WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
POWER INVERTER
OPERATOR’S MANUAL
56-VOLT
POWER INVERTER
MODEL NUMBER PAD5000/ PAD5000-FC
IN/OUT
FAST
CHARGE
USB-A
18W
PD-100W
18W
USB-C
USB-C
120V-3.3A
400W
PURE SINE WAVE
Español p. 51
Français p. 25
56-VOLT POWER INVERTER2
TABLE OF CONTENTS
FCC Statement...........................................4
Safety Symbols ..........................................5
Safety Instructions.....................................6-10
Introduction ............................................11
Specications ..........................................12
Packing List ............................................12
Description ............................................13
Operation ...........................................14-19
Maintenance ...........................................20
Troubleshooting .........................................21
Warranty ...........................................22-23
56-VOLT POWER INVERTER 3
READ ALL INSTRUCTIONS!
READ & UNDERSTAND
OPERATOR’S MANUAL
WARNING: To reduce the risk of injury, fire, electric shock, user must read and
understand the operator’s manual for their USB accessories and AC devices in addition
to this instruction sheet. Ensure compatibility before using the power inverter. Do not
use this product if any part is damaged or missing.
56-VOLT POWER INVERTER4
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
NOTICE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures: Reorient or relocate the receiving antenna. Increase
the separation between the equipment and receiver. Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.
56-VOLT POWER INVERTER 5
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger. The
instructions and warnings they give are no substitutes for proper accident prevention
measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this product. Failure to following all instructions listed
below may result in electric shock, fire, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER, WARNING, OR CAUTION. May
be used in conjunction with other symbols or pictographs.
56-VOLT POWER INVERTER6
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate it.
Safety Alert Indicates a potential personal injury hazard.
Read &
Understand
Operator’s Manual
To reduce the risk of injury, user must read
and understand the operator’s manual before
using this product.
V Volt Voltage
A Amperes Current
lb Pound Weight
kg Kilogram Weight
Alternating
Current Type or a characteristic of current
Direct Current Type or a characteristic of current
56-VOLT POWER INVERTER 7
IMPORTANT SAFETY INSTRUCTIONS
WARNING: When using this product, basic precautions should always be
followed, including the following:
Read all the instructions before using the product.
To reduce the risk of injury, close supervision is necessary when the product is
used near children.
Do not put fingers or hands into the product.
Use of an attachment not recommended or sold by power pack (inverter)
manufacturer may result in a risk of fire, electric shock, or injury to persons.
To reduce risk of damage to the electric plug and cord, pull the plug rather than
the cord when disconnecting the power pack (inverter).
Do not use a battery pack or appliance that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behavior resulting in fire, explosion,
or risk of injury.
Do not operate the power pack (inverter) with a damaged cord or plug, or a
damaged output cable.
Do not disassemble the power pack (inverter), take it to a qualified service person
when service or repair is required. Incorrect reassembly may result in a risk of fire
or electric shock.
To reduce the risk of electric shock, unplug the power pack (inverter) form the
outlet before attempting any instructed servicing.
WARNING: RISK OF EXPLOSIVE GASES
To reduce risk of battery explosion, follow these instructions and those published
by battery manufacturer and manufacturer of the equipment you intend to use in
vicinity of the battery. Review cautionary marking on these products.
PERSONAL PRECAUTIONS
NEVER smoke or allow a spark or flame in vicinity of battery.
Be extra cautious to reduce risk of dropping a metal tool onto battery. It might
spark or short circuit battery or other electrical part that may cause explosion.
56-VOLT POWER INVERTER8
When charging the internal battery, work in a well ventilated area and do not
restrict ventilation in any way.
Under abusive conditions, liquid may be ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
Have plenty of fresh water and soap nearby in case battery acid contacts skin,
clothing, or eyes.
Wear complete eye protection and clothing protection. Avoid touching eyes while
working near battery.
If battery acid contacts skin or clothing, wash immediately with soap and water.
If acid enters eye, immediately flood eye with running cold water for at least 10
minutes and get medical attention immediately
Do not expose a power pack (inverter) to fire or excessive temperature. Exposure
to fire or temperature above 265 °F (130°) may cause explosion.
Have servicing performed by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the product is maintained.
WARNING: Read all safety warnings and instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference
Risk of re and electric shock. Dry location use only. Do not expose the
power inverter to rain or wet conditions. Water entering the power inverter will
increase the risk of electric shock.
For household use only.
Do not allow the power inverter to be used as a toy. Close attention is
necessary when used by or near children.
The power inverter is not intended for any use other than charging small
USB electronics or small AC devices specied in SPECIFICATIONS in this
manual. Any other use may result in damage.
Do not put ngers or hands into the power inverter.
Switch off the power inverter when not in use.
56-VOLT POWER INVERTER 9
Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to battery pack, picking up or carrying the power inverter.
Carrying the power inverter with your finger on the switch or energizing power
inverter that has the switch on invites accidents.
Disconnect the battery pack from the power inverter before making
any adjustments, changing accessories, or storing power inverter. Such
preventive safety measures reduce the risk of starting the power inverter
accidentally.
Recharge only with the charger specied by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
Use power inverter only with specically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
Use only with the battery packs and chargers listed below:
BATTERY PACK CHARGER
BA1400, BA1400-FC, BA2800, BA2800-FC,
BA4200, BA4200-FC, BA1400T, BA1400T-FC,
BA2242T, BA2242T-FC, BA2800T, BA2800T-FC,
BA3360T, BA3360T-FC, BA4200T, BA4200T-FC,
BA5600T, BA5600T-FC, BA6720T, BA6720T-FC
CH2100, CH2100-FC,
CH3200, CH3200-FC,
CH5500, CH5500-FC,
CH2800D, CH2800D-FC,
CH7000, CH7000-FC
When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects, that
can make a connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
Do not use a battery pack or power inverter that is damaged or modied.
Damaged or modified batteries may exhibit unpredictable behavior resulting in
fire, explosion, or risk of injury.
Follow all charging instructions and do not charge the battery pack or
appliance outside of the temperature range specied in the instructions.
Charging improperly or at temperatures outside of the specified range may
damage the battery and increase the risk of fire.
56-VOLT POWER INVERTER10
Do not modify or attempt to repair the power inverter or the battery pack
except as indicated in the instructions for use and care.
Store idle power inverter out of the reach of children and do not allow
persons unfamiliar with the power inverter or these instructions to operate
the power inverter. Power inverters are dangerous in the hands of untrained
users.
Maintain power inverter and accessories. Check for misalignment or
breakage of parts and any other condition that may affect the power
inverter’s operation. If damaged, have the power inverter repaired before
use. Many accidents are caused by poorly maintained power inverter.
Save these instructions. Refer to them frequently and use them to instruct
others who may use this product. If you loan someone this product, loan them
these instructions also.
SAVE THESE INSTRUCTIONS!
