Dyson V12 Detect Slim Manuel utilisateur

User manual

SV12 JN.00000 PN.000000-00-00

00.00.00 VERSION NO.01

Contents

In the box

Getting started

The LCD screen

Charging your machine

Changing your click-in battery

Caring for your floors

Emptying your bin

Cleaning your bin

Washing your filter

Clearing blockages

Washing your Laser Slim Fluffy™

brush bar

Clearing blockages from your Hair

screw tool

Cleaning your tools

Looking after your machine

Top view of the Dyson V12 detect

slim machine, showing cleaner

head, wand, bin and main body.

Dyson V12 detect slim

In the box

Combination tool Soft dusting brush

Vacuum cleaner

Wand

Laser Slim Fluffy™cleaner head Direct drive cleaner head

Crevice tool Stubborn dirt brush

Hair screw tool

Two tools in one –wide

nozzle and brush,

for quick switching

between cleaning and

dusting tasks around

your home or car.

Enclosed in a skirt

of soft nylon bristles

for gentle, vacuum-

assisted dusting of

delicate objects and

surfaces.

Engineered for precise

cleaning around

tricky edges and into

hard-to-reach narrow

spaces.

Stiff nylon bristles

dislodge ground-in dirt

from coarse carpets,

high traffic areas and

car interiors.

Anti-tangle conical

brush bar spirals hair

off and into the bin.

Motor-driven cleaning

for smaller spaces.

A precisely-angled laser makes

invisible dust visible on hard

floors.

Deep cleans carpets and

hard floors.

Charger

Charges your vacuum with

or without a dock.

Wall dock

Charges your vacuum with

or without a dock.

Your machine will come with one or more of these cleaner heads –

not all will be included.

Wand clip

Getting started

Eco

中文

한국어

Boost

中文

한국어

Auto

Power modes

Eco mode

Auto and Med mode

Boost mode

Measures microscopic dust particles

Your machine has three power modes for

different tasks. Change power modes quickly

using a single button.

Maximum run time for longer cleans all

around your home.

The optimum balance of power and run time.

Attach your cleaner head or Hair screw tool to

activate Auto mode. Suction power automatically

adapts to dust levels.

Designed for intensive spot cleaning

of ground–in dirt

A piezo sensor continuously sizes

and counts dust particles at the inlet.

Attach your cleaner head or Hair

screw tool and use in Auto mode to

automatically increase suction power

when needed.1

1. Quantity and size of dust displayed on screen varies depending on usage. Automatic suction adaptation only occurs in auto mode.

Med

Turn your laser on and off

Turn your laser on or off with the slider

switch on your cleaner head.

Class 1 laser product – safe

for pets and humans. Avoid

looking directly into the beam.

9,927,641

1.1M

450K

1.6K

10m 60 180 500

Diagram showing the connection of

the wand onto the main body, with

the wand release button aligned

with the top of the main body.

The screen showing the machine set to

Eco mode with a full battery in green

to show that this will give the longest

battery life of the three modes.

The screen showing the machine set

to Boost mode with a red battery to

show that this will give the shortest

battery life of the three modes.

Location of the Selection button

on the screen on the filter end

of the machine.

The screen, on the end of the

main body, showing a graph of

the sizing and counting of the

dust particles.

Arrow showing the end

of the wand connecting

to the cleaner head.

Two screens showing the machine

set to Auto mode and Med mode

with a blue battery showing that this

will give a medium length of battery

life.

The LCD screen

Settings menu

Change language

Change alert settings

Control the settings on your machine using the button.

To enter the settings menu, press and hold the button until the menu screen

appears. Tap to scroll through the options available.

The LCD screen shows your particle count information and performance,

including the cleaning mode selected, remaining run time, filter maintenance

and blockage information.

To change the language on your screen, press the button and hold until the

language list appears. Release the button.

Tap the button to scroll through the language list to your preferred language.

Press and hold the button until the countdown ends.

A green tick will appear on the screen to show your language selection is

complete.

To cancel your selection, release the button during the countdown.

You can turn the alert motor pulse off. Your motor will no longer pulse but

run time alert information will continue to be displayed on the LCD screen

when your machine needs your attention.

