the setting.

You can temporarily deactivate Child-safe start

by pressing the Start and Stop buttons at the

same time. Child-safe start will be deactivated for

3 minutes.

Child safety

1 3 4 5 62

Lint filter5.Main power switch1.

Outer door6.Condensed water container2.

Steamer and filter7.Panel3.

Type plate4.

Description of the tumble dryer

Here are some tips that may help you before you

begin tumble-drying.

Have the clothes been spun?

Items to be tumble-dried should be spun at 1000

rpm or faster. Higher spin speeds save energy

and reduce drying time.

Materials that can be tumble-dried

This symbol means that the material is suitable

for tumble-drying. Fabrics best suited to

tumble-drying are cotton fabrics, terry cloth and

synthetic fibres. Garments will be softer and lighter

when tumbled than when hung out to dry.

NOTE!

The tumble dryer does not cause any significant

wear on fabrics. The lint that collects in the lint

filter consists of dust and fibre residues formed

when the items are used.

Materials that must not be

tumble-dried

This symbol means that the material is not

suitable for tumble-drying. Certain materials may

melt or become a fire hazard if exposed to heat,

and others can lose their shape or shrink.

And do not tumble-dry

• materials labelled "Do not dry near heat".

•garments that have been dry-cleaned at home.

• plastic foam.

• fibreglass material.

• wool must not be tumble-dried because of the

risk of felting.

Static electricity

To reduce the risk of static electricity in the laundry

after tumble drying you can:

• Use fabric softener when washing.

•Wait five minutes after the drying program ends

before opening the door and removing the

laundry from the dryer.

NOTE!

You can stop the tumble dryer by pressing the

Stop button for three seconds or by opening the

door. In both cases the programme is stopped

and starts from the beginning if restarted.

If you do not want to restart the programme then

immediately remove all laundry and spread it out

to allow the heat to dissipate.

Advice and tips before you tumble-dry

Below are step-by-step instructions to help you

achieve the best possible tumble-drying results.

1Sort your fabrics

You will achieve the most uniform drying

results if the items are made of the same

type of material. Do up zips and buttons, fasten

belts, sort the items and adjust the load and

temperature.

2Press the main power switch

until the display lights.

3Open the door, load the items

and then close the door

Tumble drying

4Select the programme

Main power switch

Programme selector Display window

Start Stop

Guidelines as to what specific

programmes can be used for:

The Auto extra dry, Auto dry and Auto normal dry

programmes have two temperature settings.

Normal temperature but also low temperature for

more delicate items.

Auto extra dry

Temperature normal. This programme is for items

that are particularly difficult to dry, such as jeans

with very thick seams.

Auto dry

Temperature normal. These programmes shut off

the heat once the load is dry but before it is "bone

dry". The Auto dry programme shuts off the heat

slightly later than Auto normal dry. Use trial and

error to find out what works best. Use these

programmes when you want items to be

completely dry.

Auto normal dry

Temperature normal. These programmes shut off

the heat once the load is dry but before it is "bone

dry". The Auto dry programme shuts off the heat

slightly later than Auto normal dry. Use trial and

error to find out what works best. Use these

programmes when you want items to be

completely dry.

Auto extra dry (low temperature)

Energy Save. This programme is for items that

are particularly difficult to dry, such as jeans with

very thick seams.

Auto dry (low temperature)

Energy Save. These programmes shut off the

heat once the load is dry but before it is "bone

dry". The Auto dry programme shuts off the heat

slightly later than Auto normal dry. Use trial and

error to find out what works best. Use these

programmes when you want items to be

completely dry.

Auto normal dry (low temperature)

Energy Save. These programmes shut off the

heat once the load is dry but before it is "bone

dry". The Auto dry programme shuts off the heat

slightly later than Auto normal dry. Use trial and

error to find out what works best. Use these

programmes when you want items to be

completely dry.

Auto Iron dry

This programme shuts off the heat once the load

is just damp enough for ironing or pressing.

Tumble drying

Table des matières

Autres manuels Electrolux Séchoir

Electrolux

Electrolux EDH3896GDW Manuel utilisateur

Electrolux

Electrolux ZANUSSI ZDC 5370W Manuel utilisateur

Electrolux

Electrolux 134066300 Manuel utilisateur

Electrolux

Electrolux Dito 601837 Manuel utilisateur

Electrolux

Electrolux EWMED70J IW Manuel utilisateur

Electrolux

Electrolux EIMED60J IW Manuel utilisateur

Electrolux

Electrolux EDP2074GDW Manuel utilisateur

Electrolux

Electrolux EDV5051 Manuel utilisateur

Electrolux

Electrolux EDV805JQSA Manuel utilisateur

Electrolux

Electrolux EIGD55H - Gas Dryer With 8.0 cu. Ft.... Manuel utilisateur

Electrolux

Electrolux EWED65HSS - 27" Electric Dryer Manuel utilisateur

Electrolux

Electrolux TK SL5 E Manuel utilisateur

Electrolux

Electrolux TW SL5 E Manuel utilisateur

Electrolux

Electrolux T5290 Manuel utilisateur

Electrolux

Electrolux EDC2075GDW Manuel utilisateur

Electrolux

Electrolux 864500 Manuel utilisateur

Electrolux

Electrolux EDH3684PDW Manuel utilisateur

Electrolux

Electrolux EDE 5335 Manuel utilisateur

Electrolux

Electrolux 300 Series Manuel utilisateur

Electrolux

Electrolux TWLEEV300 Manuel utilisateur

Electrolux

Electrolux EW2C327R1 Manuel utilisateur

Electrolux

Electrolux EIMED55HIW Manuel utilisateur

Electrolux

Electrolux EDE 425 M Guide rapide

Electrolux

Electrolux EW6C527G2 Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire

Bosch

Bosch WTX8HKM9SN Manuel utilisateur
