Echo GT-2000 Type 1E Mode d’emploi
1
KEY PART NUMBER QTY DESCRIPTION REMARKS
GT-2000 TYPE 1E
GRASS TRIMMER
PARTS CATALOG
MODEL GT-2000
TYPE 1E
SERIAL NUMBER 001001 & UP
ECHO, INCORPORATED
400 OAKWOOD ROAD
LAKE ZURICH, IL 60047
99922202768
08/01
2
GT-2000 TYPE 1E
26
ENGINE, EXTERNAL/INTERNAL/CRANKCASE/FAN HOUSING/COVER
3
KEY PART NUMBER QTY DESCRIPTION REMARKS
GT-2000 TYPE 1E
1 10151448730 1 COVER,CYLINDER
2 10101146830 1 CYLINDER
3 90016205022 2 BOLT,H.S. 5X22
4 10101044332 1 GASKET,CYLINDERBASE USEKIT88900042031
5 10000048730 1 PISTONKIT INCLUDES ITEMS 6, 7, 8 & 10
6 10001105330 2 RING,PISTON
7 10001311520 1 PIN,PISTON
8 10001504630 2 CIRCLIP,PISTONPIN
9 10001251230 1 BEARING,NEEDLE
10 10001411520 2 SPACER,PISTONPIN
11 ------------------ 1 CRANKCASEKIT(USESB1026) INCLUDESITEMS 13,14, 15& 17
12 10021242030 2 OILSEAL
13 10021503930 2 PIN,DOWEL
14 90081036201 2 BEARING, BALL 6201
15 ------------------ 1 CRANKSHAFT(USESB1026)
16 ------------------ 1 GASKET,CRANKCASE USEKIT88900042031
17 90025304012 2 SCREW 4X12
18 90016205028 3 SCREW 5X28
19 89011548730 1 LABEL,MODEL
20 90025304016 2 SCREW 4X16
21 90056500005 2 NUT 5
22 90014205028 2 BOLT 5X28
23 90023804018 4 SCREW 4X18
24 10150348730 1 COVER,FAN(INCLUDESCLUTCHDRUM,BEARINGS&CIRCLIP)
25 90025305016 1 SCREW 5X16
26 15991248630 1 GUARD,TOP
ENGINEREPOWER
SB1026 1 SHORTBLOCK INCLUDESFACTORYASSEMBLED
CYLINDER,CRANKCASE,PISTON,
CRANKSHAFT,BEARINGSANDSEALS.
OPTIONAL
88900042031 1 GASKETKIT
10101044332 1 GASKET,CYLINDERBASE
------------------ 1 GASKET,CRANKCASE
13001642031 1 GASKET,INTAKE
13001042031 1 GASKET,INTAKE
14586642031 1 GASKET,MUFFLERLID
14551042031 2 GASKET,MUFFLER
ENGINE, EXTERNAL/INTERNAL/CRANKCASE/FAN HOUSING/COVER
4
GT-2000 TYPE 1E
4
25
STARTER, IGNITION, CLUTCH
5
KEY PART NUMBER QTY DESCRIPTION REMARKS
GT-2000 TYPE 1E
1 15680144730 1 FLYWHEEL S/N001001-005037
1 15680109660 1 FLYWHEEL S/N 005038 & UP
2 17500049030 1 CLUTCHASY
3 90016204022 2 SCREW 4X22
4 15660152130 1 COIL,IGNITION S/N001001-005037
415662609660 1 COIL,IGNITION S/N 005038 & UP
5 15011244330 1 GROMMET,H.T.CORD
6 15901201620 1 CAP, SPARK PLUG
7 15901103432 1 COIL,SPARK PLUG CAP
8 15901010630 1 PLUG, SPARK BPM-7A
8 15901010230 1 PLUG, SPARK BPMR-7A CANADIANMODELSONLY
9 16340003460 1 SWITCH,IGNITION
10 16381044330 1 BRACKET,SWTICH
11 17720244330 1 PAWL ASY, STARTER INCLUDESITEMS 12&13
12 17723442030 1 SPRING, RETURN
13 17721844330 1 PAWL,STARTER
14 17720044334 1 STARTERASY INCLUDESITEMS 15 -21
15 17723644330 1 SCREW
16 17721442030 1 WASHER
17 17721542030 1 DRUM,STARTER
18 17722806530 1 GRIP,STARTER
19 17722742030 1 GUIDE,ROPE
20 ------------------ 1 ROPE,STARTER USEBULKROPE99944400040
DIA.3mm (.12IN.) X890 mm(35IN.)
