Malibu and Malibu GT
Owner’s Manual
930 W. 16th St., Suite C-2
Costa Mesa, CA 92627
www.E-LuxBikes.com
2| P a g e
Thanks so much for purchasing your new E-Lux Electric Beach Cruiser
and welcome to a world of new possibilities!
With your new electric bike, you will be able ride farther, faster, and
easier than ever before on a bicycle which equates to Fun, Fun, and
more Fun! All while traveling for less than half a cent a mile - it’s not
only good for your wallet but it’s good for the planet!
If you have any questions, suggestions, concerns, or if you just want to
say “Hi!” please feel free to drop us a line at info@E-Luxbikes.com.
Happy Trails!
From Jerry and J.P., co-founders of E-Lux Electric Bikes
3 | P a g e
Table of Contents
Carton/Box Contents ................................................................................ 4
Assembly ................................................................................................... 5
Understanding the Display and Display Settings .................................... 10
Battery Care and Charging ...................................................................... 15
Removing Your Battery ........................................................................... 18
Checking Your Battery Charge ................................................................ 19
Battery Life .............................................................................................. 19
Before Your First Ride…. ......................................................................... 20
Stopping the Motor ................................................................................. 23
Brakes ...................................................................................................... 24
Gears ....................................................................................................... 25
Tires ......................................................................................................... 27
Appearance and Care .............................................................................. 28
Commonly Asked Questions ................................................................... 28
Technical Assistance ............................................................................... 29
Important! Read Before Riding! .............................................................. 30
One Year Limited Warranty (Battery Three Years) ................................. 31
Recording Your E-Lux Bike Information .................................................. 35
4| P a g e
Carton/Box Contents
Caution – Please use care when opening box with sharp objects to avoid
cutting any bicycle parts inside.
After opening please check the box for the following contents:
1. Bicycle
2. Handlebar
3. Small Box Containing Battery Charger
4. Small Box Containing Pedals, Manual, Stem Cap, Neck
Cover, Cargo Straps, and Battery Charger
5 | P a g e
Assembly
E-Lux suggests taking your electric bike to a professional bike
technician for assembly. This can be done for a nominal fee at your
local bike shop. If you are comfortable assembling it on your own then
please refer to the directions below. You can also view our assembly
video on our website at www.E-Luxbikes.com/assembly.
What You Will Need
1. Scissors
2. 15 mm wrench
3. 4/5/6 mm Allen wrench(es)
4. All-Purpose Grease
Warning – When removing packaging and zip ties do not use box cutters
or knives as you may damage paint or tires. We suggest a pair of scissors.
1. Carefully remove the packing from around bicycle.
2. Carefully cut the zip ties holding the handlebars to the frame.
3. Place the bike upright on wheels and kickstand.
4. Apply a small amount of grease inside of the gooseneck tube as
well as the threads and slider on the stem of gooseneck.
5. Making sure that all wires and cables are facing front and not
twisted; install handlebar into handlebar stem tightening the bolt
on the handlebar stem using an Allen wrench.
6. Tilt the handlebars up, making sure they are level and centered
before tightening the two additional bolts.
6| P a g e
7. Pull the seat clamp handle out from the seat post to release
pressure allowing you to remove the seat. Remove seat post and
apply a small bit of grease inside seat tube. Then replace seat.
7 | P a g e
8. Caution – When installing pedals there are two separate pedals
for the left and right sides of the bike. They have different thread
patterns and it is important to be sure each is installed on the
correct side of the bike to avoid stripping the threads. The
following procedure is performed so that when the bike is pedaled
it tightens the pedals.
9. Apply a small amount of grease on pedal threads.
8| P a g e
10. Right Pedal – Facing the bike from the chain side, place pedal
with R on the end of its bolt-on chain side of bike and tighten by
turning clockwise (top of wrench turning towards the front of bike
as noted in the picture below). Tighten pedal very tight.
9 | P a g e
11. Left Pedal – Facing the bike from the kickstand side, place
remaining pedal on the kickstand side of the bike and tighten by
turning counter-clockwise (top of wrench turning towards the
front of bike as noted in the picture below.) Tighten pedal very
tight.
12. Align seat on seat post to your comfort (typically hip height).
13. Use the following recommended tire pressures:
Malibu – 30 to 55 P.S.I.
10| P a g e
Understanding the Display and Display Settings
1. The picture below shows the Display Control Unit on the left
handlebar and the Display centered above the gooseneck.
