Elation PALADIN Manuel utilisateur

PALADIN PANEL™

User Manual

images, and instructions herein are subject to change without notice. ELATION

PROFESSIONAL logo and identifying product names and numbers herein are trademarks of

ELATION PROFESSIONAL. Copyright protection claimed includes all forms and matters of

copyrightable materials and information now allowed by statutory or judicial law or

hereinafter granted. Product names used in this document may be trademarks or

registered trademarks of their respective companies and are hereby acknowledged. All

non-ELATION brands and product names are trademarks or registered trademarks of their

respective companies.

ELATION PROFESSIONAL and all affiliated companies hereby disclaim any and all liabilities

for property, equipment, building, and electrical damages, injuries to any persons, and direct

or indirect economic loss associated with the use or reliance of any information contained

within this document, and/or as a result of the improper, unsafe, insufficient and negligent

assembly, installation, rigging, and operation of this product.

Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040

323-582-3322 |323-832-9142 fax | www.elationlighting.com |info@elationlighting.com

Elation Professional B.V. | Junostraat 2 | 6468 EW Kerkrade, The Netherlands

+31 45 546 85 66 |+31 45 546 85 96 fax |www.elationlighting.eu |info@elationlighting.eu

Elation Professional Mexico | AV Santa Ana 30 | Parque Industrial Lerma, Lerma, Mexico 52000

+52 (728) 282-7070

DOCUMENT VERSION

Due to additional product features and/or enhancements,

an updated version of this document may be available

online. Please scan the QR Code with your mobile device or

visit www.elationlighting.com for the latest revision/update of

this manual, before installation and/or programming.

Date

Document

Version

Software

Version ≥

DMX

Channel Modes

Notes

07/30/19

1.0

1.0.1

RGB – 3/4/8/10/16/80/82/88

HSI – 4 / 10 / 38

Initial release.

08/19/19

1.1

N/C

NO CHANGE

Updated release.

CONTENTS

General Information

Warranty Returns (USA Only)

Safety Guidelines

Maintenance Guidelines

Fixture Overview

Fixture Installation

System Menu

Pixel Zone Control

E-FLY Wireless DMX Set Up

DMX Channel Functions and Values

Specifications

Optional Accessories

GENERAL INFORMATION

INTRODUCTION

Please read and understand all the safety and use instructions in this manual carefully and

thoroughly before attempting to operate this device.

IP65 RATED

An IP rated lighting fixture is one, which is commonly installed in outdoor environments and

has been designed with an enclosure that effectively protects the ingress (entry) of external

foreign objects such as dust and water. The International Protection (IP) rating system is

commonly expressed as "IP" (Ingress Protection) followed by two numbers (i.e. IP65) where

the numbers define the degree of protection. The first digit (Foreign Bodies Protection)

indicates the extent of protection against particles entering the fixture and the second digit

(Water Protection) indicates the extent of protection against water entering the fixture. An

IP65 rated lighting fixture is one, which has been designed and tested to protect against the

ingress of dust (6) and high-pressure water jets from any direction (5).

UNPACKING

Every device has been thoroughly tested and has been shipped in perfect operating

condition. Carefully check the shipping carton for damage that may have occurred during

shipping. If the carton is damaged, carefully inspect the device for damage, and be sure all

accessories necessary to install and operate the device have arrived intact. In the event

damage has been found or parts are missing, please contact our customer support team for

further instructions. Please do not return this device to your dealer without first contacting

customer support. Please do not discard the shipping carton in the trash. Please recycle

whenever possible.

CUSTOMER SUPPORT

Contact ELATION Service for any product related service and support needs.

Also visit forums.elationlighting.com with questions, comments or suggestions.

ELATION SERVICE USA - Monday - Friday 8:00am to 4:30pm PST

323-582-3322 | Fax 323-832-9142 | support@elationlighting.com

ELATION SERVICE EUROPE - Monday - Friday 08:30 to 17:00 CET

+31 45 546 85 63 | Fax +31 45 546 85 96 | suppo[email protected]

REPLACEMENT PARTS please visit parts.elationlighting.com

WARRANTY RETURNS (USA ONLY)

To obtain warranty service, a Return Materials Authorization (RMA) number must first be

obtained from ELATION. It is the Customer’s responsibility to provide product proof of

purchase and serial number by acceptable evidence (i.e. invoice copy and/or Extended

Warranty Certificate), and any applicable maintenance records at the time warranty service

is sought. Failure to provide acceptable evidence of product proof of purchase, serial

number, and applicable maintenance records may be cause for denial of warranty service.

