Important information
The burners of type EK 6.../ 7.../ 8.../
9...L-E have been designed for the
combustion of light fuel oil EL.
The burners should be installed and
taken into operation by qualified person-
nel only who will be responsible for the
proper performance of this work in
accordance with the applicable regulati-
ons and guidelines.
Any repair work on monitors, limiters
and automatic furnace controllers and
on the other safety facilities are allowed
to be done only by the manufacturers
themselves or specialists authorized by
them. Original parts should only be
exchanged by a duly qualified specia-
list.
Standards and regulations
The following standards should be
observed in the interest of a safe, easy-
on-the-environment and energy-saving
operation of the burner:
According to DIN 4755, the user must
be instructed in the operation of the bur-
ner.
For the installation of an oil furnace
system, care should be taken to
observe DIN 4755, TRbF (Technical
Regulation onCombustible Liquids) and
the local furnace construction regulati-
ons applicable in the country.
Place of installation
The burner must not be operated in
rooms containing aggressive vapours
(e.g. spray, perchloroethylene, hydro-
carbon tetrachloride, solvent, etc.) or
tending to heavy dust formation or high
air humidity.
Adequate ventilation must be provided
at the place of installation of the furnace
system to ensure a reliable supply with
combustion air.
Maintenance
The furnace system should be serviced
at least once a year by an authorized
specialist. It is recommended to con-
clude a maintenance agreement to this
effect.
Warranty
Manufacturer will not accept any war-
ranty if the operating instructions have
not been duly observed in the start-up
and maintenance of the burner and
damages have been caused by impro-
per installation, incorrect adjustment,
unauthorized interference or operating
errors.
Product description
The burners of type EK 6.../EK 7.../EK
8.../EK9...L-E can be used for the com-
bustion of light fuel oil EL according DIN
51603-1.
The burners are equipped with combu-
stion air fan andair pressure switch with
test key, windbox with actuator for the
air control dampers, oil pressure atomi-
zer with oil high-pressure pump, nozzle
rod, return nozzle and oil hydraulics
block (with pressure switches, valves
and control shaft), pressure hoses and
electric ignition system.
The burners are designed to operate
with an electronic compound control
system.
EN267/
DIN4787 Oil atomizer burners
VDE 0116 Electrical Equipment
of furnace
