1
CHAPTER ONE
1
Overview
The eDAQ pH/mV Amp is designed to work with an e-corder system,
recording signals from:
• pH electrodes
• potentiometric ion selective electrodes (ISEs)
• redox (or ORP, oxidation–reduction) potentiometric electrodes
• other high impedance sources up to ±2 V requiring electrometer
input.
The in built temperature amplifier can be used to provide automatic
temperature compensation (ATC) for pH and ion selective electrodes.
This chapter provides an overview of the pH/mV Amp, and describes
its basic features.
2
pH/mV Amp
How to Use this Manual
This manual describes how to set up and begin using your pH/mV
Amp. The use of the pH/mV Amp with the Chart software pH
Calibration extension is discussed. The appendices provide technical
and troubleshooting information.
Checking the pH/mV Amp
Before you begin working with the pH/mV Amp, please check that:
• all items described in the packing list are included; and that
• there are no signs of damage that may have occurred during
transit.
Contact your eDAQ distributor if you encounter a problem.
You should also become familiar with the basic features of your
e-corder
system, which are discussed in the
e-corder
Manual
on the
Installer CD.
.
eDAQ Amps
The pH/mV Amp is part of a family of preamplifiers known as eDAQ
Amps.
The pH/mV Amp is designed for recording signals from pH and other
potentiometric electrodes. As with other eDAQ Amps, it is designed to
be operated under full software control and is automatically recognized
by Chart or Scope software which controls its gain range, signal
filtering, and other settings.
The range of eDAQ Amps includes the:
•
pH/mV Amp
, suitable for connection of pH, ion selective, and
potentiometric (ORP) electrodes
Chapter 1 —
Overview
3
•
Potentiostat
, a three–electrode potentiostat that can be used for
voltammetric and amperometric experiments. Gain ranges of 20 nA
to 100 mA in 1:2:5 steps.
•
Picostat
, a high sensitivity three–electrode potentiostat suitable for
use with carbon fibre and other microelectrodes. Current gain
ranges of 10 pA to 100 nA in 1:2:5 steps.
•
Bridge Amp
, suitable for sensors requiring a low drift, high gain
differential amplifier. Also provides DC excitation
•
GP Amp
, suitable for high output sensors requiring a high
impedance single ended or differential amplifier. Also provides DC
excitation.
See our web site at www.eDAQ.com for more information.
4
pH/mV Amp
pH/mV Amp
5
CHAPTER TWO
2
The pH/mV Amp
This chapter describes how to connect and use your pH/mV Amp.
IMPORTANT:
Always make sure that the
e-corder
is turned off before
you connect or disconnect the pH/mV Amp. Failure to do this may
result in damage to the
e-corder
and/or the pH/mV Amp.
6
pH/mV Amp
The Front Panel
The
front panel of the pH/mV Amp is shown in Figure 2–1.
The Electrode and Reference Input
The BNC input connector of the pH/mV Amp provides connection for a
pH, ISE or redox electrode. Combination electrodes (that is those with
an internal reference) will only need to be connected to this input.
Electrodes that do not have an internal reference (most ISEs and some
pH electrodes), will need to be used with a separate reference
electrode. This electrode can be connected via the 4 mm Reference
socket. This is in common with the shield (ground) of the BNC electrode
input connector.
The Online Indicators
When lit, these indicate that the software (such as Chart or Scope) has
located and initialized the pH/mV Amp. If the light does not go on
when the software is run, check that the pH/mV Amp is properly
connected. There are two indicators, one to show connection of the
electrode signal, and the second to show connection of the temperature
signal.
pH / mV Amp
Electrode Reference
Temperature
Temperature probe input,
3-pin mini-audio socket
On-line indicator,
temperature signal
Reference electrode,
4 mm socket
Electrode input,
BNC connector
On-line indicator,
electrode signal
Figure 2–1
The pH/mV Amp front
panel
