Electrify America HomeStation Manuel utilisateur
HomeStation
Level 2 Charger
INSTALLATION AND OPERATION MANUAL
Version 1.0.0
Issue Date: December 11, 2020
ELECTRIFYHOME.COM
Customer Support: (833) 532-2778
Contents
INFORMATION
o Copyright
o About This Document
o Intended Use
o Charger – Intended Use
o IMPORTANT SAFETY INSTRUCTIONS
o EMC Compliance Statement: FCC Part 15
PRODUCT OVERVIEW
o Included Component List
o Recommended Tools
INSTALLATION INSTRUCTIONS
o Before Installing
o Installation Steps
o Installation with Hardwiring
OPERATING INSTRUCTIONS
CHARGER STATUS
o Status Indicator
o Indicator Definition
o Understanding Status Indicator Patterns
o Faults
TROUBLESHOOTING
SPECIFICATIONS
MOVING, TRANSPORTATION AND STORAGE
CLEANING
WARRANTY
DISPOSAL
Information
1) Copyright
Copyright © 2020 Electrify America, All Rights Reserved. This document is copyright protected.
It may not be changed, reproduced, or distributed without prior agreement issued in writing
by Electrify America.
2) About this Document
These operating instructions describe how to operate the charger properly. For your personal
safety, follow these operating instructions exactly. Hardwiring must be performed by a
certified electrician. Do not carry out any work that is not described here. When in doubt,
consult a certified electrician.
3) Intended Use
These operating instructions apply to the charger and its use in the USA. Follow all federal,
provincial, and local laws, regulations, ordinances, codes, and safety standards.
4) Charger – Intended Use
1) This device is intended for indoor and outdoor use. Do not obscure the label of the
chargers. All persons using the charger must first read and understand these instructions
2) This device is intended exclusively for the charging of electric vehicles fitted with a Type-1
plug (SAE J1772) and charging current control via the pilot signal (IEC 61851-1). Do not use
the charger to charger or supply other devices. Follow all federal, provincial, and local
laws, regulations, ordinances, and safety standards regarding use of this device.
5) IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ ALL THE INSTRUCTIONS BEFORE INSTALLING, OPERATING, MAINTAINING, OR USING
THIS PRODUCT. SAVE THESE INSTRUCTIONS. THEY MUST BE PROVIDED TO EACH NEW OWNER.
DANGER: RISK OF ELECTRICAL SHOCK
INSTRUCTIONS PERTAININED TO A RISK OF FIRE OR ELECTRIC SHOCK
1) Do not use any adapters, converters, extension cords, or extension cables to increase the
length of the charging cable or supply power cord.
2) Do not install this charger on a GFCI circuit breaker.
3) Supervise children when device is in use. Children under 16 should not operate this device.
Also, small parts are dangerous for children. Do not install in the presence of children.
4) Do not put fingers into the electric vehicle connector.
5) Do not use this product if the power cord or the electric vehicle cable is frayed, has broken
insulation, or shows any other signs of damage.
6) Do not use this product if the enclosure or the electric vehicle connector is broken,
cracked, open, or shows any other indication of damage.
7) The ambient operating temperature range for this device is -22°F (-30°C) to 122°F (50°C).
Do not operate the charger outside this operating range.
8) Electrify America is not responsible for physical injury, damage to property or equipment
caused by the installation, usage, repair, or maintenance of this product.
9) These operating instructions describe the usage of the charger in most commonly used
installation and mounting scenarios. If situations arise in which it is not possible to
perform an operation following the procedures provided in this document, contact
Electrify America. Electrify America is not responsible for any damages that may occur
resulting from custom installations or operations that are not described in this document.
10) Personal Protection Equipment: Use of proper personal protection equipment, including, but not
limited to, eye protection, shock protection, gloves, and other appropriate protection, is
recommended when installing or servicing any electrical equipment. To reduce the risk of fire, only
connect this equipment to a maximum 50 amperes overcurrent protection device in accordance
with the National Electrical Code, ANSI/NFPA.
