EDM Solution 862 Manuel utilisateur
Solution Ultima 862
Operators Manual
ISSUE 1.00
Solution Ultima 862
Operators Manual
Copyright 1998 by Electronics Design and Manufacturing Pty Limited,
SYDNEY, AUSTRALIA
Document Part Number MA486O
DOCUMENT ISSUE 1.00
Printed 16 February 1999
This documentation is provided to suit the Solution Ultima 862 Control Panel (CC486).
Firmware Revision 1.00
Hardware Revision A - F
Copyright Notice
All rights reserved. No part of this publication may be reproduced, transmitted or stored in a retrieval system in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Electronics Design and Manufacturing Pty Limited.
Trademarks
Throughout this document trademark names may have been used. Rather than put a trademark symbol in every
occurrence of a trademark name, we state that we are using the names only in an editorial fashion and to the
benefit of the trademark owner with no intention of infringement of the trademark.
Notice of Liability
While every precaution has been taken in the preparation of this document, neither Electronics Design and
Manufacturing Pty Limited nor any of its official representatives shall have any liability to any person or entity
with respect to any liability, loss or damage caused or alleged to be caused directly or indirectly by the
information contained in this book.
Electronics Design and Manufacturing Pty Limited reserves the right to make changes to features and
specifications at any time without prior notification in the interest of ongoing product development and
improvement.
Table Of Contents
INTRODUCTION .............................................................................................................................6
CODEPAD INDICATORS................................................................................................................7
Zone Indicators...............................................................................................................................................7
AWAY Indicator.............................................................................................................................................7
STAY Indicator...............................................................................................................................................8
System Disarmed.............................................................................................................................................8
MAINS Indicator............................................................................................................................................8
Off Indicator / Zone Sealed.............................................................................................................................8
On Indicator / Zone In Alarm.........................................................................................................................8
FAULT Indicator............................................................................................................................................9
Audible Indications.........................................................................................................................................9
ARMING THE SYSTEM................................................................................................................10
Forced Arming.........................................................................................................................................10
Arming In AWAY Mode...............................................................................................................................10
Arming In STAY Mode 1 .............................................................................................................................11
Entry Guard Timer For STAY Mode........................................................................................................11
Arming In STAY Mode 2 .............................................................................................................................12
Entry Guard Timer For STAY Mode........................................................................................................12
Programming STAY Mode 2 Zones............................................................................................................. 12
DISARMING THE SYSTEM .........................................................................................................13
ADDING USER CODES.................................................................................................................13
ADDING RADIO REMOTE USER CODES .................................................................................13
DELETING USER CODES/RADIO USER CODES.....................................................................14
RADIO TRANSMITTER OPERATIONS .....................................................................................14
CODEPAD DURESS ALARM........................................................................................................15
CODEPAD PANIC ALARM...........................................................................................................15
CODEPAD FIRE ALARM..............................................................................................................15
CODEPAD MEDICAL ALARM....................................................................................................15
CODEPAD TAMPER (ACCESS DENIED)...................................................................................15
ISOLATING ZONES ......................................................................................................................16
Standard Isolating......................................................................................................................................... 16
Code To Isolate..............................................................................................................................................17
FAULT ANALYSIS MODE ........................................................................................................... 17
Fault Descriptions......................................................................................................................................... 19
System Fault................................................................................................................................................ 19
Low Battery............................................................................................................................................. 19
Date and Time.......................................................................................................................................... 19
RF Receiver Fail...................................................................................................................................... 19
Horn Speaker........................................................................................................................................... 19
Telephone Line Fail................................................................................................................................. 19
E2 Fault................................................................................................................................................... 19
Fuse Fail.................................................................................................................................................. 19
RF Low Battery........................................................................................................................................... 19
Tamper Fail................................................................................................................................................. 20
Sensor Watch Fault ..................................................................................................................................... 20
RF Sensor Watch Fault................................................................................................................................ 20
