Electrolux Professional Compass Pro WB6-13 Manuel utilisateur

Installation manual

Washer extractor

WB6–13, WB6–18

Compass Pro

Type W3...

Original instructions

438917594/EN

2022.08.12

Contents

1 Safety Precautions ..............................................................................................................................5

1.1 General safety information..........................................................................................................6

1.2 Commercial use only..................................................................................................................6

1.3 Symbols....................................................................................................................................6

2 Warranty terms and exclusions.............................................................................................................7

3 Technical data.....................................................................................................................................8

3.1 Drawing ....................................................................................................................................8

3.2 Barrier partition..........................................................................................................................9

3.3 Technical data .........................................................................................................................10

3.4 Connections ............................................................................................................................10

4 Setup ............................................................................................................................................... 11

4.1 Unpacking............................................................................................................................... 11

4.2 Unpacking for machines delivered on a base .............................................................................12

4.3 Recycling instruction for packaging ...........................................................................................16

4.4 Siting ......................................................................................................................................17

4.5 Mechanical installation .............................................................................................................18

5 Water connection ..............................................................................................................................19

6 Connection of external dosing systems ...............................................................................................20

6.1 Connection of the hoses...........................................................................................................20

6.2 Electrical connection of external dosing system..........................................................................20

6.2.1 Machine with connectors.................................................................................................21

6.2.2 Machine without connectors............................................................................................22

6.2.3 Outputs .........................................................................................................................23

6.2.4 Inputs ............................................................................................................................24

7 Drain connection ...............................................................................................................................25

8 Electrical connection..........................................................................................................................26

8.1 Electrical installation ................................................................................................................26

8.2 Electrical connections ..............................................................................................................26

8.3 Machine connection .................................................................................................................27

8.3.1 Single-phase connection.................................................................................................27

8.3.2 Three-phase connection .................................................................................................27

8.4 Functions for I/O-cards.............................................................................................................28

8.4.1 Outputs for detergent signals and inputs for pause signals, "empty" signal (2D)...................28

9 Steam connection .............................................................................................................................29

10 At first power up ................................................................................................................................31

10.1 Select language.......................................................................................................................31

10.2 Set time and date.....................................................................................................................31

11 Function check..................................................................................................................................32

12 Disposal information ..........................................................................................................................33

12.1 Disposal of appliance at end of life ............................................................................................33

12.2 Disposal of packing..................................................................................................................33

The manufacturer reserves the right to make changes to design and component specifications.

Installation manual 5

1 Safety Precautions

• Servicing shall be carried out only by authorized personnel.

• Only authorized spare parts, accessories and consumables shall be used.

• Only use detergent intended for water-wash of textiles. Never use dry cleaning agents.

• The machine shall be connected with new water hoses. Re-used water hoses must not

be used.

• The machine's door lock must under no circumstances be bypassed.

• If the machine develops a fault, this must be reported to the person in charge as soon

as possible. This is important both for your safety and that of others.

• DO NOT MODIFY THIS APPLIANCE.

• When performing service or replacing parts, the power must be disconnected.

• When the power is disconnected, the operator must see that the machine is discon-

nected (that the plug is removed and remains removed) from any point to which he has

access. If this is not possible, due to the construction or installation of the machine, a

disconnection with a locking system in the isolated position shall be provided.

• In accordance with the wiring rules: mount a multi-pole switch prior to the machine to

facilitate installation and service operations.

• If different rated voltages or different rated frequencies (separated by a /) are stated at

the machine data plate, instructions for adjusting the appliance for operation at the re-

quired rated voltage or rated frequency are stated in the installation manual.

• Stationary appliances not fitted with means for disconnection from the supply mains

having a contact separation in all poles that provide full disconnection under overvolt-

age category III, the instructions state that means for disconnection must be incorpo-

rated in the fixed wiring in accordance with the wiring rules.

• The openings in the base, shall not be obstructed by a carpet.

• Maximum mass of dry cloth: WB6–13: 14 kg, WB6–18: 20 kg.

• A-weighted emission sound pressure level at working stations:

– Wash: WB6–13: <70 dB(A), WB6–18: <70 dB(A).

– Extraction: WB6–13: <70 dB(A), WB6–18: <70 dB(A).

• Maximum inlet water pressure: 1000 kPa

• Minimum inlet water pressure: 50 kPa

• Additional requirements for the following countries; AT, BE, BG, HR, CY, CZ, DK, EE,

FI, FR, DE, GR, HU, IS, IE, IT, LV, LT, LU, MT, NL, NO, PL, PT, RO, SK, SI, ES, SE, CH,

TR, UK:

– This appliance shall not be installed where the public has access.