11) Do not use this equipment in an area with hazardous or flammable materials or vapors.
12) Arcing Component in Contactor: The charger includes contactors that, when opened or closed, will
cause a short duration arc. The contactor is enclosed in an appropriate electrical enclosure, but
caution is required if this arc occurs in the presence of flammable vapors as the vapors could ignite,
creating an explosion. Store hazardous and flammable vapors and materials away from all electrical
equipment. If hazardous or flammable sources are present, allow sufficient time for ventilation
before operating the charger.
13) Do not open the charger at any time during installation or operation! Only trained personnel should
open the charger.
14) Handling live components incorrectly may cause grievous injuries or death.
15) If the electricity service to the charger is damaged, immediately shut down the power to the
charger by switching off the circuit breaker and contact a licensed electrician.
16) Turn off circuit before remounting or replacing the charger.
17) To reduce the risk of fire, connect only to a circuit provided with the proper maximum branch
circuit overcurrent protection in accordance with the National Electrical Code and local laws,
regulations, codes, and standards.
18) Ensure that all components are dry throughout the installation.
19) Product subject to modification without prior notice. This document might not contain the latest
changes to the product’s specifications or processes described herein. For the most up-to-date
information, please visit electrifyhome.com
6 ) EMC Compliance Statement: FCC Part 15 Subpart B, Class B
FCC ID: 2AX8SEA2R040JPA1000
1) RF Exposure warning
This equipment must be installed and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20
cm from all persons and must not be co-located or operating in conjunction with any other antenna
or transmitter. End-users and installers must be provide with antenna installation instructions and
transmitter operating conditions for satisfying RF exposure compliance.
2) FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority
to operate the equipment.
Product Overview
Recommended Tools
1 TOOLS FOR PLUG-IN INSTALLATION
1. Level
2. Pencil
3. Electric Drill
4. Philips-head Screwdriver
2 TOOLS FOR HARDWIRED INSTALLATION
1. Level
2. Pencil
3. Electric Drill
4. Phillips Head Screwdriver
5. Diagonal Cutter
6. Needle-Nose Pliers
7. Wire Stripper
8. Ferrule Crimping Tool
Installation Instructions
Before Installing
These installation instructions are intended for specialized electricians. Only qualified, specialized electricians
should hardwire the charger. In addition to the charger installation instructions, follow all federal, provincial
and local laws, regulations, ordinances, codes and safety standards.
When considering installation locations, there are a few things to keep in mind:
1. Make sure to follow all local codes and regulations for safety and accessibility.
Determine Your Power Rating
1. Prior to installing your charger, work with your electrician to determine the amperage setting that best fit your
home’s electrical capacity. This may determine which type of installation you will need and the best location
for the charger.
Configuration
Installation Type
16A
Hardwire Only
30A
Plug
-
In or Hardwire
32A
Plug
-
In or Hardwire
40A
Plug
-
In or Hardwire
Pick your Location
1. Install the mounting bracket for the charger measured from the bottom of the bracket between 31.5 (80 cm)
and 47.2" (120 cm) above the ground.
2. Install the holster measured from the bottom between 31.5" (80 cm) and 43.3" (110 cm) above the ground.
1. To allow for proper airflow and working room, the charger should be located 12" (30.5 cm) from any other
equipment, walls, or other obstructions.
2. The bracket must be mounted on a flat surface so that the bracket does not deform when properly secured.
3. Plug-In Installation Note: Prior to mounting the charger, turn off the circuit breaker for the desired outlet and
plug in the charger. This will allow for proper placement of the charger. Be sure the plug cord has a gentle
curve and is not stretched.
1. When selecting a location to install the charger, make sure that when your electric vehicle is parked, the
charge cable can easily connect to the vehicle. Keep in mind where the vehicle’s charging port is located (it
varies from vehicle to vehicle) and how the vehicle will usually be parked.
2. The best installation locations have enough space to easily store the cable around the charger itself or the
holster provided with the charger and will not interfere with pathways or other items in the garage or
driveway.
