EN Dishwasher User Manual

CONTENTS

1. SAFETY INFORMATION....................................................................................2

2. SAFETY INSTRUCTIONS..................................................................................4

3. PRODUCT DESCRIPTION................................................................................ 6

4. CONTROL PANEL ............................................................................................ 7

5. PROGRAMMES................................................................................................. 7

6. SETTINGS..........................................................................................................9

7. OPTIONS..........................................................................................................11

8. BEFORE FIRST USE....................................................................................... 12

9. DAILY USE....................................................................................................... 13

10. HINTS AND TIPS........................................................................................... 15

11. CARE AND CLEANING..................................................................................17

12. TROUBLESHOOTING....................................................................................18

13. TECHNICAL INFORMATION......................................................................... 21

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website to:

Get usage advice, brochures, trouble shooter, service and repair information:

www.electrolux.com/support

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

www.electrolux.com2

responsible for any injuries or damage that are the result

of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Children between 3 and 8 years of age and persons

with very extensive and complex disabilities shall be

kept away from the appliance unless continuously

supervised.

•Children of less than 3 years of age should be kept

away from the appliance unless continuously

supervised.

•Do not let children play with the appliance.

•Keep detergents away from children.

•Keep children and pets away from the appliance when

the door is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•This appliance is intended to be used in household

and similar applications such as:

–farm houses; staff kitchen areas in shops, offices

and other working environments;

–by clients in hotels, motels, bed & breakfast and

other residential type environments.

•Do not change the specification of this appliance.

•The operating water pressure (minimum and

maximum) must be between 0.5 (0.05) / 8 (0.8) bar

(MPa)

•Follow the maximum number of 13 place settings.

ENGLISH 3

•If the supply cord is damaged, it must be replaced by

the manufacturer, its Authorised Service Centre or

similarly qualified persons in order to avoid a hazard.

•Put the cutlery in the cutlery basket with the sharp

ends pointing down or put them in the cutlery drawer

in a horizontal position with the sharp edges down.

•Do not leave the appliance with the open door

unattended to avoid stepping accidentally onto it.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•If the appliance has ventilation openings in the base,

they must not be covered e.g. by a carpet.

•The appliance is to be connected to the water mains

using the new supplied hose-sets. Old hose sets must

not be reused.

2. SAFETY INSTRUCTIONS

2.1 Installation

WARNING!

Only a qualified person must

install this appliance.

• Remove all the packaging.

• Do not install or use a damaged

appliance.

• Follow the installation instructions

supplied with the appliance.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use the appliance

where the temperature is less than

0 °C.

• Install the appliance in a safe and

suitable place that meets installation

requirements.

2.2 Electrical connection

WARNING!

Risk of fire and electric

shock.

• The appliance must be earthed.

• Make sure that the parameters on the

rating plate are compatible with the

electrical ratings of the mains power

supply.

• Always use a correctly installed

shockproof socket.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need to

be replaced, this must be carried out

by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance is fitted with a 13 A

mains plug. If it is necessary to

change the mains plug fuse, use only

www.electrolux.com4

a 13 A ASTA (BS 1362) fuse (UK and

Ireland only).

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and

clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

• The water inlet hose has a safety

valve and a sheath with an inner

mains cable.

WARNING!

Dangerous voltage.

• If the water inlet hose is damaged,

immediately close the water tap and

disconnect the mains plug from the

mains socket. Contact the Authorised

Service Centre to replace the water

inlet hose.

2.4 Use

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Dishwasher detergents are

dangerous. Follow the safety

instructions on the detergent

packaging.

• Do not drink and play with the water in

the appliance.

• Do not remove the dishes from the

appliance until the programme is

complete. Some detergent may

remain on the dishes.

• Do not store items or apply pressure

on the open door of the appliance.

• The appliance can release hot steam

if you open the door while a

programme operates.

2.5 Internal lighting

WARNING!

Risk of injury.

• Concerning the lamp(s) inside this

product and spare part lamps sold

separately: These lamps are intended

to withstand extreme physical

conditions in household appliances,

such as temperature, vibration,

humidity, or are intended to signal

information about the operational

status of the appliance. They are not

intended to be used in other

applications and are not suitable for

household room illumination.

• To replace the internal lighting,

contact the Authorised Service

Centre.

2.6 Service

• To repair the appliance contact the

Authorised Service Centre. Use

original spare parts only.

• Please note that self-repair or non-

professional repair can have safety

consequences and might void the

guarantee.

2.7 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains supply.

• Cut off the mains cable and discard it.

• Remove the door catch to prevent

children and pets to get closed in the

appliance.

ENGLISH 5

3. PRODUCT DESCRIPTION

The graphics below is just a

general product overview.

