Easypix 5.2 Manuel utilisateur

Digital Video Camera

User Manual

Contents

Content.................................................................................... 1

Section 1 Getting to Know Your Camera.............................. 2

Section 2 Getting Up and Running ....................................... 5

Section 3 Record Mode.......................................................... 7

Section 4 Playback Mode .................................................... 35

Section 5 Listening to MP3 Music ......................................49

Section 6 Reading eBook .................................................... 51

Section 7 Viewing MPEG4 Movie on PC............................. 53

Section 8 Viewing Pictures and Movies on a TV ............... 54

Section 9 Video File Converter............................................ 55

Section 10 Burning the Recorded Clip into DVD............... 63

Section 11 Transferring Data to a Computer...................... 65

Section 12 Specifications and System Requirements ...... 67

Section 1

Getting to Know Your Camera

Overview

The camera with 5.2 Mega Pixel sensor can take DVD-Quality MPEG-4 movies. By way of

using MPEG-4 technology, more videos can be taken within certain amount of memory. High

quality images with up to 11 mega-pixels can also be delivered smoothly. With a color LCD

monitor, users can compose images and examine them easily.

Exposure and color balance can either be adjusted automatically or allowed to be changed

manually. An 8x digital zoom increases user control over the movies and pictures you take.

The camera is also ideally suited for using as a PC camera hooked up to your home computer

via high speed USB 2.0 port

Biuld-in 64 MB memory allows you to take pictures and movies without memory card. The

memory card slot allows users to increase the storage capacity up to 4GB.

Note

Partial memory of the built-in 64MB memory is used

for Firmware code

Standard Accessories

Unpack the package and make sure all standard accessories listed are included:

zCamera

zUSB Cable

zAV Cable

zAA Battery

zQuick Guide

zCD-ROM ( Driver, Arcsoft Software and User Manual)

zEarphone

zStrap

zPouch

Front View

KeyPad illustration

LCD Panel

Enter Button

Picture Shutter Button

Movie Shutter Button

Tele-Wide Button

TV Out /ear Phone Port

Mini USB 2.0 port

Strap Hole

Green /Red Led

Lens

LED

Right Button

Left Button

RECORD/PLAY Button

Power Button

Side View

Speaker

Battery Cover

Marco

Microphone

Section 2

Getting Up and Running

Loading the Battery

Before using the camera, end users must load

NP60 rechargeable Li-ion Battery.

1. Follow the arrow direction and slide to eject the

battery cover.

2. Insert the batteries according to the correct

polarity marks ( + or -)

3. Close the battery cover firmly.

Inserting and Removing an SD Card（Optional）

The camera comes with internal memory which allows you to store pictures, movies, voice

recordings and music. You can expand the memory capacity by using an optional SD or MMC

memory card up to 4GB. To insert a memory card, refer to the figure as below:

1. Insert the memory card into the right position.

2. To remove an installed SD card, press the card inwards to

release it.

3. When the card pops out, gently remove it from its slot.

Note

When a memory card is fitted, movies and pictures are

saved on card rather than on the built-in memory.

Protecting Data on an SD Card

SD card is read-only by locking the SD card. No pictures, movies and voice can be recorded

when the SD card is locked. Make sure the lock is on writeable position before recording any

media.

Writeable position Write-Protected

Position

Writeable position Write-Protected

Position

Turning the Camera On and Getting Started

To turn on the camera:

(1) Flip out the LCD panel; the camera will turn on automatically.

(2) Or press Power Button for one second to turn on it.

ÖTo take a movie, press the Movie Shutter Button ( ).

ÖTo take a picture, press the Picture Shutter Button ( ).

ÖTo record the voice, press the enter key and press Right/Left Button to voice pen for voice

recording.

ÖTo view stored movies, pictures, listen to voice recordings, press RECORD/PLAY Button

once to switch to Playback Mode. Press a second time to return to Record Mode.

Turning the Camera Off

To turn off the Camera, you can either press the Power Button for one second, or you can

place the LCD panel back to its original position.

Section 3

Record Mode

Button Function

Power Button: Press down for one second to turn

on or turn off the camera.

Movie Shutter Button:

1. Start to take movie, or record voice.

2. To stop recording, press it again.

Picture Shutter Button:

Take the picture

Tele-Wide Button: Digital Zoom in and out.

OK Button : Menu ON

Right Button : Flash ON/OFF/Red-Eye

Reduction/Light ON/Auto

Left Button :Self-Timer ON/OFF

RECORD/PLAY Button:

1. Switch between Record /Playback Mode.

2. Return to the previous page.

LCD Monitor Information

The indicator shows below may display on LCD when movies and pictures are recorded

(1) Record Mode

Movie Record Mode

Picture Record Mode

Voice Record Mode

Motion Stabilization

Photo Frame

Multi-Snap Mode

Night Mode

Backlight Mode

(2) Resolution

Movie High / Standard / Low

Picture: High / Standard / Low

(3) Number of images or recording time of movie that can still be taken at current resolution.

(4) SD card inserted

(5) Macro Position Focusing

(6) Manual White Balance

(7) Battery indicator：full power / medium power / low power / power empty

(8) Flash On

Flash Off

Red Eye Reduction

Light on

Auto

(9) Self-timer enabled

(10) 8X digital zoom

(11) Date/Time : YYYY/MM/DD

(12) Motion Detection (Enable)

MPEG4 Movie Recording

Press Movie Shutter button ( ) to start recording. When a movie is recording, a time

indicator will display on LCD monitor. To stop recording, press Movie Shutter Button ( )

again. Press RECORD/PLAY Button to view the recorded movie.

Three resolution settings are available:

Quality

High Quality

Standard Quality

Low Quality

Picture Recording

Press the Picture Shutter Button ( ) to take a picture.

Press RECORD/PLAY Button to view the picture.

Three resolution settings are available:

Image Quality

High Quality

Standard Quality

Low Quality

Using Digital Zoom

The digital zoom magnifies images, when recording movies or taking pictures.

1. To zoom in/out, press the Tele/Wide Button.

2. The digital zoom can be set from 1x to 8x and the magnification ratio is shown on the

LCD monitor.
