Electra IOD 7 Manuel utilisateur

Service Manual

Compact Series

REFRIGERANT

R407C

R22

COOLING ONLY

HEAT PUMP

SEPTEMBER - 2005

Indoor Units Outdoor Units

IOD 7 CON 7

IOD 9 CON 9

IOD 12 CON 12

LIST OF EFFECTIVE PAGES

Revision Y05-01 Service Manual - COMPACT

LIST OF EFFECTIVE PAGES

Note: Changes in the pages are indicated by a “Revision#” in the footer of each effected page

(when none indicates no changes in the relevant page). All pages in the following list represent

effected/ non effected pages divided by chapters.

Dates of issue for original and changed pages are:

Original ....... 0 ........ 15 December 2004

Total number of pages in this publication is 108 consisting of the following:

Page

No.

Revision

No. #

Page

No.

Revision

No. #

Page

No.

Revision

No. #

Title....................... 0

A ........................... 0

i............................. 0

1-1 - 1-4................ 0

2-1 - 2-6................ 0

3-1 - 3-2................ 0

4-1 - 4-2................ 0

5-1 - 5-24.............. 1

6-1 - 6-2................ 0

7-1 - 7-2................ 0

8-1 - 8-2................ 0

9-1 - 9-2................ 0

10-1-10-4.............. 0

11-1-11-2............... 0

12-1-12-32............ 0

13-1-13-2.............. 0

14-1-14-20............ 0

15-1-15-6.............. 0

Appendix -A...........0

• Zero in this column indicates an original page.

*Due to constant improvements please note that the data on this service manual can be modiﬁed

with out notice.

**Photos are not contractual

TABLE OF CONTENTS

Revision Y05-01Service Manual - COMPACT

Table of Contents

1. INTRODUCTION ...................................................................................................1-1

2. PRODUCT DATA SHEET......................................................................................2-1

3. RATING CONDITIONS..........................................................................................3-1

4. OUTLINE DIMENSIONS .......................................................................................4-1

5. PERFORMANCE DATA & PRESSURE CURVES ................................................5-1

6. SOUND LEVEL CHARACTERISTICS ..................................................................6-1

7. ELECTRICAL DATA..............................................................................................7-1

8. WIRING DIAGRAMS .............................................................................................8-1

9. ELECTRICAL CONNECTIONS.............................................................................9-1

10. REFRIGERATION DIAGRAMS.............................................................................10-1

11. TUBING CONNECTIONS......................................................................................11-1

12. CONTROL SYSTEM .............................................................................................12-1

13. TROUBLESHOOTING ..........................................................................................13-1

14. EXPLODED VIEWS AND SPARE PARTS LISTS.................................................14-1

15. OPTIONAL ACCESSORIES .................................................................................15-1

16. APPENDIX A

1-1

INTRODUCTION

Revision Y05-01Service Manual - COMPACT

1. INTRODUCTION

1.1 General

The new COMPACT split wall mounted range comprise the ST (cooling only)

and RC (heat pump) models, as follows:

• Cooling Only COMPACT 7 ST, COMPACT 9 ST, COMPACT 12 ST

• Heat Pump COMPACT 7 RC, COMPACT 9 RC, COMPACT 12 RC

The indoor COMPACT units are available as LED display types only, featuring esthetic

design, compact dimensions, and low noise operation.

1.2 Main Features

• R22 and R407C models

• Microprocessor control.

• Infrared remote control with liquid crystal display.

• Cross ﬂow fan, allowing low noise level operation.

• Indoor coil with treated aluminum ﬁns and coating for improved efﬁciency.

• Easy access to the interconnecting tubing and wiring connections, so that

removing the front grill or casing is not necessary.

• Refrigerant pipes can be connected to the indoor unit from 6 different optional

directions.

• Automatic treated air sweep.

• Low indoor and outdoor noise levels.

• Easy installation and service.

1-2

INTRODUCTION

Revision Y05-01 Service Manual - COMPACT

1.3 Indoor Unit

The indoor unit is wall mounted, and can be easily ﬁtted to many types of residential

and commercials applications.

It includes:

• Casing with air inlet and outlet grills.

• tangential fan.

• Coil with treated aluminum ﬁns.

• Motorized ﬂaps

• Multi-speed motor with internal protection

• Advanced electronic control box assembly

• Interconnecting wiring terminal block

• Mounting plate

1.4 Filtration

The COMPACT series presents several types of air ﬁlters:

• Easily accessible, and re-usable pre-ﬁlters (mesh)

• Pre-charged electrostatic ﬁlter (disposable) – optional

• Active carbon ﬁlter (disposable) – optional

1.5 Control

The microprocessor indoor controller, and an infrared remote control, supplied as

standard, provides complete operating function and programming. For further details

please refer to the Operation Manual, Appendix A.