Products returned for warranty service must be sent without any accessories (i.e. power,

data, and safety cables, brackets, clamps, rigging hardware, frost filters, gel frames, barn

doors, lens, hoses, nozzles, rack mounting hardware, etc.), must be boxed using the original

and/or suitable packaging materials (double-box and foam) that provide ample product

protection for ground and/or air freight transit, and must be shipped freight pre-paid and

insured to ELATION in Los Angeles, CA or to an ELATION Authorized Service Center. The

RMA number must be clearly written on the outside of the return box and a brief description

of the problem and the RMA number must be documented and included in the box.

Products returned for warranty service without an RMA number clearly marked on the

outside of the package will be refused and returned to the shipper at the customer’s expense.

Products returned for warranty service, which are received damaged due to poor and

improper packaging and/or due to damage caused by shipping carrier, may incur additional

repair charges before warranty service begins and/or may void this warranty. If any product

accessories (included and/or optional) are shipped with the product, ELATION and/or the

ELATION Authorized Service Center shall have no liability what so ever for the loss and/or

damage to any such accessories, nor for the safe return thereof. If the requested warranty

repairs or service (including parts replacement) are within the terms of this warranty,

ELATION will pay return shipping charges to a single designated point within the United

States.

SAFETY GUIDELINES

This fixture is a sophisticated piece of electronic equipment. To guarantee a smooth

operation, it is important to follow all instructions and guidelines in this manual. Elation

Professional is not responsible for injury and/or damages resulting from the misuse of this

fixture due to the disregard of the information printed in this manual. Only qualified and/or

certified personnel should perform installation of this fixture and only the original rigging

parts (omega brackets) included with this fixture should be used for installation. Any

modifications to the fixture and/or the included mounting hardware will void the original

manufactures warranty and increase the risk of damage and/or personal injury.

PROTECTION CLASS 1 - FIXTURE MUST BE PROPERLY GROUNDED

THERE ARE NO USER SERVICEABLE PARTS INSIDE THIS UNIT.

DO NOT ATTEMPT ANY REPAIRS YOURSELF; DOING SO WILL VOID

YOUR MANUFACTURES WARRANTY. DAMAGES RESULTING FROM

MODIFICATIONS TO THIS FIXTURE AND/OR THE DISREGARD OF

SAFETY INSTRUCTIONS AND GUIDELINES IN THIS MANUAL VOID

THE MANUFACTURES WARRANTY AND ARE NOT SUBJECT TO ANY

WARRANTY CLAIMS AND/OR REPAIRS.

DO NOT PLUG FIXTURE INTO A DIMMER PACK!

NEVER OPEN THIS FIXTURE WHILE IN USE!

UNPLUG POWER BEFORE SERVICING FIXTURE!

NEVER TOUCH FIXTURE DURING OPERATION, AS IT MAY BE HOT!

KEEP FLAMMABLE MATERIALS AWAY FROM FIXTURE!

NEVER LOOK DIRECTLY INTO THE LIGHT SOURCE!

RETINA INJURY RISK - MAY INDUCE BLINDNESS!

SENSITIVE PERSONS MAY SUFFER AN EPILEPTIC SHOCK!

ENSURE ALL CONNECTIONS AND END CAPS ARE PROPERLY

SEALED WITH A DIELECTRIC GREASE (AVAILABLE AT MOST

ELECTRICAL SUPPLIERS) TO PREVENT WATER CORROSION AND/OR

ELECTRICAL SHORT CIRCUIT.

MINIMUM DISTANCE TO OBJECTS/SURFACES

MUST BE 1.6 FOOT (0.5 METER)

MINIMUM DISTANCE OF INFLAMMABLE MATERIALS

FROM THE SURFACE 1.6 FEET (0.5 METER)

MAXIMUM AMBIENT OPERATING TEMPERATURE 113°F. (45°C)

SAFETY GUIDELINES

DO NOT TOUCH the fixture housing during operation. Turn OFF the power and allow

approximately 15 minutes for the fixture to cool down before serving.