• Additional requirements for other countries:

– This appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless

they have been given supervision or instruction concerning use of the appliance by a

person responsible for their safety. Children should be supervised to ensure that they

do not play with the appliance.

– This appliance is intended to be used in household and similar applications such as:

(IEC 60335-2-7) staff kitchen areas in shops, offices and other working environments,

farm houses, by clients in hotels, motels and other residential type environments, bed

6Installation manual

and breakfast type environments, areas for communal use in blocks of flats or in

launderettes.

1.1 General safety information

The machine is only intended for water-wash use.

Do not hose down the machine with water.

In order to prevent damage to the electronics (and other parts) that may occur as the result of condensation, the ma-

chine should be placed in room temperature for 24 hours before being used for the first time.

1.2 Commercial use only

The machine/machines covered by this manual is/are made for commercial and industrial use only.

1.3 Symbols

Caution

Caution, high voltage

Read the instructions before using the machine

Installation manual 7

2 Warranty terms and exclusions

If the purchase of this product includes warranty coverage, warranty is provided in line with local regulations and sub-

ject to the product being installed and used for the purposes as designed, and as described within the appropriate

equipment documentation.

Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance

in accordance with Electrolux Professional user and maintenance documentation made available in paper or elec-

tronic format.

Electrolux Professional strongly recommends using Electrolux Professional approved cleaning, rinse and descaling

agents to obtain optimal results and maintain product efficiency over time.

The Electrolux Professional warranty does not cover:

• service trips cost to deliver and pick up the product;

• installation;

• training on how to use/operate;

• replacement (and/or supply) of wear and tear parts unless resulting from defects in materials or workmanship re-

ported within one (1) week from the failure;

• correction of external wiring;

• correction of unauthorized repairs as well as any damages, failures and inefficiencies caused by and/or resulting

from;

– insufficient and/or abnormal capacity of the electrical systems (current/voltage/frequency, including spikes and/

or outages);

– inadequate or interrupted water supply, steam, air, gas (including impurities and/or other that does not comply

with the technical requirements for each appliance);

– plumbing parts, components or consumable cleaning products that are not approved by the manufacturer;

– customer’s negligence, misuse, abuse and/or non-compliance with the use and care instructions detailed within

the appropriate equipment documentation;

– improper or poor: installation, repair, maintenance (including tampering, modifications and repairs carried out

by third parties not authorized third parties) and modification of safety systems;

– Use of non-original components (e.g.: consumables, wear and tear, or spare parts);

– environment conditions provoking thermal (e.g. overheating/freezing) or chemical (e.g. corrosion/oxidation)

stress;

– foreign objects placed in- or connected to- the product;

– accidents or force majeure;

– transportation and handling, including scratches, dents, chips, and/or other damage to the finish of the product,

unless such damage results from defects in materials or workmanship and is reported within one (1) week of deliv-

ery unless otherwise agreed;

• product with original serial numbers that have been removed, altered or cannot be readily determined;

• replacement of light bulbs, filters or any consumable parts;

• any accessories and software not approved or specified by Electrolux Professional.

Warranty does not include scheduled maintenance activities (including the parts required for it) or the supply of

cleaning agents unless specifically covered within any local agreement, subject to local terms and conditions.

Check on Electrolux Professional website the list of authorized customer care.

8Installation manual

3 Technical data

3.1 Drawing

LIG

fig.6813E

1 Operating panel

2 Detergent container

3 Liquid detergent supply

4 Electrical connection

5Cold water

6 Hot water

7Cold/hot water

8 Steam connection

9 Drain

10 Door opening, loading side: WB6–13: 280 x 280 mm, WB6–18: 320 x 280 mm

11 Door opening, unloading side: WB6–13: ⌀395 mm, WB6–18: ⌀435 mm

12 Plinth

13 Barrier frame

14 Barrier partition

mm A B C D E F G H

WB6–13 910 875 1325 435 1035 160 1245 215

WB6–18 970 975 1410 470 1120 150 1330 230

mm I J K L M N O P

WB6–13 1225 300 380 825 455 105 305 45

WB6–18 1330 315 395 1120 485 110 335 45

mm Q R S T U

WB6–13 390 345 575 285 100

WB6–18 390 385 610 200 100

Installation manual 9

3.2 Barrier partition

The barrier partition (3) shall be built before the installation of the machine.

Centre and align the machine with the barrier partition (3).

Mount the rubber seal (2) in the aluminium section (1).

Fasten the aluminium section (1) with screws in the barrier partition (3).

