Ebyte TXWF-PCB-3214 Manuel utilisateur

TXWF-PCB-3214 Antenna User Manual

2.4G/5.8GHz FPC Antenna

IPEX-1 Interface , 2dBi Gain

Chengdu Ebyte Electronic Technology Co., Ltd. TXWF-PCB-3214 User Manual

Contents

1. Introduction....................................................................................................................................................................... 1

2. Antenna Features.............................................................................................................................................................. 2

VSWR Chart................................................................................................................................................................... 2

Smith chart......................................................................................................................................................................2

3. FAQ.....................................................................................................................................................................................3

About us..................................................................................................................................................................................3

Disclaimer

EBYTE reserves all rights to this document and the information contained herein.

Products, names, logos and designs described herein may in whole or in part be

Chengdu Ebyte Electronic Technology Co., Ltd. TXWF-PCB-3214 User Manual

subject to intellectual property rights. Reproduction, use, modification or disclosure to

third parties of this document or any part thereof without the express permission of

EBYTE is strictly prohibited.

The information contained herein is provided “as is” and EBYTE assumes no liability

for the use of the information. No warranty, either express or implied, is given,

including but not limited, with respect to the accuracy, correctness, reliability and

fitness for a particular purpose of the information. This document may be revised by

EBYTE at any time. For most recent documents, Please visit www.ebyte.com.

Chengdu Ebyte Electronic Technology Co., Ltd. TXWF-PCB-3214 User Manual

1. Introduction

TXWF-FPC-3710 is a 2.4/5.8G dual-band FPC built-in antenna, the antenna size is 37*10mm, the feeder length is

120mm, with IPX 1 generation interface, suitable for various 2.4/5.8GHz wireless modules, network equipment, etc.

Band wireless equipment.

Electrical parameters

Center

frequency

2.4/5.8GHz

Antenna

bandwidth

2.4-2.5G/5.15-5.8GHz

Antenna gain

2dBi

Voltage

standing wave

ratio

≤1.5

Polarization

direction

Linear polarization

Radiation

direction

Omnidirectional

input resistance

50Ω

Power Capacity

Hardware Parameter

Product Size

32mm*14mm

Overall weight

Antenna

material

PCB

Feeder length

120mm (can be customized)

Interface

method

IPX 1st generation

Operating

temperature

-40℃～+85℃

Storage

temperature

-40℃～+85℃

Chengdu Ebyte Electronic Technology Co., Ltd. TXWF-PCB-3214 User Manual

2. Antenna Features

VSWR Chart

Smith chart

Chengdu Ebyte Electronic Technology Co., Ltd. TXWF-PCB-3214 User Manual

3. FAQ

The antenna frequency must match the frequency of the wireless device, otherwise the communication effect will be

poor;

The lower the communication frequency and the longer the wavelength, the better the diffraction performance;

When there is a straight line communication obstacle, the communication distance will be attenuated accordingly;

Please pay attention to the antenna radiation direction, the incorrect installation direction of the antenna leads to a

short transmission distance;

The ground absorbs radio waves, and the test result near the ground is poor. It is recommended to increase the

height;

Sea water has a strong ability to absorb radio waves, so the seaside test results are not good;

If there is a metal object near the antenna or placed in a metal shell, the signal attenuation will be very serious;

The poor impedance matching between the antenna and the communication device will lead to poor communication

effects.

About us

Website: www.ebyte.com

Sales: info@cdebyte.com

Support: support@cdebyte.com

Tel: +86-28-61399028 Ext. 812 Fax: +86-28-64146160

Address: Building B5, Mould Industrial Park, 199# Xiqu Ave, West High-tech Zone, Chengdu, 611731, Sichuan, China
