E.A.R. Full Shell Manuel utilisateur

If you have any questions, or if your hearing protection

requires service, please contact your hearing professional.

E.A.R./Insta-Mold, Inc. • P.O. Box 18888

Boulder, CO. 80308 U.S.A. • 800-525-2690

303-447-2619 • E-mail: [email protected]

www.earinc.com • www.freehearingtest.com

WORLDWIDE DISTRIBUTION

Innovation Design Practicality Excellence

Quick Fit™

MiniCanal™

BTE

identification

Serial numbers are imprinted on the back of

Full Shell, Half Shell, and CIC (Completely in

Canal) models, on the side of the Quick Fit™

and on the shell of MiniCanal™ models.

The serial number for Behind-The-Ear (BTE)

units can be found inside the battery door

or imprinted on the shell.

Full Shell, Half Shell, and CIC (Completely

in Canal) models are marked with a red

dot on the back of the instrument to indi-

cate that the unit is intended for the right

ear and a blue dot to indicate the left ear.

Some MiniCanals™ feature a red shell (right)

and a blue shell (left). Some MiniCanals™

with beige shell feature a red indication

(right) and a blue indication (left).

Full Shells – Rear View

table of contents

Identification .........................................3

Features: Full-Shell, Half-Shell, CIC (Completely-In-Canal) ......... 4

Features: Rechargeable, MiniCanal™........................5

Features: BTE (Behind-The-Ear), Quick Fit™...................6

Noise Levels .......................................... 7

Healthy Hearing .......................................7

Battery Installation and Removal...........................8

Battery Warning .......................................8

Volume Control Adjustments .............................9

MiniCanal™

Application and Removal of Silicone Tip.................10

Inserting and Removing Your MiniCanal™ ...............10

Rechargeable ........................................11

How To Charge ...................................11

Half Shell Models

Inserting Your Half Shell ............................12

Removing Your Half Shell ...........................12

Full Shell Models

Inserting Your Full Shell.............................13

Removing Your Full Shell ............................13

Behind-The-Ear (BTE) Models

Installation and Removal of the Battery .................14

Volume Control Adjustment..........................14

How to Wear Your BTE .............................15

Removing Your BTE ................................15

M-T-O Switch .....................................15

Quick Fit™ Models

Installation and Removal of the Battery .................16

Volume Control Adjustment..........................16

How to Wear Your Quick Fit™........................17

Multi-Memory Button ...............................17

Using the Private Ear™ Option ...........................18

Multi-Memory Button ..................................19

Music Monitor Option ..................................20

Select-A-Vent System ...................................20

Care and Storage ..................................... 21

Troubleshooting Guide .................................22

Repair and Service ....................................22

Limited Warranty .....................................23

features: rechargeable

features: Minicanal™

Your MiniCanal™ model may differ from the one shown here.

Removal Line

(Lanyard Placement)

Microphone Port and

Wind Screen

Volume Control

Battery Drawer

Tone Adjustment

(Analog Only)

Receiver Port

Removable Silicone Tip

Volume Control

Programming Socket

Your hearing protection may have different combinations of these features.

features: full shell

features: half shell

Removal Line

(Lanyard

Placement)

Removal Line

(Lanyard

Placement)

Removal Line

(Lanyard Placement)

Multi-Memory

Button

(Digital Only)

Lanyard

Audio Input

(Optional)

Audio Upgrade

(Optional)

Battery Drawer

Microphone Port and

Wind Screen

Tone

Adjustment

(Advantage Only)

Tone Adjustment

(Advantage Only)

Receiver

Port

Receiver

Port

Volume

Control

Volume Control

Microphone

Port

Battery Drawer

Microphone

Port

Select-A-Vent (Optional)

Private Ear™ (Optional)

features: cic

(coMPletelY in canal)

healthY hearing

Proper use of your hearing protection is crucial to reduce the

risk of hearing damage due to high level noise exposure.

It is highly recommended that you have an annual hearing

evaluation by a licensed Hearing Healthcare Professional.

This will keep you informed of any changes in your hearing.

