Ecolink NanoFIL Manuel utilisateur

Contents

Chapter 1. Introduction

Chaper2. Parameters

Chapter 3 Product Working Principles

Chapter 4. Product Features

Chapter 5. Using Steps

Chapter 6. Calibration

Chapter 7. Pollution Comparison Table

Chapter 8. Precautions

Chapter 9. Care and Maintenance

Chapter 10: Customer Service and Warranty Clauses

Chapter 11. Recommended places to use

Chapter 12. Connection to Network

Chapter 13. Product packaging List

Chapter 1. Introduction

is a versatile air quality monitor that can simultaneously detect PM2.5, PM10,

CO2, TVOC, formaldehyde, temperature and humidity data. Users can register an account on

NanoFIL cloud platform, and associate it with different NanoFIL Air Monitors where their data

detected will be displayed on PC terminal, mobile App, TV or display device for real-time

monitoring.

In addition, the monitor can be used to automatically control air purification devices according to

the air quality data and parameters of the detecting points. NanoFIL cloud platform also supports

multi-account management control, for the convenience of managing air monitoring and

purification equipment in large scale.

Cloud Air Detector

Display Screen

Alarm Button

Switch Button

WIFI Button

Power Button

Air Inlet

USB interface

1. Air Inlet: Collect the detected air. Do not block the inlet during operation

2. Power Button : Press for 3 seconds to turn on or press for 3 seconds to turn off the

monitor

3. Switch Button : Press once at a time to switch to view different data detected;

4. Alarm Button : When the detection value exceeds the pre-set parameter, the device

buzzer will automatically alarm. Press the button once to turn off. Press again to activate.

5. WiFi Button : Press the WiFi button to connect the device to the Internet. Press again to

turn off

6. Display Screen: PM2.5 concentration value, TVOC concentration value, CO2 concentration

value, formaldehyde concentration value, temperature and humidity, WiFi, remaining

power, alarm on / off reminder, year-date-time

7. Air Outlet: Exchange of air. Do not block the inlet during operation

8. USB interface: USB charging.

Chaper2. Parameters

PM2.5

CO2

TVOC

Temperature

Humidity

Formaldehyde

Air Inlet

Air Outlet

1. Product Size

Dimension: 89.5 * 63.5 * 174mm

2. Product Weight

Host weight: 320g

3. Power parameters

Input voltage: 5V

Battery capacity: 4400mAh

Power: 8W

Charge current: 1.6A

Measurement indicators and scope

Sensor Parameters

Parameter

Measuring range

measurement

accuracy

Resolution

PM2.5

0-2000µg/m³

±10%

0.3μm

CO2

0-2000ppm

±50ppm

1ppm

TVOC

0.000-9.999mg/m³

±0.01mg/m³

0.01mg/m³

Formaldehyde

0.000-4.0mg/m³

0.01-0.2mg/m³

±5%

0.01mg/m³

Temperature /

Humidity

-40-80℃0-99.9%RH

±1℃±1%℃

0.1%RH

Note: If the instrument is placed in an environment beyond the measuring range for an extended

period of time (such as placing a cigarette at the instrument air inlet for a long time), it may result

in measurement error.

Environmental conditions

Working environment: 5 to 45 ℃

Storage environment: -20 to 30 ℃

Product Model Configuration Table

NanoFIL Air Monitor

PM2.5

√

CO2

√

TVOC

√

Formaldehyd

√

Temperature

/ Humidity

√

WiFi

√

Chapter 3 Product Working Principles

versatile air quality monitor that can simultaneously detect PM2.5, PM10,

CO2, TVOC, formaldehyde, temperature and humidity data. PM2.5 sensor is a digital particle

concentration sensor, based on the principle of laser scattering. It can continuously collect and

calculate per unit volume of air in different sizes and concentration of suspended particulate

matter, and then converted to mass concentration and digital data output. It can be embedded in a

variety of airborne suspended particulate matter concentration-related instruments or

environmental improvement equipment, to provide timely and accurate concentration data. CO2

sensor collects data by NDIR infrared measurement principle. Formaldehyde is detected by the

principle of electrochemical. TVOC is detected by the principles including semiconductor

measurement.

Chapter 4. Product Features

1. The latest technology: the current PM2.5 laser scattering precision detection technology,

sensitive response, accurate data measurement;

2. Real-time detection: automatically refresh the data to detect air quality;

3. Multi-purpose: real-time display of PM2.5, PM10, CO2, TVOC, formaldehyde, temperature

and humidity data;

4. Color screen display: digital LCD display, simple and intuitive;

5. Tiny and convenient: easy to carry, easy to operate;

6. Quick response: fast data reading, stable performance;

7. WiFi interface: press WiFi button to connect to the network.

8. Standby power consumption: long operating time, can be used continuously for 8 hours;

Cloud Air Detector is a

Chapter 5. Using Steps

First time of use:

1. Before you begin, plug the instrument into the power and charge it for 2 to 4 hours;

2. When warming up the instrument, put it in an area with adequate air circulation (such as

near a window) to calibrate.

