Electrolux 6000 Manuel utilisateur

5995456869 April 2006

SERVICE MANUAL

5.75 Cu. Ft. Dryer

Gas & Electric

6000 and 7000

Models

ELECTROLUX MAJOR APPLIANCES OF NORTH AMERICA

White-Westinghouse

ATTENTION!!!

This service manual is intended for use by persons having electrical and mechanical

training and a level of knowledge of these subjects generally considered acceptable in the

appliance repair trade. Electrolux Home Products cannot be responsible, nor assume any

liability, for injury or damage of any kind arising from the use of this manual.

SAFE SERVICING PRACTICES - ALL APPLIANCES

To avoid personal injury and/or property damage, it is important that Safe Servicing

Practices be observed. The following are some limited examples of safe practices:

1. DO NOT attempt a product repair if you have any doubts as to your ability to

complete it in a safe and satisfactory manner.

2. Before servicing or moving an appliance:

• Remove the power cord from the electrical outlet, trip the circuit breakerto the

OFF position, or remove the fuse.

• Turn off the gas supply.

• Turn off the water supply.

3. Never interfere with the proper operation of any safety device.

4. USE ONLY REPLACEMENT PARTS CATALOGED FOR THIS APPLIANCE.

SUBSTITUTIONS MAY DEFEAT COMPLIANCE WITH SAFETY

STANDARDS SET FOR HOME APPLIANCES.

5. GROUNDING: The standard color coding for safety ground wires is GREEN, or

GREEN with YELLOW STRIPES. Ground leads are not to be used as current

carrying conductors. It is EXTREMELY important that the service technician

reestablish all safety grounds prior to completion of service. Failure to do so will

create a hazard.

6. Prior to returning the product to service, ensure that:

• All electrical connections are correct and secure

• All electrical leads are properlydressed and secured awayfrom sharp edges,

high-temperature components, and moving parts

• Allnon-insulated electrical terminals, connectors, heaters, etc. are adequately

