E-line ELI-PRO3 series Manuel utilisateur

ＮｅｔＤＶＲ

Preface

Thank you for selecting our products. We will offer the best service for you wholeheartedly.

We take 16 channel DVR (960H) as a sample. In this series, different product models’ configuration will have a little difference, and it will work the difference between product

function and operation.

It is for reference only. We will not provide any new information separately for later firmware update. The updating files will be added into the new edition of the user manual and

will also be posted on our website in the download center. This user manual may have some inaccuracy or misprint. We sincerely hope your timely feedback and comments to let us correct

and improve this booklet in the subsequent edition.

eLineTechnology.com

ＵｓｅｒＭａｎｕａｌ

CONTENT

Preface....................................................................................................................................................................................................................................................................... 1

Chapter1 Brief Introduction about the DVR ............................................................................................................................................................................................................. 6

1.1 Summarization ............................................................................................................................................................................................................................................... 6

Chapter2 Technology Guideline and Main Functions .............................................................................................................................................................................................. 6

2.1 Technology Guideline .................................................................................................................................................................................................................................. 6

2.2 Main Functions ............................................................................................................................................................................................................................................. 8

Chapter3 Equipment Installation and Illustration.................................................................................................................................................................................................. 12

3.1 Installation Environment and Cautions ...................................................................................................................................................................................................... 12

3.1.1 Attentions on Installing Hard Disk ................................................................................................................................................................................................... 13

3.2 Package Checking ....................................................................................................................................................................................................................................... 13

3.3 Device Interface ........................................................................................................................................................................................................................................... 14

3.3.1 Video/Audio Connection ................................................................................................................................................................................................................... 14

3.3.2 USB Backup Interface ......................................................................................................................................................................................................................... 14

3.3.3 Network Interface ............................................................................................................................................................................................................................... 14

3.3.4 Alarm Input/Output Connection ........................................................................................................................................................................................................ 14

3.3.5 RS-485 Connection ............................................................................................................................................................................................................................ 18

eLineTechnology.com

ＮｅｔＤＶＲ

3.3.6 Keyboard Controlling........................................................................................................................................................................................................................ 18

3.3.7 Intercommunication Port .................................................................................................................................................................................................................... 18

3.4 Front Panel Description ............................................................................................................................................................................................................................. 19

3.5 IR Remote Controller Operation ................................................................................................................................................................................................................. 22

3.6 Mouse Operation ........................................................................................................................................................................................................................................ 24

3.7 Menu Operation Description ...................................................................................................................................................................................................................... 26

3.7.1 Menu Structure Chart ......................................................................................................................................................................................................................... 26

3.7.2 Menu Option Schedule ...................................................................................................................................................................................................................... 27

Chapter4 Device Operation .................................................................................................................................................................................................................................... 33

4.1 Power On/0ff and Login /Lock ................................................................................................................................................................................................................... 33

4.1.1 Keystroke Unlock/Lock .................................................................................................................................................................................................................... 33

4.1.2 System Login ..................................................................................................................................................................................................................................... 33

4.1.3 System Lock ....................................................................................................................................................................................................................................... 34

4.1.4 Main Menu ......................................................................................................................................................................................................................................... 34

4.1.5 Status Bar ........................................................................................................................................................................................................................................... 34

4.2 Power on Wizzard ....................................................................................................................................................................................................................................... 35

4.3 Data Inquiry and Playback ......................................................................................................................................................................................................................... 36

4.3.1 Time Inquiry ....................................................................................................................................................................................................................................... 36

4.3.2 Event Inquiry ..................................................................................................................................................................................................................................... 36

4.3.3 Data Management ............................................................................................................................................................................................................................... 39

4.4 Backup Management ................................................................................................................................................................................................................................... 39

eLineTechnology.com

ＵｓｅｒＭａｎｕａｌ

4.4.1 Quick Backup..................................................................................................................................................................................................................................... 40

4.4.2 Manual Backup .................................................................................................................................................................................................................................. 40

4.4.3 Schedule Backup ................................................................................................................................................................................................................................ 40

4.5 Record Setup ............................................................................................................................................................................................................................................... 41

4.5.1 Record Parameter ................................................................................................................................................................................................................................ 41

4.5.2 Screenshots Parameter ........................................................................................................................................................................................................................ 42

4.5.3 Advanced ........................................................................................................................................................................................................................................... 42

4.5.4 Manual Record ................................................................................................................................................................................................................................... 43

4.5.5 Manual Snapshot................................................................................................................................................................................................................................ 43

4.5.6 Schedule Record ................................................................................................................................................................................................................................. 44

4.6 Alarm Setup ................................................................................................................................................................................................................................................. 44

4.6.1 Motion ............................................................................................................................................................................................................................................... 44

4.6.2 Sensor ................................................................................................................................................................................................................................................. 46

4.6.3 Alarm Output ..................................................................................................................................................................................................................................... 46

4.6.4 Other Alarms ...................................................................................................................................................................................................................................... 47

4.6.5 Manual Alarm ..................................................................................................................................................................................................................................... 47

4.7 System Setup ............................................................................................................................................................................................................................................... 48

