EM PRO midi E – Revision 1 - Device Reference Manual – P –

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Manufacturer

E.E.P.D. Electronic Equipment Produktion & Distribution GmbH

Gewerbering 3

85258 Weichs

Phone: +49 8136 2282 – 0

Fax: +49 8136 2282 – 109

Web: https://www.eepd.de

E-Mail: sales@eepd.de

09/2021 Version 1.2

General Notes

This user manual is for your information only.

The information contained herein has been checked carefully and is believed

to be reliable. However, E.E.P.D. GmbH gives no guarantee or warranty

concerning the accuracy of spoken information and shall not be responsible

for any loss or damage of any nature resulting from the usage of or from

reliance upon it.

We are thankful for all suggestions or improvements at any time.

E.E.P.D. GmbH reserves the right to make changes in the products or

specifications, or both, at any time without notice.

E.E.P.D. GmbH copyrights this document. You may not reproduce, transmit,

transcribe, store in a retrieval system, or translate into any language or

computer language, in any form or by any means, or otherwise, any part of

this publication without the express written permission of E.E.P.D. GmbH.

Trademark Acknowledgement

E.E.P.D.® and EMTRUST® are registered trademarks of E.E.P.D. GmbH. All

rights reserved. All other mentioned trademarks are registered trademarks of

their owners.

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Disclaimer

This document is provided for the general information of the customer. It

describes the general functionality of the system and is not considered as

assured characteristics. The written declarations in this specification are not

constituent part of any contract.

E.E.P.D. GmbH reserves the right to modify the information contained in this

manual as necessary and the customer should ensure that he has the most

recent revision of this document.

E.E.P.D. GmbH makes no warranty for the use of its products and bears no

responsibility for any errors, which may appear in this document. The

customer should be on notice that the field of personal computers is the

subject of many patents held by different parties. Customers must ensure that

they take appropriate action so that their use of the products does not infringe

upon any patents. It is the policy of E.E.P.D. GmbH to respect the valid patent

rights of third parties and not to infringe upon or assist others to infringe upon

such rights.

E.E.P.D. GmbH assumes no responsibility for circuits, descriptions and tables

within this document as far as patents or other rights of third parties are

concerned.

Life Support Applications

E.E.P.D. GmbH products are not intended for being used as critical

components in life support appliances, devices or systems in which the failing

of an E.E.P.D. GmbH product could be expected to result in personal injury.

FCC and CE Disclaimer

E.E.P.D. GmbH gives no warranty at all that their products will meet the FCC

and CE standards when used in combination with other third party products

or when used in any other way than specified.

Warranty

The warranty and/or guarantee conditions according to the current terms and

conditions of E.E.P.D. GmbH apply.

Reshipment

If you return the EM PRO system to E.E.P.D. GmbH please remove all

connections and peripheral equipment.

Protect the unit with a suitable packaging, preferably use the original

packaging.

Packaging

The EM PRO system is in a protective package to avoid damage during

transport.

This protective package should be recycled in an environmentally friendly way

after use.

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Disposal of Device

At the end of the lifetime please dispose and/or recycle the

components of the device accordingly.

Technical Support

For technical information about hardware and software please contact:

support@eepd.de

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Table of Contents

General Notes ...............................................................................................1

Symbols.........................................................................................................6

Safety Instructions .......................................................................................7

System Information......................................................................................8

Options............................................................................................................8

Accessories ....................................................................................................9

Intended Use ..................................................................................................9

Scope of Delivery........................................................................................10

Type Label....................................................................................................10

System Dimensions......................................................................................11

Technical Data ............................................................................................13

Interfaces.....................................................................................................14

Connection Overview....................................................................................14

Power Button with LED.................................................................................15

HDD/SSD LED..............................................................................................16

Connections................................................................................................17

MiniDisplay Ports..........................................................................................17

Dual-USB 3.1 Gen2 (900mA each) ..............................................................17

Standard pin assignment..............................................................................17

2.5 Gigabit Ethernet Dual-Port .....................................................................18

Power Connector (DC)..................................................................................18

RS232 Port 1 ................................................................................................19

RS232 Port 2 ................................................................................................19

Front USB-C Port (max. 1.5A)......................................................................19

Commissioning...........................................................................................20

Switching on the device / Operation.............................................................20

UEFI/BIOS....................................................................................................21

Entering Setup ..............................................................................................21

Main Menu ....................................................................................................22

Advanced Menu............................................................................................25

Security Menu...............................................................................................55

Power Menu..................................................................................................59

Boot Menu.....................................................................................................61

AMD PBS Menu............................................................................................67

AMD CBS Menu............................................................................................71

Exit Menu......................................................................................................89

Revision History..........................................................................................91

Index of Figures..........................................................................................92

Index of Tables............................................................................................93

List of Abbreviations..................................................................................94

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Symbols

The red danger sign warns you if incorrect operation puts your

life or health at great risk. Both the components and the

peripherals could be destroyed.