Turning off alerts will not turn off the blockage alert pulsing. This is to ensure

you clear any blockages, preventing damage to your machine.

Tap to scroll through the settings menu. Select the ‘Alerts’ option.

Scroll to select on or off. Hold the button until the countdown ends and a tick

appears on the screen. To cancel your selection, release the button during

the countdown

English

Espanol

English

selected

Particle count and graph

Select to turn the measuring and counting of particles on and off. Turn off

the measuring and counting of particles to stop your machine automatically

adjusting suction power and turn off the graph.

Adjust reactive suction power sensitivity.

Use the selection button to change how sensitive the particle count is. This

will change how your machine automatically reacts to the dust particles.

For more information and support for your machine

go online: www.dyson.com/support

The Selection button

on the screen being

pressed.

Two screens, the first with

the language list and then

the tick screen to show that

the language has been

successfully changed.

The screen with an

amber warning

triangle to demon-

strate an alert.

Battery health

Run time countdown

Alerts

To get the best performance and life from your battery, use Eco or Auto/Med mode.

When the battery needs charging, your machine will pulse three times and a

low run time icon will appear on the screen.

When your battery is empty, a red warning icon will appear on the screen.

The alerts you might see are:

Filter – the filter isn’t fitted correctly, or needs cleaning.

Blockage – your machine has a blockage that needs removing.

4:50

Exit settings menu

To exit the settings menu. Tap to scroll through the selection menu.

Select ‘Exit menu’.

When Particle count and graph is turned on, low run time will be in amber

and red when in Boost mode.

The screen with a

battery time remaining

shown as a number and

as a half filled battery.

The battery health is

shown on the batter-

ies on the screen.

Screen with Exit

menu wording and

return icon.

A red screen with an icon

with a plug being con-

nected to the power sup-

ply. This demonstrates

the battery is empty and

needs charging.

Alert icon with

Filter needs cleaning

wording.

Alert icon with

Airways blocked

wording.

Alert icon with Filter

not sealed wording.

Alert icon with Fully

charge before first

use wording.

Charging your machine

Connect to charger either directly or in the dock.

The blue LEDs on either side of the battery will flash during charging.

When the battery is fully charged, both LEDs will light for 5 seconds.

Your battery is fully charged when the display shows 100%.

Your machine won’t operate or charge if the ambient temperature is below

5°C(41°F). This is designed to protect both the motor and battery.

If you have additional click-in batteries, we recommend that you alternate

the batteries to maintain even performance.

Caring for your floors

Check that the underside of the cleaner head or tool is clean and free from

any objects that may cause damage.

Before vacuuming your flooring, rugs, and carpets, check the manufacturer’s

recommended cleaning instructions.

The brush bar on your machine can damage certain carpet types and floors.

Some carpets will fuzz if a rotating brush bar is used when vacuuming. If this

happens, we recommend vacuuming without the motorised floor tool and

consulting with your flooring manufacturer.

Changing your click-in battery

It’s important to fully charge your new machine before using it for the first

time, and after every clean. This is because the battery and monitoring

system’s algorithm ‘learns’ over time, and fully charging your machine helps

it to more accurately calculate and display remaining run time.

Removing your battery

Push the Battery release button on the handle and slide the battery off

your machine.

Charge the battery.

Refitting your battery

Align your battery with the handle and slide it in. Push firmly until it clicks

into place.

The charger connected from

the power supply using the

wall dock.

The charger connected from

the power supply directly

into the front of the battery.

Arrows showing the location of the Battery release button

and the battery coming off the handle when the button is

pressed. The battery is then shown being replaced on the

base of the handle, clicking into place.

Minimise dust contact

Empty as soon as the dirt reaches the MAX level – don’t overfill. Using your

machine when the dirt is above the MAX line may affect the performance

and require more frequent filter washing.

Emptying your bin

Press the red wand release button, on the top of the wand, and pull the wand away

from the bin.

Hold the machine over the bin, pointing downwards.

Firmly push the red bin release button. The bin will slide down, cleaning the shroud

as it goes, and the bin base will open.

The bin base won’t open if the red bin release button isn’t pushed down all the way.

Release the dirt

Cover your bin tightly in a dust proof bag while you empty. Remove the bin carefully,

seal the bag tightly and dispose.