spaced away from all metal parts and panels

• All safety grounds (both internal and external) are correctly and securely

connected

• All panels are properly and securely reassembled

SAFE SERVICING PRACTICES 2

QUICK REFERENCE SHEET 7

Serial nameplate location 7

Serial number breakdown 7

Tech sheet location 7

Function test sequence 8

Specification 9

Component resistance chart 10

Sample wiring diagram for electric models 11

Sample wiring diagram for gas models 12

SECTION A - OPERATING INSTRUCTIONS 13

Before operating your dryer 13

Operating Steps 13

Cycle Selection 13

Auto Dry 13

Towels 14

Heavy Duty 14

Normal 14

Perm Press 14

Delicates 14

Touch Up 14

Timed Dry 14

Cycle Settings 14

Drying Temperature 14

Dryness Level 14

Options 15

Dryer Features 15

Control Lock 15

Start/Pause 15

Cancel 15

Status Lights 15

Errer Code Chart 16

Dryer Setting Chart 17

SECTION B - OWNERS GUIDE 18

Product Registration 18

Safety Information 18

What To Do If You Smell Gas 18

Your Safety And The Safety Of Other Is Very Important 18

Pedestal 19

Important Safety Instructions 19

Prevent Fire 19

Protect Children 19

Prevent Injury 19

Drying Procedures 21

Features 22

End Of Cycle Signal 22

Drum Light 22

Reversible Dryer Door 22

Drying Rack 22

Common Drying Problems 23

Care And cleaning 24

Inside 24

Outside 24

Avoid Service Checklist 25

Sample Warranty 27

SECTION C - INSTALLATION INSTRUCTIONS GAS & ELECTRIC DRYER 28

What To Do If You Smell Gas 28

Pre-installation Requirements 29

Tools And Materials Required For Installation 29

Electrical Requirements 29

Electric Dryers 29

Gas Dryers 29

Exhaust System Requirements 29

Exhaust Directions 31

Exhaust Duct Locating Dimensions 31

Location Of Your Dryer 31

Do Not Install Your Dryer 31

Installation In A Recess Or Closet 31

Minimum Installation Clearances 32

This Dryer Must Be Exhausted Outdoors 32

Dryer Installation Dimensions 33

Mobile Home Installation 34

Unpacking 34

Reversing Door Swing 34

Electrical Installation 36

Electric Dryers 36

Grounding Requirements Non Canadian Electric Dryers 36

For A Grounded, Cord-connected Dryer 36

For A Permanently Connected Dryer 36

Canadian Electric Dryer 36

All Gas Dryer 37

Electrical Connections For 3-wire System Non Canadian Electric Dryers 37

Electrical Connections For 4-wire System Non Canadian Electric Dryers 37

Gas Connection 38

General Installation 38

Replacement Parts 39

SECTION D - Pedestal Installation Instructions 40

Washer Installation 40

Dryer Installation 42

Warranty 44

SECTION E - HOW THE COMPONENTS WORK 45

The Basic Components 45

Drum 45

Heat Source 45

Electric 45

Gas 45

Drive Motor And Blower 45

Control Thermistor 46

Electronic Control Board 46

Airflow 46

Airflow Electric Dryers 46

Airflow Gas Dryers 47

Airflow Problems 47

Restrictions 48

Air Leaks 48

Short Unrestricted Vents 48

Electrical Operation (Electric Dryers Models) 48

Electronic Control Board Circuits 48

Drive Motor Circuit 49

Temperature Sensing Circuit 49

The Heating Circuit 49

Drying Time 50

Electrical Operation (Gas Dryers Models) 50

Electronic Control Board Circuits 50

Drive Motor Circuit 51

Temperature Sensing Circuit 51

The Heating Circuit 51

Drying Time 52

SECTION F - TROUBLESHOOTING 53

Reading Error Codes 53

Failure Code Chart 53

Troubleshooting Flow Charts Index 55

Electric Dryer Completely Inoperative 56

Gas Dryer Completely Inoperative 57

Electric And Gas Dryers; Blower Motor Runs But Drum Does Not Turn 58

Electric And Gas Dryers; Longer Than Normal Drying Times 56

Electric Dryer Not Heating Properly 59

Gas Dryer Not Heating Properly 60

Electric and Gas Dryers; Dryer Over Heating 60

Electric Dryers; Blower Motor Runs But Dryer Does Not Heat 61

Gas Dryers; Blower Motor Runs But Dryer Does Not Heat 62

Electric And Gas Dryers; Clothes Not Dry In Auto Cycle 63

Electric And Gas Dryers; Selector LEDs Do Not Light. 64

SECTION G - TEARDOWN 65

Removing The Top Panel 65

Removing The Console 65

Removing The Control Board 66

Removing The Control Board’s Rear Cover 66

Removing The Interface Board 66

Removing The Selector Knob 66

Removing The Button Spring 67

Removing The Buttons 67

Removing The Loading Door 67

Disassembling The Loading Door 68

Removing The Catch Plate 69

Removing The Catch 69

Removing The Door Switch 70

Removing The Front Panel 70

Replacing The Sensor Bars 71

