Electro-Voice EVID 3.2 Manuel utilisateur

EVID 3.2 SOS Monitor and MA-3 Mic Stand Adapter

The EVID 3.2 SOS is a near-field monitor with volume control and

¼ in ut jack that can be easily mounted on a micro hone stand

for convenient lacement anywhere. An adjustable swivel lets you

mount it at exactly the right angle for any a lication. A boom

ada ter is also included to mount an o tional boom and

micro hone (not included)*

MA-3 Mic Stand Ada ter kit lets you mount any standard EVID 3.2

on a micro hone stand for easy lacement anywhere you need it.

MA Series

SOS 3.2 Series

Assembly Instructions

:sedulcnItiK3-AM

metIytQnoitpircseD

11 retpadAdnatSciM

21 retpadAmooB

32 ).D.I"52.,.D.O"88.(rehsaWtalF

:sedulcnIrotinoMSOS2.3DIVE

metIytQnoitpircseD

11 retpadAdnatSciM

21 retpadAmooB

32 ).D.I"52.,.D.O"88.(rehsaWtalF

41 kcaJ"4/1htiw,rotinoM2.3DIVE

51 tnuoMenohporciMfoorP-kcohS

1/4” Input Jack

Volume Control

Knob

Positioning for Boom and Microphone EVID 3.2 SOS Rear Panel Detail

*To ensure ro er balance, when a

boom and micro hone are attached, the

EVID must be angled u ward and the

booms counterweight ro erly

ositioned as shown.

Correct Incorrect

CAUTION: This system is rated for 75W RMS.

When connecting the VID 3.2 SOS to the

amplifier, make sure that the amplifiers

power output does not exceed this rating.

U.S.A. and Canada only. For customer orders,

contact the Customer Service department at

800/392-3497 Fax: 800/955-6831

Europe, Africa and Middle East only. For customer orders,

contact the Customer Service department at

49 9421-706 0 Fax: 49 9421-706 265

For warranty information, contact the Service Repair department at:

616/695-6831 or 800/685-2606

For technical assistance, contact Technical Support at:

866/78AUDIO

Specifications subject to change without notice.

12000 Portland Avenue South, Burnsville, MN 55337

Phone: 952/884-4051, Fax: 952/884-0043

www.electrovoice.com

Part Number 38110-087 Rev C

Mounting a Microphone and Boom to your EVID (MA-3 and SOS)

Step 1:

Attach the Boom Ada ter (Item 2) to the to

of the EVID with a flat washer (Item 3) in

between the Ada ter and the EVID.

Step 2:

Mount the Boom (Not Included) to the Boom

Ada ter (Item 2).

Step 3:

Re lace any micro hone mount with the

Shock-Proof Mic Mount (Item 5, EVID 3.2

SOS only).

Item 1

Item 4

Item 3

Item 2

Item 5

(Included only with

EVID 3.2 SOS

Monitor Package)

Boom

(Not Included)

Mic Stand Mounting (MA-3 and SOS)

Step 1:

Attach the Mic Stand Ada ter (Item 1) to

your micro hone stand (not included).

Step 2:

Attach the EVID 3.2 (or the 3.2 SOS) to the

Mic Stand Ada ter using one flat washer

(Item 3) in-between the Ada ter and the

EVID.

Step 3:

Use the adjustment knob to adjust the angle

of the EVID.

If not attaching a boom to the EVID, attach

Logo Ca as shown.

Item 1

Item 4 Item 3

Adjustment

Knob

Logo Cap

(Included with

standard EVID 3.2)