1.6 Outdoor Unit

The COMPACT outdoor units can be installed as ﬂoor or wall mounted units by using

a wall supporting bracket. The metal sheets are protected by anti- corrosion paint work

allowing long life resistance. All outdoor units are pre-charged. For further information

please refer to the Product Data Sheet, Chapter 2.

It includes :

• A Rotary Compressor mounted in a soundproofed compartment :

• Axial fan.

• Outdoor coil with hydrophilic louver ﬁns for RC units.

• Outlet air fan grill.

• Service valves” ﬂare” type connection.

• Interconnecting wiring terminal block.

1-3

INTRODUCTION

Revision Y05-01Service Manual - COMPACT

1.7 Tubing Connections

Flare type interconnecting tubing to be produced on site.

For further details please refer to the Installation Manual, Appendix A.

1.8 Accessories

ASK (All Season Kit):

For low ambient working conditions in cooling, an ASK can be installed inside the

outdoor unit. This kit allows cooling operation down to outdoor temp of -10 ºC by

gradually controlling the outdoor fan speed motor.

RCW Wall Mounted Remote Control

The RCW remote control is mounted on the wall, and controls the unit either as an

infrared remote control or as a wired controller. The wired controller can control up to

10 Indoor units with the same program settings and adjustments.

For further details please refer to Optional Accessories, Chapter 15.

1.9 Inbox Documentation

Each unit is supplied with its own installation and operation manuals.

1.10 Matching Table

1.10.1 R407C / R22

OUTDOOR UNITS

INDOOR UNITS

MODEL REF’ IOD 7 IOD 9 IOD 12

CON 7 ST/ RC R407C/R22 √

CON 9 ST/ RC R407C/R22 √

CON 12 ST/ RC R407C/R22 √

2-1

PRODUCT DATA SHEET

Revision Y05-01Service Manual - COMPACT

2. PRODUCT DATA SHEET

2.1 R407C

Model Indoor Unit IOD-7

Model Outdoor Unit CON-7

Installation Method of Pipe Flared

Characteristics Units Cooling Only Cooling Heating

Capacity (1) Btu/hr 7230 7230 7400

kW 2.12 2.12 2.17

Power input (1) kW 0.83 0.83 0.73

EER (Cooling) or COP(Heating) (1) W/W 2.55 2.55 2.97

Energy efﬁciency class EED

Power supply V/Ph/Hz 230V/Single/50Hz

Rated current A 3.7 3.7 3.3

Starting current A 18

Circuit breaker rating A 10

INDOOR

Fan type & quantity Cross ﬂow x 1

Fan speeds H/M/L RPM 1150/950

Air ﬂow(2) H/M/L m3/hr 400/320

External static pressure Min-Max Pa 0

Sound power level (3) H/M/L dB(A) 50/45

Sound pressure level(4) H/M/L dB(A) 37/31

Moisture removal l/hr 0.7

Condensate drain tube I.D mm 16

Dimensions WxHxD mm 680*250*180

Weight kg 7

Package dimensions WxHxD mm 770*265*325

Packaged weight kg 9.5

Units per pallet units 36

Stacking height units 9 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type, model Rotary, HITACHI CG433EG1UC

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 850

Air ﬂow H/L m3/hr 1200

Sound power level H/L dB(A) 61 62

Sound pressure level(4) H/L dB(A) 51 52

Dimensions WxHxD mm 610*520*240

Weight kg 24 24.5

Package dimensions WxHxD mm 730*560*350

Packaged weight kg 26.5 26.5

Units per pallet Units 12

Stacking height units 4 levels

Refrigerant type R407C

Refrigerant chargless distance kg/m 0.58kg/m

Additional charge per 1 meter g/m 4m<Lin<8m:+5g/m Lin>8m:+9g/m

Connections between

units

Liquid line In.(mm) Ф 1/4”(6.35)

Suction line In.(mm) Ф 3/8”(9.53)

