Edwards STP Series Manuel utilisateur

MT-21E-0A3-D

STP Series Turbomolecular Pumps (extract)

STP-301H/451H

STP-L301H/L451H

(Third Edition - d)

Instruction Manual

This Manual has extracted the difference of

the STP-301/451 series and STP-301H/451H,

the STP-L301/L451 series and STP-

L301H/L451H.

For the "Safety Precautions", installation,

operation and maintenance, read the "STP-

301/451 Series Instruction Manual" or "STP-

L301/L451 Series Instruction Manual".

Keep this Manual in a place where you can

quickly access it at any time.

Sep. 2021

STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

INTRODUCTION

Thank you very much for purchasing Edwards’turbomolecular pump.

The turbomolecular pump is designed to be installed in the vacuum equipment to exhaust

gases from it.

This manual covers all items necessary to ensure safe installation, operation and

maintenance of the following series of the turbomolecular pump:

Model Name Specification

•STP-301H High-vacuum type

•STP-451H High-vacuum type

•STP-L301H Low-vibration type, High-vacuum type

•STP-L451H Low-vibration type, High-vacuum type

For the specifications of other models, contact Edwards.

In this manual, the above STP pump series is collectively called the "STP pump".

This manual picks up the points of difference between the STP-301/451 series and

STP-301H/451H, the STP-L301/L451 series and STP-L301H/L451H. For the "Safety

Precautions", installation, operation and maintenance, read the "STP-301/451 Series

Instruction Manual" or "STP-L301/L451 Series Instruction Manual".

The points of difference are as follows:

Item

Points of difference

Reference

"CON4" connector

Standard equipment

Sec 1

Chassis

Optional accessory by

order specifications

Sec 2

Size of inlet port flange

(Only STP-301H/STP-L301H)

ISO100 special type

See "External Appearance of

the STP Pump"

STP-301H/451H Instruction Manual (extract)
STP-L301H/L451H Instruction Manual (extract)

2
TABLE of CONTENTS
INTRODUCTION
1“CON4” Connector ..........................................................................3
2Installation of the Chassis (Optional Accessory)..............................3
2.1 Name and Function Each Part............................................................................................. 3
2.2 Attaching the Chassis Front Panel to a Rack...................................................................... 4
2.3 Cable Connection ................................................................................................................ 5
2.3.1 Name and Dimensions of Cable................................................................................. 5
2.3.2 How to Connection the Cable..................................................................................... 5
3External Appearance of the STP pump ...........................................7

 FIGURE
Figure 2.1 Chassis......................................................................................................................... 3
Figure 2.2 Example of Securing the Chassis................................................................................ 4
Figure 2.3 External Appearance of Power Cable.......................................................................... 5
Figure 2.4 External Appearance of the Chassis (with STP Control Unit) ..................................... 6
Figure 3.1 External Appearance of STP-301H.............................................................................. 7
Figure 3.2 External Appearance of STP-L301H............................................................................ 8
 TABLES
Table 2.1 Connecting the Power Cable......................................................................................... 5



STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

1 "CON4" Connector

STP-301H/451H and STP-L301H/L451H include "CON4" connector as standard equipment.

Refer to Section 7, "How to Start/Stop the STP Pump" and Section 8, "Remote Input/Output

Signal Terminal Block" in "STP-301/451 Series Instruction Manual" or "STP-L301/L451

Series Instruction Manual".

2 Installation of the Chassis (Optional Accessory)

The size of the STP control unit attached to the chassis that is full-rack size is the same as

that of STP-300H.

2.1 Name and Function Each Part

(1) Distribution Cable for Power

⚫For distribution of power

(2) AC POWER Connector

⚫For primary power input.

⚫Power cable for STP-300H can be connected to this connector.

Figure 2.1 Chassis

STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

2.2 Attaching the Chassis Front Panel to a Rack

The dimensions of the chassis front panel conform to EIA Standard. Therefore, this panel can

be attached to any type of commercially-available racks.

Attach the front panel unit to the rack according to the following steps:

•Attach the front panel to a rack using the screw holes for the front panel.

