EDILGRAPPA PR16 Instructions de fonctionnement

BENDING-STRAIGHTENING TOOL

PR16-32 WITH ADJUSTABLE HEAD

USE AND MAINTENANCE

INSTRUCTIONS

MANUAL

PR16-32

BENDING-STRAIGHTENING TOOL PR16-32

AVAILABLE IN THE FOLLOWING VERSIONS:

1. SINGLE-PHASE ELECTRIC MOTOR 230 V 50 Hz

NAME

P/N

BENDING-STRAIGHTENING TOOL PR16-32 WITH ADJUSTABLE HEAD

1.50.2631

PR16-32




3

CONTENTS
DESCRIPTION OF THE MACHINE ...........................................................5
01 MACHINE COMPONENTS......................................................................................................5
02 SAFETY AND DANGER STICKERS -CE PLATE ...................................................................6
03 LIST OF ACCESSORIES INCLUDED INTHE SUPPLY...........................................................7
TECHNICAL FEATURES .............................................................................7
01 HYDRAULIC, MECHANICAL AND ELECTRICAL SPECIFICATIONS....................................7
DELIVERY, COMMISSIONING AND SET-UP.........................................9
01 DELIVERY...............................................................................................................................9
02 ELECTRIC MOTOR...............................................................................................................10
02.01 ELECTRICAL CONNECTIONS....................................................................................10
02.02 COMMISSIONING .......................................................................................................10
03 DOUBLE-ACTING LEVER....................................................................................................10
04 EQUIPMENT OPERATION....................................................................................................11
04.01 HEAD IN STANDARD CONFIGURATION....................................................................11
04.02 ACCESSORIES AVAILABLE ON REQUEST...............................................................12
04.03 STARTING...................................................................................................................13
05 FORESEEN USE AND RESIDUAL RISKS............................................................................17
ROUTINE MAINTENANCE .......................................................................18
01 CHANGING AND TOPPING UP THE OIL..............................................................................18
02 CHECKING SCREWS...........................................................................................................20
03 HYDRAULIC COMPONENTS................................................................................................20
03.01 UNSUCCESSFUL OUTWARD STROKE .....................................................................20
03.02 MAX. PRESSURE VALVE INCORRECTLY ADJUSTED..............................................20
03.03 MAIN CHECKS ON THE MOTOR................................................................................20
04 CHECKING TOOLS...............................................................................................................21
POTENTIAL PROBLEMS AND MEASURES TO BE ADOPTED
...................23
01 GENERAL.............................................................................................................................23
02 TROUBLESHOOTING THE MOTOR.....................................................................................23
03 TROUBLESHOOTING THE HYDRAULIC COMPONENTS ...................................................24
STORAGE AND RESTARTING ................................................................25
01 STORAGE.............................................................................................................................25
01.01 ELECTRIC MOTOR.....................................................................................................25
01.02 CYLINDER AND HYDRAULIC COMPONENTS...........................................................25
02 RESTARTING .......................................................................................................................25
MACHINE DISPOSAL.................................................................................26


PR16-32

A brief legend indicating the most important symbols used in this manual is shown below.

THIS SYMBOL WARNS USERS TO PAY SPECIAL ATTENTION WHEN FOLLOWING

THE RELATIVE INSTRUCTIONS.

FAILURE TO OBSERVE THESE INSTRUCTIONS CAN CAUSE THE MACHINE TO

OPERATE INCORRECTLY.

THIS SYMBOL INDICATES POSSIBLE HAZARDS, TAKE ALL PRECAUTIONS TO

PREVENT THESE SITUATIONS FROM OCCURRING.

BEFORE WORKING ON THE MACHINE, CAREFULLY READ ALL THE

INSTRUCTIONS, ESPECIALLY THOSE CONTAINED IN BOXES.

“OPERATOR”: A person suitably trained and authorised to operate,

adjust, clean and transport the machine.

“MAINTENANCE

PERSON”: A person trained and authorised to perform routine

maintenance on the machine and replace certain

components.

“MACHINE”: The equipment described in this manual.

“ELECTRIC TOOL”: Used in the safety precautions, it is a more general

definition of the machine in question as it refers to

mains-powered electric tools (with cable) or battery-

powered electric tools (cordless).

PR16-32

0 DESCRIPTION OF THE MACHINE

CAUTION!! FIRST READ THE MANUAL REGARDING THE GENERAL AND SAFETY

REGULATIONS!

