E-FLITE Cap 232 BP 3D Manuel utilisateur

Cap 232 BP 3D

Assembly Manual

Introduction................................................................3

Specifications.............................................................3

Using the Manual .......................................................3

Contents of Kit/Parts Layout .........................................4

Required Radio Equipment...........................................5

Important Information About Motor Selection .................5

High Power Outrunner Setup........................................6

Lightweight Outrunner Setup ........................................6

Optional Accessories ..................................................6

Note on Lithium Polymer Batteries.................................6

Required Tools and Adhesives ......................................7

Warning....................................................................7

Date of Purchase Warranty Period ................................7

Limited Warranty ........................................................8

Damage Limits............................................................9

Safety Precautions.......................................................9

Questions, Assistance, and Repairs...............................9

Inspection or Repairs.................................................10

Warranty Inspection and Repairs................................10

Table of Contents

Non-Warranty Repairs...............................................11

Safety, Precautions, and Warnings..............................12

Airframe Assembly....................................................13

Hinging ...................................................................18

Landing Gear Installation...........................................22

Radio Installation ......................................................25

Power System Installation...........................................33

Control Throws .........................................................38

Center of Gravity......................................................39

Range Test Your Radio...............................................39

Preflight ...................................................................40

Flying Your Cap 232 BP............................................41

2006 Official AMA

National Model Aircraft Safety Code..........................42

Introduction

The Cap 232 BP 3D combines the sturdy construction of a

balsa/light-ply airframe with the uninhibited 3D capability

of a lightweight profile park flyer. It’s all made possible

by its intelligently engineered, open structure design that

keeps weight to a bare minimum while providing all the

structural integrity of a real wood airframe. This feather-

light construction, combined with a high-output brushless

motor, will provide spine-tingling 3D and freestyle

performance that will let you really push the limits. And it

comes from the factory 90% built and covered in genuine

UltraCote®and UltraCote Light so you can be up and

flying in no time

Specifications

Wingspan: 35.5 in (900mm)

Length: 35.5 in (900mm)

Wing Area: 425 sq in (27.5 sq dm)

Weight w/o Battery: 13–14 oz (370–400 g)

Weight w/ Battery: 15.5–17 oz (440–480 g)

Using the Manual

This manual is divided into sections to help make assembly

easier to understand, and to provide breaks between each

major section. In addition, check boxes have been placed

next to each step to keep track of each step completed.

Steps with a single circle () are performed once, while

steps with two circles () indicate that the step will

require repeating, such as for a right or left wing panel,

two servos, etc.

Remember to take your time and follow the directions.

Contents of Kit/Parts Layout

Large Replacement Parts

EFL2401 Wing w/Ailerons

EFL2402 Fuselage with Rudder

EFL2403 Horizontal Tail Assembly

EFL2405 Landing Gear

Small Replacement Parts

EFL2404 Pushrod Set

EFL2406 Hardware Set

EFL2407 Wheel Set

EFLA213 E-flite/JR/Horizon Decals

EFLM1915 Outrunner Stick Mount

Required Radio Equipment

You will need a minimum 6-channel transmitter, crystals,

micro receiver, and four sub-micro servos. You can choose

to purchase a complete radio system that includes all of

these items or, if you are using an existing transmitter, just

purchase the other required equipment separately.

Complete Radio System

SPM2460 DX6 DSM®6CH Park Flyer

w/4-S75 Servos

Note: We recommend the crystal-free,

interference-free Spektrum® DX6 2.4GHz DSM

6-Channel System, which includes a micro

receiver and 4 sub-micro servos.

Or Purchase Separately

SPM6000 AR6000 DSM DuaLink™ 6-Channel

Park Flyer Rx

JSP30610 6-Channel UltraLite Rx w/o Crystal,

Positive Shift JR/AIR (72MHz)

JSP30615 6-Channel UltraLite Rx w/o Crystal,

Negative Shift FUT/HRC (72MHz)

JRPXFR** FM Receiver Crystal

EFLRS75 7.5-Gram Sub-Micro Servo (4)

Important Information About Motor

Selection

We recommend the E-flite®Park 450 Brushless

Outrunner, 890Kv (EFLM1400) to provide you with

excellent high-power motor system, or the Park 400

Brushless Outrunner 920 Kv (EFLM1305) for sport power

and a worry-free outrunner motor. The Cap 232 BP 3D

does not include a propeller.

High Power Outrunner Setup

EFLM1400 Park 450 BL Outrunner, 890Kv

EFLA311B 20-Amp Brushless ESC

THP13203SPL 1320mAh 3-Cell 11.1V Li-Po

APC11038SF 11 x 3.8 Electric Prop

EFLAEC303 EC3 Device & Battery Connector,

Male/Female

EFLC3005 Celectra 1- to 3-Cell Li-Po Charger

This is a high-power performance setup for strong

3D flights.

