Catalog #7798, 7799

Rev. 12/07 - AJ/mc

Brochure #63-0487

BIG BLOCK CHRYSLER VALLEY COVER PLATES

For B and RB Chrysler Engine Blocks

Catalog #7798 & 7799

INSTALLATION INSTRUCTIONS

PLEASE study these instructions carefully before beginning this installation. Most installations can be accomplished with

common tools and procedures. However, you should be familiar with and comfortable working on your vehicle. If you do

not feel comfortable performing this installation, it is recommended to have the installation completed by a qualified

mechanic. If you have any questions, please call our Technical Hotline at: 1-800-416-8628, 7:00 am - 5:00 pm, Pacific

Standard Time, Monday through Friday or e-mail us at [email protected].

IMPORTANT NOTE: Proper installation is the responsibility of the installer.

Improper installation may result in poor performance and engine or vehicle damage.

DESCRIPTION: These steel Valley Cover Plates are designed to cover the lifter valley of Chrysler big block V8 engines

when Edelbrock Victor Big Block Chrysler cylinder heads #77919 or 77929 are used. A stock sheet-metal valley cover

may not be used with Edelbrock Victor cylinder heads. Part #7798 fits Chyrsler RB (413-426 Wedge-440) engine blocks

and #7799 fits Chrysler B (361-383-400) engines.

KIT CONTENTS:

❑1 Valley Cover Plate

❑14 1/4-20 x 1/2” bolts

INSTALLATION PROCEDURE

(NOTE: Install the valley cover only AFTER your Edelbrock cylinder heads have been installed.)

Edelbrock Corporation • 2700 California St. • Torrance, CA 90503

Tech Line: 1-800-416-8628

E-Mail: [email protected]

1. Be sure that the mating surfaces of the block and the surface of the cylinder heads that will meet the valley

cover are thoroughly clean and free of any oils or debris before installation. Use alcohol or lacquer thinner

on a lint-free rag to clean.

2. Apply a continuous, 1/8” bead of automotive RTV silicone sealer to the end sealing surfaces on block and

along bottom of intake flange on the cylinder head where it will meet the valley cover.

3. Pay special attention to the corners of the cylinder heads where they meet the end seal surfaces (Use a

bit more silicone here).

4. Position the valley cover in place on the engine and install the supplied bolts.

5. Tighten bolts to 10-12 ft./lbs., starting in the center and working your way to the ends.

6. Place the intake manifold in position and torque manifold bolts to 25 ft. lbs., following the factory torque

sequence.