DO NOT shake fixture, avoid brute force when installing and/or operating fixture.

DO NOT operate fixture if the power cord is frayed, crimped, damaged and/or if any of the

power cord connectors are damaged and do not insert into the fixture securely with ease.

NEVER force a power cord connector into the fixture. If the power cord or any of its

connectors are damaged, replace it immediately with a new one of similar power rating.

DO NOT block any air ventilation slots.

All fan and air inlets must remain clean and never blocked.

Allow approx. 6” (15cm) between fixture and other devices or a wall for proper cooling.

Always disconnect fixture from main power source before performing any type of service

and/or cleaning procedure. Only handle the power cord by the plug end, never pull out the

plug by tugging the wire portion of the cord.

During the initial operation of this fixture, a light smoke or smell may emit from the interior of

the fixture. This is a normal process and is caused by excess paint in the interior of the casing

burning off from the heat associated with the lamp and will decrease gradually over time.

Consistent operational breaks will ensure fixture will function properly for many years.

ONLY use the original packaging and materials to transport the fixture in for service.

MAINTENANCE GUIDELINES

DISCONNECT POWER BEFORE PERFORMING ANY MAINTENANCE!

CLEANING

Frequent cleaning is recommended to insure proper function, optimized light output, and

an extended life. The frequency of cleaning depends on the environment in which the

fixture operates: damp, smoky or particularly dirty environments can cause greater

accumulation of dirt on the fixture’s optics. Clean the external lens surface at least every

20 days with a soft cloth to avoid dirt/debris accumulation.

NEVER use alcohol, solvents, or ammonia-based cleaners.

MAINTENANCE

Regular inspections are recommended to insure proper function and extended life.

There are no user serviceable parts inside this fixture, please refer all other service issues

to an authorized Elation service technician. Should you need any spare parts, please order

genuine parts from your local Elation dealer.

Please refer to the following points during routine inspections:

A detailed electric check by an approved electrical engineer every three months, to make

sure the circuit contacts are in good condition and prevent overheating.

Be sure all screws and fasteners are securely tightened at all times. Lose screws may fall out

during normal operation resulting in damage or injury as larger parts could fall.

Check for any deformations on the housing, color lenses, rigging hardware and rigging

points (ceiling, suspension, trussing). Deformations in the housing could allow for dust to

enter into the fixture. Damaged rigging points or unsecured rigging could cause the fixture

to fall and seriously injure a person(s).

Electric power supply cables must not show any damage, material fatigue or sediments.

NEVER remove the ground prong from the power cable.

FIXTURE OVERVIEW

FRONT

LED Array

Removable Magnetic Frost Filter

SIDES

Manual Tilt Adjustment Knobs

BACK

Carrying Handle

OLED Control System Menu Display

Mode, Down, Up, Enter Buttons

IP65 Twist Lock Power In/Out

IP65 5pin DMX In/Out

E-FLY Wireless DMX Antenna

BOX CONTENTS

Magnetic Frost Filter

Frost Filter Safety Cable

Fixture Safety Cable

Omega Brackets (x2)

IP65 Twist Lock Power Cable

FIXTURE INSTALLATION

FLAMMABLE MATERIAL WARNING

Keep fixture minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotechnics.

ELECTRICAL CONNECTIONS

A qualified electrician should be used for all electrical connections and/or installations.

USE CAUTION WHEN POWER LINKING OTHER MODEL FIXTURES AS THE

POWER CONSUMPTION OF OTHER MODEL FIXTURES MAY EXCEED THE MAX

POWER OUTPUT ON THIS FIXTURE. CHECK SILK SCREEN FOR MAX AMPS.

MINIMUM DISTANCE TO OBJECTS/SURFACES

MUST BE 1.6 FOOT (0.5 METER)

MINIMUM DISTANCE OF INFLAMMABLE MATERIALS

FROM THE SURFACE 1.6 FEET (0.5 METER)

MAXIMUM AMBIENT OPERATING TEMPERATURE 113°F. (45°C)

DO NOT INSTALL THE FIXTURE IF YOU ARE NOT QUALIFIED TO DO SO!