For more detailed

information, refer to other

chapters and/or documents

provided with the appliance.

10 9

11 67

1Worktop

2Upper spray arm

3Lower spray arm

4Filters

5Rating plate

6Salt container

7Air vent

8Rinse aid dispenser

9Detergent dispenser

10 Cutlery basket

11 Lower basket

12 Upper basket

www.electrolux.com6

4. CONTROL PANEL

2 3 4 5

678

1On/off button

2Programs button

3Programme indicators

4Display

5Delay button

6Start button

7Indicators

8Options button

4.1 Indicators

Indicator Description

Washing phase. It comes on when the washing phase operates.

Drying phase. It comes on when the drying phase operates.

TimeManager indicator.

XtraDry indicator.

Rinse aid indicator. It is always off while the programme operates.

Salt indicator. It is always off while the programme operates.

5. PROGRAMMES

The order of the programmes in the table may not reflect their sequence on the control

panel.

ENGLISH 7

Programme Degree of soil

Type of load

Programme phases Options

1) • Normal soil

• Crockery and

cutlery

• Prewash

• Wash 50 °C

• Rinses

• Dry

• TimeManager

• XtraDry

2) • All

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash from 45 °C to

70 °C

• Rinses

• Dry

• XtraDry

• Heavy soil

• Crockery, cut‐

lery, pots and

pans

• Prewash

• Wash 70 °C

• Rinses

• Dry

• TimeManager

• XtraDry

3) • Fresh soil

• Crockery and

cutlery

• Wash 60 °C or 65 °C

• Rinses

• XtraDry

• Normal or light

soil

• Delicate crock‐

ery and glass‐

ware

• Wash 45 °C

• Rinses

• Dry

• XtraDry

4) • All • Prewash -

1) This programme offers the most efficient use of water and energy consumption for crock‐

ery and cutlery with normal soil. This is the standard programme for test institutes.

2) The appliance senses the degree of soil and the quantity of items in the baskets. It auto‐

matically adjusts the temperature and the quantity of water, the energy consumption and the

programme duration.

3) This programme is suitable for washing a load or a half load with fresh soil. It gives good

washing results in a short time.

4) With this programme, you can quickly rinse off food remains from dishes and prevent

odours forming in the appliance. Do not use detergent with this programme.

5.1 Consumption values

Programme 1) 2) Water

(l)

Energy

(kWh)

Duration

(min)

9.9 0.920 237

7 - 12 0.7 - 1.5 45 - 160

13 - 15 1.4 - 1.6 140 - 160

9 0.8 30

www.electrolux.com8

Programme 1) 2) Water

(l)

Energy

(kWh)

Duration

(min)

13 - 14 0.9 - 1.1 70 - 85

4 0.1 14

1) The pressure and the temperature of the water, the variations of the mains supply, the

options and the quantity of dishes can change the values.

2) The values for programmes other than ECO are indicative only.

5.2 Information for test institutes

To receive the necessary information for conducting performance tests (e.g. according

to EN60436 ), send an email to:

[email protected]

In your request, please include the product number code (PNC) found on the rating

plate.

For any other questions regarding your dishwasher, please refer to the service book

provided with your appliance.

6. SETTINGS

6.1 Programme selection mode

and user mode

When the appliance is in programme

selection mode it is possible to set a

programme and to enter the user mode.

Settings available in the user mode:

• The level of water softener according

to the water hardness.

• Activation or deactivation of the rinse

aid empty notification.

• Activation or deactivation of AirDry.

As the appliance stores the saved

settings, there is no need to configure

it before every cycle.

How to set the programme

selection mode

The appliance is in programme selection

mode when the programme indicator

is on and the display shows the

programme duration.

After activation, the appliance is in

programme selection mode by default. If

not, set the programme selection mode

the following way:

Press and hold simultaneously

Programs and Options until the

appliance is in programme selection

mode.

How to enter user mode

Make sure the appliance is in

programme selection mode.

To enter user mode, press and hold

simultaneously Delay and Start until the

indicators , and

flash and the display is blank.

6.2 The water softener

The water softener removes minerals

from the water supply, which would have

a negative effect on the washing results

and on the appliance.

The higher the content of these minerals,

the harder your water is. Water hardness

is measured in equivalent scales.

The water softener should be adjusted

according to the hardness of the water in

your area. Your local water authority can

advise you on the hardness of the water

in your area. It is important to set the

ENGLISH 9

right level of the water softener to assure

good washing results. Softening hard water

increases the consumption

of water and energy as well

as the programme duration.

The higher the level of water

softener, the higher the

consumption and the longer

the duration.