Communication Fail.................................................................................................................................... 20
DATE AND TIME........................................................................................................................... 20
TELCO ARM/DISARM SEQUENCE ........................................................................................... 21
TURNING OUTPUTS ON/OFF..................................................................................................... 22
Reset Latching Outputs ................................................................................................................................ 22
TESTING......................................................................................................................................... 23
Horn Speaker Test........................................................................................................................................ 23
Bell Test......................................................................................................................................................... 23
Strobe Test .................................................................................................................................................... 23
Walk Test Mode............................................................................................................................................ 23
Test Report.................................................................................................................................................... 23
Event Memory............................................................................................................................................... 23
DAY ALARM.................................................................................................................................. 24
CODEPAD BUZZER TONE CHANGE ........................................................................................ 24
REMOTE ARMING VIA TELEPHONE ...................................................................................... 24
DOMESTIC DIALLING ................................................................................................................ 25
Acknowledging Domestic Calls..................................................................................................................... 25
Programming Domestic Telephone Numbers.............................................................................................. 26
Disable Domestic Dialling............................................................................................................................. 26
BASIC PAGER REPORTING ....................................................................................................... 27
Basic Pager Display Information.................................................................................................................. 27
Subscriber ID Number ............................................................................................................................. 27
Zone Status.............................................................................................................................................. 27
System Status........................................................................................................................................... 27
GLOSSARY OF TERMS................................................................................................................ 29
WARRANTY STATEMENT.......................................................................................................... 31
YEAR 2000 COMPLIANCE...........................................................................................................31
SPECIFICATIONS..........................................................................................................................31
ADVICE TO USERS.......................................................................................................................32
NEW ZEALAND TELEPERMIT NOTES.....................................................................................32
INSTALLATION NOTES...............................................................................................................33
INDEX..............................................................................................................................................37
IntroductionCongratulations on selecting the Solution Ultima 862 control panel to protect you and your
property. So that you can obtain the most from your unit, we suggest that you take the time
to read through this manual and familiarise yourself with the numerous outstanding
operating features of this system. You will notice that in all aspects of planning,
engineering, styling, operation, convenience and adaptability, we have sought to anticipate
your every possible requirement.
Programming simplicity and speed have been some of the major considerations and we
believe that our objectives in this area have been more than satisfied.
This manual will explain all aspects of operating the control panel. All system parameters
and options are detailed; however, suitability is left up to the individual. Every system can
be tailored to meet all requirements quickly and easily.
Notice To All Owners
It is recommended that you test the sirens, strobe and zones at weekly intervals. Refer to
Testing on page 25 for further information.
6Solution Ultima 862 Operators Manual
ISSUE100.DOC Electronics Design and Manufacturing Pty Limited
Codepad Indicators
Figure 1: CP5 Eight Zone
LED Codepad Figure 2: CP5 Eight Zone
LCD Codepad
The codepad is the communications interface between you and your alarm system. The codepad allows you to
issue commands and offers both visual and audible indications that guide you through the general operation.
The codepad incorporates numerous indicators. There are zone indicators that are used to show the condition of
each zone and four others for general status. The following pages outline a list of situations and the relevant
indicators that will be seen.
Zone Indicators
The zone indicators (1-8) are used to display the status of the zones. The following table
lists the various circumstances that the indicators will display (ie. Zone Sealed / Zone
Unsealed).
Zone Indicator Definition
On Zone Is Unsealed
Off Zone Is Sealed
Flashing Fast
(0.25 Sec On/0.25 Sec Off) Zone Is In Alarm Condition
Flashing Slow
(1 Sec On/1 Sec Off) Zone Is Manually Isolated Or Selected To Be Isolated
Table 1: Zone Indicator
AWAY Indicator
The AWAY indicator is used to display that the system is armed in AWAY Mode. The
AWAY indicator will also flash in unison with the STAY indicator when programming
various options throughout the operator’s manual.
Refer to page 10 for information on the different methods of arming the system in AWAY
Mode.
AWAY Indicator Definition
On System Is Armed In AWAY Mode
Off System Is Not Armed In AWAY Mode
Table 2: AWAY Indicator
1 2 3 ….
Solution Ultima 862 Operators Manual 7
Electronics Design and Manufacturing Pty Limited ISSUE100.DOC
STAY Indicator
The STAY indicator is used to display that the system is armed in STAY Mode 1 or STAY
Mode 2. The STAY indicator will also flash in unison with the AWAY indicator when
programming various options throughout the operator’s manual.
Refer to page 11 for information on the different methods of arming in STAY Mode 1. For
information and the method of arming in STAY Mode 2, refer to page 12.
STAY Indicator Definition
On System Is Armed In STAY Mode 1 Or STAY Mode 2
Off System Is Not Armed In STAY Mode 1 Or STAY Mode 2
Flashing Twice A Second Zone Isolating Mode Or Setting STAY Mode 2 Zones
Flashing Once Every
3 Seconds Day Alarm Status – Day Alarm Turned On
Table 3: STAY Indicator
System Disarmed
This indicator will display with the indicator when the system has been disarmed.
MAINS Indicator
The MAINS indicator is used to display that the systems AC mains supply is normal or has
failed.