•Also support the chassis from the bottom using a support angle or a similar tool.

•To protect the chassis during transport, remove the rubber foot from the bottom and

attach the chassis to the rack using the screw holes for the rubber foot.

◇The chassis cannot be supported with only the screws on the front panel (the

STP control unit and chassis are heavy products).

Always support it from the bottom.

◇When installing the STP control unit and chassis, DO NOT block the ventilation

port of the STP control unit by the support angle or other things. It causes the

control unit to overheat.

◇For the dimensions of the front panel and positions of screw holes for the rubber

foot, see "External Appearance of the chassis (with STP Control Unit)".

Figure 2.2 Example of Securing the Chassis

STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

2.3 Cable Connection

2.3.1 Name and Dimensions of Cable

STP Control Unit Side Power Side (Primary)

3pin (socket)

PE( )

L(L1)

N(L2)

Distribution Part of Chassis

3pin (socket-type)

Power cable for STP-300H

A Power cable is not included with shipment.

Use the power cable for STP-300H.

Figure 2.3 External Appearance of Power Cable

2.3.2 How to Connection the Cable

1) Connecting the Power (Primary Side) Cable

Connect the power cable to the "AC POWER" connector on the chassis as shown in Table 2.1.

Table 2.1 Connecting the Power Cable

CON1

Pin No.

Remakes

Chassis

Outline of AC POWER

connector

Single phase 200 to 240VAC

(for 200V specification)

Single phase 100 to 120VAC

(for 100V specification)

50/60Hz

Ground

◇Confirm the power voltage on the name plate.

◇Connect the primary power cable securely to prevent incorrect wiring.

◇DO NOT apply surge voltage exceeding 1kV to the input power line.

◇Always ground the primary power cable to prevent electric shock.

◇Allowable input voltage fluctuation is -/+ 10 %.

◇A Power cable is not included with shipment. Use the power cable for

STP-300H.

STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

132.6

31.3 209.7

482.6

14.7 453.2

21.9 88.9

27.3 78

50 309

26.3 430 26.3

200 9.85

3.8 125

117.7

41.75 346.5 41.75

430

12 406

15 5

470

508

Screw hole for

rubber foot

(M4x4)

Handle (2pcs)

(Fixed with flat-head

screw(M5x8))

14.7

21.8

35 3

Figure 2.4 External Appearance of the Chassis (with STP Control Unit)

STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

3 External Appearance of the STP pump

The size of the inlet port flange of STP-301H and STP-L301H is different from that of STP-301 and STP-L301.

STP-301H/STP-L301H

STP-301/STP-L301

Size of inlet port flange

ISO100 special type

ISO100

External Appearance

Figure 3.1, Figure 3.2

Ｂ

99.5

108

φ115 4.1

2.4

R1.5

φ125

25ﾟ

20ﾟ

φ130

φ112

φ156

φ180

(33) 197

φ128

Min.230

34 12

(8) 50 (1) 171

230

35ﾟ

Ａ

φ160

Detail A

(Bending dimension of

the STP connection cable)

Inlet port flange

(ISO100 special type)

Figure 3.1 External Appearance of STP-301H

STP-301H/451H Instruction Manual (extract)

STP-L301H/L451H Instruction Manual (extract)

(33)

(8)

Min.227

99.5

108

φ160

25ﾟ

20ﾟ

φ180

(73)

Detail A

7.5ﾟ

37.5ﾟ

15ﾟ

φ107

207

φ130

240

φ115

φ148.5

φ115

4.1

2.4

φ128

φ156

φ180

166

(Bending dimension of

the STP connection cable)

Figure 3.2 External Appearance of STP-L301H

For more information, contact the nearest Service Office.

( http://www.edwardsvacuum.com/ )

Manufacturer:

Edwards Japan Limited

1078-1, Yoshihashi, Yachiyo-shi, Chiba 276-8523 JAPAN

Telephone: Domestic 047-458-8853

International +81-47-458-8853

Facsimile: Domestic 047-458-8048

International +81-47-458-8048