Close your bin

Push the bin base upwards until the bin and bin base click into place.

Remove your wand

If it is necessary to clean your bin, empty it as shown in the ‘Emptying your bin’ section.

Press the red button located on the bin runner to release the bin and slide your bin off the runner.

Only clean your bin with a damp cloth.

Make sure that the bin and seals are completely dry before replacing.

Cleaning your bin

Remove your bin

Refit your bin

Overfilling your bin could result in inaccurate readings on the particle graph.

Insert the spine on to the bin runner.

Close your bin by pushing the bin base upwards until the bin and bin base click into place.

Your bin isn’t dishwasher safe and the use of detergents, polishes or air fresheners to clean your bin

isn’t recommended, as it may damage your machine.

The MAX mark on the bin of

the machine, showing that

the dirt should not be filled

over the Max mark when

the machine is at the angle

of normal use.

Illustration of the bin being

emptied into a bag with imag-

es demonstrating to take care

not to press the trigger when

emptying the bin.

The bin lid closing with an audible

click and the bin being pushed up-

wards with another click once it is fully

in place.

The bin being removed and the

location of the bin release lever on

the underside of the bin runner.

The bin being pushed back

into position on the bin

runner.

To check for blockages in the main body of the machine, remove the bin

following the instructions in the Cleaning your bin section and remove the

blockage.

If you cannot clear an obstruction, you may need to remove the brush bars.

Disconnect your machine from the charger before looking for blockages.

Be careful not to touch the trigger and be aware of sharp objects.

Leave your machine to cool down before looking for blockages.

Don't use your machine when looking for blockages as this could cause

injury.

Clearing blockages

Remove the bin and check for blockages in the main body of your machine.

Make sure any blockages are completely cleared and all parts are fitted

before using your machine.

If your machine detects a blockage, the motor will pulse and you won’t be

able to use your machine until the blockage has been cleared.

If you try to use your machine when the motor is pulsing, it will automatically

cut out.

Refit all parts securely before using your machine.

Clearing blockages isn't covered by your guarantee.

With the bin removed,

check for blockages, paying

particular attention to the air

inlet, located at on the right–

hand side of the machine just

below the point where the bin

joins the main body of the

machine.

With the wand

removed from the

machine, check for

blockages at both ends

of the wand.

Turn the cleaner

head over to check

for obstructions on

the brush bar and air

inlet.

Twist off your filter

Twist your filter anti-clockwise and pull it away from your machine.

Tap your filter

Before washing your filter, tap it gently over a bin to remove any loose dust

and debris.

Wash your filter

Wash with warm, running tap water – gently rubbing your filter with your fingers

to remove the dirt.

Fill and shake

Place your hand over one end of your filter.

Fill the filter with warm tap water.

Place your hand over the open end of the filter and shake it firmly to remove

trapped dirt and debris.

Repeat these steps until the water runs clear.

Shake out the water

Empty the filter and shake firmly to remove excess water.

Shake with the filter in both an upward and downward position.

Keep shaking until there’s no water coming from the filter.

Dry your filter

Washing your filter

Wash your filter at least once a month to maintain optimum suction power.

For more information and support for your machine go online: www.dyson.com/support

Important: your filter must be completely dry before you put it back into the

machine. Your machine could be damaged if used with a damp filter.

Leave your filter to dry for at least 24 hours in a well-ventilated, warm place.

Don’t dry your filter in a tumble dryer, microwave or near a naked flame.

Important: your filter must be completely dry before you put it back into the

machine. Your machine could be damaged if used with a damp filter.

Holding the filter by the hard,

plastic end, tap the other end

over the bin.

Filter held in upright position,

with the wider end in the palm

of a hand. Water running from a

tap into the narrower end.

Filter with hand over the

open end with arrows

showing a shaking motion.

The filter is located at the

rear of your machine.

A hand holding the filter with the narrow end

pointing downwards with droplets of water

being shaken from the filter and again, with the

end pointing downwards shaking water out.

The filter is left to dry with

the pleated filter end facing

upwards.

Replace your brush bar

Your Laser Slim Fluffy™cleaner head has a washable brush bar. To maintain

optimum performance, check and wash your brush bar regularly.