There are many things that contribute to hearing loss,

including natural aging, diseases and lack of protection to

high levels of noise. Your hearing protection can reduce

the risk of hearing damage when used properly. Use your

hearing protection when sound levels are greater than

normal everyday levels (i.e. gunshots, motorcycles, etc.)

features: bte (behind-the-ear) noise levels

features: Quick fit™

Microphone Port

and Windscreen

Potentiometers (Featured

on various SHS units)

Ear Hook

Volume Control

Battery Drawer

Microphone Port

and Windscreen

Multi-Memory Button

Interchangeable Tips –

Open, Closed or Custom

(Open Tip shown here)

Volume Control

Battery Drawer

Your hearing protection may have different combinations of these features.

Painful:

150 dB = firearms, rock music

140 dB = air raid siren, jet engine

130 dB = jackhammer

120 dB = jet plane take-off, amplified rock music at

4-6 ft., car stereo, band practice

Very loud:

110 dB = rock music, model airplane

106 dB = timpani and bass drum rolls

100 dB = snowmobile, chain saw, pneumatic drill

90 dB = lawn mower, shop tools, truck traffic

80 dB = alarm clock, busy street

70 dB = busy traffic, vacuum cleaner

60 dB = conversation

Comfortable:

50 dB = moderate rainfall, quiet room

30 dB = whisper, quiet library

voluMe controls

Volume Control

Allows you to adjust the amount

of amplification

provided by the protection.

For Full Shells, Half Shells and

MiniCanals, to increase amplifica-

tion, turn the volume control

forward, toward your face. To

decrease amplification, turn the

volume control backward, toward

the back of your head.

For SHS models. turn the

Volume Control to a higher

number for higher volume.

On Quick Fit™ models, the

Volume Control is located on

the bottom of the instrument.

Rotate clockwise for higher

volume, counter-clockwise

for lower volume.

Turning your instrument

On and Off. Your instrument

is on any time a functioning

battery is placed in the compart-

ment, and the battery drawer is

closed. To turn your instrument

off, fully open the battery drawer

and remove the battery.

Full Shell, Half Shell

MiniCanal™

SHS

Quick Fit™

batterY installation & reMoval

Your hearing protection uses either a size 13, 10A or 312

battery. Your hearing professional will advise you on which

battery to use.

Installing the battery

Open the battery compartment by

gently lifting the raised edge of the

swing-out drawer. Place the battery

in the drawer with the “+” side fac-

ing the same direction as the “+”

sign on the drawer. Close the bat-

tery compartment by gently swing-

ing the drawer until it securely snaps

in place. Remove installed batteries

by fully opening the drawer and

pushing the battery out from the bottom.

If the drawer does not close easily, verify that the battery is

placed correctly in the compartment. DO NOT FORCE THE

BATTERY DRAWER SHUT.

batterY Warning

Warning: Batteries are dangerous if swallowed.

If ingested, immediately contact a physician or

the National Button Battery Ingestion

Hotline at (202) 625-3333.

Dispose of used batteries in the proper waste or recycling

container. Keep batteries out of reach of children and pets.

rechargeable

How to Charge

Plug the charge box power cord

into an electrical outlet. Make sure

the hearing protection units are

turned off before charging! Turn

the charger power switch on and a

red light will appear on the switch.

Place the units face down and level

in the charging cups. A red light

will also glow inside the units to let

you know they are charging.

Prior to initial use, the hearing instruments should be charged

for 12 hours to receive maximum rechargeable cell life.

After the initial charge cycle, we recommend 8 hours of

daily recharging time for up to 16 hours use. A routine of

daily recharging (8 hours) should provide maximum cell life.

Charge for at least 8 hours, but no more than 24 hours.

After charging, your units will last about 16 hours.

Recharging the unit for more than 72 continuous hours

may damage the recharging system.

Make sure you turn your charger switch to the off position

when you are not charging your units.

1110

Minicanal™

Application and removal of silicone tip

To apply silicone tip, hold tip between

thumb and index finger. Insert

MiniCanal™ tip into silicone tip as shown.