Max.tubing length m. Max.10

Max.height

difference m. Max.7

Operation control type Remote control

Heating elements kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

2-2

PRODUCT DATA SHEET

Revision Y05-01 Service Manual - COMPACT

Model Indoor Unit IOD-9

Model Outdoor Unit CON-9

Installation Method of Pipe Flared

Characteristics Units Cooling Only Cooling Heating

Capacity (1) Btu/hr 8530 8530 9080

kW 2.5 2.5 2.66

Power input (1) kW 1.03 1.03 0.93

EER (Cooling) or COP(Heating) (1) W/W 2.43 2.43 2.86

Energy efﬁciency class EED

Power supply V/Ph/Hz 230V/Single/50Hz

Rated current A 4.5 4.5 4.0

Starting current A 20

Circuit breaker rating A 10

INDOOR

Fan type & quantity Cross ﬂow x 1

Fan speeds H/M/L RPM 1250/1050

Air ﬂow (2) H/M/L m3/hr 450/350

External static pressure Min-Max Pa 0

Sound power level (3) H/M/L dB(A) 52/47

Sound pressure level(4) H/M/L dB(A) 40/36

Moisture removal l/hr 1

Condensate drain tube I.D mm 16

Dimensions WxHxD mm 680*250*180

Weight kg 7

Package dimensions WxHxD mm 770*265*325

Packaged weight kg 9.5

Units per pallet units 36

Stacking height units 9 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type, model Rotary, TOSHIBA PG170X1C-4DZ3

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 900

Air ﬂow H/L m3/hr 1265

Sound power level H/L dB(A) 62 63

Sound pressure level(4) H/L dB(A) 52 53

Dimensions WxHxD mm 610*520*240

Weight kg 26 26.5

Package dimensions WxHxD mm 730*560*350

Packaged weight kg 29 29

Units per pallet Units 12

Stacking height units 4 levels

Refrigerant type R407C

Refrigerant chargless distance kg/m 0.63kg/m

Additional charge per 1 meter g/m 4m<Lin<8m:+5g/m Lin>8m:+15g/m

Connections between

units

Liquid line In.(mm) Ф 1/4”(6.35)

Suction line In.(mm) Ф 3/8”(9.53)

Max.tubing length m. Max.12

Max.height

difference m. Max.7

Operation control type Remote control

Heating elements kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

2-3

PRODUCT DATA SHEET

Revision Y05-01Service Manual - COMPACT

Model Indoor Unit IOD-12

Model Outdoor Unit CON-12

Installation Method of Pipe Flared

Characteristics Units Cooling Only Cooling Heating

Capacity (1) Btu/hr 12620 12450 12620

kW 3.7 3.65 3.7

Power input (1) kW 1.29 1.26 1.25

EER (Cooling) or COP(Heating) (1) W/W 2.87 2.90 2.96

Energy efﬁciency class CCD

Power supply V/Ph/Hz 230V/Single/50Hz

Rated current A 5.7 5.7 6.0

Starting current A 30

Circuit breaker rating A 15

INDOOR

Fan type & quantity Cross ﬂow x 1

Fan speeds H/M/L RPM 1250/1000

Air ﬂow (2) H/M/L m3/hr 600/450

External static pressure Min-Max Pa 0

Sound power level (3) H/M/L dB(A) 54/47

Sound pressure level(4) H/M/L dB(A) 42/36

Moisture removal l/hr 1.7

Condensate drain tube I.D mm 16

Dimensions WxHxD mm 840*250*180

Weight kg 8

Package dimensions WxHxD mm 930*265*325

Packaged weight kg 11

Units per pallet units 36

Stacking height units 9 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type, model Rotary, TOSHIBA PG215X2C-4FS

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 735

Air ﬂow H/L m3/hr 1550

Sound power level H/L dB(A) 66 67

Sound pressure level(4) H/L dB(A) 56 57

Dimensions WxHxD mm 760*545*245

Weight kg 37 38

Package dimensions WxHxD mm 880*610*310

Packaged weight kg 40.5 40.5

Units per pallet Units 12

Stacking height units 4 levels

Refrigerant type R407C

Refrigerant chargless distance kg/m 1.015kg/m

Additional charge per 1 meter g/m 4m<Lin<7.5m:+10g/m 7.5M>Lin>15m:+15g/m

Connections between

units

Liquid line In.(mm) Ф 1/4”(6.35)

Suction line In.(mm) Ф 1/2”(12.7)

