EK QuantumX Manuel utilisateur
USER GUIDE
EK-QuantumX
CoolingStation Monoblock for PS5
Please note the installation of the product is intended to be undertaken
by an adequately trained and experienced person. You are installing the
product at your own risk. If you are not properly trained or experienced
or feel unsure about the installation procedure, please refrain from
installing the product yourself and contact our tech support for
assistance. We disclaim our liability for any damages to the product as
well as incidental, consequential, or indirect damages incurred due to
improper or inappropriate installation.
Safety precautions
Carefully read the manual before beginning with the
installation process.
The EK Fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
The use of corrosion-inhibiting coolants is always
recommended for liquid cooling systems and mandatory for
nickel-plated water blocks!
Do not use pure distilled water!
For best results, EK recommends the use of EK-CryoFuel
coolants! To reach optimal performance, make sure to
thoroughly bleed the air out of your water block!
The product warranty period is 24 months.
We disclaim our liability for any damages to the Sony PS5
as well as incidental, consequential, or indirect damages
incurred due to improper or inappropriate installation.
Dismantling the PS5 voids its Sony warranty.
- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
MONOBLOCK AND BACKPLATE DIMENSIONS 5
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS 6
BACKPL ATE 6
MONOBLOCK 7
PS5 TEARDOWN 8
REMOVING THE STOCK COOLER 8
PREPARING THE PS5 PCB 8
REMOVING THE POWER SUPPLY AND ANTENNAS WIFI AND BLUETOOTH 8
PREPARING THE MONOBLOCK 10
REMOVING THE BACKPLATE 10
INSTALLING THE MONOBLOCK 12
PLACING WIFI AND BLUETOOTH ANTENNAS 12
OPTION ADDING SSD DISC 13
CUTTING AND PLACING THERMAL PADS MONOBLOCK SIDE 14
INSTALLING THE BACKPLATE 18
CUTTING AND PLACING THERMAL PADS 18
PLACING THE BACKPLATE 19
ATTACHING THE BACKPLATE 19
INSTALLING PS5 INTO PC CASE 20
FITTINGS AND TUBING 22
CONNECTING THE D-RGB LED STRIP 22
TESTING THE LOOP 23
MAINTENANCE TIPS 23
CLEANING GUIDE 24
PREVENTIVE STEPS 24
SUPPORT AND SERVICE 25
SOCIAL MEDIA 25
- 4 -
Allen Key 2 mm (1 pc)
Allen Key 2.5 mm (1 pc)
EK-Plug Out Spludger Tool (1 pc)
Standoff M2.5-M3 x 6.6mm (9 pcs)
Standoff M4-M2.5 x 7.4mm (1pc)
BOX CONTENTS
5 mm
Thermal Pad F 1.0 mm (6 pcs)
Thermal Grease (1 pc)
M2.5 x 5 AX1 Screw (6 pcs)
M3 x 6 DIN 7984 Screw (4 pcs) M3 x 4 DIN 7984 Screw (4 pcs)
M3 x 8 DIN 7984 Screw (9 pcs)
EK-QuantumX CoolingStation
Monoblock for PS5
PVC Washer M3 (9 pcs)
120 mm
16 mm
Thermal Pad F 2.0 mm (1 pc)
120 mm
16 mm
Mounting Mechanism: EAN: 106985
- 5 -
MONOBLOCK AND BACKPLATE DIMENSIONS
232.9 mm
212.5 mm
28.2 mm 228.9 mm
212.5 mm
9.2 mm
232.9 mm
212.5 mm
40.2 mm
232.8 mm
167.5 mm
14 mm
- 6 -
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS
- Dimensions: (L x H x W): 232.85 x 212.5 x 40.15 mm
- D-RGB LED count: 24
- D-RGB cable length: 500 mm
- D-RGB connector standard 3-pin (+5V, Data, Blocked, Ground)
BACKPLATE
Position EAN Description Quantity
1106864 Coldplate (Ni) 1
2106870 Metal plate - backplate 1
38472 Screw M3 x 6 DIN7991 28
4106987 OR - QuantumX PS5 2-2 1
2
4
3
1
- 7 -
8
4
3
MONOBLOCK
Position EAN Description Quantity
1106862 Coldplate (Ni) 1
2106874 Top plate - plexi 1
3106867 Front Cover (Black E.) 1
4106869 Side Cover (PC White) 1
5103305 Jet plate 1
6106938 PCB -Power adapter 1
7106945 PA housing bottom (Black E.) 1
8106943 PA housing top (Black E.) 1
98205 Screw M4 x 10 DIN7991 28
10 8533 Standoff M4/M2.5 x 2.5 mm 5
11 9044 Screw M4 x 8 DIN7991 8
12 8541 Standoff M4/M2.5 x 6.60 mm 9
13 8204 Screw M3 x 20 DIN7991 2
14 106873 Wifi antena holder (Acetal) 2
15 8211 Screw M3 x 5 DIN7991 4
16 106986 OR - QuantumX PS5 1-2 1
17 5001 OR - 15 x 1.5 mm 1
18 100663 EK - Badge 1
7
16 13
10
1
2
12
15
14
6
17
11
15
9
14
18
5
- 8 -
PS5 TEARDOWN
PREPARING THE PS5 PCB
REMOVING THE STOCK COOLER
Important! Before starting, make sure to have a clean, flat surface to work
on. To protect electronic components from electrostatic damage, place the
product on an antistatic surface.
Place your PS5 on a flat surface and carefully remove the stock cooler as shown
in the video: https://www.ekwb.com/shop/ek-quantumx-coolingstation-
monoblock-for-ps5 Pay attention to the following steps in order to install the
EK-QuantumX CoolingStation Monoblock for PS5 onto the PS5 PCB.
STEP 1
REMOVING THE POWER SUPPLY AND ANTENNAS WIFI
AND BLUETOOTH
As shown in the video PS5 Teardown: An up-close and personal look
at the console hardware carefully detach the connectors from the
PS5 motherboard and remove the Wi-Fi and Bluetooth antenna from
original casing. Both antennas are reused later on the installation of
the PS5 Monoblock.
STEP 1
- 9 -
STEP 2
Remove the power supply which will not be needed. Power will come
from two 8-pin GPU power connectors which are already on the
Monoblock.
STEP 3
Clean the Liquid metal from the CPU heat spreader. Do not remove
or damage the protective foam around the CPU!
STEP 2
STEP 3
LIQUID
METAL
PROTECTIVE FOAM
- 10 -
Allen Key 2 mm
PREPARING THE MONOBLOCK
STEP 1
REMOVING THE BACKPLATE
First, unscrew (4) M3 x 18 DIN7991 Screws from the Backplate. Make
sure that the Terminal with O-ring stays in place. Save the removed
parts for later steps.
STEP 1
For this step, you will need:
M3 x 18 DIN7991 SCREW
