Electrolux EKC 60353 Manuel utilisateur

Ceramic Free-Standing

Electric Cooker

ÇëåêôñéêÞ Êïõæßíá

ìå ÊåñáìéêÝò Åóôßåò

EKC 60353

INSTRUCTION BOOKLET

ÖÕËËÁÄÉÏ ÏÄÇÃÉÙÍ

2electrolux

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class product from Electrolux, which hopefully

will provide you with lots of pleasure in the future. The Electrolux ambition is to offer

a wide variety of quality products that make your life more comfortable. You find

some examples on the cover in this manual. Please take a few minutes to study

this manual so that you can take advantage of the benefits of your new machine.

We promise that it will provide a superior User Experience delivering Ease-of-Mind.

Good luck!

4electrolux

The following symbols will be found in the text to guide you throughout the

Instructions:

Safety Instructions

Step by step instructions for an operation

Hints and Tips

Environmental Information

Guide to Use the instructions

This appliance is manufactured according to the following EEC directives:

2006/95 EEC - 93/68 EEC - 89/336 EEC current edition.

Important Safety Information ............................................................................. 5

Control Panel .................................................................................................... 8

Operation .......................................................................................................... 9

Using the ceramic glass hob .......................................................................... 10

Electric Oven ................................................................................................... 12

Before the First Use of the appliance ............................................................... 13

Electric Programmer ........................................................................................ 14

Using the Oven ............................................................................................... 18

Hints and tips for using the oven ..................................................................... 20

Defrosting ....................................................................................................... 20

Cooking Chart - Conventional and fan cooking ................................................ 21

Cooking Chart - Grilling ................................................................................... 22

Cooking Chart - Pizza ..................................................................................... 22

Cleaning the Ceramic Hob .............................................................................. 23

Cleaning the Oven ........................................................................................... 24

Something not working ................................................................................... 27

Service and Spare Parts .................................................................................. 32

EUROPEAN GUARANTEE ............................................................................... 32

For the User

For the Installer

Instructions for the Installer .............................................................................. 28

Technical data ................................................................................................. 28

Electrical connections ...................................................................................... 30

Contents

electrolux 5

Installation

• The work of installation must be

carried out by competent and

qualified installers according to the

regulations in force.

• Any modifications to the domestic

electrical mains which may be

necessary for the installation of the

appliance should be carried out only

by competent personnel.

• Check your appliance for any

transport damage. Never connect a

damaged appliance. If your

appliance is damaged, contact your

supplier.

• It is dangerous to modify, or attempt

to modify, the characteristics of this

appliance.

• Avoid installation of the appliance

near inflammable material (e.g.

curtains, tea towels, etc.).

• This appliance is heavy. Take care

when moving it.

• This appliance cannot be positioned

on a base.

• Remove all packaging before using

the appliance.

• Some parts have a shock-resistant

plastic film protection. Be sure to

remove this plastic film before you

start operating the appliance and

clean the parts involved using a soft

cloth wrung out in warm water to

which a little washing up liquid has

been added.

• Ensure that the electrical supply

complies with the type stated on the

rating plate.

Child Safety

• This appliance is designed to be

operated by adults. Do not allow

children to play near or with the

appliance.

• The appliance gets hot when it is in

use. Children should be kept away

until it has cooled.

• This appliance is not intended for use

by children or other persons whose

physical, sensory or mental

capabilities or lack of experience and

knowledge prevents them from using

the appliance safely without

supervision or instruction by a

responsible person to ensure that

they can use the appliance safely.

• Children can also injure themselves

by pulling pans or pots off the

appliance.

During Use

• This appliance is intended for

domestic cooking only. It is not

designed for commercial or industrial

purposes.

• Do not use this appliance if it is in

contact with water.

• Do not operate the appliance with

wet hands.

• Ensure the control knobs are in the

‘OFF’ position when not in use.

You MUST read these warnings carefully before installing or using the hob. If you

need assistance, contact our Customer Care Department.

Important Safety Information

ENGLISH

6electrolux

• During use the appliance becomes

hot. Care should be taken to avoid

touching heating elements inside the

oven.

• Always stand back from the oven

when opening the oven door, to

allow any build-up of steam or heat

to release.

• When using other electrical

appliances, ensure the cable does

not come into contact with the hot

surfaces of the appliance.

