O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

Effective: March 2011

iEATON Corporation www.chfire.com

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

Effective: March 2011

1. 1

2. 1

2.1 2

2.2 2

2.2.1 Pump Running check 2

2.2.2 Common Alarm check 2

2.2.3 Phase Failure check 2

2.3 2

2.3.1 Engine Running' & 'Controller in OFF Mode' check 2

2.3.2 Common Alarm' and 'Low Fuel' check 2

2.4 3

2.4.1 Lamp Test Button 3

2.4.2 Normal and Supervisory (Backup) Voltage 3

2.4.3 Audible Alarm 3

2.4.4 Silence Alarm Button 3

2.4.5 Normal Power ON LED 3

2.4.6 Output Contacts 3

2.4.7 Output Relays 3

2.4.8 Alarm Inputs 3

3. 4

4. 5

5. 6

6. 7

ELECTRICAL CONNECTIONS

TABLE OF CONTENTS

INSTALLATION AND MOUNTING OF THE CONTROLLER

FIGURE 1: ELECTRIC DIMENSIONS & SHIPPING WEIGHTS

FIGURE 2: DIESEL DIMENSIONS & SHIPPING WEIGHTS

FIGURE 3: ELECTRIC WIRING SCHEMATIC

FIGURE 4: DIESEL WIRING SCHEMATIC

ELECTRICAL CHECKOUT INSTRUCTIONS

ELECTRIC ALARM PANELS

DIESEL ALARM PANELS

OPERATION

INSTALLATION & MAINTENANCE

MANUAL FOR REMOTE ALARM

PANELS

In order to familiarize yourself with the Remote

Alarm Panel, please read the instruction manual

thoroughly and carefully. Retain the manual for

future reference.

1. Installation and Mounting of the

Controller

Carefully unpack the controller and inspect

thoroughly.

The controller is not free standing and must be

bolted securely to a wall. For dimensional and

weight data please refer to the respective data

sheets for the Remote Alarm Panels.

Figure #1 - Electric Remote Alarm Panel

Figure #2 - Diesel Remote Alarm Panel

2. Electrical Connections

All electrical connections should meet national

and local electrical codes and standards.

The controller should be located or so protected

that they will not be damaged by water escaping

from pumps or pump connections. Current carrying

parts of controllers shall be a minimum of 12 inches

(305 mm) above the floor level.

? Prior to starting, verify all data on the

nameplate such as, catalog number and AC line

voltage.

? Inspect all electrical connections,

components and wiring for any visible damage and

correct as necessary. Ensure that all electrical

connections are tightened before energizing.

? Install necessary conduit using proper

methods and tools.

? Incoming Normal power and Supervisory

(backup) power connections are clearly marked L

and N and are located on the upper right side of the

microprocessor board.

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

EATON Corporation www.chfire.com

Effective: March 2011

2.1 Electrical Checkout Instructions (For Use with Eaton Remote Alarm Panels)

WARNING:The following procedures should be carried out by a qualified electrician familiar with the electrical safety

procedures associated with this product and its associated equipment.

2.2 Electric Remote Alarm Panels (Full Service) – For Electrical Schematic Refer to Figure #3

Note: The alarm buzzer can be silenced by pressing the 'Silence Alarm' button on the front of the controller.

2.2. - Turn power on to the Fire Pump Controller and to the Remote Alarm Panel

- In the Fire Pump Controller press the 'Local Start' pushbutton, the controller will start

- The 'Pump Running' LED should illuminate and the alarm will sound on the Alarm Panel

- Press the 'Stop' pushbutton on the front of the fire pump controller

2.2. - Move the disconnect handle on the Fire Pump Controller to the 'OFF' Position

- The 'Common Alarm' and 'Phase Failure' LED's should illuminate and the alarm will sound on the Alarm Panel

- Move the disconnect handle back to the 'ON' Position

2.2.3 - In the menu under the Alarm category, change the phase rotation to the opposite of what it is currently set for.

- The 'Common Alarm' and 'Phase Reversal' LED's should illuminate and the alarm will sound on the Alarm

Panel

- Return the menu setting to the correct rotation.

2.3 Diesel Remote Alarm Panels – For Electrical Schematic Refer to Figure #4

Note: The alarm buzzer can be silenced by pressing the 'Silence Alarm' button on the front of the controller.

2.3.1 - Turn power on to the Fire Pump Controller and to the Remote Alarm Panel

- Place the controller in the 'AUTO' mode by turning the Main Switch to “AUTO”

- Start the controller by pushing the “Engine Test" button on the Diesel controller membrane / keypad,

then push the “Acknowledge” button.

