Echogear EGAV-SFSBP2 Manuel utilisateur

EGAV-SFSBP2

INSTRUCTION MANUAL

Bookshelf

SPEAKER STANDS

#YourGearUpgraded

25 lbs.

(11 kg)

"Give it back

to Phil when

you ﬁnish"

Speaker Weight Limit:

DO NOT EXCEED

Tools Needed

Phillips Screwdriver

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the

item to your dealer; contact the ECHOGEAR Pros. Never use damaged parts!

CAUTION: Avoid potential personal injuries and property damage!

•Check your speaker owner’s manual to see if there are any special requirements for mounting your speaker.

•Please read through these instructions completely to be sure you’re comfortable with this easy install process.

• Do not use this product for any purpose not explicitly speciﬁed by manufacturer.

• Manufacturer is not responsible for damage or injury caused by incorrect assembly or use.

• If you do not understand these instructions or have doubts about the safety of the installation,

assembly or use of this product, contact Customer Service.

Yea, the boring stuff ... but read it, so you don’t jack things up!

ECHOGEAR.com ECHOGEAR.com

Confuzzled? Contact the ECHOGEAR Pros:

(Australia)

+61 (0) 7 3299 7000

(North America)

P: 1-855-428-2490

(Europe)

P: +44 (0) 800 0568188

helpmehelpy[email protected] helpme@ECHOGEAR.com

#10 x 2 ¼ in.

#10 x 1 in.

1/4-20 x 5/8 in.

1/4-20

1/4-20 x 1 ½ in.

qty. 2 qty. 2

qty. 2

qty. 8

qty. 1

qty. 8

qty. 4

PILLAR

CABLE COVER

TOP PLATE

1/4-20 Carpet Spike

1/4-20 x 5/8 Screw

Speaker Stud

Speaker Pads (8)

#10 x 2-1/4” Wood Screw (Base)

#10 x 1” Wood Screw (Top Plate)

1/4-20 Nut

BASE

Plastic Foot

02 03

What’s in the Box ... What’s IN THE Boooooxx

WARNING: DO NOT FEED TO CHILDREN! This product contains small items that could be a choking hazard if swallowed. Keep these

items away from young children!

CAUTION:

DO NOT

overtighten

screws.

CAUTION:

DO NOT

overtighten

screws.

“We can’t have

nice things!”

"Hey, nice rug

... it really

ties the room

together."

"Scratch [skrach]:

A boo boo that causes

temporary or permanent

damage to skin or ﬂooring."

08 09

"For even MORE security,

try museum putty ... sold at

museums everywhere."

02 12

6901-602388 00
