Dune HD CONNECT Manuel utilisateur
English
Quick Start GuideƔɄɪɚɬɤɨɟɪɭɤɨɜɨɞɫɬɜɨ
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535
& other U.S.and worldwide patents issued & pending. DTS, the Symbol, & DTS and
the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark
of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved
Dune HD Connect Quick Start Guide
3
Table of Contents
Table of Contents
English
Quick Start Guide
• Introduction
• Key Features
• Extra Functions
• Package Contents
• Exterior
• Remote Control
• Getting Started
• Quick Setting of Video Output Mode
• Connecting USB Drives
• Accessing Network Drives
• Formatting HDD
• Switching the Player On and Off
• NAS (Network Attached Storage)
• Wi-Fi
• Limitations
• Updating Your Player and Getting More Information
416
Ɋɭɫɫɤɢɣ
Ʉɪɚɬɤɨɟ ɪɭɤɨɜɨɞɫɬɜɨ
• ȼɜɟɞɟɧɢɟ
• Ɉɫɧɨɜɧɵɟ ɨɫɨɛɟɧɧɨɫɬɢ
• Ⱦɨɩɨɥɧɢɬɟɥɶɧɵɟ ɮɭɧɤɰɢɢ
• ɋɨɞɟɪɠɢɦɨɟ ɤɨɪɨɛɤɢ
• ȼɧɟɲɧɢɣ ɜɢɞ
• ɉɭɥɶɬ ɭɩɪɚɜɥɟɧɢɹ
• ɇɚɱɚɥɨ ɪɚɛɨɬɵ
• Ȼɵɫɬɪɨɟ ɢɡɦɟɧɟɧɢɟ ɜɢɞɟɨɪɟɠɢɦɚ
• ɉɨɞɤɥɸɱɟɧɢɟ USB-ɧɚɤɨɩɢɬɟɥɟɣ
• Ⱦɨɫɬɭɩ ɤɫɟɬɟɜɵɦ ɞɢɫɤɚɦ
• Ɏɨɪɦɚɬɢɪɨɜɚɧɢɟ ɠɟɫɬɤɨɝɨ ɞɢɫɤɚ
• ȼɤɥɸɱɟɧɢɟ ɢɜɵɤɥɸɱɟɧɢɟ ɩɪɨɢɝɪɵɜɚɬɟɥɹ
• NAS (Network Attached Storage)
• Wi-Fi
• Ɉɝɪɚɧɢɱɟɧɢɹ
• Ɉɛɧɨɜɥɟɧɢɟ ɩɥɟɟɪɚ ɢɞɨɩ. ɢɧɮɨɪɦɚɰɢɹ
4
Dune HD Connect Quick Start Guide
Introduction
Dune HD Connect is an all-in-one solution for up to Full HD (1080p) video playback.
Key Features
ƔThe newest Sigma Designs SMP8674/8675 media processor: enjoy excellent playback and performance of
interactive features.
ƔNetwork player: connect the player to a local network and play content directly from PC or NAS (UPnP, SMB, NFS).
ƔMKV player: play HD and SD video in a popular MKV format and other modern video file formats, including top
quality HD video with very high bitrate.
ƔUSB port: conveniently connect HDDs, USB flash drives, USB card readers and other USB storage devices.
ƔHDMI port: ensure the best possible quality of HD video and HD audio.
ƔMicro SD card slot: easily play media files on micro SD memory cards from your camera or other devices.
ƔVideo output flexibility: output video in any resolution and format (from SD to 1080p, 24p/PAL/NTSC).
ƔUpscaling: high quality upscaling of DVD and any other SD video content to Full HD (1080p) or other HD resolution.
ƔFile browser: convenient file browser with powerful file management (copy, move, delete, rename, organize, sort).
5
English
Extra Functions
ƔHigh-quality music playback: play very high-quality (up to 192 Khz / 24-bit) music files in various formats (FLAC,
Monkey’s Audio APE, WAV/PCM, etc).
ƔPlaylists: build playlists from your folders, use your own playlists, use repeat and shuffle functions.
ƔNAS function: access files on storage devices (HDD, optical drive, etc) attached to the player from the local
network (using SMB or FTP).