Replacing The Front Panel Air Duct 71

Replacing The Drum Light Bulb 72

Replacing The Drum Light Housing 72

Replacing The Drum Light Socket 72

Replacing The Felt Seal 72

Replacing The Foam Seal 72

Removing The Rear Access Panel 73

Releasing The Dryer Belt 73

Removing The Vane From The Drum 73

Removing The Drum 73

Removing The Belt 74

Removing The Hitch Ball From The Drum 74

Removing The Teflon Glides 74

Removing The Drum Heat Shield (Electric Dryers) 74

Removing The Hitch 75

Removing The High Limit Thermostat 75

Removing The Thermal Limiter (Electric Dryers) 75

Removing The Heating Element Assembly (Electric Dryers) 75

Removing The Control Thermistor 76

Removing The Blower Housing And Fan Blade 76

Removing The Idler Pulley 77

Removing The Idler Pulley Assembly 77

Removing The Drive Motor 77

Removing The Burner (Gas Dryers) 78

Removing The Ignitor (Gas Dryers) 78

Removing The Gas Valve Assembly (Gas Dryers) 78

Removing The Gas Valve Coils (Gas Dryers) 79

Removing The Sensor (Gas Dryers) 79

Removing The Combustion Chamber (Gas Dryers) 79

Removing The Duct And Heat Shield (Gas Dryers) 80

Removing The Manifold Pipe (Gas Dryers) 80

Removing The Vent Pipe (Gas Dryers) 81

Removing The Gasket Between The Vent Pipe And Blower Housing 81

QUICK REFERENCE SHEET

1. Serial nameplate location: on the front

panel at the left side of the dryer door

opening.

2. Serial number breakdown.

3. Tech sheet location:

On the right-hand bodyside behind the

front panel and inside rear access panel.

XD60402247

Incremented unit number

Production week

Last digit of production year

Product identification

Manufacturing Facility

FUNCTION TEST SEQUENCE

1. Press and hold Select and Cancel buttons simultaneously for 6 seconds to reset the control. The buzzer will

sound 1 time and “rES” will be shown briefly in the display.

2. Immediately after, rotate cycle selector knob 5 turns counterclockwise to the second position from the bottom.

Press and hold the Options and Cancel buttons simultaneously for 2 seconds. The control will enter test

mode, the buzzer will sound 3 times and all LED’s will rapidly flash.

After entering the test mode, the cycle selector knob can now be rotated to select the following tests:

Rotate the cycle selector knob clockwise from the starting position:

0 turns: All LED’s will flash.

1 turn: Drive motor runs; heat source is on. Drying LED is lit. “H” and the control thermistor reading will

toggle back and forth in the display.

2 turns: Drive motor runs; heat source is off. Cool Down LED is lit and “AF” (Air Fluff) is displayed.

3 turns: Drive motor runs; heat source is off. Drying and Cool Down LED’s are lit and numbers appear in

the display showing moisture sensor readings. Opening the door (press in on door switch plunger)

and placing a finger on the both moisture sense bars at the same time will make the numbers

decrease. In controls that do not have a digit display, the More Dry LED should be ON. Opening

the door (press in on door switch plunger) and placing a finger on the both moisture sense bars at

the same time will make the Damp LED come on.

4 turns: Drive motor runs; heat source is off.

Key test:

a. When the Temperature key is pressed, all the temperature LED’s should light.

b. When the Dryness key is pressed, all the dryness level LED’s should light.

c. When the Options or Select key is pressed, all the Option LED’s should light.

d. When the Start/Pause key is pressed, all the cycle status LED’s should light.

e. When the Cancel key is pressed, all the cycle status LED’s should light.

5 turns: Drive motor runs; heat source is off. Cool Down LED is lit. Control thermistor reading is

displayed.

6 turns: Drive motor runs; heat source is on. Drying LED is lit. Control thermistor reading is displayed.

7-11 turns: All LED’s will flash.

To EXIT test mode, press and hold the Select and Cancel buttons simultaneously for 6 seconds or disconnect

power from dryer. Dryer will be reset for regular operation.

QUICK REFERENCE SHEET

SPECIFICATION

Electrical

Volts 120/208 or 120/240

Amps (circuit)

Motor wattage

Heat input (Watts @ 240 VAC)

Heat input (BTU/Hr.)

Auto. Elec. Ignition

Drum

Size (Cu. Ft.)

Finish

R.P.M.

Airflow CFM

DRUM TEMPERATURES (Max.

opening on 1st cycle)

Maximum

High

Medium

Low

Dimension (Inches)

Height

Width

Depth

Vent Capability**

Top Finish

Port Opening (Sq. In.)