0.01 MACHINE COMPONENTS

This machine is fitted with a single-phase alternating current motor.

The equipment comprises:

- a motor,

- a hydraulic pump driven by the motor,

- a rod actuator (piston) driven by the oil pressured by the pump,

- a fixed head with tool.

Figure 1 shows the main parts of the equipment, in particular:

1. cylinder with hydraulic components

2. tool-adjustable head

3. double-acting lever

4. grip with start button

5. electrical connecting cable complete with plug

6. electric motor

7. handle

8. oil cap

Fig. 1

PR16-32

0.02 SAFETY AND DANGER STICKERS - CE PLATE

Position of plate and safety and danger stickers on the machine:

PR16-32

Observe the warnings on the plates and stickers. Failure to do so could lead to

injury or death. Make sure the plates and stickers are attached and legible. If not,

apply them or request the maker for replacements.

0.03 LIST OF ACCESSORIES INCLUDED IN THE SUPPLY

•Case

•General safety rules, Use and maintenance instructions

•Declaration of conformity

•Warranty certificate

•Simple repair key, if appropriate

1 TECHNICAL FEATURES

1.01 HYDRAULIC, MECHANICAL AND ELECTRICAL SPECIFICATIONS

Maximum bending size and characteristics of material [ mm and

daN/mm² ]

Ø 32 mm / R = 75 daN/mm²

Maximum output force from rod [ t ]

21.1

Maximum operating pressure [ bar ]

550

Dimensions: Length X Width X Height [ mm ]

601 x 300 x 229

Bending angle

180° to 80° (depending on the

diameter and hardness of the

material)

Weight [ kg ]

24.4

Guaranteed no-load LwA sound level (CEI EN 60745-1 and CEI

EN 60745-2-8) [ dB ]

No-load operator Lpa (CEI EN 60745-1 and CEI EN 60745-2-8)

[ dB ]

Vibrations when bending Ø 32 mm rod (CEI EN 60745-1 and EN

ISO 5349)

4.01 m/s²

Input voltage [ V ]

230

Frequency [ Hz ]

Electrical power [ W ]

1100

Input current [A]

5.3

Insulation class

RPM

10000

PR16-32

2 DELIVERY, COMMISSIONING AND SET-UP

2.01 DELIVERY

The machine is normally shipped and delivered inside

a special hard case, well secured and in a stable

position (see adjacent figure). All materials shipped

are checked prior to delivery.

Upon receipt, check the machine for any damage (breakages or major denting)

caused during transport. If so, it is necessary to immediately inform the shipping

company and to write on the Delivery note the “Accepted subject to checking"

clause.

In the event of damage, send a written complaint to the forwarder within 8 days of

receipt.

Promptly inform Edilgrappa s.r.l. if major damage, caused during transport, is

found upon receipt, or if any parts are missing.

It is also necessary to check the delivered materials against the detailed shipping

list.

The machine can be moved easily both when it is inside its special rigid case, using the

upper handle, and by gripping its upper or lower handle.

Loads must be moved in compliance with current occupational safety regulations.

After use, put the machine back into its case or place it on a stable surface, making sure

this can withstand its weight.

PR16-32

2.02 ELECTRIC MOTOR

2.02.01 ELECTRICAL CONNECTIONS

THE USER SYSTEM AND THE RESPECTIVE CONNECTIONS MUST BE MADE IN

STRICT OBSERVANCE OF THE REGULATIONS IN FORCE, BY COMPETENT

PERSONNEL QUALIFIED TO DO THE JOB.

BEFORE CONNECTING THE APPLIANCE BY MEANS OF THE PLUG SOCKETS,

TURN THE MAIN SWITCH TO OPEN POSITION "O".

2.02.02 COMMISSIONING

These machines do not need any adjustment or particular precautions before

commissioning.

The only controls to perform concern:

- Machine integrity:

make sure that nothing happened during transport that could damage the insulation or

mechanical parts.

- Completeness of supply:

check that all the supplied accessories are fitted.

- Oil level:

check the oil level and top up if necessary as per the instructions in Para 3.01.

IMPORTANT: Before loosening the oil cap carefully read the instructions in Para

3.01.

2.03 DOUBLE-ACTING LEVER

The double-acting lever has two positions (see fig. 2)

-Position 1 ( open ): The piston returns to its original position.

-Position 2 ( close ): The piston performs its outward stroke (bending-straightening

phase).

Fig. 2