Water hardness

German de‐

grees (°dH)

French de‐

grees (°fH)

mmol/l Clarke de‐

grees

Water softener

level

47 - 50 84 - 90 8.4 - 9.0 58 - 63 10

43 - 46 76 - 83 7.6 - 8.3 53 - 57 9

37 - 42 65 - 75 6.5 - 7.5 46 - 52 8

29 - 36 51 - 64 5.1 - 6.4 36 - 45 7

23 - 28 40 - 50 4.0 - 5.0 28 - 35 6

19 - 22 33 - 39 3.3 - 3.9 23 - 27 5 1)

15 - 18 26 - 32 2.6 - 3.2 18 - 22 4

11 - 14 19 - 25 1.9 - 2.5 13 - 17 3

4 - 10 7 - 18 0.7 - 1.8 5 - 12 2

<4 <7 <0.7 < 5 1 2)

1) Factory setting.

2) Do not use salt at this level.

Regardless of the type of detergent

used, set the proper water hardness

level to keep the salt refill indicator

active.

Multi-tabs containing salt are

not effective enough to

soften hard water.

How to set the water softener

level

Make sure the appliance is in user mode.

1. Press Programs.

• The indicators and

and are off.

• The indicator still flashes.

• The display shows the current

setting: e.g. = level 5.

2. Press Programs repeatedly to

change the setting.

3. Press the on/off button to confirm the

setting.

6.3 The rinse aid empty

notification

The rinse aid helps to dry the dishes

without streaks and stains.

The rinse aid is automatically released

during the hot rinse phase.

When rinse aid chamber is empty, the

rinse aid indicator is turned on notifying

to refill rinse aid. If the drying results are

satisfactory while using multi-tablets only,

it is possible to deactivate the notification

for refilling rinse aid. However, for best

drying performance, always use rinse

aid.

www.electrolux.com10

Autres manuels pour ESF5542LOW

Table des matières

Autres manuels Electrolux Lave-vaisselle

Electrolux

Electrolux ESF4200LOW Manuel utilisateur

Electrolux

Electrolux FAVORIT 88010 Manuel utilisateur

Electrolux

Electrolux KEQB7300L Manuel utilisateur

Electrolux

Electrolux EIDW6405HT - Fully Integrated Dishwasher Manuel utilisateur

Electrolux

Electrolux ESF 67060 Manuel utilisateur

Electrolux

Electrolux ESL 68040 Manuel utilisateur

Electrolux

Electrolux ESL 68070 Manuel utilisateur

Electrolux

Electrolux BW195 Instructions de montage

Electrolux

Electrolux ESF65052 Manuel utilisateur

Electrolux

Electrolux dishlex DX303 Manuel utilisateur

Electrolux

Electrolux ESF5206LOW Manuel utilisateur

Electrolux

Electrolux ESI 66065 Manuel utilisateur

Electrolux

Electrolux ESF2450 Manuel utilisateur

Electrolux

Electrolux EIDW6405HT - Fully Integrated Dishwasher Manuel utilisateur

Electrolux

Electrolux GA60LI221 Manuel utilisateur

Electrolux

Electrolux Compact Manuel utilisateur

Electrolux

Electrolux EEA12100L Manuel utilisateur

Electrolux

Electrolux ESL5310LO Manuel utilisateur

Electrolux

Electrolux ESL5327LO Manuel utilisateur

Electrolux

Electrolux ZANUSSI DE 6955 Manuel utilisateur

Electrolux

Electrolux EIDW1805KS Manuel utilisateur

Electrolux

Electrolux ESF611 Guide rapide

Electrolux

Electrolux ESL 5201LO Manuel utilisateur

Electrolux

Electrolux ESL 679 Manuel utilisateur

Manuels Lave-vaisselle populaires d'autres marques

KitchenAid

KitchenAid KUDB230B Manuel utilisateur

Brandt

Brandt BDJ424DB Manuel utilisateur

Asko

Asko DSD767UXXL.AU Manuel utilisateur

Beko

Beko DFN26210W Manuel utilisateur

NEFF

NEFF S153ITX00E Fiche technique

Midea

Midea SV 4.45 wi Manuel utilisateur

LG LDF7932 Manuel utilisateur

Gorenje

Gorenje GV63214 Manuel utilisateur

Hotpoint

Hotpoint HDA1100ZWH Manuel de service

Blomberg

Blomberg LDFN2240W Manuel utilisateur

AEG

AEG FFB83836PM Manuel utilisateur

Cylinda

Cylinda DM3220RFD Manuel utilisateur

Atag

Atag DW8214MB Manuel utilisateur

GE GLD8000 Series Manuel utilisateur

Siemens

Siemens SN23HI02KE Fiche technique

Omega

Omega ODW717X Manuel utilisateur

BORETTI

BORETTI BVW-683 Manuel utilisateur

Siemens

Siemens SN 56N591 Manuel utilisateur