MAINS Indicator Definition
On AC Mains Power Normal
Flashing AC Mains Supply Has Failed
Table 4: MAINS Indicator
Off Indicator / Zone Sealed
The indicator will display when the system is in the disarmed state and will flash when a
zone becomes unsealed during the disarmed state. The indicator will stop flashing when all
zones are sealed.
On Indicator / Zone In Alarm
The indicator will display when the system is armed in AWAY Mode and will flash
when an alarm occurs. The indicator will reset once a valid user code has been entered.
8Solution Ultima 862 Operators Manual
ISSUE100.DOC Electronics Design and Manufacturing Pty Limited
FAULT Indicator
The FAULT indicator is used to display that the system has detected a system fault. Refer to
Fault Analysis Mode on page 17 for additional information on system faults.
Every time a new system fault has been detected (eg: FAULT indicator flashing), the
codepad will begin to beep once every minute. Pressing the # button once will cancel the
once a minute beep and acknowledge the fault (eg: FAULT indicator on steady).
FAULT Indicator Definition
On There Is A System Fault That Needs To Be Rectified
Off The System Is Normal, There Are No Faults
Flashing There Is A System Fault That Needs To Be Acknowledged
Table 5: FAULT Indicator
Audible Indications
In general, the audible indicators given out by the codepad buzzer are as follows:
Audible Indicator Definition
Once Short Beep A Button Has Been Pressed On The Codepad, Or, End Of Exit
Time When Armed In STAY Mode 1 Or STAY Mode 2
Two Short Beeps The System Has Accepted Your Code
Three Short Beeps The Requested Function Has Been Executed
One Long Beep Indicates the End Of Exit Time When Armed In AWAY
Mode, Or The Requested Operation Has Been Denied Or
Aborted
One Beep Every Second Walk Test Mode Is Currently Active Or Warning Before
Automatic Arming Takes Place
One Short Beep Every
Minute There Is A System Fault Waiting To Be Acknowledged
Table 6: Audible Indicators
Solution Ultima 862 Operators Manual 9
Electronics Design and Manufacturing Pty Limited ISSUE100.DOC
Arming The System
There are several different ways to arm the system depending on whether you are leaving the
premises and require all active zones to be in a ready state for an intruder, or, if you are
remaining in the premises and only require part of the system to be in a ready state for an
intruder.
If a zone is not sealed at the end of exit time, the zone will be automatically isolated and will
be constantly displayed on the remote codepad. The zone will again become an active part
of the system when the zone has resealed (ie. If a window is left open after exit time has
expired, the window will not be an active part of the system until the window has closed.
Opening the window after exit time has expired will cause an alarm condition).
The different methods for arming the system include:
ØAWAY Mode
Arms the entire system. Refer to Arming In AWAY Mode on page 10.
ØSTAY Mode 1
Arms all zones except those programmed to be automatically isolated by the installer.
Refer to Arming In STAY Mode 1 on page 11.
ØSTAY Mode 2
Arms all zones except those programmed to be automatically isolated by the Master
Code holder. Refer to Arming In STAY Mode 2 on page 12.
Forced Arming
The feature of arming the system when a zone is not sealed is known as forced arming. If
the system does not arm and a long beep is heard, forced arming is not permitted. If this is
the case, you must ensure that all zones are sealed or manually isolated before you can arm
the system.
Arming In AWAY Mode
When you leave your premises and require all zones to be in a ready state to detect intrusion,
you would arm the system in AWAY Mode.
There are two different methods for arming the system in AWAY Mode. Method one is
standard and will always operate. Method two is optional and may be disabled by your
installer if you do not wish to use single button arming.
Method OneHow To Arm The System In AWAY Mode
1. Enter your user code followed by the # button (eg: 2580#).
Two beeps will be heard and the AWAY indicator will display. Exit time will now
commence counting.
Method TwoHow To Arm The System In AWAY Mode
1. Hold down the # button until two beeps are heard.
The AWAY indicator will display and exit time will commence counting.
10 Solution Ultima 862 Operators Manual
ISSUE100.DOC Electronics Design and Manufacturing Pty Limited
Autres manuels pour Solution 862
2
Table des matières
Autres manuels EDM Panneau de contrôle
EDM
EDM Solution 862 Manuel utilisateur
EDM
EDM Solution Ultima 844 Manuel utilisateur
EDM
EDM Solution-16 Safecom Manuel utilisateur
EDM
EDM Solution 6+6 Wireless-AE Manuel utilisateur
EDM
EDM Solution 4+4 Manuel utilisateur
EDM
EDM Solution-16 Safecom Manuel utilisateur
EDM
EDM Solution-8 Manuel utilisateur
EDM
EDM Solution 862 Manuel utilisateur
