WIRELESS SMOKE DETECTOR

WIRELESS SMOKE & CO DETECTOR

COMPLIES WITH EN 14 6042005

USER GUIDE

V2.0

EWF1

EWF1CO

EN RU LT IT

EWF1 is a wireless smoke detector; EWF1CO is a wireless carbon monoxide

(CO) detector combined with smoke detector. In case of smoke detecion or car-

bon monoxide level increase, EWF1/EWF1CO will indicate the alarm and noify

ELDES system about the event.

EWF1     ; EWF1CO -

      ( ),

   .   

   CO, EWF1/EWF1CO    

     ELDES.

EWF1 yra belaidis opinio ipo dūmų juiklis; EWF1CO yra belaidis elektroche-

minis anglies monoksido (CO) ir opinio ipo dūmų juiklis. Apikus dūmus arba

viršytą CO lygį, EWF1/EWF1CO sukelia aliarmą ir belaidžiu ryšiu siunčia signalą

į ELDES apsaugos sistemą.

EWF1 è un rivelatore fotoeletrico di fumo senza ili; EWF1CO è un rivelatore

combinato fotoeletrico ed eletrochimico di monossido di carbonio (Co) sen-

za ili. Quando la concentrazione di fumo / Co supera un livello determinato,

EWF1/EWF1CO l’analizzatore indicherà il simbolo allarme e avvisare ELDES

system di eveni.

EWF1-EWF1COEN | RU | LT | IT

0,9m

(2.95 ft)

0,9m

(2.95 ft)

MIN

+5°C(41°F)

MAX

+45°C (113°F)

MIN

+5°C(41°F)

MAX

+45°C (113°F)

MIN

+5°C(41°F)

MAX

+45°C (113°F)

EWF1-EWF1CO EN | RU | LT | IT

3 MIN.

TEST

ELDES

Coniguraion

Tool

WAIT FOR 3 MIN.

 3 .

PALAUKITE 3 MIN.

ATTENDERE PER 3 MIN.

PRESS FOR 2 SEC.

   2 .

SPAUSKITE 2 SEK.

PREMERE PER 2 SEC.

EWF1-EWF1COEN

1. PLACEMENT

1. Place the detector as close as possible to the center of the ceiling. If not possible, mount no closer

than 10cm (0.33t) from a wall or corner. Also, if local codes allow, install the detectors on walls,

between 10 and 30cm (0.33 and 0.98t) from ceiling/wall intersecions.

2. Install a minimum of two units in every house, no mater how small the house is.

3. Place a detector in each room that is divided by a parial wall.

For best protecion we recommend that you install a detector in every room.

DO NOT place EWF1/EWF1CO in the following locaions:

• Near appliances or areas where normal combusion regularly occurs (kitchens, near furnaces,

hot water heaters). Use specialized detector with unwanted alarm control for this areas.

• In areas with high humidity, like bathrooms or areas near dishwashers or washing machines.

Install at least 3m (9.84t) away from these areas.

• Near air returns or heaing and cooling supply vents. Install at least 1m (3.28t) away from these

areas. The air could blow smoke away from the detector, interruping the alarm.

• In rooms where temperatures may fall below +5°C (+41°F) or rise above +45°C (+113°F).

• In extremely dusty, dirty, or insect-infested areas where loose paricles interfere with the detec-

tor operaion.

Incorrect placement will result in the decrease of operaional efeciveness.

EWF1-EWF1CO EN

2. WHAT SHOULD I KNOW

2.1 CARBON MONOXIDE CO POISONING

Carbon monoxide is a product of incomplete combusion of organic mater. It is a toxic

gas, but, being colorless, odorless, tasteless, and iniially non-irritaing, it is very dii-

cult for people to detect.

CONCENTRATION SYMPTOMS

35 ppm (0.0035%) Headache and dizziness within six to eight hours of

constant exposure

100 ppm (0.01%) Slight headache in two to three hours

200 ppm (0.02%) Slight headache within two to three hours; loss of

judgment

400 ppm (0.04%) Frontal headache within one to two hours

800 ppm (0.08%) Dizziness, nausea, and convulsions within 45 min; insen-

sible within 2 hours

1,600 ppm (0.16%) Headache, increased heart rate, dizziness, and nausea

within 20 min; death in less than 2 hours

ppm - Parts Per Million - is used to describe concentraions of contaminants in air.

In the event of ALARM caused by a criical CO concentraion level, keep calm and

carry out the following acions in the priority order:

• Open all windows and doors to increase the rate of venilaion.

• Turn of the appliances and stop using them where possible.

• Evacuate the building leaving the windows and doors open. You may re-enter the

property only when the alarm has stopped.

• Get immediate medical assistance for anyone sufering the efects of carbon mon-

oxide poisoning (nausea, headache), and report that carbon monoxide inhalaion is

suspected. Contact the gas or other fuel supplier on their emergency phone number

in order to idenify and eliminate the source of carbon monoxide emissions.

EWF1-EWF1COEN

• Do not use the appliance again unil it has been veriied and conirmed by a compe-

tent person according to naional regulaions.

There could be other sources of carbon monoxide emissions. For example, large

amount of city gas, tobacco smoke or smoldering ire can cause CO concentra-

ion ALARM.

2.2 CO ALARM/RESTORE AND FAULT INDICATIONS

• Fresh air level - when CO concentraion is 0-29ppm. This level causes no alarm when reached

as well as it results in zone restore event when one of the criical levels has been reached and

decreased to 0-29ppm aterwards. The zone restore event is indicated by SMS text message

delivered to the listed user phone number and data message delivered to the monitoring staion

followed by silenced sirens. Also, data message noifying about CO gas fault is delivered to EL-

DES Cloud Services and added to the Event Log.

• CO criical level 1 – when CO concentraion of 30-49ppm remains for more than 120 minutes.

Indicated by fault indicaion displayed by EKB2 LCD keypad (only for ESIM364) and a warning

delivery to the listed user by SMS text message. This level causes no zone alarm when reached

as well as it results in zone restore event in case the CO concentraion of 300ppm or more (crit-

ical level 4) has been reached and decreased to 30-49ppm aterwards. Also, data messages

noifying about CO criical level 1 and gas fault detecion are delivered to ELDES Cloud Services

and added to both Event Log and Fault Log respecively.

• CO criical level 2 – when CO concentraion of 50-99ppm remains for more than 60 minutes.

Indicated by a 2-second beep every 5 seconds, LED indicator lash, fault indicaion displayed

by EKB2 LCD keypad (only for ESIM364) and a warning delivered to the listed user by SMS text

message. This level causes no zone alarm when reached. Also, data messages noifying about

CO criical level 2 and gas fault detecion are delivered to ELDES Cloud Services and added to

both Event Log and Fault Log respecively.

• CO criical level 3 – when CO concentraion of 100-299ppm remains for more than 10 minutes.

Indicated by a 2-second beep every 5 seconds, LED indicator lash and fault indicaion displayed