ƔCustomizable user interface: work with media collections using cover art and icon browsing (with Full HD graphics).
ƔInternet radio: playback and record various Internet radio stations (HTTP/MP3 and other formats).
ƔDigital TV: playback and record Digital TV channels (OTT/IPTV).
6
Dune HD Connect Quick Start Guide
Package Contents
1. Dune HD Connect media player
2. Remote control (batteries may not
be included)
3. HDMI Extender
4. IR extender
5. Power Supply with USB cable
6. AV cable (3xRCA)
7. Quick start guide
NOTE: Additional items (optional) may be included into the package, depending on player configuration, region, and
distributor.
1
5
2
76
4
3
7
English
Exterior
1. HDMI connector
2. Power/USB port
3. IR Extender port
4. LAN port (10/100 mbps)
5. Wi-Fi antenna port*
6. Micro SD Card slot
7. AV Out port
* - depends on configuration
1
2
3
4
5
6
7
8
Dune HD Connect Quick Start Guide
Remote Control
1. —reserved (optional), POWER — toggle the standby mode.
2. A (Red), B (Green), C (Yellow), D (Blue) — control some player functions.
3. ZOOM — change the zoom factor for the video content being played. MODE — switch
the video output mode; control some other player functions. SEARCH — jump to a
speci¿ed playback position. SETUP — enter/leave the setup menu; adjust playback
settings during playback. REC —start/stop TV channel recording.
4.
— control the playback. MUTE — turn the sound on/off.
5. Arrows , ENTER, RETURN, TOP MENU, POP UP MENU,
INFO — main buttons for controlling the player (navigate across the items on the screen,
open/use the currently selected item, go back to the previous screen, go to main menu,
show popup menu with actions, show information, control some other player functions).
6. V+/V- (volume up / volume down) — adjust the volume.
7. P+/P- (page up / page down) — scroll up and down in various lists; control some other
player functions.
8.
SUBTITLE, AUDIO — choose an audio track or subtitles during playback (if presented)
1
2
3
4
9
10
5
6
7
8
9
English
9. 0–9 — enter numbers and text; control some other player functions.
10.
CLEAR, SELECT —control some player functions.
NOTES:
Ɣ8se alkaline AAA batteries
Ɣ2bserYe polarity Zhen inserting batteries
Ɣ'irect the remote control to the player7here must be no obstacles betZeen the 5& and the player
Ɣ,f 5& functions only at short distances or stops functioning, make sure to replace the batteries
Ɣ6ome 5& buttons may haYe seYeral functions depending on the current player mode
Ɣ6ome 5& buttons may be aYailable only in certain player modes or only during playback of a certain content
10
Dune HD Connect Quick Start Guide
Getting Started
Ensure the RC has batteries installed.
Connect the player to your TV and to other A/V equipment in an appropriate way. Use HDMI connection to get the
best possible quality of video and audio. Make sure to switch off the player and all relevant A/V equipment before
connecting them. Ensure your TV and other A/V equipment are configured to use proper inputs.
Switch on the player. The player will perform its initial loading procedure, which may take up to about 1 minute. During
the loading procedure, "DUNE HD" logo is shown on the TV.
ƔIf you do not see "DUNE HD" logo on the TV when you switch on the player, it may mean some problem with the
connection between the player and the TV or that a wrong video input is chosen in the TV or A/V receiver/switch. In
such a case, recheck the cables and the settings of the TV or A/V receiver/switch, or try to use different cables or a
different way of connecting the player to the TV.
ƔIf you see "DUNE HD" logo on the TV when you switch on the player, but then the picture disappears and no other
picture appears during at least 10 seconds, it may mean that a wrong video output mode is configured in the player.
In such a case, press the "MODE" RC button, and then press one of the RC buttons "1", "2", "3", "4" or "5" to
switch to a different video output mode (see "Quick Setting of Video Output Mode").
Finally, you should see the main screen of the player menu. The main screen shows items allowing to use different
player functions and access all storage devices and network drives connected to the player.
Adjust the player settings as needed using "SETUP" item on the main screen of the player menu or «SETUP» RC
button. In particular, you may want to adjust video settings, audio settings, and network settings.