21 17722042030 1 SPRING,REWIND
22 17723244332 1 CASE,STARTER
23 90016204016 2 SCREW 4X16
24 89011849130 1 LABEL,ECHO
25 16202152130 1 LEAD
REVISED08/01
STARTER, IGNITION, CLUTCH
6
GT-2000 TYPE 1E INTAKE, AIR CLEANER, EXHAUST, FUEL SYSTEM
4
21 4
5
6
7
KEY PART NUMBER QTY DESCRIPTION REMARKS
GT-2000 TYPE 1E
1 21041752730 1 WINGSTUD
2 13031306562 1 COVER,AIR CLEANER
4 13031054130 1 FILTER,AIR
5 90024205065 2 SCREW 5X65
6 12901152730 1 PLATE,PREVENT
7 13030706561 1 CASE,AIRCLEANER
8 89012106360 1 LABEL,CHOKE
9 12520049030 1 CARBURETOR C1U-K47 S/N001001-229418
9 12520013312 1 CARBURETORC1U-K52 S/N 229419 & UP
10 13001642031 1 GASKET,INTAKE
11 13001742031 1 INSULATOR
12 13001042031 1 GASKET,INTAKE
13 90050000005 1 NUT5
14 90023805020 2 SCREW 5X20
15 14580042031 1 MUFFLERASY INCLUDESITEMS16-22
16 14551042031 2 GASKET,MUFFLER
17 14587144331 1 COVER,MUFFLER
18 14580642030 1 MUFFLER
19 14586240630 1 SCREEN,MUFFLER
20 14586642031 1 GASKET,MUFFLERLID
21 14586354130 1 HOLDER,SCREEN
22 90023804010 3 SCREW 4X10
23 90060000005 2 WASHER 5
24 90010505055 2 BOLT,H.S. 5X55
25 13100448730 1 CAP ASY, FUEL INCLUDESITEM26
26 13101640930 1 GASKET,FUEL TANK CAP
28 13100544330 1 TANK,FUEL
29 90060300005 2 WASHER 5
30 90023805016 2 SCREW 5X16
31 13130040630 1 VENT ASY
32 13201013930 1 PIPE, FUEL
33 13131244330 1 PIPE 3X5X70
34 13201246730 1 PIPE
35 13211546730 1 GROMMET,FUEL
36 13201309820 1 CLIP
37 13120507320 1 STRAINER,FUEL
INTAKE, AIR CLEANER, EXHAUST, FUEL SYSTEM
8
GT-2000 TYPE 1E
30
31 32 33
34
35
36
29
DRIVE SHAFT, HANDLES, THROTTLE
37
38
21 22 23
24
28
27
26
25
20
9
KEY PART NUMBER QTY DESCRIPTION REMARKS
GT-2000 TYPE 1E
1 89031744530 1 LABEL, CAUTION
2 35160009630 1 HANDLE ASY INCLUDES ITEMS 3, 4 & 16
3 90003000008 1 NUT 1/4-20
4 90003500008 1 WASHER, FLAT 1/4"
5 90050000005 2 NUT 5
6 90056000005 1 LOCKNUT 5
7 35121344330 1 GRIP, HANDLE
8 89015204930 1 LABEL, CAUTION
9 61060944330 1 HOUSING ASY, DRIVESHAFT INCLUDES ITEM 17
10 90050200006 2 NUT 6 (3)
11 17800244430 1 WIRE, THROTTLE
12 90024205025 2 SCREW 5X25
13 17804306930 1 SPRING, THROTTLE RETURN
14 17801048731 1 CONTROL, THROTTLE
15 17811005330 1 SCREW
16 90001708048 1 BOLT 1/4-20
17 61021744330 1 LINER, FLEXIBLE
18 61001309630 1 SHAFT, FLEXIBLE
19 90070000004 1 E-RING, 4MM
20 61040452430 1 HOUSING ASY INCLUDES ITEMS 21 - 28
21 61030552430 1 PLATE, ADAPTER
22 90070200030 1 CIRCLIP 30
23 90081106200 1 BEARING, BALL 6200
24 61031052430 1 SHAFT, P.T.O.
25 90081006200 1 BEARING, BALL 6200
26 61041052430 1 HOUSING, BEARING
27 90024204010 1 SCREW 4X10
28 90015205025 1 BOLT, H.S. 5X25
29 69900440630 1 SHIELD ASY, W/LABEL INCLUDES ITEMS 30 - 37
30 90001708064 1 BOLT, 1/4-20X2
31 69901040631 1 SHIELD
32 90003500008 1 WASHER, FLAT 1/4"
33 90003000008 1 NUT 1/4-20
34 89016844330 1 LABEL, CAUTION
35 90024205016 2 SCREW 5X16
36 69901644330 1 KNIFE, CORD
37 90050000005 2 NUT 5
38 89011848830 1 LABEL, ECHO
DRIVE SHAFT, HANDLES, THROTTLE
10
GT-2000 TYPE 1E
1
2
4
10
15
3
CARBURETOR S/N 001001 - 229418
6
7
8
9
5
11 12 13
14
16 17 14
15 18 19
20
21
22
23
24
26
27
28
29
30
31
32
33
25