During use:

1. Whenever the monitor needs to restart, it will require 5 to 10 seconds to warm up after

reboot, the carbon dioxide sensor needs to warm up for 3 minutes. Upon completion, the

monitor can start measurement.

2. Put the monitor in a better environment to start measurement. When the data is stable, the

reading is done;

3. Take measurement at different points of a room and calculate an average value of the

measurement results, then it will be the average pollution value of the room.

Chapter 6. Calibration

Calibration instructions:

1. First place the instrument in a good place (such as: outdoor, balcony, window), turn on the

instrument for more than 10 minutes. TVOC will be automatically calibrated;

2. Press MODE switch button to select the formaldehyde interface, then simultaneously

press MODE switch button and alarm button for 3 seconds. Formaldehyde will be

automatically calibrated;

3. PM2.5 and carbon dioxide do not need calibration.

Time calibration: be performed without network connection

Chapter 7. Pollution Comparison Table

PM 2.5 Concentration Comparison Table

PM 1.0 Concentration Comparison Table

Pm2.5 Concentration

（ug/m³)

Air Quality

Pm1.0 Concentration

（ug/m³)

Air Quality

0-35

Excellent

0-50

Excellent

35-75

Good

50-100

Good

75-115

Mild pollution

100-200

Mild pollution

115-150

Moderate

pollution

200-300

Moderate

pollution

150-250

Severe pollution

Above 300

Severe pollution

Above 250

Serious pollution

CO2 Concentration Comparison Table

TVOC Concentration Comparison Table

CO2 Concentration

（ppm）

Air Quality

TVOC Concentration

（mg/m³）

Air Quality

450-700

Fresh

0.0-0.6

Good

700-1000

Better

0.6-1.0

Mild pollution

1000-1500

Little turbid

1.0-1.6

Moderate

pollution

1500-2000

Turbid

Above 1.6

Severe pollution

Formaldehyde Concentration Comparison Table

Formaldehyde Concentration（mg/m³）

Air Quality

0.00-0.03

Excellent

0.03-0.1

Good

0.1-0.2

Mild pollution

0.2-0.3

Moderate pollution

0.3-0.8

Serious pollution

Above 0.8

Severe pollution

Chapter 8. Precautions

1. Multi-point detection

The composition of the air in different locations is not necessarily uniform, like the content

of pollution will certainly be different at every corner of the room. Users are better to detect

by multi-point sampling, and take the average value as reference.

2. Avoid interference

During measurement process, please try to avoid the interference of methanol / ethanol

fume, such as cigarettes, alcohol, perfume, cosmetics, skin care products (hand oil) to avoid

measurement error. Before measurement, set the monitor in good ventilation to eliminate

interference. In addition, be sure not to blow the monitor with mouth, doing so will after

the lifespan of sensors.

3. Low temperature detection

When the temperature is below zero degree, the sensitivity of sensors will decrease.

Therefore, please do not leave the monitor work in prolonged low temperature (longer than

30 minutes).

4. Ensure the air flow is stable

Gas molecules in space have been following random Brownian motion, gas distribution is

susceptible to air flow interference. As far as possible to make the air flow stable before

measurement.

5. Not used for a long time

When monitor has not been used for a long time, it will require to reboot by following the

First Time of Use procedure in Chapter 5.

Chapter 9. Care and Maintenance

1. Please keep the product dry against rain, moisture and various liquids that may corrode the

electronic circuit, resulting in damage to product;

2. Do not disassemble the internal components and casing;

3. Avoid strong shocks or vibrations to the instrument;

4. Do not seal the instrument;

5. Do not use the instrument in an environment of high soot concentration, that will affect the

life of the instrument;

6. Please keep the air inlet of this product unobstructed.

Chapter 10: Customer Service and Warranty Clauses

NanoFil provide products within the scope of the provisions of the Three Guarantees service

1. Consumers who have quality problems within 7 days from the date of purchase of the

NanoFil Air Monitor have the option to return / exchange their products.

2. Consumers who have quality problems within 30 days from the date of purchase of the

NanoFil Air Monitor have the option to replace new instrument.

3. Consumers enjoy a full year of warranty from the date of purchase of NanoFil Air Monitor

Situations of non-warranty:

a) Purchase receipt and warranty card are the certificate for the Three Guarantees. Warranty

service cannot be provided if there is any record modification or product information does not

match with the real.

b) Disassemble or modify the product to cause malfunction or damage to the product;

c) Man-caused damage

d) Does not comply with the relevant provisions of the Three Guarantees;

e) Malfunctions caused by bad environment, such as excessive input voltage, moisture,

corrosion, rust, etc .;

If exceeding the warranty period, our company will only charge costs for repairing.

