USER MANUAL
Rev 01
EK-Fluid Gaming
USER MANUAL
Safety precautions
Fill the cooling system before turning the PC on!
Do not use pure distilled water!
Always pull out the main plug before care or maintenance
work!
During normal operation, all covers, filters and side panels
shall be correctlly inserted and closed.
Connect the PC only to a standardized earthed socket outlet.
Use only provided power supply cable or cable set with the
same ratings and comparable certifications.
Only a qualified person can replace the motherboard battery.
The PC is completely turned off when the power cable is
disconnected from the electrical network!
Do not interfere with the interior of the PC while operating.
Some parts of the computer heat up during operation. Before
any maintenance, make sure that the computer cools down
(for at least 30 minutes).
Using corrosion-inhibiting coolants is always recommended
for liquid cooling systems and mandatory for nickel-plated
water blocks!
For best results, EK recommends the use of EK-CryoFuel
coolants! To reach optimal performance, make sure to
thoroughly bleed the air out of your system!
The EK Plugs require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
General informations
Carefully read the manual before beginning with the
installation process.
Instructions for hardware parts are included in the package.
Warnings and information notices provide important
information for hazard-free operations.
- 3 -
TABLE OF CONTENTS
MODELS 4
PACKAGE CONTENT 4
UNPACKING THE BOX 4
LIST OF HARDWARE PARTS 5
HARDWARE LIST EKFLUID GAMING ZEN LOTUS 5
HARDWARE LIST EKFLUID GAMING SIDE TASK 5
BASIC PC CHASSIS INFORMATION (PORT LAYOUT) 6
HARDWARE LIST EKFLUID GAMING DIGITAL REEF 6
EKFLUID GAMING SIDE TASK CORSAIR 7000D AIRFLOW PC CASE 6
EKFLUID GAMING ZEN LOTUS FRACTAL DESIGN TORRENT PC CASE 7
EKFLUID GAMING DIGITAL REEF FRACTAL DESIGN TORRENT PC CASE 7
POWER SUPPLY MODES (Seasonic GX 1200W Gold 80+ PSU) 8
HYBRID MODE 8
NORMAL MODE 8
FIRST-TIME SETUP INSTRUCTIONS 9
FILLING THE SYSTEM 9
EKFLUID GAMING SIDE TASK 10
EKFLUID GAMING ZEN LOTUS 11
EKFLUID GAMING DIGITAL REEF 12
DRAINING PROCEDURE 12
EKFLUID GAMING SIDE TASK 13
EKFLUID GAMING ZEN LOTUS 14
EKFLUID GAMING DIGITAL REEF 15
MAINTENANCE TIPS 16
CLEANING PARTS 16
TROUBLESHOOTING 17
DECLARATION OF CONFORMITY 18
SUPPORT AND SERVICE 21
SOCIAL MEDIA 21
- 4 -
UNPACKING THE BOX
MODELS PACKAGE CONTENT
Carefully open the outer and inner boxes. Remove the computer
from the box and carefully lift it on the flat surface. Be aware that
box content is heavy and is meant to be manipulated by two (2)
persons. All the additional stickers, foam, and packaging materials
must be removed before running up the computer. The computer
is heavy and some of the components are fragile.
Visually inspect the components before further steps. If you notice
any errors, please contact the customer support:
http://support.ekwb.com/
In the box contents, we also include the user manuals of every
installed Hardware.
The packing materials can be recycled. Please dispose
of packaging in accordance with the environmental
regulations.
- EK-Fluid Gaming Side Task
- EK-Fluid Gaming Zen Lotus
- EK-Fluid Gaming Digital Reef
- Premium Gaming PC (1 pc)
- PSU Cables
- SSD Expansion card
- Filling bottle (1 pc)
- EK Cryofuel Premix Coolant (2 pcs)
- Drain tube (2 pcs)
- EK - Loop Multi Allen Key (1 pc)
- Hardware instructions
- USB Key (1 pc)
Model
EK-FG Zen Lotus [14900K | RTX 4090] Liquid-Cooled Gaming PC
Power supply
100 / 240V ~ 50 Hz/60 Hz; 15 - 7,5 A
Net weight
25 - 26 Kg
Manufacturer
EKWB d.o.o., Pod lipami 18, SI - 1217 Komenda , Slovenia, Europe
Operational temperature
35°C
Maximum operational
altitude
5000 m
Pollution degree
Office environment PD2
Model
EK-FG Side Task [14900K | RTX 4090] Liquid-Cooled Gaming PC
Power supply
100 / 240V ~ 50 Hz/60 Hz; 15 - 7,5 A
Net weight
33 - 34 Kg
Manufacturer
EKWB d.o.o., Pod lipami 18, SI - 1217 Komenda , Slovenia, Europe
Operational temperature
35°C
Maximum operational
altitude
5000 m
Pollution degree
Office environment PD2
Model
EK-FG Digital Reef [14900K | RTX 4090] Liquid-Cooled Gaming PC
Power supply
100 / 240V ~ 50 Hz/60 Hz; 15 - 7,5 A
Net weight
24 - 25 Kg
Manufacturer
EKWB d.o.o., Pod lipami 18, SI - 1217 Komenda , Slovenia, Europe
