34 Control console 1202. Basic operation 1202
9Making a call when any of the targeted
zones is in “private” mode
If three groups -for instance- have been
previously created:
GR 01 ((And then the sign “<” appears
next to GR 01) +
If, in the selected group, any of the
zones is in “private” mode:
If, instead of a group, a zone had been
selected which was in “private” mode,
the name given to that zone would
appear in the screen.
YES will send the message to the
whole group.
NO will send the message only to the
zones of the selected group which are
not in “private” mode.
1Enabling and disabling the general
access password
If three groups -for instance- have been
previously created:
SETUP
Provided that there is NEITHER a pre-recorded
message player (1103) NOR a module for sending
messages over the telephone (1104) in the system:
MORE
PASSWORD
NO disables the general access password.
1+ 2 + 3 + 4 will turn on the led
lamp next to YES.
If then we press YES then the code 1234 has
been enabled as general access password.
The 4 bottom keys ; ; SETUP and
act here as numeric keys.
2Entering the general access password
If the general access password is acti-
ve, whenever we want to access to the
advanced functions of the system, the
module for sending messages over the
telephone, or the pre-recorded
message player, a password will be
required by the following screen:
The 4 bottom keys ; ; SETUP
and act here as numeric keys.
If we make a mistake when entering the
password, it is possible to start again
by pressing ERASE.
For each entered digit, a " –" symbol
will be substituted by a " *" symbol.
Control console 1202. Access restrictions 1202
As long as we keep the button
pressed, what is said to the
microphone will be broadcast in all
the selected zones.
It is also possible to select several
groups or zones, or even a combination
of groups and zones -taking into
account that if we enter a group to
select some of its zones, the selection of
that group (as a whole unit) will
automatically be cancelled-.
If the paging line is busy because
another call is being broadcast or a
pre-recorded message is being played
or saved from another console 1202,
instead of the last two screens, the
following message will appear:
