Heater Connection Requirements
1. The heater is connected to an alternating current network with a voltage of 220-240 volts.
2. The heater (s) are connected to a separate line with a circuit breaker with a current cut-off rating
corresponding to the power of the heater (s).
When installing the line, use a cable and sockets corresponding to the power consumption of the heater
(s).
Do not neglect grounding.
!!! Do not use an aluminum cable for the wiring device.
!!! Do not use extension cords as they are not designed to connect powerful consumers.
Safety warnings
1. Use the heater only for its intended purpose.
2. Observe the required distances to the suspension height when installing and using the heater. Heater
suspension height - not less than 1500 mm, distance to heated surfaces - not less than 600 mm.
3. Do not place or store flammable objects and materials in the place where the heater is used.
4. Do not touch the parts of the heater during operation, and do not allow children and pets to come into
contact with the heater.
5. Unplug the power cord from the outlet whenever the heater is not in use.
Heater remote control
There are 3 buttons on the remote control panel. Button 1 (bottom right) - power on /
off. Buttons 2 and 3 - selection of 4 heating power modes. The selected mode is displayed
on the display of the heater control module. It is possible to control several heaters using one
remote control.
Heater maintenance
• In order to ensure stable operation of the product, regularly inspect the heater and the supply
cable for external damage;
• As the heater and reflector become dirty, clean in the following order:
- make sure that the heater has not been used in the near future and that the casing of the heater is at ambient
temperature;
- disconnect the heater from the power source, remove it from the attachment point and place it on a horizontal
surface;
- clean the external elements of the heater with a dry, clean soft cloth;
- remove the side (left) cover of the heater casing, for which unscrew two screws from the end of the heater
and two screws from the rear wall of its casing;
- carefully slide the protective grille to the left up to the side wall of the reflector;
- clean the internal elements of the compartment with a dry clean soft cloth (it is allowed to use a vacuum
cleaner or a hair dryer without contact with the heater elements);
!!! Use clean cotton gloves to clean to avoid skin contact with the IR lamp. Direct contact with the lamp will
leave prints, which will negatively affect its operation and reduce the resource;
- after cleaning the internal elements of the heater, reassemble in the reverse order and install the heater in
the workplace.
Warranty
During the warranty period, the ELCON company removes the detected product defects free of charge,
in the manner prescribed by the law "On Protection of Consumer Rights", provided that the consumer
observes the rules of operation and storage, the safety of seals and the absence of mechanical damage to
the product.