ELECTRIC MODELS

120/208 or 120/240

160-350 Watts

3200/4500

---

5.75

Powder Paint Epoxy

48 - 54

200

138° - 190°

134° - 180°

130° - 170°

120° - 165°

36”

27”

28.5”

4-Way

Powder Paint Enamel

235

GAS MODELS

120

160-350 Watts

---

20,000

Yes

5.75

Powder Paint Epoxy

48 - 54

200

145° - 190°

140° - 180°

130° - 170°

120° - 165°

36”

27”

28.5”

3-Way

Powder Paint Enamel

235

** Electric dryers can be vented four ways: through back, bottom, right or left side.

** Gas dryers can be vented three ways: through back, bottom, or right side.

QUICK REFERENCE SHEET

Component Resistances*

Drive motor (120 volt, 60 Hz, 1/4 h.p. 1725 rpm)

Motor Start Winding

Motor Run Winding

Heating Element

Control Thermistor

Burner Assembly

Ignitor

Secondary Coil

Booster Coil

Electric Models

4.5 Ohms

3.8 Ohms

12.8 Ohms

50K Ohms +/- 5% @ 77° F

---

Gas Models

4.5 Ohms

3.8 Ohms

50K Ohms +/- 5% @ 77° F

50 - 400 Ohms

1200 Ohms

1320 Ohms

* +/- 10% @ 77° F

Autres manuels pour 6000

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Electrolux Séchoir

Electrolux

Electrolux TW SL EEV Manuel utilisateur

Electrolux

Electrolux EDC 5371 Manuel d'utilisation

Electrolux

Electrolux EDH 97981W Manuel utilisateur

Electrolux

Electrolux TW SL4 E Manuel utilisateur

Electrolux

Electrolux TD6-14LAC Manuel utilisateur

Electrolux

Electrolux EDC 5320 Manuel utilisateur

Electrolux

Electrolux EWED65HSS - 27" Electric Dryer Manuel utilisateur

Electrolux

Electrolux EDH3684PDW Manuel utilisateur

Electrolux

Electrolux SWISSLINE TW SL5M 100 Manuel utilisateur

Electrolux

Electrolux EDE1074PDW Manuel utilisateur

Electrolux

Electrolux EIED55H IW Feuille d'instructions

Electrolux

Electrolux EIED55H IW Manuel utilisateur

Electrolux

Electrolux EDE1072PDW Manuel utilisateur

Electrolux

Electrolux EIMGD60LT3 Manuel utilisateur

Electrolux

Electrolux TK L2 E Manuel utilisateur

Electrolux

Electrolux TE1220E Manuel utilisateur

Electrolux

Electrolux EW8H259ST Manuel utilisateur

Electrolux

Electrolux TW SL3 M100 Manuel utilisateur

Electrolux

Electrolux EIMED60J IW Manuel utilisateur

Electrolux

Electrolux EIED55HIW - 8.0 cu. Ft. Electric Dryer Manuel utilisateur

Electrolux

Electrolux WT252 Mode d’emploi

Electrolux

Electrolux 6000 Mode d'emploi

Electrolux

Electrolux 300 Series Manuel utilisateur

Electrolux

Electrolux EDE 57150 W Manuel utilisateur

Manuels Séchoir populaires d'autres marques

Bosch

Bosch WTA79200GB Manuel utilisateur

Amana

Amana W10233410A Manuel utilisateur

Miele

Miele TWH 780 WP Manuel utilisateur

Asko

Asko T760 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuel utilisateur

Bosch

Bosch Logixx 10 WTB76556GB Fiche technique

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Mode d’emploi

Beko

Beko DS8433RX1M Manuel utilisateur

Dawlance

Dawlance Spinner DS 6000 C Manuel utilisateur

AEG

AEG TR838P4OB Manuel utilisateur

Indesit

Indesit IDV 75 Manuel utilisateur

Infiniton

Infiniton SD-DG85C Manuel utilisateur

BOMANN

BOMANN WT 5019 Manuel utilisateur

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuel utilisateur

Asko

Asko T793C Manuel utilisateur

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuel utilisateur

Frigidaire

Frigidaire CAQE7077KW0 Manuel du propriétaire

Bosch

Bosch WTX8HKM9SN Manuel utilisateur