Make sure your machine is disconnected from the charger and take care not

to touch the trigger.

Washing your Laser Slim Fluffy™brush bar

Remove your brush bar

Wash and dry your brush bar

Don’t put any part of your machine in a dishwasher or use detergents,

polishes or air fresheners.

Press the cleaner head release button on the end of the wand. Place the

cleaner head upside down.

Push the end cap up fully and pull the brush bar out of the cleaner head.

Hold your brush bar under running water and gently rub to remove any lint

or dirt.

Stand your brush bar upright as shown. Leave to dry completely for at least

24 hours.

Before replacing, check that your brush bar is completely dry.

Reattach the end cap to your brush bar.

Slide your brush bar into the cleaner head. Push the end cap back down to

the closed position.

Cleaning your laser lens

To maintain optimum performance, keep your laser lens clean. Only clean

the lens when the cleaner head is not attached to your machine.

Use a soft, dry, lint-free cloth to wipe the lens.

The end cap is

located at the side

of the cleaner head.

Push this upwards to

unlock the brush bar.

Don't wash the end

cap.

The end cap should

be attached to the

cleaner head at an

angle less than 90°,

any angle greater

than this will not allow

the end cap to close.

The brush bar an

open end and a

closed end. Stand

upright, with the

closed end facing

upwards, to dry.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Dyson Aspirateur

Dyson

Dyson Ball Manuel utilisateur

Dyson

Dyson V7 Motorhead Manuel utilisateur

Dyson

Dyson DC19T2I Manuel utilisateur

Dyson

Dyson DC54 Animal Pro Manuel utilisateur

Dyson

Dyson DC 23 Manuel utilisateur

Dyson

Dyson 4236580 Manuel utilisateur

Dyson

Dyson Slim Manuel utilisateur

Dyson

Dyson Digital Slim DC35 Manuel utilisateur

Dyson

Dyson DC39 multi floor Manuel utilisateur

Dyson

Dyson DC03 Manuel utilisateur

Dyson

Dyson DC23 Turbinehead Manuel utilisateur

Dyson

Dyson DC05 Manuel utilisateur

Dyson

Dyson absolute Manuel utilisateur

Dyson

Dyson DC 29 Manuel utilisateur

Dyson

Dyson Micro 1.5kg Manuel utilisateur

Dyson

Dyson DC14 Telescope Reach Manuel utilisateur

Dyson

Dyson DC47 Manuel utilisateur

Dyson

Dyson DC24 Blueprint Limited Edition Manuel utilisateur

Dyson

Dyson CINETIC BIG BALL ABSOLUTE Manuel utilisateur

Dyson

Dyson DC 52 Manuel utilisateur

Dyson

Dyson DC34 ANIMAL Manuel utilisateur

Dyson

Dyson DC39c Manuel utilisateur

Dyson

Dyson DC07 Origin Manuel utilisateur

Dyson

Dyson DC24 Blueprint Limited Edition Manuel utilisateur

Manuels Aspirateur populaires d'autres marques

Bissell

Bissell LittleGreen Proheat 1425 Series Manuel utilisateur

Panasonic

Panasonic MC-YL637S147-AE Manuel utilisateur

NEFF

NEFF N17XH10 0 Series Manuel utilisateur

LG A9 Series Manuel utilisateur

Oreck

Oreck Cordless Captura BK51700 Series Manuel utilisateur

Kogan

Kogan KAVACROBVWA Manuel utilisateur

Kränzle

Kränzle VENTOS 50 ID Guide de l'utilisateur

EVVO

EVVO Ai35 Manuel utilisateur

DeWalt

DeWalt DWH200D Manuel utilisateur

Pontec

Pontec Pondomatic Vacuum Cleaner Manuel utilisateur

Cleanmaxx

Cleanmaxx PC-P007E Manuel utilisateur

Exido

Exido 240-114 Manuel utilisateur

RIDGID

RIDGID WD1685AU0 Manuel utilisateur

Ezviz

Ezviz RE4P Manuel utilisateur

STG global

STG global TANVAC HDV3000 Manuel utilisateur

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuel utilisateur

Factory

Factory M3340 Manuel utilisateur

Shop-Vac

Shop-Vac VN92 SERIES Manuel utilisateur
