ImmersoJet Series
No. 330, 10/02
Design Guide
Eclipse
ImmersoJet
v2.20 Design Guide 330, 10/02
Copyright I997 by Eclipse Combustion,Inc.All rights reserved
worldwide.This publication is protected by federal regulation and
shall not be copied, distributed, transmitted, transcribed or
translated into any human or computer language, in any form or
by any means, to any third parties, without the express written
consent of Eclipse Combustion, Inc., Rockford, Illinois, U.S.A.
We reserve the right to change the construction and/or
configuration of our products at any time without being obliged
to adjust earlier supplies accordingly.
The material in this manual is believed adequate for the intended
use of the product. If the product, or its individual modules or
procedures, are used for purposes other than those specified
herein, confirmation of their validity and suitability must be
obtained. Eclipse Combustion, Inc. warrants that the material
itself does not infringe any United States patents. No further
warranty is expressed or implied.
We have made every effort to make this manual as accurate and
complete as possible. Should you find errors or omissions, please
bring them to our attention so that we may correct them. In this
way we hope to improve our product documentation for the
benefit of our customers. Please send your corrections and
comments to our Documentation Manager.
It must be understood that Eclipse Combustion’s liability for its
products, whether due to breach of warranty, negligence, strict
liability, or otherwise, is limited to the furnishing of such
replacement parts and Eclipse Combustion will not be liable for
any other injury, loss, damage or expenses, whether direct or
consequential, including but not limited to loss of use, income of
or damage to material arising in connection with the sale,
installation, use of, inability to use or the repair or replacement
of Eclipse Combustion’s products.
Any operation expressly prohibited in this Guide, any adjustment,
or assembly procedures not recommended or authorized in
these instructions shall void the warranty.
COPYRIGHT
DISCLAIMER NOTICE
LIABILITY AND
WARRANTY
2
Eclipse ImmersoJet v2.20 Design Guide 330, 10/02
AUDIENCE
RELATED DOCUMENTS
About this manual
This manual has been written for people who are already
familiar with all aspects of an immersion burner and its add-on
components, also referred to as “the burner system.”
These aspects are:
• design/selection
• use
• maintenance.
The audience is expected to have experience with this kind of
equipment.
Design Guide No. 330
• This document
Data Sheet No. 330-2, 330-3, 330-4, 330-6, 330-7, 330-8
• Available for individual IJ models
• Required to complete design calculations in this guide
Installation Guide No. 330
• Used with Data Sheet to complete installation
Price List No. 330
• Used to order burners
• EFE 825 (Combustion Engineering Guide)
• Eclipse bulletins and Info Guides:
610, 710, 720, 730, 742, 744, 760, 930
Purpose
The purpose of this manual is to make sure that the design of a
safe, effective and trouble-free combustion system is carried out.
IMMERSOJET
DOCUMENTS
3
Eclipse
ImmersoJet
v2.20 Design Guide 330, 10/02
There are several special symbols in this document.You must
know their meaning and importance.
The explanation of these symbols follows below. Please read it
thoroughly.
dDanger:
Indicates hazards or unsafe practices which WILL
result in severe personal injury or even death.
Only qualified and well trained personnel are
allowed to carry out these instructions or
procedures.
Act with great care and follow the instructions.
wWarning:
Indicates hazards or unsafe practices which
could result in severe personal injury or damage.
Act with great care and follow the instructions.
cCaution:
Indicates hazards or unsafe practices which could result in
damage to the machine or minor personal injury.
Act carefully.
nNote:
Indicates an important part of the text. Read thoroughly.
If you need help,you can contact your local Eclipse Combustion
representative. You can also contact Eclipse Combustion at any
of the addresses listed on the back of this document.
DOCUMENT
CONVENTIONS
HOW TO GET HELP
4
Eclipse ImmersoJet v2.20 Design Guide 330, 10/02
Table of Contents
About this manual ............................................................. 3
Table of contents ................................................................ 5
Introduction ........................................................................... 7
Product Description .................................................................. 7
Safety.......................................................................................... 9
Introduction ................................................................................. 9
Safety ............................................................................................ 9
Capabilities ................................................................................... 10
OperatorTraining ....................................................................... 10
Replacement Parts ..................................................................... 10
System Design...................................................................... 11
Step 1: Burner model selection ......................................... 11
Step 2:Tube design................................................................ 13
Step 3: Control methodology ............................................ 15
Step 4: Ignition system ......................................................... 16
Step 5: Flame monitoring system ...................................... 16
Step 6: Combustion air system.......................................... 17
Step 7: Main gas shut-off valve train ................................. 20
Step 8: Process temperature control system ................. 20
Appendix.................................................................................. 21
Key to the system schematics ................................................. 22
1
2
3
5
Eclipse
ImmersoJet
v2.20 Design Guide 330, 10/02
This page left blank intentionally.
6
Eclipse ImmersoJet v2.20 Design Guide 330, 10/02
Introduction
PRODUCT
DESCRIPTION
Figure 1.1 The ImmersoJet Burner
1
The combustion gases from the burner scrub the inner tube
surface and produce high heat transfer rates. This, in
combination with the high velocity flow through the smaller
diameter tubes allows for system efficiencies in excess of 80%.
The smaller ImmersoJet tubes also have smaller bends which
means less tank space is occupied by the tubes.With a
combustion chamber that is integral to the burner body, the
new version of the ImmersoJet can sit lower on the tank than
previous ImmersoJet models.
FEATURES
7
The ImmersoJet (IJ) is a nozzle-mix tube-firing burner that is
designed to fire at high velocities through small diameter
immersion tubes. The standard burner includes a packaged
blower, actuator control motor, integral butterfly valve, ratio
regulator, burner body, combustion chamber, nozzle (specific to
fuel used), rear cover, spark and flame rods, and gas orifice (also
specific to fuel used).
Eclipse
ImmersoJet
v2.20 Design Guide 330, 10/02
This page left blank intentionally.
8
Eclipse ImmersoJet v2.20 Design Guide 330, 10/02
Safety 2
In this section you will find important notices about safe
operation of a burner system.
dDanger:
The burners covered in this manual are designed
to mix fuel with air and burn the resulting
mixture. All fuel burning devices are capable of
producing fires and explosions when improperly
applied, installed, adjusted, controlled or
maintained.
Do not bypass any safety feature; You can cause
fires and explosions.
Never try to light the burner if the burner shows
signs of damage or malfunctioning.
wWarning:
The burner is likely to have HOT surfaces.Always
wear protective clothing when approaching the
burner.
nNote:
This manual gives information for the use of these burners
for their specific design purpose. Do not deviate from any
instructions or application limits in this manual without
written advice from Eclipse Combustion.
Read this entire manual before you attempt to start the
system. If you do not understand any part of the information
in this manual, then contact your local Eclipse representative
or Eclipse Combustion before you continue.
INTRODUCTION
SAFETY
9
Eclipse
ImmersoJet
v2.20 Design Guide 330, 10/02
Adjustment, maintenance and troubleshooting of the mechanical
and the electrical parts of this system should be done by
qualified personnel with good mechanical aptitude and
experience with combustion equipment.
The best safety precaution is an alert and competent operator.
Thoroughly instruct operators so they demonstrate an
understanding of the equipment and its operation. Regular
retraining must be scheduled to maintain a high degree of
proficiency.
Order replacement parts from Eclipse only.Any customer-
supplied valves or switches should carry UL, FM, CSA,CGA and/
or CE approval where applicable.
CAPABILITIES
OPERATOR
TRAINING
REPLACEMENT PARTS
10