Operational temperature
35°C
Maximum operational
altitude
5000 m
Pollution degree
Office environment PD2
- 5 -
LIST OF HARDWARE PARTS
HARDWARE LIST EKFLUID GAMING ZEN LOTUS
CPU Intel Core i9 14900K
GPU NVIDIA GeForce RTX 4090
Motherboard ASUS ROG MAXIMUS Z790 HERO
RAM 64GB (2x32GB) DDR5 6000MHz RGB RAM
SSD Primary 1TB Seagate Firecuda 530 PCIe 4.0 M.2 SSD
SSD Secondary 2TB Seagate Firecuda 530 PCIe 4.0 M.2 SSD
PSU Seasonic GX 1200W Gold 80+ PSU
Cooling EK Quantum Custom Loop Liquid Cooling
Case Fractal Design Torrent
OS Windows 11 Home
HARDWARE LIST EKFLUID GAMING SIDE TASK
CPU AMD Ryzen 9 7950X3D
GPU NVIDIA GeForce RTX 4090
Motherboard ASUS ROG Crosshair X670-E
RAM 64GB (2x32GB) DDR5 6000MHz RGB RAM
SSD Primary 1TB Seagate Firecuda 530 PCIe 4.0 M.2 SSD
SSD Secondary 2TB Seagate Firecuda 530 PCIe 4.0 M.2 SSD
PSU Seasonic GX 1200W Gold 80+ PSU
Cooling EK Quantum Custom Loop Liquid Cooling
Case Corsair 7000D
OS Windows 11 Home
- 6 -
BASIC PC CHASSIS INFORMATION (PORT LAYOUT)
EKFLUID GAMING SIDE TASK CORSAIR 7000D
AIRFLOW PC CASE
USB 3.0
POWER BUTTON
USB 3.1 Type-C
HD AUDIO
RESTART BUTTON
HARDWARE LIST EKFLUID GAMING DIGITAL REEF
CPU Intel Core i9 14900K
GPU NVIDIA GeForce RTX 4090
Motherboard ASUS ROG MAXIMUS Z790 HERO
RAM 64GB (2x32GB) DDR5 6000MHz RGB RAM
SSD Primary 1TB Seagate Firecuda 530 PCIe 4.0 M.2 SSD
SSD Secondary 2TB Seagate Firecuda 530 PCIe 4.0 M.2 SSD
PSU Seasonic GX 1200W Gold 80+ PSU
Cooling EK Quantum Custom Loop Liquid Cooling
Case Fractal Design Torrent
OS Windows 11 Home
- 7 -
EKFLUID GAMING ZEN LOTUS FRACTAL DESIGN
TORRENT PC CASE
EKFLUID GAMING DIGITAL REEF FRACTAL DESIGN
TORRENT PC CASE
USB 3.0
HD AUDIO
POWER BUTTON
USB 3.1 Type-C
RESTART BUTTON
USB 3.0
HD AUDIO
POWER BUTTON
USB 3.1 Type-C
RESTART BUTTON
- 8 -
POWER SUPPLY MODES (Seasonic GX 1200W Gold 80+ PSU)
The selected power supply (PSU) has two mode options. Normal
and Hybrid.
To learn more about the selected Power Supply, please refer
to the power supply manufacturer’s instruction manual. The
instruction manual is included in the package.
The differences between normal and hybrid modes:
HYBRID MODE
If the plug shown is not switched on, the power supply is in hybrid
mode. In Hybrid mode, the fan will not turn.
NORMAL MODE
If the plug shown is switched on, the power supply is in normal mode.
In Normal mode, the fan will turn.
Important!
EN: Connect the PC only to a standardized earthed socket outlet.
SE: Apparaten skall anslutas till jordat uttag
FI: Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
DK: Apparatets stikprop skal tilsluttes en stikkontakt med jord
som giver forbindelse til stikproppens jord
NO: Apparatet må tilkoples jordet stikkontakt
HYBRID MODE
NORMAL MODE
- 9 -
FIRST-TIME SETUP INSTRUCTIONS
FILLING THE SYSTEM
Disconnect all the external cables including the power cable.
Ensure all the plug-s are sufficiently tightened and fill the reservoir/
distribution plate through the top/fill port with the provided filling
bottle. Momentarily power on the system until the coolant in the
reservoir/distribution plate level drops enough to add more coolant.
Repeat this process until the components are completely free of air.
We recommend carrying out a pressure test before filling the
system. Link to pressure tester instructions:
https://www.ekwb.com/shop/EK-IM/EK-IM-3831109848388.pdf
It is recommended to protect the exposed hardware
with a few paper towels in case there is a leak, or you
accidentally spill the coolant while pouring it.
It is recommended to protect hands with latex gloves.
Filling example
For the filling process, you will need:
EK-Loop Multi
Allen Key (1 pc)
EK-Cryofuel
Coolant
Filling Bottle
- 10 -
FILL PORT
EKFLUID GAMING SIDE TASK
Before filling the loop, you must remove the Plug cover from the Fill
port (the Fill port is marked in the picture). After removing the Plug
cover, unscrew the Plug using the EK- Loop Multi Allen Key.
After filling the system, reuse the removed Plug and Plug cover.
When tightening the Plug, be careful not to apply too much force
(Max Torque: 0.6 Nm).
The additional information regardingSideTaskconfigurationcan also
be found here: https://www.youtube.com/watch?v=1oGTagMK5A4
* Please note that the components in the video may differ from
the latest configuration.