• Never use the ceramic hob as a

working space. Do not store things

on the ceramic hob.

• Never use plastic or aluminium foil

dishes on the ceramic hob.

• Never use plastic dishes in the oven.

Never line any part of the oven with

aluminium foil.

• Unstable or misshapen pans should

not be used on the cooking zones as

unstable pans can cause an accident

by tipping or spillage.

• The ceramic hob is shockproof, but

not unbreakable! Hard or pointed

objects falling from a height can

damage the hob. If scratches or

cracks are noticed, disconnect the

cooker from the electrical supply

and call you nearest Service Force

Centre.

• Never leave the appliance

unattended when cooking with oil

and fats.

• This appliance should be kept clean

at all times. A build-up of fats or

foodstuffs could result in a fire.

• Always ensure that the oven vent

which is located at the centre back

of the hob is left unobstructed to

ensure ventilation of the oven cavity.

• Perishable food, plastic items and

areosols may be affected by heat

and should not be stored above the

appliance.

• Only heat-resistant plates may be

placed in the drawer situated under

the oven. Do not put combustible

materials there.

• Never use steam or high pressure

steam cleaners to clean the

appliance.

• Do not use harsh abrasive cleaners

or sharp metal scraper to clean the

oven door glass since they can

scratch the surface, which may

result in shattering of the glass.

Service

• This appliance should only be

repaired or serviced by an authorised

Service Engineer and only genuine

approved spare parts should be

used.

Keep this instruction book for future

reference and ensure it is passed on

to any new owner.

These instruction are only valid in

the countries whose symbols

appear on this booklet’s cover.

electrolux 7

Environmental

Information

• After installation, please dispose of

the packaging with due regard to

safety and the environment.

• When disposing of an old appliance,

make it unusable, by cutting off the

cable.

• The symbol on the product or

on its packaging indicates that this

product may not be treated as

household waste. Instead it shall be

handed over to the applicable

collection point for the recycling of

electrical and electronic equipment.

By ensuring this product is disposed

of correctly, you will help prevent

potential negative consequences for

the environment and human health,

which could otherwise be caused by

inappropriate waste handling of this

product. For more detailed

information about recycling of this

product, please contact your local city

office, your household waste disposal

service or the shop where you

purchased the product.

8electrolux

1. Front left cooking zone control knob

2. Back left cooking zone control knob

3. Back right cooking zone control knob

4. Front right cooking zone control knob

5. Electronic programmer

6. Oven function control knob

7. Mains on light

8. Oven thermostat pilot light

9. Oven thermostat control knob

654

Control Panel

Storage drawer

The storage drawer is located

underneath the oven cavity.

During cooking the storage

drawer may become hot if the

oven is on high for a long period

of time, therefore flammable

materials such as oven gloves, tea

towels, plastic aprons etc. should

not be stored in the drawer.

Oven accessories such as baking

sheets, will also become hot,

therefore care should be taken

when removing these items from

the drawer whilst the oven is in use

or still hot.

Accessories

Oven Shelf

(x 2)

The oven cavity

Oven Light

Dripping Pan

(x 1)

Grill element

Oven fan

electrolux 9

Push-Pull control knobs

Some models are provided with push-

pull control knobs (see picture). These

knobs can be completely sunken inside

the control panel when the oven is not

working.

Ceramic hob cooking zones

To switch on a cooking zone, turn the

relevant control knob clockwise to the re-

quired heat setting.

The control knob is numbered 0 - 9.

0 - OFF

9 - Maximum.

The hob has two types of cooking zones:

3 normal cooking zones (back left,

back right and front right)

We recommend the plates are

switched to maximum (9) for a short

while to boost the cooking zone, and

then adjusted to the required setting.

1 double circuit cooking zone (front

left)

The front left cooking zone has two

heating elements.

- To switch on the smaller circular

cooking zone, turn the relevant con-

trol knob clockwise to the required

heat setting.

- To switch on both heating elements,

turn the control knob clockwise to

maximum heat setting (9) then turn the

knob further to nearly reach the "0"

symbol. You will hear a "click" and the

wider cooking zone will switch on.

Then turn back the knob to position 9

and adjust it to the required heat

setting.

Please be aware that the two heating

elements will now operate together, giv-

ing a higher power output than a normal

cooking zone.