4.7.1 General Setting .................................................................................................................................................................................................................................. 48

4.7.2 Time Setting ....................................................................................................................................................................................................................................... 49

4.7.3 Output Setting ................................................................................................................................................................................................................................... 50

4.7.4 COM Setting ...................................................................................................................................................................................................................................... 53

4.7.5 PTZ Setting ........................................................................................................................................................................................................................................ 54

4.7.6 Network Setting ................................................................................................................................................................................................................................. 56

4.7.7 Input Settings..................................................................................................................................................................................................................................... 61

4.8 HDD Management ....................................................................................................................................................................................................................................... 61

eLineTechnology.com

ＮｅｔＤＶＲ

4.8.1 Basic Information................................................................................................................................................................................................................................ 62

4.8.2 HDD Group ....................................................................................................................................................................................................................................... 63

4.8.3 SMART .............................................................................................................................................................................................................................................. 63

4.9 Information Inquiry ..................................................................................................................................................................................................................................... 63

4.9.1 System Information ............................................................................................................................................................................................................................. 64

4.9.2 Record Status ..................................................................................................................................................................................................................................... 64

4.9.3 Alarm Status ....................................................................................................................................................................................................................................... 65

4.9.4 Online Status ..................................................................................................................................................................................................................................... 65

4.9.5 Log Inquiry ........................................................................................................................................................................................................................................ 66

4.9.6 Input State .......................................................................................................................................................................................................................................... 66

4.10 System Maintenance .................................................................................................................................................................................................................................. 67

4.10.1 Quick Settings ................................................................................................................................................................................................................................. 67

4.10.2 User Management ............................................................................................................................................................................................................................. 67

4.10.3 Reset to Default ................................................................................................................................................................................................................................ 68

4.10.4 Upgrade Management ....................................................................................................................................................................................................................... 69

4.10.5 Timing to Restart .............................................................................................................................................................................................................................. 71

4.11 Logout/Shutdown/Reboot ....................................................................................................................................................................................................................... 72

4.12 Password Reset ......................................................................................................................................................................................................................................... 72

4.13 Power Resume ........................................................................................................................................................................................................................................... 72

Appendix 1: IE Operation Instructions .................................................................................................................................................................................................................. 73

1. LAN Configuration for IE Browse ............................................................................................................................................................................................................... 73

2. WAN Operation Instructions ....................................................................................................................................................................................................................... 74

Appendix 2: Net DVR Q&A ................................................................................................................................................................................................................................... 77

eLineTechnology.com

ＵｓｅｒＭａｎｕａｌ

Chapter 2 Technology Guideline and Main Functions

2.1 Technology Guideline

Chapter 1 Brief Introduction about the DVR

1.1 Summarization

1. Video parameters

The series DVR are designed for video/audio digital surveillance system. They are adopting H.264 compress format, integrate the embedded RTOS and processor to realize all of the

functions like video and audio acquisition and compression, storing, remote control, Multi-PTZ control and alarm in a single board. This series DVR achieve the integrate host to a

single plate structure, which ensure the system’s high-integration and reliability.

This series of equipment use private file systems MFS V2.0, namely flow media file system second edition. This file system is based on Microsoft FAT32 to innovate, suitable for DVR

special file system, support more than 2TB hard disk; Long time operation does not produce disk fragments; Reasonable flow media operation scheduling, the operation has fast response;

Increase check protection in the MFS key information, avoid key areas damaged cause to catastrophic problem.

This device can be the local independent work, also can build a strong safety monitoring system by network. Can be applied to Banks, telecommunications, electric power,

transportation, intelligent community, factory, warehouse, etc.

Video input: Composite video input, PAL (25fps), NTSC (30fps), BNC (1Vp-p, 75Ω）

eLineTechnology.com

ＮｅｔＤＶＲ

Video output:

2. Audio parameters

1 channel composite video output, PAL (625 line), NTSC (525 line), BNC (1Vp-p, 75

1 channel analog video output (VGA)

9. Serial interface: Support RS485 half-duplex, network transparent and COM control keyboard

10. Operation mode: multi-functional IR remote control, USB mouse, serial keyboard

11. Backup interface: USB2.0 interface

12. Network port: RJ45 10M/100M/1000M Ethernet Interface

13. Power supply: 220 ±30% V, 50 ±3% HZ, 110 ±20% V, 60 ±3% HZ

Alarm input: Alarm input support normal on/off

Alarm output: Normal on, relay output

3. Video compression: Compression arithmetic H.264

Default resolution FD1: PAL (704*576) 25 fps/ch, NTSC(704*480) 30 fps/ch;

Resolution 960H: PAL (928*576) 25 fps/ch, NTSC (928*480) 30 fps/ch.

