Installation Guide
tel - 1-800-477-2267 (East Coast) - 1-888-883-2790 (West Coast)
SSM-RBP / SSM-DIS
Parking Sensor System
with Buzzer or Display
Introduction
Box Contents Key Features
uCustomizable sensor kit to t your application
uDigital LED Display (SSM-DIS only)
uAdjustable volume control buzzer (SSM-RBP only)
uFully automatic operation
uBuzzer silence with no movement detection
uSpeed dependent automatic power on
for front camera
uBuzzer (SSM-RBP only)
uDisplay (SSM-DIS only)
uOverride Button (SSM-DIS only)
uSensor Module
uPower Harness
uData cable (SSM-DIS only)
uInstallation Accessories
uWarranty Card
uInstallation Guide
Congratulations on purchasing EchoMaster parking sensors. This ultrasonic
detection system is designed for you and your vehicle’s safety.
Disclaimer:
EchoMaster® is strictly a driver assistance device, and should not be relied upon as a substitute for safe driving
practices. Use common sense when parking and always follow recommended safe driving guidelines from your local,
State and County Department of Motor Vehicles regarding parking procedures. To help prevent accidents, always
use caution when parking, looking visually to ensure your path is clear. Keep speeds under three miles per hour. The
owner shall not be entitled to recover from the Company, its successors or assignees, incidental and consequential
damages, such as personal injury, loss of income, loss of time, loss of prots, loss of vehicle use or property damage.
No employee, agent or representative of the Company of the Selling Retailer may modify alter or extend this Warranty
in any way. This Warranty gives you specic legal rights. You may also have other rights under this Warranty which
may vary from state to state.
Note: Under no circumstances should you attempt to open the control box or any other component. Doing so will void
all manufacturer’s warranties.
This manual covers the following products:
SSM-DIS Sensor Module with Display - Front/Rear
SSM-RBP Rear Sensor Module with Buzzer
These products are to be used with any of the following:
SEN-XX Colored Sensors to match your vehicle
SEN-MB Sensors made for metal bumpers
SEN-FM Flush Mount sensors for OEM look