The orange warning sign warns you that an incorrect or missing

operation could seriously endanger your health or destroy the

used components.

The yellow caution sign indicates that an incorrect or missing

action could damage the components.

The yellow ESD symbol indicates that electrostatic sensitive

components could be destroyed. Unpack shielded

components only with ESD protection such as an ESD

wristband or on an ESD protected area.

The information sign gives you further information and advice

for optimal use of this product.

For example, it draws your attention to necessary or optional

accessories.

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Safety Instructions

Safety of People

The product generates considerable heat. The housing

transports this heat to the environment and thus becomes hot.

Take care if you touch the housing as this may cause burns!

Please follow all safety instructions at the installation site.

Make sure that no or only necessary cables are connected to

the BoxPC during installation.

If access to the BoxPC interfaces is not available after

installation, all necessary connections must be made before.

Device Safety

The BoxPC operates exclusively within the specified DC

voltage range. Repair work should only be made by an

authorized and certified specialty retailer or by the

manufacturer's customer service. Do not open the device to

avoid damage.

Modifications that have not been approved by the

manufacturer void the warranty. Dust, dirt, moisture, and

extreme temperatures may significantly impair proper

operation.

The device may only be opened by a qualified person.

Cooling System

The BoxPC consists of a compact, robust metal housing with

ventilation holes. It is equipped with an automated fan. To

ensure sufficient heat dissipation, never cover the ventilation

holes of the case. Do not place any objects onto the device.

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

System Information

Required Tools

For the installation of the EM PRO system the following standard tools are

recommended:

•Cable connection: Slot screwdriver

•Socket wrench 5.5 mm

•Torx screwdriver T10

Other required tools are depending on the installation place and method.

External Notice

All external documentation to install the EM PRO system should be obeyed.

Software

Supported operating systems are:

Microsoft® Windows® 10

Microsoft® Windows® 10 IoT Enterprise

Linux Ubuntu 20.04 LTS.

Options

Description

Memory*

V2000 processors: Max. 32 GB dual-

channel DDR4 SODIMM up to 3200 MT/s,

with ECC-support

SSD*

64 GB – 2 TB

Operating System*

Windows® 10, Windows® 10 IoT

Enterprise, Linux Ubuntu 20.04 LTS

*factory assembled on request

ODM option

Tab. 1: Options

EM PRO midi E Device Reference Manual – P – Revision 1

E.E.P.D. GmbH | Gewerbering 3 | 85258 Weichs

Accessories

For accessories please contact our sales department.

Accessories

Description

Power supply (180 W / 19.5

V or 120 W / 24 V))

Power supply incl. cable with EU plug

Display cable

Cable MiniDP to HDMI, 2 m, with interlock

Cable MiniDP to DP, 2 m

Tab. 2: Accessories

Intended Use

The EM PRO midi is a personal computer to be used with Windows 10,

Windows 10 IoT Enterprise or Ubuntu Linux 20.04 LTS. It has been designed

for office and workshop environments.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels E.E.P.D. Ordinateur de bureau

E.E.P.D.

E.E.P.D. EM PRO mini Manuel utilisateur

Manuels Ordinateur de bureau populaires d'autres marques

HP m9060n - Pavilion - Elite Fiche technique

Asus

Asus E210 Series Manuel utilisateur

Dell

Dell Inspiron 600m Manuel utilisateur

Dell

Dell Inspiron 3662 Manuel utilisateur

TotalFlow

TotalFlow uFLO Manuel utilisateur

HP Presario SV7000 - Desktop PC Manuel utilisateur

HP ProDesk 400 G5 Manuel

Logitech

Logitech MK320 Manuel utilisateur

Dell

Dell XPS 730 H2C Manuel utilisateur

Sony

Sony Vaio Series Manuel utilisateur

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuel utilisateur

Alto

Alto MD 250 Manuel utilisateur

Lenovo

Lenovo ThinkCentre Edge 72 Manuel

Lenovo

Lenovo ThinkStation D20 Manuel

Arbor Technology

Arbor Technology FPC-7800 Series Manuel utilisateur

Sony

Sony VAIO VGX-TP1 Series Manuel utilisateur

Asus

Asus Eee Box B204 Manuel utilisateur

Dell

Dell Optiplex 9010 All In One Manuel utilisateur