Operation

Control knob for normal cooking

zone

Control knob for double circuit

cooking zone

10 electrolux

Residual heat indicators

The hob is fitted with four residual heat

indicators corresponding to each cook-

ing zone. The corresponding indicator will

remain on until the temperature falls be-

low 30°C, even after the cooking zone is

switched off.

When a cooking zone is switched

on, a short buzzing may be heard.

This is quite normal and does not

affect the hob operation in any way.

Mains on light

The mains on light will come on when

the oven function control knob and/or the

cooking zone control knobs are set.

Ceramic glass surface

The glass is hard, and has been

tempered to withstand heat, cold and

temperature shocks. But like all glass it

is sensitive to impact. Do not stand on

the ceramic glass surface.

If scratches or cracks are

noticed, disconnect the

cooker from the electrical

supply to avoid the possibility

of electric shock and call you

nearest Service Force Centre.

Keep all objects and materials

which can melt away from the

cooking surface, e.g. plastics,

aluminium foil.

Care should be taken when

preparing food or drinks

containing sugar. If anything of

this nature accidentally comes

into contact with the ceramic

surface it must be scraped off

immediately while still hot and

wiped away to avoid damage to

the surface.

Using the ceramic glass hob

Table des matières

Autres manuels Electrolux Cuisinière

Electrolux

Electrolux EVE915 Mode d’emploi

Electrolux

Electrolux EK 5162 Manuel utilisateur

Electrolux

Electrolux Electric and Gas Cookers Mode d'emploi

Electrolux

Electrolux EKG913A2 Manuel utilisateur

Electrolux

Electrolux EVEP916 Manuel utilisateur

Electrolux

Electrolux EKG603202 Manuel utilisateur

Electrolux

Electrolux EKC6461AEW Manuel utilisateur

Electrolux

Electrolux EKC60752 Manuel utilisateur

Electrolux

Electrolux FHH 6885 GK Manuel utilisateur

Electrolux

Electrolux Insight EKG6049 Manuel utilisateur

Electrolux

Electrolux EKI7553BTW Manuel utilisateur

Electrolux

Electrolux EHG645BE Manuel utilisateur

Electrolux

Electrolux EK 5741 Manuel utilisateur

Electrolux

Electrolux EKM6700X Manuel utilisateur

Electrolux

Electrolux EVE611SA Manuel utilisateur

Electrolux

Electrolux LKM620000X Manuel utilisateur

Electrolux

Electrolux Range Manuel utilisateur

Electrolux

Electrolux Electric Cooker Manuel utilisateur

Electrolux

Electrolux EKK925A0OX Manuel utilisateur

Electrolux

Electrolux LKI66440NX Manuel utilisateur

Electrolux

Electrolux EKC6461AOW Manuel utilisateur

Electrolux

Electrolux EKC 603505 Manuel utilisateur

Electrolux

Electrolux EKC60154 Manuel utilisateur

Electrolux

Electrolux EKM 6701 X Manuel utilisateur

Manuels Cuisinière populaires d'autres marques

Modena

Modena FC 7645 SGM Manuel du propriétaire

Stanley

Stanley Donard 60 Manuel utilisateur

Bartscher

Bartscher 201TC Manuel utilisateur

Parkinson Cowan

Parkinson Cowan 50 GR/BU Manuel utilisateur

Siemens

Siemens HK9P00020U Manuel utilisateur

Creda

Creda S150E Mode d’emploi

Creda

Creda HB48309 Manuel utilisateur

Bosch

Bosch HCE743220F Manuel utilisateur

Tricity Bendix

Tricity Bendix SE545P Manuel utilisateur

NEFF

NEFF E1461A2/01 Manuel utilisateur

Zanussi

Zanussi ZCM 700 X Manuel utilisateur

Smeg

Smeg SNL61MA9 Manuel utilisateur

RiverGrille

RiverGrille TF2002501-RG Manuel utilisateur

Vollrath

Vollrath 69504F Manuel utilisateur

Tricity Bendix

Tricity Bendix CSIE500 Manuel utilisateur

AEG

AEG Competence 5731 V Manuel utilisateur

Euromaid

Euromaid ES60 Manuel utilisateur

Hotpoint

Hotpoint HUI 62 TP Manuel utilisateur