Fixture MUST be installed following all local, national, and country commercial electrical and

construction codes and regulations.

Before rigging/mounting a single fixture or multiple fixtures to any metal truss/structure or

placing the fixture(s) on any surface, a professional equipment installer MUST be consulted

to determine if the metal truss/structure or surface is properly certified to safely hold the

combined weight of the fixture(s), clamps, cables, and accessories.

Overhead rigging requires extensive experience, including amongst others calculating

working load limits, installation material being used, and periodic safety inspection of all

installation material and the fixture. If you lack these qualifications, do not attempt the

installation yourself. Improper installation can result in bodily injury.

Maximum ambient operating temperature is 113°F. (45°C)

Fixture(s) should be installed in areas outside walking paths, seating areas, or away from

areas were unauthorized personnel might reach the fixture by hand.

NEVER stand directly below the fixture(s) when rigging, removing or servicing.

Overhead fixture installation must always be secured with a secondary safety attachment,

such as an appropriately rated safety cable.

Allow approximately 15 minutes for the fixture to cool down before serving.

Autres manuels pour PALADIN

Table des matières

Autres manuels Elation Projecteur

Elation

Elation ELED DW PAR56 Manuel utilisateur

Elation

Elation STAGE SETTER-24 Manuel utilisateur

Elation

Elation ARENA ZOOM Q7IP Manuel utilisateur

Elation

Elation VISION 575 Manuel utilisateur

Elation

Elation VISION 250 Manuel utilisateur

Elation

Elation Color Tone 50 Instructions d'installation

Elation

Elation KLF832 Manuel utilisateur

Elation

Elation DESIGN SPOT 575E Manuel utilisateur

Elation

Elation DESIGN SPOT 575E Manuel utilisateur

Elation

Elation Event Brick W System Manuel utilisateur

Elation

Elation ARENA PAR ZOOM Manuel utilisateur

Elation

Elation CUEPIX BLINDER WW2 Manuel utilisateur

Elation

Elation Active Scan 250 Manuel utilisateur

Elation

Elation DLED 12 BRICK Manuel utilisateur

Elation

Elation Design LED 36MH Manuel utilisateur

Elation

Elation DLED Par Zoom Manuel utilisateur

Elation

Elation Design LED 72MKII Manuel utilisateur

Elation

Elation ELAR EXFLOOD Manuel utilisateur

Elation

Elation PROTEUS LUCIUS PRL546 Manuel utilisateur

Elation

Elation ELARQUADBAR Manuel utilisateur

Elation

Elation ELAR EX TRIFLOOD HP Manuel utilisateur

Elation

Elation TVL2000 II Manuel utilisateur

Elation

Elation Design LED 108IP Manuel utilisateur

Elation

Elation PAR56 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

VIZULO

VIZULO Micro Martin Guide de l'utilisateur

EuroLite

EuroLite LED IP FL-100 SMD Manuel utilisateur

Cooper Wheelock

Cooper Wheelock XB12 Manuel utilisateur

Allen + Roth

Allen + Roth 17624-000 Manuel utilisateur

ADJ

ADJ 4 STAGE PAK Manuel utilisateur

Cooper Lighting

Cooper Lighting EGL91SW233 Manuel utilisateur

Max

Max 37496 Manuel utilisateur

BEGA

BEGA 85 143 Manuel utilisateur

Beamz

Beamz 151.226 Manuel utilisateur

EuroLite

EuroLite LED IP FL-8 Manuel utilisateur

Ledj

Ledj PERFORMER 36 RGB Manuel utilisateur

Perel

Perel ELS3 Manuel utilisateur

Perel

Perel ELS3WD Manuel utilisateur

LumX

LumX LM 36130 Manuel utilisateur

Xtricity

Xtricity 4-80053 Manuel utilisateur

Stahl

Stahl 6521/4 Series Manuel utilisateur

Ecosense

Ecosense EcoSpec Manuel utilisateur

Ayrton

Ayrton minipanel FX Manuel utilisateur