Lightweight Outrunner Setup

EFLM1305 Park 400 BL Outrunner, 920Kv

EFLA311B 20-Amp Brushless ESC

THP9103SJPL 910mAh 3-Cell 11.1V Li-Po

APC11038SF 11 x 3.8 Electric Prop

EFLAEC303 EC3 Device & Battery Connector,

Male/Female

EFLC3005 Celectra 1- to 3-Cell Li-Po Charger

This is a lightweight sport setup with adequate power

for 3D flights.

Optional Accessories

EFLA110 Power Meter

Note on Lithium Polymer Batteries

Lithium Polymer batteries are significantly

more volatile than alkaline or Ni-Cd/

Ni-MH batteries used in RC applications.

All manufacturer’s instructions and warnings

must be followed closely. Mishandling of Li-Po

batteries can result in fire. Always follow the

manufacturer’s instructions when disposing of

Lithium Polymer batteries.

Required Tools and Adhesives

Tools & Equipment

EFLA250 Park Flyer Tool Assortment, 5-piece

Or Purchase Separately

EFLA257 Screwdriver, #0 Phillips (or included

with EFLA250)

EFLA251 Hex Wrench: 3/32” (or included

with EFLA250)

Drill

Drill bit: 1/16” (1.5mm), 5/64” (2mm)

Felt-tipped pen

String

Straight edge

Threadlock

Razor saw

T-pins

Thin CA

Medium CA

Paper towels

Hobby knife (#11 blade)

6-minute epoxy

Pliers

Ruler

Square

Sandpaper

Warning

An RC aircraft is not a toy! If misused, it can cause

serious bodily harm and damage to property. Fly

only in open areas, preferably at AMA (Academy of

Model Aeronautics) approved flying sites, following all

instructions included with your radio.

Keep loose items that can get entangled in the propeller

away from the prop, including loose clothing, or other

objects such as pencils and screwdrivers. Especially keep

your hands away from the propeller.

Date of Purchase Warranty Period

Horizon Hobby, Inc., (Horizon) warranties that the

Products purchased (the “Product”) will be free from

defects in materials and workmanship at the date of

purchase by the Purchaser.

(a) This warranty is limited to the original Purchaser

("Purchaser") and is not transferable. REPAIR OR

REPLACEMENT AS PROVIDED UNDER THIS WARRANTY

IS THE EXCLUSIVE REMEDY OF THE PURCHASER. This

warranty covers only those Products purchased from an

authorized Horizon dealer. Third party transactions are

not covered by this warranty. Proof of purchase is required

for warranty claims. Further, Horizon reserves the right

to change or modify this warranty without notice and

disclaims all other warranties, express or implied.

(b) Limitations- HORIZON MAKES NO WARRANTY

OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT

NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS

FOR A PARTICULAR PURPOSE OF THE PRODUCT. THE

PURCHASER ACKNOWLEDGES THAT THEY ALONE

HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY

MEET THE REQUIREMENTS OF THE PURCHASER’S

INTENDED USE.

shall be that Horizon will, at its option, (i) repair or

(ii) replace, any Product determined by Horizon to be

defective. In the event of a defect, these are the Purchaser's

exclusive remedies. Horizon reserves the right to inspect

any and all equipment involved in a warranty claim.

Repair or replacement decisions are at the sole discretion

of Horizon. This warranty does not cover cosmetic damage

or damage due to acts of God, accident, misuse, abuse,

negligence, commercial use, or modification of or to any

part of the Product. This warranty does not cover damage

due to improper installation, operation, maintenance, or

attempted repair by anyone other than Horizon. Return of

any goods by Purchaser must be approved in writing by

Horizon before shipment.

Limited Warranty

Damage Limits

HORIZON SHALL NOT BE LIABLE FOR SPECIAL,

INDIRECT OR CONSEQUENTIAL DAMAGES, LOSS OF

PROFITS OR PRODUCTION OR COMMERCIAL LOSS IN

ANY WAY CONNECTED WITH THE PRODUCT, WHETHER

SUCH CLAIM IS BASED IN CONTRACT, WARRANTY,

NEGLIGENCE, OR STRICT LIABILITY. Further, in no event

shall the liability of Horizon exceed the individual price of

the Product on which liability is asserted. As Horizon has

no control over use, setup, final assembly, modification

or misuse, no liability shall be assumed nor accepted for

any resulting damage or injury. By the act of use, setup or

assembly, the user accepts all resulting liability.

If you as the Purchaser or user are not prepared to accept

the liability associated with the use of this Product, you

are advised to return this Product immediately in new and

unused condition to the place of purchase.

Law: These Terms are governed by Illinois law (without

regard to conflict of law principals).