To remove silicone tip, grasp the MiniCanal™ instrument and

tip between thumb and index finger and gently pull apart.

Inserting and Removing your MiniCanal™

To insert your MiniCanal™, hold it with

the extraction line between your thumb

and index finger. The microphone open-

ing should be at the bottom. Gently guide

the MiniCanal™ into your ear canal until

you feel resistance. Release the extraction

line. Using your index finger, push the

MiniCanal™ in until it is seated comfort-

ably in your ear canal. Pulling down on

your ear lobe with your other hand as

you push may help with insertion.

To remove, grasp the extraction line and gently pull the

MiniCanal™ out of your ear canal.

DO NOT USE THE BATTERY DRAWER AS HOLDING POINT

TO REMOVE YOUR MINICANAL™. DAMAGE MAY OCCUR.

full shell Models

Inserting your Full Shell

To insert your

Full Shell, hold it

between your thumb

and index finger

with the battery drawer facing

away from the ear.

Slowly insert the

Full Shell into your

ear canal. Gently

twist the Full Shell

until it is securely and comfort-

ably seated in your ear.

To achieve the highest level

of protection, the instrument

must be properly inserted.

Removing your Full Shell

To remove your Full Shell, grasp the instrument with your

thumb and index finger, and gently twist it as you pull

outward.

DO NOT USE THE BATTERY DRAWER TO REMOVE YOUR

FULL SHELL. DAMAGE MAY OCCUR.

half shell Models

Inserting your Half Shell

To insert your

Half Shell, hold it

between your thumb

and index finger.

The volume control should

be at the top.

Gently guide the

Half Shell into your

ear canal. Press on

the instrument to

ensure that it is in place. To

achieve the highest level of

protection, the instrument

must be properly inserted.

Removing your Half Shell

To remove your Half Shell, reach into the ear with your

thumb and index finger, and gently pull out the instrument.

DO NOT USE THE BATTERY DRAWER TO REMOVE YOUR

HALF SHELL. DAMAGE MAY OCCUR.

1312

behind-the-ear (bte) Models

How to Wear Your BTE

To insert your custom earmold

or foam tip (shown here), hold

it between your thumb and

index finger.

Slowly insert the custom earmold

or foam tip into your ear canal.

Gently twist until it is securely and

comfortably seated in your ear. To

achieve the highest level of protection the

instrument must be properly inserted.

Place the hearing protection

behind your ear.

To Remove Your BTE, take the instrument out from

behind your ear and gently pull the earmold outward.

M-T-O switch

Some BTEs are equipped with an M-T-O

switch. For normal listening situations,

set the switch to the “M” or Microphone

position. When using the Private Ear™

option, set the switch to the “T”. To turn

the BTE off, set the switch to the “O” or

off position. Some models feature a Multi-

Memory button to perform these functions.

behind-the-ear (bte) Models

Installing the Battery

Open the battery compartment

by gently lifting the raised edge

of the swing-out drawer.

Place the battery in the drawer with

the + side facing the same direction

as the + sign on the drawer.

Close the battery compartment by

gently swinging the drawer until it

securely snaps in place.

DO NOT FORCE THE BATTERY DRAWER SHUT.

If the drawer does not close easily, verify that the

battery is placed correctly in the compartment.

Your Quick Fit™ hearing protection uses a size 13 battery.

Remove installed batteries by fully opening the drawer

and pushing the battery out from the bottom.

Volume control adjustment

To increase amplification, turn the

volume control upward to display a

higher number.

To decrease, turn downward to a

lower number.

Quick fit™ Models

How to Wear Your Quick Fit™

The Quick Fit™ comes with two types of

interchangeable tips. Use the Open Tip

for hearing enhancement in quiet activi-

ties like bow hunting, nature listening,

and communications. Use the Closed

Tip for hearing protection from loud sounds such as gun-

fire, industrial noise, racing and motorcycling. (Note: In this

case, superior sound quality remains, but most users will

experience some degree of occlusion due to the closed tips

required to reduce loud sounds.)