- The 'Engine Running' light should illuminate and the alarm will sound on the alarm panel

- Place the controller in the 'OFF' mode by turning the Main Switch to “OFF”

- The 'Not in Auto Mode' LED will illuminate and the alarm will sound on the alarm panel

2.3.2 - Place the controller in the 'AUTO' mode by turning the Main Switch to “AUTO”

- Place a jumper between Terminal #38 & #11 in the Fire Pump Controller (Low Fuel)

- The 'Common Alarm’ and ‘Low Fuel’ LED’s should illuminate and the alarm will sound on the alarm panel

- Place the controller in the 'OFF' mode by turning the Main Switch to “OFF”

Start the controller by pushing the “Engine Test" button on the Diesel controller membrane / keypad,

then push the “Acknowledge” button.

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

2EATON Corporation www.chfire.com

Effective: March 2011

2.4 Operation

2.4.1 Lamp Test Button

Each remote alarm panel is equipped with a Lamp Test

button that fully tests all LED’s when pressed. Operating

the lamp test button will not change the state of the

internal output relays

2.4.2 Normal and Supervisory (backup)

Supply Voltage

The remote alarm panels will accept both 120 volt

50/60Hz and 240 volt 50/60Hz power supply on either of

the normal and supervisory (backup) source inputs. If the

normal source of supply is lost, the panel will

automatically switch to the supervisory (backup) source.

Both the normal and supervisory (backup) sources must

be independent of each other.

2.4.3 Audible Alarm

When any alarm conditions are present, the audible

alarm will sound. It will continue to sound until either the

silence alarm button is pressed, or the alarm condition is

satisfied.

2.4.4 Silence Alarm Button

An audible alarm silencing button is provided that

silences all active alarms when pressed. Pressing the

button has no effect on the associated alarm LED(s).

Should a second alarm condition occur after the silence

button has been pressed, the audible alarm will re-sound

until the silence button is pressed again, or the alarm

condition has been satisfied.

2.4.5 Normal Power ON LED

The normal power ON LED indicates when normal power

is available and will turn off when the controller switches

to the supervisory (backup) power source. An audible

alarm will sound when normal power is not available and

will remain ON until normal power is restored, or the

silence pushbutton is pressed.

2.4.6 LED Visual Indicators

The FDAP-M electric remote alarm panel has four LED

visual indicators to indicate Pump Running, Phase

Failure, Common Alarm and Phase Reversal. The

DFDAP-M diesel remote alarm panel also has four LED

visual indicators that indicate Not in AUTO Mode, Engine

Running, Common Alarm and Low Fuel.

EATON Corporation www.chfire.com

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

2.4.7 Output Relays

The relays are printed circuit board style mounted on the

alarm panel main circuit board. They are rated for

8 amps / 250VAC. They are de-energized under normal

conditions regardless of input status selected.

2.4.8 Alarm Inputs

Each controller is equipped with eight user selectable

alarm inputs. Each can be selected as normally open

(N.O.) or normally closed (N.C.) by the use of jumpers on

the microprocessor board.

Two Form-C alarm output relays can be programmed to

indicate specific alarm conditions.

Effective: March 2011

Electrical Remote Alarm Panel - FDAP-M

FIGURE 1

4EATON Corporation www.chfire.com

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

N. Y. C.

APPROVED

15.49 [393] 11.56 [294]

9.55 [243]

4.74 [120]

8.00 [203]

9.75 [248]

n0.27 [n7]x4

WALL MTG. HOLES

NOTE:

1. ALL ENCLOSURES FINISHED IN FIRE PUMP RED

2. CABLE ENTRANCE EITHER TOP OR BOTTOM

3. STANDARD ENCLOSURE TYPE NEMA 1

Effective: March 2011

Diesel Engine Remote Alarm Panel - DFDAP-M

FIGURE 2

EATON Corporation www.chfire.com

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

N. Y. C.

APPROVED

15.49 [393] 11.56 [294]

9.55 [243]

4.74 [120]

8.00 [203]

9.75 [248]

n0.27 [n7]x4

WALL MTG. HOLES

NOTE:

1. ALL ENCLOSURES FINISHED IN FIRE PUMP RED

2. CABLE ENTRANCE EITHER TOP OR BOTTOM

3. STANDARD ENCLOSURE TYPE NEMA 1

Effective: March 2011

Wiring Schematic - Electric Remote Alarm Panel - FDAP-M

FIGURE 3

6EATON Corporation www.chfire.com

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

N. Y. C.

APPROVED

Effective: March 2011

Wiring Schematic - Diesel Remote Alarm Panel - FDAP-M

FIGURE 4

EATON Corporation www.chfire.com

O & M Manual IM05805008K

Remote Alarm Panels

EATON DFDAP-M / FDAP-M

Effective: March 2011

N. Y. C.

APPROVED

Eaton Corporation

10725 - 25th Street NE Unit 124

, Alberta, Canada

Tel: +1-403-717-2000

Fax: +1-403-717-0567

email: [email protected]

www.chfire.com

Calgary

3N 0A4

Printed in Canada

Publication No.: IM05805008K

March 2011