Safety Precautions

This is a sophisticated hobby Product and not a toy. It

must be operated with caution and common sense and

requires some basic mechanical ability. Failure to operate

this Product in a safe and responsible manner could result

in injury or damage to the Product or other property. This

Product is not intended for use by children without direct

adult supervision. The Product manual contains instructions

for safety, operation and maintenance. It is essential

to read and follow all the instructions and warnings in

the manual, prior to assembly, setup or use, in order to

operate correctly and avoid damage or injury.

Questions,Assistance, and Repairs

Your local hobby store and/or place of purchase

cannot provide warranty support or repair. Once

assembly, setup or use of the Product has been started,

you must contact Horizon directly. This will enable

Horizon to better answer your questions and service

you in the event that you may need any assistance. For

questions or assistance, please direct your email t

o productsupport@horizonhobby.com, or call

877.504.0233 toll free to speak to a service technician.

Inspection or Repairs

If this Product needs to be inspected or repaired, please

call for a Return Merchandise Authorization (RMA). Pack

the Product securely using a shipping carton. Please note

that original boxes may be included, but are not designed

to withstand the rigors of shipping without additional

protection. Ship via a carrier that provides tracking and

insurance for lost or damaged parcels, as Horizon is

not responsible for merchandise until it arrives and

is accepted at our facility. A Service Repair Request is

available at www.horizonhobby.com on the “Support” tab.

If you do not have internet access, please include a letter

with your complete name, street address, email address

and phone number where you can be reached during

business days, your RMA number, a list of the included

items, method of payment for any non-warranty expenses

and a brief summary of the problem. Your original sales

receipt must also be included for warranty consideration.

Be sure your name, address, and RMA number are clearly

written on the outside of the shipping carton.

Warranty Inspection and Repairs

To receive warranty service, you must include your

original sales receipt verifying the proof-of-purchase

date. Provided warranty conditions have been met,

your Product will be repaired or replaced free of charge.

Repair or replacement decisions are at the sole discretion

of Horizon Hobby.

Table des matières

Autres manuels E-FLITE Jouet

E-FLITE

E-FLITE UMX MiG 15 DF Manuel utilisateur

E-FLITE

E-FLITE AT-6 25e Texan ARF Manuel utilisateur

E-FLITE

E-FLITE Aeronca Champ 15E ARF Manuel utilisateur

E-FLITE

E-FLITE Funtana 300 AR Manuel utilisateur

E-FLITE

E-FLITE Blade SR Manuel utilisateur

E-FLITE

E-FLITE Deuces Wild ARF Manuel utilisateur

E-FLITE

E-FLITE Beechcraft Bonanza 15e ARF Manuel utilisateur

E-FLITE

E-FLITE Carbon-Z Splendor Manuel utilisateur

E-FLITE

E-FLITE Mini Ultra Stick Manuel utilisateur

E-FLITE

E-FLITE UMX PT-17 Manuel utilisateur

E-FLITE

E-FLITE Super Airliner ARF Manuel utilisateur

E-FLITE

E-FLITE Beast 60e Manuel utilisateur

E-FLITE

E-FLITE Viper 70mm EDF Manuel utilisateur

E-FLITE

E-FLITE P-51D Mustang Manuel utilisateur

E-FLITE

E-FLITE Mini Pulse XT Manuel utilisateur

E-FLITE

E-FLITE Ultimate 20-300 10 ARF Manuel utilisateur

E-FLITE

E-FLITE UMX F4U corsair Manuel utilisateur

E-FLITE

E-FLITE EFLA370H Manuel utilisateur

E-FLITE

E-FLITE EDGE 540QQ 280 Manuel utilisateur

E-FLITE

E-FLITE Blade CP Pro 2 PNP Manuel utilisateur

E-FLITE

E-FLITE G210 Manuel utilisateur

E-FLITE

E-FLITE Blade CP Manuel utilisateur

E-FLITE

E-FLITE Mini Pulse XT Manuel utilisateur

E-FLITE

E-FLITE UMX PittsS-1S Manuel utilisateur

Manuels Jouet populaires d'autres marques

marklin

marklin 37321 Manuel utilisateur

Canon

Canon PAPER CRAFT Manuel utilisateur

GREAT PLANES

GREAT PLANES Pitts M-12S Manuel utilisateur

NOCH

NOCH 14261 Manuel utilisateur

Hausler

Hausler 450 SE V2 Manuel utilisateur

Dynaflite

Dynaflite Daydream Manuel utilisateur

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuel

Kenner

Kenner Batman 63651 Manuel utilisateur

LEGO

LEGO 8527 Manuel utilisateur

iKarus

iKarus ECO 8 Manuel utilisateur

Multiplex

Multiplex EasyStar II Mode d’emploi

Walkera

Walkera 38 Mode d’emploi

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuel utilisateur

MD MXION SWD Manuel utilisateur

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuel utilisateur

marklin

marklin 39671 Manuel utilisateur

Meccano

Meccano 15103 Manuel utilisateur

LEGO

LEGO TECHNIC 8735 Manuel utilisateur