Service hotline: (852) 3955 0207

Working hours: Monday to Friday 9:00 am to 6:00 pm (Closed on holidays)

Chapter 11. Recommended places

Suitable for a variety of indoor and outdoor places.

Chapter 12. Connection to Network

1. Press and hold the Power Button on the monitor. After powering on, press the MODE

Switch button to display the QR code screen. Scan the QR code with your mobile phone

to download the APP and register an account or login by Wechat. After clicking the APP,

select scan QR code and scan the QR code at the bottom of the instrument;

2. Short press the "WiFi" button on the monitor to start the WiFi icon, press and hold the

WiFi button for about 3 seconds, then after the “beep” sounds the WiFi icon on the

display will flash, click “Next”;

3. Connect your mobile phone with WiFi, APP will automatically detect WiFi router’s name.

Enter WiFi password manually. Click “Next”, it will display "Uploading Server". Wait for

around ten seconds, and if it displays "Network Matching Success", it indicates successful

matching of network;

4. Users can edit the device name and select its location. After that, click to enter the

homepage. (When the time expires, “Configuration Timeout” will be displayed, click “OK”.

At this time, check if the mobile phone is connected to the WiFi router or the WiFi password

is correct. If there is no problem, press the “WiFi” button and turn it off for 3 seconds.

Then turn it on and repeat Step 2;

5. According to users’ requirements, it can be provided in digital TV and advertisement

machines. Users simply log in the APP on the interface, the data of each detecting points

can be monitored in real time.

Adding device

1. Click “Register Now” on the User Login interface in mobile phone and follow the instructions

to register.

2. After registration, enter the user name and password and click “Login” to enter the list.

3. Click “Add” to add device, click “+” icon on the upper right corner, scan the QR code on the

device bottom and then repeat step 2,3,4.

APP Download: www.nanofil.com.hk

Chapter 13. Product packaging List

1. Host Device: 1

2. Adapter: 1

3. Charging Line: 1

4. User Manual: 1

5. Maintenance Card: 1

Table des matières

Autres manuels Ecolink Capteur de sécurité

Ecolink

Ecolink Firefighter FF-ZWAVE5 Manuel utilisateur

Ecolink

Ecolink CS-202 Manuel utilisateur

Ecolink

Ecolink URC4470BC0-X-R Manuel utilisateur

Ecolink

Ecolink FLZB1-ECO Mode d’emploi

Ecolink

Ecolink WST-740 Manuel

Ecolink

Ecolink WST-712 Manuel utilisateur

Ecolink

Ecolink Firefly WST-602 Manuel utilisateur

Ecolink

Ecolink WST-702 Manuel utilisateur

Ecolink

Ecolink WST-612 Mode d’emploi

Ecolink

Ecolink CS-732 Manuel utilisateur

Ecolink

Ecolink firefighter Manuel utilisateur

Ecolink

Ecolink WST-702 Manuel utilisateur

Ecolink

Ecolink WST-601 Mode d’emploi

Ecolink

Ecolink WST-621v2 Manuel utilisateur

Ecolink

Ecolink TX-E611 Instructions de montage

Ecolink

Ecolink Firefighter FFZB1-ECO Mode d’emploi

Ecolink

Ecolink WST-302 Manuel utilisateur

Ecolink

Ecolink FireFighter CS-602 Mode d’emploi

Ecolink

Ecolink ClearSky CS-242 Manuel

Ecolink

Ecolink WST-611 Manuel utilisateur

Ecolink

Ecolink PIR-ZWAVE2 Manuel utilisateur

Ecolink

Ecolink Firefighter CS-600 Mode d’emploi

Manuels Capteur de sécurité populaires d'autres marques

THORLABS

THORLABS PDA10JT Manuel utilisateur

Waeco

Waeco UV-DETECT Manuel utilisateur

Intermatic

Intermatic IOS-DSIMF Manuel utilisateur

urmet domus

urmet domus 1083 Manuel utilisateur

Siemens

Siemens AZL66 Series Manuel utilisateur

BTI

BTI Profiline Multi Finder Manuel utilisateur

Challenger

Challenger SL01 Manuel utilisateur

DMP Electronics

DMP Electronics 1122INT Manuel utilisateur

Rielta

Rielta Ladoga MK-RK Manuel utilisateur

Mirion Technologies

Mirion Technologies ACCURAD PRD Manuel utilisateur

Bosch

Bosch DS835 Manuel utilisateur

DBI SALA

DBI SALA EZ Stop Manuel de l'opérateur

Lamptime

Lamptime ST05C Manuel utilisateur

Ubiquiti

Ubiquiti MFI-MSC Manuel utilisateur

Subsite

Subsite 910R Instructions d'installation

Satel

Satel OPAL Pro Manuel utilisateur

Aleph

Aleph XC-1XTEU Manuel utilisateur

Pima

Pima LARIS QUAD Manuel utilisateur
