Edimax IC-9000 Manuel utilisateur

publication may be reproduced, transmitted, transcribed, stored in a retrieval

system, or translated into any language or computer language, in any form or

by any means, electronic, mechanical, magnetic, optical, chemical, manual or

otherwise, without the prior written permission of this Company.

This company makes no representations or warranties, either expressed or

implied, with respect to the contents hereof and specifically disclaims any

warranties, merchantability or fitness for any particular purpose. Any software

described in this manual is sold or licensed "as is". Should the programs prove

defective following their purchase, the buyer (and not this company, its

distributor, or its dealer) assumes the entire cost of all necessary servicing,

repair, and any incidental or consequential damages resulting from any defect

in the software. Further, this company reserves the right to revise this

publication and to make changes from time to time in the contents hereof

without obligation to notify any person of such revision or changes.

The product you have purchased and the setup screen may appear slightly

different from those shown in this QIG. For more detailed information about

this product, please refer to the User's Manual on the CD-ROM. The software

and specifications could be subjected to change without notice. Please visit

brand and product names mentioned in this manual are trademarks and/or

registered trademarks of their respective holders.

Notice according to GNU/GPL

Version 2

This product includes software that is subject to the GNU/GPL-Version 2.

You find the text of the license on the product cd/dvd. The program is free

software and distributed without any warranty of the author. We offer, valid

for at least three years, to give you, for a charge no more than the costs of

physically performing source distribution, a complete machine-readable

copy of the corresponding source code.

Please contact Edimax at: Edimax Technology co., Ltd, NO. 3, Wu-Chuan

3rd RD Wu-Ku-Industrial Park, Taipei Hsien, Taiwan. R.O.C., TEL :

+886-2-77396888, FAX : +886-2-77396887, sales@edimax.com.tw

1. Product Information

Thank you for purchasing this IC-9000! The IC-9000 is designed

with the “user-friendly” concept. You can install the IP Camera easily

on your home network and then access the IP Camera anywhere in

the world with the video management utility. No need to set

complicated DNS name or change the router’s configuration. It’s

just a plug & play.

Before you start to use the IC-9000, please check the package

contents. If anything is missing, please contact the dealer of

purchase and return the package to claim for missing contents.

2. Check Your Package Contents



One IC-9000 DDNS-Free Outdoor IP Camera



One Power Adapter



One Ethernet Cable



One Bracket



One Installation Guide



One CD ROM (User Guide & Utility)



One Account Card



One Accessory Bag (Including Anchors & Screws)

If any of the above items are missing, please contact your

supplier.

3. System Requirement



CPU: Pentium 4 (or equivalent AMD) 1.0 GHz or above, 1 GB

RAM



OS: Windows XP/Vista/Win 7



Browser: IE 7 or above

4. Interface Information

Item

No.

Name Description

Ethernet

Indication

LED (blue)

Indicates if the Ethernet link is ok and

packet traffic is sending/receiving. When the

Ethernet cable is connected, the LED is

constant blue light. When there is packet

sending/receiving, the LED is blinking blue

light.

Status

Indication

LED (red)

Indicates the Internet connection status.

When the Internet connection is connected,

the LED will be constant red light. If there is

any Internet connection problem, the LED

will be blinking red light.

3 Lens The focus of the lens is fixed. The effective

focus range is from 30cm to infinity.

4 IR LEDs Totally 36 IR LEDs which can provide

approximately 30m distance night vision

5 Light Sensor

The light detector can detect when the light

is becoming dark and turn on the IR LEDs

automatically

6 Ethernet

Jack

10/100Mbps fast Ethernet port (Connects to

your local area network)

7 Digital Input This is for alarm detection, an open circuit is

Status Indication LED

Ethernet Indication LED

Terminal

Block

off, a close circuit is on.

8 Power Jack

Connects to12V/1.0A power adapter.

Please make sure you are using the correct

power adaptor

9 Reset Button

The button to reset the IP CAM to default

factory settings. You need to press the reset

button for more than 4 seconds to enable

the reset function.

5. Hardware Installation

Please follow the following instructions to set up the IC-9000:

1. Please connect the IP CAM accessories to the body of the

IC-9000 correctly, including the bracket, power adapter and

Ethernet cable, as shown in the above figure.

2. Connect the other end of the Ethernet cable to the home

network or office network. Usually, this Ethernet cable is plugged

into a home NAT/router device or an Ethernet switch if in the

office, as shown in the above figure.

3. Since the default settings of the IP CAM use DHCP function and

very often there is a DHCP server on most of the Home/office

network, the IP CAM should be connected to the Internet

immediately

6. Software Installation

1. Before installing CamView software on your PC or laptop, please

make sure you have correctly installed the IC-9000. It’s highly

recommended to close other Windows applications to prevent

the installation from any possbile confliction.

2. Please insert the installation CD into the CD-ROM drive in your

notebook or personal computer (must be running Microsoft

Windows OS)

3. Execute the program CamView on the disk. The program will

pop-up some windows about the installation options, please

press the “Next” button to proceed with the installation.

4. After the installation is complete, there will be a CamView icon

on the desktop of your computer screen, please execute this

icon. The CamView program will run immediately.

7. Start to Use CamView Software

1. Start the CamView application from either Start -> Programs ->

CamView or the shortcut on the desktop of the Microsoft

Windows.

2. Once the CamView Started, it will search the IC-9000 in your

Local Area Network automatically and show the CAM ID of each

of the found IP Cam in the tree menu –“Auto Search” folder of

the Cam List page.

Note: To save the found Cam ID on your PC, simply drag it from

“Auto Search” folder to “CameraList”. By doing so, you can

easily play the video without memorizing the Cam ID

3. To View the video, simply double click on the CAM ID which you

want to see or drag the CAM ID to one of the video play

windows.

Note: If the Camera you want to see is outside of your LAN and

the Cam ID is not sored in the “CameraList”, please right-click on

the “CameraList”, choose “New Camera” and enter the Cam ID

and password.

Note: For further operation, please refer to the manual.

R&TTE Compliance Statement

This equipment complies with all the requirements of DIRECTIVE 1999/5/EC

OF THE EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999

on radio equipment and telecommunication terminal Equipment and the

mutual recognition of their conformity (R&TTE)

The R&TTE Directive repeals and replaces in the directive 98/13/EEC

(Telecommunications Terminal Equipment and Satellite Earth Station

Equipment) As of April 8, 2000.

Safety

This equipment is designed with the utmost care for the safety of those who

install and use it. However, special attention must be paid to the dangers of

electric shock and static electricity when working with electrical equipment. All

guidelines of this and of the computer manufacture must therefore be allowed

at all times to ensure the safe use of the equipment.

EU Countries Intended for Use

The ETSI version of this device is intended for home and office use in Austria,

Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy,

Luxembourg, Bulgaria, Cyprus, Czech Republic, Estonia, Hungary, Latvia,

Lithuania, Malta, Poland, Romania, Slovakia, Slovenia, the Netherlands,

Portugal, Spain, Sweden, and the United Kingdom.

The ETSI version of this device is also authorized for use in EFTA member

states: Iceland, Liechtenstein, Norway, and Switzerland.

EU Countries not intended for use

None

EuP, 2005/32/EC.

Article15,5,(a): there shall be no significant negative impact on the

functionality of the product, from the perspective of the user