If machines are to be installed in an existing wall thicker than 100 mm please contact authorized service personnel.

fig.6822A

1 Aluminium section

2 Rubber seal

3 Barrier partition

4 Removable barrier partition

5 Minimum 70 mm, maximum 100 mm

mm ABCD

WB6–13 990 1650 150 40

WB6–18 1050 1650 150 40

10 Installation manual

3.3 Technical data

WB6–13 WB6–18

Weight, net kg 296 356

Drum volume litres 130 180

Drum diameter mm 650 725

Drum speed during wash rpm 49 44

Drum speed during extraction rpm 910 860

G-factor, max. 300 300

Heating: Electricity kW 13 18

Heating: Steam x x

Heating: Hot water x x

Frequency of the dynamic force Hz 15.2 14.3

Floor load at max extraction kN 3.4±0.5 2.9±1.0

A-weighted emission sound pressure level at working

stations (Wash)

dB(A) <70 <70

A-weighted emission sound pressure level at working

stations (Extraction)

dB(A) 79 85

Heat emission of installed power, max % 5 5

3.4 Connections

WB6–13 WB6–18

Water valves DN

BSP

3/4”

Recommended water pressure kPa 200–600 200–600

Continuous operating pressure kPa 50–800 50–800

Capacity at 300 kPa l/min 20 60

Drain valve

⌀outer

mm 75 75

Draining capacity l/min 170 170

Steam valve connection DN

BSP

1/2”

Recommended steam pressure kPa 300–600 300–600

Functioning limits for steam valve kPa 50–800 50–800

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Electrolux Professional Rondelle

Electrolux Professional

Electrolux Professional Compass Pro WH6-8 Manuel utilisateur

Electrolux Professional

Electrolux Professional myPRO XL WE1100P Manuel utilisateur

Electrolux Professional

Electrolux Professional WB5130H Manuel utilisateur

Electrolux Professional

Electrolux Professional Lagoon WH6-6 Manuel utilisateur

Electrolux Professional

Electrolux Professional DOUBLE SKIN XL Manuel utilisateur

Electrolux Professional

Electrolux Professional WE170PP Manuel utilisateur

Electrolux Professional

Electrolux Professional WB5130H Manuel utilisateur

Electrolux Professional

Electrolux Professional WB6-20 Manuel utilisateur

Electrolux Professional

Electrolux Professional WH6-14LAG Manuel utilisateur

Electrolux Professional

Electrolux Professional Compass Pro WH6-7 Manuel utilisateur

Electrolux Professional

Electrolux Professional WE170P Manuel utilisateur

Electrolux Professional

Electrolux Professional W575N Manuel utilisateur

Electrolux Professional

Electrolux Professional QuickWash QWC Manuel utilisateur

Electrolux Professional

Electrolux Professional WH6-20LAC Manuel utilisateur

Electrolux Professional

Electrolux Professional WE170V Manuel utilisateur

Electrolux Professional

Electrolux Professional WB6-20 Manuel utilisateur

Electrolux Professional

Electrolux Professional WP4700H Mode d’emploi

Electrolux Professional

Electrolux Professional Lagoon WH6-6 Manuel utilisateur

Electrolux Professional

Electrolux Professional WE 170 P Manuel utilisateur

Electrolux Professional

Electrolux Professional WE 170 V Manuel utilisateur

Electrolux Professional

Electrolux Professional Clarus Vibe WH6-7 Manuel utilisateur

Electrolux Professional

Electrolux Professional WE 170 P Manuel utilisateur

Electrolux Professional

Electrolux Professional Wascator FOM71 CLS Manuel utilisateur

Electrolux Professional

Electrolux Professional Compass Pro WB6-18 Manuel utilisateur

Manuels Rondelle populaires d'autres marques

Tricity Bendix

Tricity Bendix AW 1000 W Guide produit

Panasonic

Panasonic NA-F60L5WRB Manuel utilisateur

GE WSLP1500 Manuel

Electrolux

Electrolux EWF1284EDW Manuel utilisateur

Bosch

Bosch WAN2829BSN Manuel utilisateur

LG TV2516DV3B Manuel utilisateur

LG TH2517DSAV Manuel utilisateur

VESTEL

VESTEL CMH-XL 7510 TE Manuel utilisateur

AEG

AEG 74335 Manuel d'utilisation

Johnson

Johnson JWF721A Manuel utilisateur

Beko

Beko WTE7604XLW0 Manuel utilisateur

Danby

Danby DTT100A1WDB Instructions de montage

Amica

Amica WA 14 Ex Manuel utilisateur

Daewoo

Daewoo DWD-F1222 Manuel utilisateur

Bosch

Bosch WAS28461AU Manuel utilisateur

Miele

Miele PW 6080 Vario Manuel utilisateur

Finlux

Finlux FLX108CF220 Manuel utilisateur

Whirlpool

Whirlpool 3LBR5132AN0 Manuel utilisateur