Max.tubing length m. Max.15

Max.height

difference m. Max.7

Operation control type Remote control

Heating elements kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

2-4

PRODUCT DATA SHEET

Revision Y05-01 Service Manual - COMPACT

1.2 R22

Model Indoor Unit IOD-7

Model Outdoor Unit CON-7

Installation Method of Pipe Flared

Characteristics Units cooling only Cooling Heating

Capacity (1) Btu/hr 7230 7230 7340

kW 2.12 2.12 2.15

Power input (1) kW 0.75 0.75 0.67

EER (Cooling) or COP(Heating) (1) W/W 2.83 2.83 3.21

Energy efﬁciency class CCC

Power supply V/Ph/Hz 230V/Single/50Hz

Rated current A 3.4 3.4 3.1

Starting current A 16

Circuit breaker rating A 10

INDOOR

Fan type & quantity Cross ﬂow x 1

Fan speeds H/M/L RPM 1150/950

Air ﬂow (2) H/M/L m3/hr 400/320

External static pressure Min-Max Pa 0

Sound power level (3) H/M/L dB(A) 50/45

Sound pressure level(4) H/M/L dB(A) 37/31

Moisture removal l/hr 0.7

Condensate drain tube I.D mm 16

Dimensions WxHxD mm 680*180*250

Weight kg 7

Package dimensions WxHxD mm 770*325*265

Packaged weight kg 9.5

Units per pallet units 36

Stacking height units 9 levels

OUTDOOR

Refrigerant control Capillary tube

Compressor type, model Rotary, HITACHI SD134CV-H6AU

Fan type & quantity Propeller(direct) x 1

Fan speeds H/L RPM 850

Air ﬂow H/L m3/hr 1200

Sound power level H/L dB(A) 61 62

Sound pressure level(4) H/L dB(A) 51 52

Dimensions WxHxD mm 610*240*520

Weight kg 23

Package dimensions WxHxD mm 730*350*560

Packaged weight kg 26.5 26.5

Units per pallet Units 12

Stacking height units 4 levels

Refrigerant type R22

Refrigerant chargless distance kg/m 0.5kg/m

Additional charge per 1 meter g/m 4m<Lin<8m:+5g/m Lin>8m:+9g/m

Connections between

units

Liquid line In.(mm) 1/4”(6.35)

Suction line In.(mm) 3/8”(9.53)

Max.tubing length m. Max.10

Max.height

difference m. Max.7

Operation control type Remote control

Heating elements kW

Others

(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units) and EN14511.

(2) Airﬂow in ducted units; at nominal external static pressure.

(3) Sound power in ducted units is measured at air discharge.

(4) Sound pressure level measured at 1 meter distance from unit.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Electra Climatiseur

Electra

Electra DCI Light Commercial Series Manuel utilisateur

Electra

Electra LS DCI Series Manuel utilisateur

Electra

Electra Trio Delta 5.2 Manuel utilisateur

Electra

Electra EMD 27 Manuel utilisateur

Electra

Electra WNG 36 Manuel utilisateur

Electra

Electra KN 30 RC Manuel utilisateur

Electra

Electra JKD DCI Series Manuel utilisateur

Electra

Electra DELTA 25 Manuel utilisateur

Electra

Electra Alpha 7 Manuel utilisateur

Electra

Electra LEX 7 Manuel utilisateur

Electra

Electra LS 35 Manuel utilisateur

Electra

Electra Alpha 7 Manuel utilisateur

Electra

Electra ELSI-JGF009-N11 Manuel utilisateur

Electra

Electra WNG 25 DCI Series Manuel utilisateur

Electra

Electra COMPACT 7 Manuel d'utilisation

Electra

Electra ELSI-JKD009-N11 Manuel utilisateur

Electra

Electra DNG DC Series Manuel utilisateur

Electra

Electra LEX 25 DCI Manuel utilisateur

Electra

Electra PXD 9 RC Manuel utilisateur

Electra

Electra TRIO 72 DCI Manuel utilisateur

Electra

Electra PXD912 Manuel utilisateur

Electra

Electra WNG 9 DCI INV Manuel utilisateur

Electra

Electra Alpha 9 SP R22 Manuel utilisateur

Electra

Electra ELSI-JKD009-N11 Manuel utilisateur

Manuels Climatiseur populaires d'autres marques

Spheros

Spheros CC 355 Manuel utilisateur

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuel utilisateur

Panasonic

Panasonic CS-E12HKEW Manuel utilisateur

nedis

nedis ACMB1WT7 Manuel utilisateur

Samsung

Samsung AR KV Series Mode d’emploi

Daikin

Daikin FCFV50A Manuel utilisateur

Fujitsu

Fujitsu Inverter ASBA30JFC Manuel utilisateur

Toshiba

Toshiba RAS-M10SMUV-E Manuel utilisateur

Daikin

Daikin FXLQ20MAVE Manuel utilisateur

Hitachi

Hitachi RAS-E24CAK Manuel utilisateur

CIAT

CIAT Magister 2 Series Mode d’emploi

Bestron

Bestron AAC6000 Manuel utilisateur

Hisense

Hisense 7K Manuel technique

Frigidaire

Frigidaire FFRE0533S1E0 Manuel utilisateur

Samsung

Samsung AS09HM3N Manuel utilisateur

Frigidaire

Frigidaire CRA073PU11 Manuel du propriétaire

Soleus Air

Soleus Air GB-PAC-08E4 Manuel utilisateur

McQuay

McQuay MCK020A Manuel utilisateur
