Eddylight Economy Manuel utilisateur

Economy 5 in 1 Flat LED Par

USER MANUAL

Tap the MENU button and UP button or DOWN button until "Addr" is displayed, press

ENTER.

“Axxx” will now be displayed, “x” represents the displayed address. Press the UP or

DOWN buttons to ﬁnd your desired address.

WARNING

•To prevent or reduce the risk of electrical shock or ﬁre, do not expose this unit to rain or moisture.

•This may cause severe eye damage. Avoid looking directly into the light source at all times

Unpacking: Thank you for purchasing the 7k5in1.Every 7k5in1 has been thoroughly tested and has been shipped in

perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If

the carton appears to be damaged, carefully inspect your ﬁxture for any damage and be sure all equipment necessary

to operate the unit has arrived intact. In the event damage has been found or parts are missing, please contact our toll

free customer support number for further instructions.

The 7k5in1 has one, ﬁve, seven or eight channel. The ﬁxture can operate in three diﬀerent operating modes; DMX

contorl,RF contorl sound-active, or in a Master/Slave conﬁguration. The 7k5in1 comes with several built in programs

that can be used, while operating as a dimmer unit or when used in multiples linked in a master/slave conﬁguration.

For best results use fog or special eﬀects smoke to enhance the beams projections.

•RGBWA Color Mixing

•Color Strobe Eﬀect

•Color Mix Eﬀect

•LED Chases (Adjustable Speeds)

•Electronic Dimming 0-100%

•Built in Microphone

•DMX-512 protocol and RF control

•1/5/7/8 DMX Modes

•Voltage:100V~240V/50~60Hz

•LEDs: 7×5W 5in1 LEDs(Red, Green,Blue, White

,Amber)

•Power Consumption:40W

•Fuse: 1 Amp

•Colors: RGBWA Color Mixing

•Maximum Ambient Temperature: 40°C

•Weight: 0.9Kg

INTRODUCTION

FEATURES

Addr-DMX Address Setting via control board

MODES

Please do not return this unit to your dealer without

contacting customer support ﬁrst.

Tap the MENU button and UP button or DOWN button until "CHND" is displayed, press

ENTER.

“1CH”, “5CH”, “7CH” or “8CH”, will now be displayed, Press the UP or DOWN buttons to

ﬁnd your desired dmx mode.

Chnd-DMX MODE Setting Channel Mode

Tap the MENU button until "SLav" is displayed, press ENTER.

"SLav" will now be displayed, Slave mode is conﬁrmed. It will be slaved by auto mode sound

mode and chase mode.

SLav - This menu will let you select your desired Master/slave mode

Tap the MENU button until "Soun" is displayed, press ENTER.

"Soux" will now be displayed, you can conﬁrm three modes by UP or DOWN for sound mode.

”Se x” will now be displayed by press ENTER, and you can conﬁrm sensitivity by UP or

DOWN for sound mode.

Soun - This menu will let you select your desired sound mode

Tap the MENU button and UP button or DOWN button until "Auto" is displayed, press

ENTER.

"Autx" will now be displayed. You can conﬁrm nine modes by press UP or DOWN for auto

mode.

”SP x” will now be displayed by press ENTER, and you can set speed by UP or DOWN for

Auto mode.

Auto-This menu will let you select your desired auto mode

Tap the MENU button and UP button or DOWN button until "CoLo" is displayed, press

ENTER.

Either "C-X", "X" representing a number between 1 - 51 will be displayed. Press the UP or

DOWN buttons to select either a static color mode. If you select a static color press ENTER

and it will be conﬁrmed.

Colo - This menu will let you select your desired colour mode

Tap the MENU button and UP button or DOWN button until "STAT" is displayed, press

ENTER.

"rxxx", "Gxxx", "bxxx", "vxx" or "Axxx", "sp xx" will be displayed. then you can adjust it

between 1 - 255 by press press UP or DOWN button and you can select other color by ENTER

to adjust it.

Stat - This menu will let you select your desired Stat mode

Tap the MENU button until "reno" is displayed, press ENTER.

“on” or ”oﬀ” will now be displayed,you can select to close or open the infrared, by the UP or

DOWN buttons.

Reno - This menu will let you select your desired sound mode

Tap the UP and DOWN button until “rest” is displayed.

“Yes” or “no” will be now displayed, then tap “ENTER” button to rest to original state when

displayed “yes”.

Rest - Rest to the original state

5CH 7CH 8CH

ch1

ch2

ch3

ch4

ch5

ch6

ch7

ch8

0 - 255

R (0-100%)

G(0-100%)

B(0-100%)

W(0-100%)

A (0-100%)

Dimming (0-100%)

R (0-100%)

G(0-100%)

B(0-100%)

W(0-100%)

A (0-100%)

Strobe speed (Slow-Fast)

Dimming (0-100%

R (0-100%)

G(0-100%)

B(0-100%)

W(0-100%)

A (0-100%)

Functional Channel

Strobe/Programm Speed (Slow-Fast)

0-15 blank, 15-31 auto mode 1,32-47 auto mode 2,****,

208-213 auto mode, 13,230-255 sound mode 2

1 CH

ch 1

0 - 4

5-9

...

250-254

255

LED Oﬀ

Colo 1

Colo 50

Colo 51

Tap the UP and DOWN button until “ver” or “temp” is displayed.

“ver” will be now displayed, tap “ENTER” button that soft version number is displayed.

“temp” will be now displayed, tap “ENTER” button that lights temperature is displayed.

Info-Display system information

DMX Channel Function.

1 Channel mode

Factory setting mode is general mode that means this product remote can use remote control.

Before using the individual control mode, setting rolling code mode that means let it learn code.

The learn code is set to “reno-on-fr.s” then tap the “ENTER” button into learn code

condition that display “......” At the same time, tap the “1” and “3” button, it is successful when

display “----” At the moment, this product is only controlled by the learned remote control.

Rest to factory setting, if all the product need to operate by remote control. Way is that “rest” -

“Yes” and “ENTER” button.

FR Controller

FR Remote control Setting Instruction

DMX

AUTO

SOUND

1 2 3

SOUND

STROBE

SPEED

DOWN

SLAVE

Power On/Oﬀ button

DMX button, to control DMX address when press

this button. It is channel mode when double click.

Master - Slave mode button.

Automatic mode buttons

Sound mode buttons

Speed adjustive button

Up and Down button, you

can choose the program

that you need or numerical.

Color choosing buttons

Strobe button