4. Audio compression: Compression arithmetic G.711A, Audio sampling rate 8K sample/sec., 16 bit/sample

5. Code stream type: VBR/CBR

6. Operation System: Linux

7. HDD interface: support 48bit LBA working mode

8. Alarm interface

Audio input: RCA interface port, input resistance: 10K , input extent: Vp-p=2.0V LINE

Audio output: RCA interface, input resistance: 10K , input extent: Vp-p=2.0V LINE

Voice chat: Input (3.5MM interface, input resistance: 10K , input extent: Vp-p=2.0V LINE in/50mV MIC in)

Ω）

eLineTechnology.com

ＵｓｅｒＭａｎｕａｌ

High effective RTOS and embedded processor are adopted in this series DVR, as well as all functions needed for the monitoring system are integrated. Code is solidified in the flash

chip to keep the system in high stability and reliability. System can also work in a long time surveillance environment and even in stringent circumstance.

Note: The following features might differ from the below description since we have series products and different hardware and software versions.

2.2 Main Functions

u Compression features

1. Support PAL/NTSC video format signal.

2. Video compression algorithm is H.264.

3. Video and audio signals are compressed into H.264 code stream. Audio and video stream are synchronous when playback, and audio recording can be canceled if only video is

in need.

4. Audio compression algorithm adopts G.711A, and every video/audio signal is compressed separately in real time, then generate composite compressed code stream. The video

and audio stream are synchronous when playback, or setting disable audio with the sampling rate of 8K sample/sec., 16 bit/sample.

5. Supporting dual stream compression: main code stream used for local storing, sub code stream used for image transmission in low-bandwidth network.

6. 6 levels of record quality is available to select. Users can choose according to requirements so that the recording time is long enough.

u Recording function

1. Support 4 record modes: manual, schedule, motion and alarm recording.

2. Support 5 screenshot modes: manual screenshot; manual, schedule, motion and alarm snapshot.

3. Video motion detection function: multi detection areas can be set up to 5 sensitive levels.

4. Support screen shield. Each channel can max setting 4 mask areas, support preview mask, record mask and all mask.

5. Each channel support 4 interested area setting.

6. Support sensor alarm. One sensor can be linked to one or more cameras. Support alarm recall to PTZ preset point.

7. Monitoring center can record the real time compression code stream, and support synchronizing record video and audio into client PC.

8. Video and audio parameters of each camera can be set up separately.

eLineTechnology.com

ＮｅｔＤＶＲ

9. Support channel title and recording time superpose.

10. Support multiplex operation, can real time recording without impacting other functions.

(such as playback, fast forward, slow playback, rewind, network monitor, VOD and remote)

11. Support pre-record feature, and pre-record time is 5-30 seconds.

12. Support record status inquiry function.

u Playback functions

1. Support inquiry recording files/pictures by time, fix position by time to record/pictures playback.

2. Support inquiry recording files/pictures by event, as per channel number/record type to inquiry/record/pictures playback.

3. Support intuitive video information graphical display and play.

4. Support zoom in on playback.

5. Support full realtime quick playback.

6. Support inquiry other time/channel recording files through list to playback.

u Real time survillance features

1. Support HDMI, VGA, CVBS dual output with different source.

2. Support SPOT sequence output.

3. Support 1/4/8/9/13/16 ch preview, the order of channels can be adjusted and the time position in preview also adjustable.

4. Support 24Hour/12Hour mode switching.

5. Support DST.

6. Support zoom in.

7. Support mask some parts of area or all.

8. Support adjust video parameter (brightness, contrast, and saturation, hue) for each channel.

9. Support cruise.

10. Support intercom.

11. Support a variety of mainstream PTZ decoders control protocol, support preset point, PTZ preset point cruise and trajectory cruise.

eLineTechnology.com

ＵｓｅｒＭａｎｕａｌ

u Storing and backup functions

1. Support maximum 2 SATA HDD.

2. Support data lock/unlock/delete for all recording files/pictures.

3. The maximum saving time of recording files/pictures can be set, the DVR will auto delete the data which exceed the setting time.

4. Support set read-only/read-write to HDD.

5. Support HDD quota management, different channels can be arranged different quota for save data.

6. Support USB backup (USB disk or external USB burner).

7. Support backup by internal burner.

8. Support batch backup as per files.

9. Support clipping for backup while playback.

10. Support log backup.

11. Support backup record files by IE browser.

12. Powerful hard disk management function, support HDD dormancy and format, support the damaged partition shield, bad disk to eliminate and alarm mechanism.

u Alarm inspection functions

1. Local alarm: manual alarm, video lost alarm, motion detection alarm, sensor alarm, HDD faulty alarm, temperature alarm, network disconnect alarm, video shield alarm.

2. Video lost alarm, motion detection alarm, sensor detection alarm response on time.

3. Network alarm linkage (upload alarm signal), sound alarm through the PC own horn.

4. Video motion detection function, each channel can be set several detection area.

5. Support upload alarm information by email, send alarm channel/type/pictures to the assigned email.

6. Support motion detection and sensor detection jump to PTZ preset point.

u Network functions

1. Support TCP/IP protocol (support ARP, RARP, IP, TCP, PPPOE, DHCP, DDNS).

2. Support 3G and ADSL dial-up network connection, and support auto-redial after disconnect.

3. Perfect network-end control order (Client manager and IE browse can be used to control the DVR, such as setting the parameters, remote upgrade, etc).

4. Support composite channel preview through IE browser.

eLineTechnology.com
