Electrolux T4130 Manuel utilisateur

Service manual

Torktumlare

T4130, T4130C

Quickdry, Quickdry C

Typ N1130

487 03 30 71/EN

2011.07.21

Service manual in original language

Service

manual

Contents

SafetyPrecautions.........................................5

Technicaldata.............................................7

Description of principal components. . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Disassemblingthedryer....................................17

Periodicmaintenance......................................21

Optimizingtheairflow......................................25

Error codes (see Compass Control Service Manual)

Controls.................................................29

Sensors and overheating thermostats . . . . . . . . . . . . . . . . . . . . . . . . . 35

Doorswitch..............................................41

Motorandtransmission.....................................43

Heating(electric)..........................................47

Drumwithbearing.........................................51

Cabinet,doorreversal......................................55

RMC ...................................................57

Safety Precautions

Service

manual

Safety Precautions

Service

manual

Service

manual

Service

manual

Safety Precautions

Do not dry unwashed items in the machine

The machine is not to be used if industrial chemicals have been used for cleaning.

Do not allow minors to use the machine.

Do not hose down the machine with water.

The machine's door lock must under no circumstances be bypassed.

Items that have been soiled with substances such as cooking oil, acetone, alcohol,

petrol, kerosene, spot removers, turpentine, waxes and wax removers should be

washed in hot water with an extra amount of detergent before being dried in the

machine.

Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber

backed articles and clothes or pillows tted with foam rubber pads should not be

dried in the machine.

Fabric softeners or similar products should be used as specied by the fabric

softener instructions.

The machine may not be used to dry oor mops that contain polypropylene.

The nal part of a drying cycle occurs without heat (cool down cycle) to ensure that

the items are left at a temperature that ensures that the items will not be damaged.

WARNING. Never stop the machine before the end of the drying cycle unless all items

are quickly removed and spread out so that the heat is dissipiated.

Remove garments from the machine as soon as they are dried. This prevents them

from becoming creased and reduces the risk of spontaneous ignition.

If the machine develops a fault, this must be reported to the person in charge as soon

as possible. This is important both for your safety and that of others.

The machine must not be located where a door, sliding door, etc., can block the

machine's door

The machine is not intended to be used by people (including minors) with reduced

physical or mental capacity or lack of experience and knowledge. Such people must

be instructed in the use of the machine by a person who has responsibility for their

safety. Minors must be supervised to ensure that they do not play with the machine.

Adequate ventilation has to be provided to avoid the back ow of gases into the room

for appliances burning other fuels, including open res.

Gas heated tumble dryer:

The machine is not to be installed in rooms containing cleaning machines with

perchloroethylene, TRICHLOROETHYLENE or CHLOROFLUOROCONTAINING

HYDROCARBONS as cleaning agents.

If you can smell gas,

• Do not switch on any equipment

• Do not use electrical switches

• Do not use telephones in the building

• Evacuate the room, building or area

• Contact the person responsible for the machine

In order to prevent damage to the electronics (and other parts) that may occur as the

result of condensation, the machine should be placed in room temperature for 24 hours

before being used for the rst time.

2. Technical data

Service

manual

Contents

Technicaldata,typeT4130................................... 8

Technical data, motor specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Technical data

Service

manual

Technical data Service

manual

Technical data - type T4130/T4130C

Heating T4130 T4130C

Drum volume: 130 litres 130 litres

Weight net: 54 kg 57 kg

Drum: Diameter 575 mm 575 mm

Depth 500 mm 500 mm

Revolutions per minute 53 rpm 53 rpm

Capacity: Factor 1:25 5.2 kg 5.2 kg

Factor 1:33 3.9 kg 3.9 kg

Heat effect: Electric heating: 5.1/3.2 kW 3.0 kW

Air consumption: Heat effect 5.1 kW 210 m3/h -

Heat effect 3.1 kW 170 m3/h

Piping: Evacuation Ø 100 -

Pressure drop:

Evacuation max.

5.1 kW 80 Pa

3.1 kW 140 Pa

Sound power level: Lw<70 dB (A) <70 dB (A)

Technical data

Service

manual

Technical data - motor specifications

T4130 T4130C

Dryer with reversal:

Motor 3-phase:

Effect 130 W 130 W

Revolutions per minute: 50 Hz 2730 rpm 2730 rpm

60 Hz 3330 rpm 3330 rpm

Motor 1-phase:

Effect 130 W 130 W

Revolutions per minute: 50 Hz 2730 rpm 2730 rpm

60 Hz 3330 rpm 3330 rpm