Carefully insert the open or closed tip into your ear canal.

To achieve the highest level of protection the tip must be

properly inserted. Bring the tubing to the top front of the

ear and place the instrument behind your ear.

The standard open and closed tips may be replaced with a

custom earmold.

Removing Your Quick Fit™

To remove, gently pull the tip or custom earmold outward.

Multi-Memory Switch

The Multi-Memory button allows you to

select from the different memory settings

that your hearing professional has pro-

grammed for you. For more information

on the Multi-Memory switch, see page 19.

Quick fit™ Models

Installing the Battery

To install the battery, open the

battery compartment by gently

lifting the raised edge of the

swing-out drawer.

Place the battery in the drawer with

the + side facing the same direction

as the + sign on the drawer.

Close the battery compartment by

gently swinging the drawer until

it securely snaps in place.

DO NOT FORCE THE BATTERY DRAWER SHUT.

If the drawer does not close easily, verify that the

battery is placed correctly in the compartment.

Your Quick Fit™ uses a size 13 battery.

Remove installed batteries by fully opening the drawer

and pushing the battery out from the bottom.

Volume control adjustment

The Quick Fit™ Volume Control is locat-

ed on the bottom of the instrument.

Rotate clockwise for higher volume, coun-

ter

-clockwise for lower volume.

using the Private ear™ oPtion

The Private Ears™ option brings com-

munications from a two-way radio or

cell-phone straight to the ear via an

induction loop system. This feature

enables the user to camouflage radio

commands communications without

any wires to the ear.

The Private Ear™ option is available on Full Shell, Half Shell,

BTE and Quick Fit™ models and is designed to activate

when used with a telephone or communication radio con-

nected to an induction loop which transmits to the hearing

protection instrument.

If your Full Shell or Half Shell is equipped with the Private Ear™

option, activate it by gently toggling the switch upward.

If you have an instrument with an

M-T-O switch, set it to “T” for Private

Ear™ option.

For units equipped with an “Active

Telecoil”, the instrument will respond

automatically.

The Private Ear™ is also available

in a stand-alone non-custom Micro

unit and features

receive-only ability.

Multi-MeMorY button (if so eQuiPPed)

Your hearing pro-

tection may be

equipped with a

multi-memory

button. The multi-

memory button

allows you to select

from the different

memory settings

that your hearing professional has programmed for you.

Your hearing professional will advise you on when to use

each memory setting.

If the hearing protection is turned off or the battery is

removed the protection will default to Memory Setting 1.

Memory Listening

Setting Environment

Full and Half Shell Quick Fit™

Micro Private Ear™

BTE

Full and Half Shell

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels E.A.R. Prothèse auditive

E.A.R.

E.A.R. MiniCanal Series Manuel utilisateur

Manuels Prothèse auditive populaires d'autres marques

Sonic

Sonic Bliss miniBTE Manuel utilisateur

Lexie

Lexie B1 Manuel de la liste des pièces

Widex

Widex FM+DEX Manuel utilisateur

Siemens

Siemens Triano Manuel utilisateur

Camplicomms

Camplicomms HC-200 Manuel utilisateur

Widex

Widex SUPER 220 S2-VSD Manuel utilisateur

Phonak

Phonak Q90 Manuel utilisateur

Williams Sound

Williams Sound SoundPlus WIR 237 Mode d’emploi

Oticon Medical

Oticon Medical Ponto SoundConnector Manuel utilisateur

Siemens

Siemens Life micon Manuel utilisateur

Starkey

Starkey Destiny Manuel utilisateur

Audicus

Audicus The Icon Manuel utilisateur

Advanced Bionics

Advanced Bionics Slim HP Standard Manuel utilisateur

Widex

Widex DREAM440 THE DREAM SERIES Manuel utilisateur

Phonak

Phonak myPilot Manuel utilisateur

NIKEN

NIKEN NK-401 Manuel utilisateur

ON Semiconductor

ON Semiconductor Ezairo 7111 Pre Suite Manuel utilisateur

Sonetik

Sonetik GOHEAR Manuel utilisateur
